- Page 1 GASBETRIEBENE GRIDDLEPLATTEN ELEKTRO-GRIDDLEPLATTEN SERIE 900 2955031 2955071 2955051 296506 296508 296509 Pag. 1/68...
- Page 2 GAS LOWERED FRY-TOPS ELECTRIC LOWERED FRY-TOPS SERIES 90 INSTALLATION, USE AND MAINTENANCE Pag. 35/68...
-
Page 3: Misure D'ingombro
MISURE D’INGOMBRO 645.5 2955031 2955071 2955051 (G= gas\ gaz) Fig. – Abb. 1: Dimensioni \ Dimensions \ Floor space dimensions \ Raumbedarfsmasse \ Espacio máximo necesario 645.5 22.5 296506 296508 296509 Fig. – Abb. 2: Dimensioni \ Dimensions \ Floor space dimensions \ Raumbedarfsmasse \ espacio máximo necesario... -
Page 4: Targhetta Caratteristiche
TARGHETTA CARATTERISTICHE CAT/KAT Made in Italy GAS/GAZ G110 G120 p mbar p mbar 3B/P p mbar 28-30 2E+3+ p mbar 2H3+ p mbar 0051 2H3+ TIPO/TYPE p mbar 2H3+ MOD. p mbar 2H3+ ART. p mbar 2ELL3B/P N°. p mbar 2H3B/P p mbar 2H3B/P... - Page 5 Figg. – Abb. 6, 7, 8: Scarico fumi \ Évacuation des fumées \ Fumes evacuation \ Rauchabzug \ Descarga de humos Fig. – Abb. 9: Simbolo equipotenziale \ Symbole equipotenziel \ Equipotenziale label \ Äquipotenzial Symbol \ Equipotencial símbolo Fig. – Abb. 10: Verifica della tenuta e della pressione di alimentazione \ Contrôle de la tenue et de la pression d'alimentation \ Checking gas tightness and pressure \ Überprüfung der Dichtigkeit und des Versorgungsdrucks \ Comprobación de la estanqueidad y de...
- Page 6 Figg. – Abb. 13 : Sostituzione del By-Pass \ Changement du by-pass \ Substituting the By-Pass \ Austausch des By-Pass \ Cambio del by- pass Fig. – Abb. 14 : Sostituzione dell’ugello bruciatore pilota \ Changement du gicleur du brûleur veilleuse \ Substituting the pilot burner nozzle \ Austausch der Zündbrennerdüse \ Cambio de la boquilla del quemador...
- Page 7 Fig.-Abb. 19 : Sostituzione termostato in sicurezza\ Remplacement robinet de gaz \ Replacement of safety thermostat \ Ersetzen von Thermostat auszutauschen \ Sustitución termostato Fig. – Abb. 20, 21, 22, 23: Accoppiamento apparecchiature \ Couplage des appareils \ Joining appliances \ Befestigung der Geräte \ Acoplamiento de los aparatos Pag.
- Page 9 (Table 4) BURNER FEATURES (NL - CAT. II 2L3B/P Gas type Nominal Reduced Diameter of main By-Pass Pilot injectors Air regulation capacity capacity [kW] injectors diameter [N°] “x” [kW] [1/100 mm] [1/100 mm] [mm] FRY TOP BURNER ½ module Liquid gas LPG 8.00 3.00 AL145...
-
Page 10: Technical Features
• The appliance is intended to be used EXCLUSIVELY with containers that are suitable for contact with food and resistant to heat), any other use is not considered appropriate. • The appliance should only be used by trained personnel and for the use for which it was designed. -
Page 11: Description Of Appliances
Declaration of compliance The manufacturer declares that the appliances of their production are compliant with the above mentioned EEC directives and requires that installation be done observing the norms in force, regarding particularly the system for letting out fumes and air exchange. DESCRIPTION OF APPLIANCES Gas fry-top Sturdy structure in steel placed on four feet which make it possible to regulate the height in the... -
Page 12: Installation
Installation Installation operations, gas or voltage conversions to other than the original, starting up the installation or appliance, ventilation, letting out fumes, and maintenance must be done following the manufacturer's instructions and observing the norms in force, by qualified personnel, in compliance with the following provisions (GB): ... - Page 13 Gas Connection Before connecting the appliance, it is necessary to check that the type of gas available corresponds to the type of gas the appliance has been set for. In the event that they do not correspond, it is necessary to proceed as described in the paragraph “Functioning with gas different from the setting”.
- Page 14 screws correctly into the pressure outlet. The pressure valve must be within the minimum and maximum values shown below: Type of gas [mbar] [mbar] [mbar] G20 (Methane) G25 (Methane) G30 (Butane) G31 (Propane) G110/G120 (town gas) If the pressure reading is not within the limits of the table, find out the cause. After solving the problem, check the pressure again.
- Page 15 Once this has been done, place the units together, remove the instrument panels by unscrewing the two fixing screws and then insert an M6 screw, together with a washer (provided with the joining kit), into the threaded hole (2) (fig. 20, p. 7). Tighten the screw well using a suitable key. Then check the level (3) along the back edge of the units, as shown in fig.
- Page 16 Substituting the By-Pass (figg.11, 13 – pag.5, 6) To substitute the by-pass, firstly the knobs (1) must be removed and then the drip pan (2). When the work area is clear, unscrew the by-pass (7) with a screwdriver and substitute it with the by-pass suitable for the type of gas to be used, shown in tables 2, 3, 4, 5, 6.
- Page 17 Abnormal functioning If for any reason, the appliance does not start up or stops working during use, check that the energy supply and the control knobs are set correctly; if all is regular, call customer service. Some problems and possible solutions Problem Possible solution Check that gas inlet pressure is the same as that shown in...
-
Page 18: Care And Maintenance Of The Appliance
CARE AND MAINTENANCE OF THE APPLIANCE Cleaning ATTENTION! Before doing any cleaning, make sure that the appliance is disconnected from the electric mains and that the gas cut off valve is closed. During cleaning operations, avoid using direct or high pressure sprays of water on the appliance. Cleaning must be done when the appliance is cold. - Page 19 SUBSTITUTING COMPONENTS ATTENTION! Before carrying out any substitutions, make sure that the appliance is disconnected from the electric mains and that the gas cut off valve is closed. Safety Thermostat (figg.11, 19- pagg.6, 7) To substitute the thermostat, it is necessary to remove the knobs, the drip pan and the control panel, as shown in figure 11;...
- Page 20 WHEN SUBSTITUTING, ONLY ORIGINAL SPARE PARTS SUPPLIED BY THE MANUFACTURER MUST BE USED. THE OPERATION MUST BE CARRIED OUT BY AUTHORIZED PERSONNEL. ATTENTION! In the event that components of the gas installation are substituted, it is necessary to check for tightness and the correct functioning of the various parts. THE MANUFACTURER RESERVES THE RIGHT TO WITHOUT NOTICE MODIFY THE FEATURES OF THE APPLIANCES DESCRIBED IN THIS MANUAL.
