Page 5: Table Of Contents
Contents Vehicle Safety P. 2 Operation Guide P. 18 Maintenance P. 128 Troubleshooting P. 175 Information P. 203 Specifications P. 224...
Page 6: Vehicle Safety
Vehicle Safety This section contains important information for safe riding of your vehicle. Please read this section carefully. Safety Guidelines ..........P. 3 Image Labels............P. 6 Safety Precautions..........P. 10 Riding Precautions ..........P. 11 Accessories & Modifications......P. 16 Loading ..............
Page 7: Safety Guidelines
Safety Guidelines Safety Guidelines Instruct your passenger on holding onto the grab rails or your waist, leaning with you in Follow these guidelines to enhance your safety: turns, and keeping their feet on the footpegs, Perform all routine and regular inspections even when the vehicle is stopped.
Page 8 Safety Guidelines Make Yourself Easy to See Keep Your Honda in Safe Condition Make yourself more visible, especially at night, It's important to keep your vehicle properly by wearing bright reflective clothing, positioning maintained and in safe riding condition. yourself so other drivers can see you, signaling...
Page 9 Safety Guidelines If you decide to continue riding, first turn the WARNING electrical system off, and evaluate the condition Running the engine of your vehicle of your vehicle. Inspect for fluid leaks, check the while in an enclosed or even partially tightness of critical nuts and bolts, and check enclosed area can cause a rapid build- the handlebar, control levers, brakes, and...
Page 10: Image Labels
Image Labels Image Labels The following pages describe the label Read instructions contained in Owner's meanings. Some labels warn you of Manual carefully. potential hazards that could cause serious injury. Others provide important safety Read instructions contained in Shop Manual information.
Page 11 Image Labels BATTERY LABEL DANGER • Keep flame and spark away from the battery. Battery produce explosive gas that can cause explosion. sample • Wear the eye protection and rubber gloves when handling the battery, or you can get burned or lose your eyesight by the battery electrolyte.
Page 12 Image Labels FO, II FO, PH type RADIATOR CAP LABEL DANGER NEVER OPEN WHEN HOT. Hot coolant will scald you. Relief pressure valve begins to open at 1.1 kgf/cm FO, II FO, PH type REAR CUSHION LABEL GAS FILLED Do not open. Do not heat. FO, II FO, PH type FO, II FO type TYRE INFORMATION &...
Page 13 Image Labels SEAT DAMPER OPENER LABEL GAS FILLED Do not open. Do not heat. FO, II FO, PH type SAFETY REMINDER LABEL For your protection, always wear helmet, protective apparel. FUEL LABEL Unleaded petrol only ETHANOL up to 10 % by volume FO, II FO, PH type CARGO LIMIT LABEL Do not exceed 5.0 kg (11.0 lb).
Page 14: Safety Precautions
Safety Precautions Safety Precautions Face shield with unobstructed field of vision ● or other approved eye protection Ride cautiously and keep your hands on the ● WARNING handlebar and feet on the step board. Not wearing a helmet increases the Instruct your passenger to keep their hands ●...
Page 15: Riding Precautions
Riding Precautions Riding Precautions Brakes Observe the following guidelines: Running-in Period Avoid excessively hard braking and ● downshifting. During the first 500 km (300 miles) of running, Sudden braking can reduce the vehicle's follow these guidelines to ensure your vehicle's stability.
Page 16 Riding Precautions Anti-lock Brake System (ABS) Engine Braking This model is equipped with an Anti-lock Brake Engine braking helps slow your vehicle down System (ABS) designed to help prevent the when you release the throttle. For further brakes from locking up during hard braking. slowing action, downshift to a lower gear.
Page 17 ( P. 83) and leave your Press down on the tip of the centre stand vehicle while taking the Honda SMART Key with your right foot and, simultaneously, pull with you. Deactivate the Honda SMART Key up and back.
