Features:
• Power Handling Rated 500 W / 8 Ohms
Peak 2000 W
• 15'' EVS-15S LF Transducer
• Integrated Low Pass Filter
• 93 dB Sensitivity, 125 dB Maximum SPL
• Pole Mount to elevate a Loudspeaker
Wir weisen ausdrücklich darauf hin, dass bei
gehängten Lautsprecherboxen die einschlägigen
Sicherheitsbestimmungen zu beachten sind. Es
muss unbedingt qualifizierte Fachberatung in
Anspruch genommen werden!
We expressly point out that the relevant safety
regulations must be observed for "flying"
loudspeaker systems. It is imperative that quali-
fied expert advice is sought.
Technische Informationen
Engineering Data Sheet
Sub 1.15
1 x 15"
Subwoofer
Order No.
Cabinet
Configuration
Nominal impedance
Minimum Impedance
Rated Power RMS
Peak Power
Sound pressure level
SPL 1 W / 1 m
Max. SPL 1 m (calculated
with peak power)
Frequency Range (-10 dB)
Nominal Coverage Angle
(Horizontal x Vertical)
LF Transducer
Connectors
Dimensions (W x H x D)
Net Weight
Shipping Weight
Enclosure material
Grille
Steel, Black Finish with Acoustic Gauze
Warranty
Spare Parts
LF Transducer
Sub 1.15
F01U165094
Subwoofer
Vented-Direct Radiator
8 Ohms
7.1 Ohms
500 W
2000 W
93 dB
125 dB
40 Hz to 260 Hz
Omnidirectional
EVS-15S, 15'' (381 mm) driver
2x Neutrik Speakon NL4
Sub 1+ / 1-
Wired through 2+ / 2-
445 mm x 605 mm x 550 mm
(17.5" x 23.8" x 21.7")
28.5 kg (62.8 lbs)
31.4 kg (69.2 lbs)
MDF with D-PUR PLUS
5 years
F01U106974
