TPM-05 and TPM-05A
USER MANUAL
Measures up to voltage harmonics 41st (L-N and L-L).
Measures up to current harmonics 41st.
Measures the neutral current. (Only on TPM-05A)
Supports 3P4W connections.
RS485 Modbus RTU.
71.5 x 61.5 Custom Design Glass LCD.
It shows the active powers of each phase and total (P).
It shows the reactive powers of each phase and total (Q).
It shows the apparent powers of each phase and total (S).
It shows power factor (PF) and Cosφ(FI) values of each phases.
It shows the min., max. and ave. values of the phase-to-phase and Phase-neutral voltages (V)
It shows the current values of each phase (I).
It shows the import and export active energies of each phase and total ( Σ kWh).
It shows the inductive and capacitive reactive energies of each phase and total ( Σ kVArh).
It shows the apparent energies of each phase and total ( Σ kVAh).
2 relay outputs (adjustable), 1 Digital Input
Event logs (voltage rise/fall, power cut, current/PF/THDV and THDI limits)
The date and time can be set.
Real time clock.
It shows demands.
You can delete energies, demand, and event logs.
The menu is password protected.
Tense Electric Electronics
MADE IN TÜRKİYE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TPM-05A and is the answer not in the manual?

Questions and answers

Related Manuals for Tense TPM-05A

Summary of Contents for Tense TPM-05A

  • Page 1 TPM-05 and TPM-05A USER MANUAL Measures up to voltage harmonics 41st (L-N and L-L). Measures up to current harmonics 41st. Measures the neutral current. (Only on TPM-05A) Supports 3P4W connections. RS485 Modbus RTU. 71.5 x 61.5 Custom Design Glass LCD.

  • Page 2: Connection Schemes

    5A/250VAC 5A/250VAC 50/60Hz. <6VA INPUT TPM-05 Curent Transformer Connections Voltage Inputs Load Figure-1A - TPM-05A Connection Diagram Load Figure-1A: 3P4W connection type 3 phase current + 1 neutral current and 3 phase voltage and neutral. 85-240VAC Curent Transformer Connections 50/60Hz. <6VA...

  • Page 3: Current Transformer Ratio

    5 - General: TPM-05 and TPM-05A Energy analyzer measures load or voltage, current, cosφ, active power, reactive power , minimum and maximum values of the load and also measures demands. It records the events. This analyzer measures current harmonics and voltage harmonics up to 41. harmonics.
  • Page 4 7- Introduction of Screen: THD-V PF I THD-I kW h Σ VA r kW h Σ VA r kW h Σ Out1 Out2 Din1 1 - Indicates the unit of the value. 2 - Indicates which phase the value belongs to . 3 - Indicates displayed values.
  • Page 5 8- Introduction of Buttons: Press this button while in menu to exit the menu without saving the values. ESC: When this key is pressed while not in the menu, the screen always shows figure-4. This button enters menu/parameter. It records the changes of parameters and remove from SET: parameter.

  • Page 6: Progress On Screen Information

    9 - Progress On Screen Information: Din1 Out1 Out2 Din1 Out1 Out2 Din1 Out1 Out2 Din1 Out1 Out2 Din1 Out1 Out2 Figure-4 Figure-5 Figure-6 Figure-7 Figure-8 Figure-4: It shows phase-neutral voltage. When you press right button, the figure-5 comes to screen. Figure-5: It shows minimum(Min) voltage values of phase-neutral voltage.
  • Page 7 2nd line, and the scalar sum of all phase currents in the 3rd line. (Only for TPM-05A.) When you press the right button, figure-19 appears on the screen. Figure-19: It shows the minimum (Min) current values of each phase. When you press the right button, figure-20 comes to the screen.
  • Page 8 kVAr kVAr kVAr kVAr kVAr kVAr kVAr kVAr kVAr kVAr kVAr kVAr Din1 Out1 Out2 Din1 Out1 Out2 Din1 Out1 Out2 Din1 Out1 Out2 Din1 Out1 Out2 Figure-30 Figure-31 Figure-32 Figure-33 Figure-34 Figure-30: It shows the reactive power value(Q) which belongs to each phase. When the right button is pressed;...
  • Page 9 THD-I THD-V THD-I THD-V THD-I Din1 Out1 Out2 Din1 Out1 Out2 Din1 Out1 Out2 Din1 Out1 Out2 Din1 Out1 Out2 Figure-44 Figure-45 Figure-46 Figure-47 Figure-48 Figure-44: It shows total harmonic distortion value(THD-I)which belongs to current of the phase. When the right button is pressed; Figure-45 comes to the screen. Figure-45: It shows the date and time of each phase exceeding (>%8) THD-V limit.
  • Page 10 10 - Fast Forwarding of Screen Information: Σ Σ kVAr Σ Din1 Out1 Out2 Din1 Out1 Out2 Din1 Out1 Out2 Din1 Out1 Out2 Figure-11 Figure-18 Figure-25A Figure-4 When the device is energized, Figure-4 comes to the screen. When you press the down button, Figure-11 comes to the screen. When you press the down button, Figure-18 comes to the screen.

  • Page 11: Menu Structure

    11 - Menu Structure: Figure-58 Din1 Out1 Out2 Din1 Out1 Out2 Figure-57 Din1 Out1 Out2 Din1 Out1 Out2 Din1 Out1 Out2 Figure-68 Figure-59 Figure-60 When you press the set button while the figure-57 is on screen, figure-58 password inquiry is displayed on the screen. If a password has been created, enter the password and press the set button.

  • Page 12: Delete Energy, Demand And Event Records

    11.1 - Setting the Current Transformer Ratio: To change the current transformer ratio, press the set button while the figure-58 is on the screen. Figure-69 comes to the screen. Press right button to move between digits. Press the down key to change the value of the digit. You can change the digit value which is the underline.

  • Page 13: Enter Password Value

    11.5 - Enter Password Value: In order to change password; press Set button while Figure-63 is on the screen. The Figure-73 comes to the screen. In order to pass through steps; press the right button. In order to change the value of the step press the down button.
  • Page 14 11.9 - Task Assignment to Relay 1 and Relay 2: To assign the task to relay 1, press the set button, when figure-77 is on the screen. There are 3 settings; these are Parameter (PAr), Function (Valued) and Value (VAL). Press the right button to move the point (.) to the parameter.

  • Page 15: Menu Values Table

    12 - Menu Values Table: Factory Minimum Maximum Parameter Parameter Unit Value Value Value Number Current Transformer Ratio 5000 Voltage Transformer Ratio 999.9 Baudrate 9600 1200 115200 Stop bits Data bits Parity none none, even, odd ModBus ID Deleting Total Energy Deleting Demand Values Deleting Event Records PASS...

  • Page 16: Table Of Contents

    16 - Contact Informations: Muratpaşa Mah. Uluyol Cad. İşkent Sanayi Sitesi. E-Blok, 1.Kat Energy and BAYRAMPAŞA / İSTANBUL / TÜRKİYE Compensation Tel: 0212 578 04 38 - 48 | Fax: 0212 578 04 36 Tracking System www.tenseenerji.com www.tense.com.tr info@tense.com.tr -15-...