Page 18 Refuelling and Fuel Guidelines Then, leave your vehicle while taking the Follow these guidelines to protect the engine, Honda SMART Key with you. Deactivate the fuel system and catalytic converter: Honda SMART Key system if necessary. Use only unleaded petrol.
Page 19 Torque Control may not compensate for rough Honda Selectable Torque Control road conditions or rapid throttle operation. When the Honda Selectable Torque Control Always consider road and weather conditions, (Torque Control) detects rear wheel spin during as well as your skills and condition, when acceleration, the system will limit the amount of applying throttle.
Page 20: Accessories & Modifications
Honda or make modifications to your vehicle from its original design. Doing so can make it unsafe. Modifying your vehicle may also void your warranty and make your vehicle illegal to operate on public roads.
Page 21: Loading
Loading Loading WARNING Overloading or improper loading can Carrying extra weight affects your vehicle's ● cause a crash and you can be seriously handling, braking and stability. hurt or killed. Always ride at a safe speed and never exceed 130 km/h (80 mph) for the load you are carrying.
Page 22: Parts Location
Parts Location Document Seat (P.123) (P.125) Luggage box (P.123) Tool kit (P.125) Throttle grip (P.166) Parking brake (P.97) Front brake fluid reservoir (P.159) Front suspension spring preload adjuster (P.168) Front suspension rebound damping adjuster (P.169) Fairing pocket (P.127) Front lower cover (P.150) Coolant reserve tank (P.157)
Page 23 Rear brake lever (P.167) Windscreen (P.171) Rear brake fluid reservoir (P.159) Front suspension spring preload adjuster (P.168) Fuel fill cap (P.120) Battery (P.148) Main fuses (P.201) Left side cover (P.152) Fuse box A/B (P.199) Drive chain (P.163) Rear suspension spring preload adjuster (P.170) Side stand...
Page 24 Instruments You can change the speed and mileage, and fuel mileage meter units. (P.41) (P.60) Do not operate the display functions for a long time with the engine stopped. It may result in a low (or dead) battery.
Page 25 Gear position indicator (P.26) Tachometer (P.23) Status bar (P.27) Selectable area (P.37) Honda RoadSync area (P.94) Speedometer (P.23) Fuel gauge Side stand indicator (P.25) Comes on when the side stand is down. Continued...
Page 26 Instruments (Continued) Parking brake indicator Lights as a reminder that you have not released the parking brake lever. (P.97) Riding mode (P.98) ECO indicator (P.26) Cruise control display (P.112) INFO area (P.29) Pop-up information (P.73)
Page 27 Speedometer/Tachometer/INFO area/Cruise control display Display type: BAR Tachometer red zone (excessive engine rpm range) Tachometer NOTICE Do not operate the engine in Speedometer the tachometer red zone. Excessive engine speed can adversely affect engine life. INFO area Cruise control display Continued...
Page 28 Instruments (Continued) This meter has three display types. The display and arrangement of speedometer, tachometer, cruise control display, and INFO area change depending on each display type. The tachometer is not displayed when select the SIMPLE type display. To change the display type: (P.41) (P.51) Display type: CIRCLE Display type: SIMPLE...
Page 29: Fuel Gauge
Fuel gauge Remaining fuel when only 1st (E) segment starts flashing: approximately 2.5 L (0.66 US gal, 0.55 Imp gal) If the fuel gauge indicator flashes in a repeat pattern or turns off: (P.184) NOTICE You should refuel when the reading approaches the E (1st) segment.
Page 30: Gear Position Indicator
Instruments (Continued) Gear position indicator ECO indicator The gear position is shown in the gear position The ECO indicator comes on according indicator. to the fuel mileage. The indicator may flash if: When the fuel consumption is improved, The front wheel leaves the ground. ECO indicator comes on.
Page 31 Status bar Status icons Air temperature gauge Displays the status of the Honda (P.28) RoadSync system. (P.94) High beam indicator DRL indicator (P.119) Warning indicator Comes on when your vehicle has Clock (12-hour or 24-hour display) warning information. To set the clock: (P.41) (P.59)
Page 32 Instruments (Continued) Air temperature gauge Displays the ambient temperature. Display range: -10 ºC to 50 ºC Less than -10ºC: “---” is displayed ● Above 50ºC: 50ºC flashes ● Road heat and exhaust from another vehicle can affect the temperature reading when your vehicle speed is less than 30 km/h (19 mph).
Page 33 INFO area TOTAL The INFO area displays various vehicle information. INST. CONS. TRIP A The following items are displayed by default. • Odometer [TOTAL] TRIP A CONS. • Current fuel mileage [INST. CONS.] • Tripmeter A [TRIP A] TRIP A AVG CONS. •...
Page 34 Instruments (Continued) The types of information item that can be Odometer [TOTAL] displayed in the INFO area are as follows: Total distance ridden. TOTAL (P.30) INST. CONS. (P.31) TRIP A (P.32) When “------” is displayed, go to your dealer TRIP A CONS. (P.32) for service.
Page 35 Current fuel mileage [INST. CONS.] Displays the instantaneous fuel mileage as a bar graph. Display range: 0 to 4 L/100 km (40 km/L, 100 mile/gal, 25 mile/L) When your speed is less than 5 km/h (3 ● mph): “zero segment” is displayed. Zero segment When “zero segment”...
Page 36 Instruments (Continued) Tripmeter A [TRIP A] Tripmeter A fuel consumption [CONS.A] Distance ridden since the tripmeter A was reset. Displays the tripmeter A fuel consumption since the tripmeter A was reset. Display range: 0.0 to 299.9 L (gal) When “----.-” is displayed, go to your dealer for service.
Page 37 Tripmeter A average fuel mileage is reset Tripmeter A average fuel mileage when you reset tripmeter A. [AVG CONS. A] To reset the tripmeter A: Displays the average fuel mileage since the (P.38) tripmeter A was reset. (P.40) The average fuel mileage will be calculated based on the value on tripmeter A.
Page 38 Instruments (Continued) Tripmeter B [TRIP B] Tripmeter B fuel consumption [CONS.B] Distance ridden since the tripmeter B was reset. Displays the tripmeter B fuel consumption since the tripmeter B was reset. Display range: 0.0 to 299.9 L (gal) When “----.-” is displayed, go to your dealer for service.
Page 39 Tripmeter B average fuel mileage is reset Tripmeter B average fuel mileage when you reset tripmeter B. [AVG CONS. B] To reset the tripmeter B: Displays the average fuel mileage since the (P.38) tripmeter B was reset. (P.40) The average fuel mileage will be calculated based on the value on tripmeter B.
Page 40 Instruments (Continued) Average speed [AVG SPEED] Blank display Displays average speed since the engine was Display is the blank. started. Display range: 0 to 299 km/h (0 to 186 mph) Initial display: “---” is displayed. ● When your vehicle has traveled less than ●...
Page 41 (P.40) • Honda RoadSync transition (P.94) • Honda RoadSync mute Honda RoadSync transition Honda RoadSync transition and Honda Move to Honda RoadSync mute can be selected only when RoadSync Honda RoadSync your smartphone is connected to the vehicle. operation display.
Page 42: Setting Mode
Instruments (Continued) General Menu Status mode The Status mode displays various vehicle You can select the following: information. • Status mode The Status mode has four pages and displays • Trip reset mode two pieces of information on each page. The •...
Page 43 To switch the information page To change the information page, press on the sel switch. Riding mode Page 1 Page 2 Page 3 Page 4 Press on the sel switch. Press on the sel switch. To change the information: (P.41) (P.54) Continued...
Page 44 Instruments (Continued) Trip reset mode You can reset the tripmeter A or tripmeter B. Select the trip reset mode. (P.38) Press on the sel switch. Also, the tripmeter A, tripmeter A fuel consumption and tripmeter A average fuel mileage are automatically reset when the fuel gauge segment increases by 2 or more after Select the A or B by pressing the refuelling and riding your vehicle for 0.1 km...
Page 45 Setting mode To shift to the setting mode Select the general menu. (P.37) Select the setting mode. (P.38) Press on the sel switch, and then display moves to the setting mode. Operation while driving is prohibited. Ordinary display Setting mode To return to the ordinary display •...
Page 46 Instruments (Continued) Setting flow Ordinary display Setting mode RIDING MODE (P.46) SHIFT POINT (P.48) SELF CANCELLING TURN FUNCTION (P.49) SIGNALS (P.49) TRIP A AUTO RESET (P.50) ECO INDICATOR (P.51) DISPLAY Press on the sel switch Press on the sel switch Press on the sel switch Press...
Page 47 FUNCTION DISPLAY TYPE (P.51) BRIGHTNESS (P.52) BACKGROUND (P.53) DISPLAY FAVORITE INFORMATION (P.54) FAVORITE SWITCH (P.57) AIR TEMP (P.58) GENERAL : Press the on the sel switch : Press the on the sel switch : Press the on the sel switch : Press the on the sel switch Continued...
Page 48 Instruments (Continued) DISPLAY DATE & TIME (P.59) UNIT (P.60) GENERAL LANGUAGE (P.61) RESTORE DEFAULT (P.62) BLUETOOTH PAIRING RESET (P.63) SERVICE Press on the sel switch Press on the sel switch Press on the sel switch Press on the sel switch...
Page 49 GENERAL MAINTENANCE (P.64) SERVICE EQUIPMENT (P.71) SYSTEM INFORMATION (P.72) Press on the sel switch Press on the sel switch Press on the sel switch Press on the sel switch Continued...
Page 50 Instruments (Continued) RIDING MODE (P.98) USER MODE You can change the setting value of the USER MODE. Select the USER 1 or USER 2 using of the sel switch. Select the parameter ("P", "EB" "D", "T" or "ABS") using of the sel switch. Select the desired setting value using of the sel switch.
Page 51 PRESET MODE You can confirm the preset riding mode setting value of the [STANDARD], [SPORT], [RAIN] and [GRAVEL]. Select the PRESET MODE using of the sel switch. Select the desired riding mode using of the sel switch. Press on the sel switch to return to the USER MODE.
Page 52 Instruments (Continued) SHIFT POINT When select the (On) Press on the sel switch to select the (On) / (Off) :You can activate or deactivate desired setting (r/min) using the shift up indicator. the sel switch. SHIFT POINT :You can change the engine Press on the sel switch to complete revolutions at which the...
Page 53 SELF CANCELLING TURN SIGNALS You can enable or disable turn signal You can enable or disable DRL. (P.119) automatic cancellation. (P.80) Select the (Auto) or (Off) using on the sel switch. Select the (On) or (Off) using Press on the sel switch to complete the on the sel switch.
Page 54 Instruments (Continued) TRIP A AUTO RESET You can enable or disable the tripmeter A automatic reset mode. Select the (On) or (Off) using on the sel switch. Press on the sel switch to complete the setting. Return to the ordinary display to complete the setting.
Page 55 ECO INDICATOR DISPLAY TYPE You can enable or disable the ECO indicator. You can change the display type. (P.23) (P.26) Select the display type ("BAR", "CIRCLE" or "SIMPLE") using on the sel switch. Select the (On) or (Off) using Press on the sel switch to complete the on the sel switch.
Page 56 Instruments (Continued) BRIGHTNESS When select the "AUTO" Press on the sel switch to complete You can adjust the backlight brightness to the setting. one of the eight levels or select the auto When select the "MANUAL" adjustment. Press on the sel switch to select the Automatic brightness control: (P.210) backlight brightness using...
Page 57: Automatic Brightness Control
BACKGROUND You can change the setting of the background to one of the two colors or select the auto adjustment. Automatic brightness control: (P.210) Select the background colour using on the sel switch. Press on the sel switch to complete the setting.
Page 58 Instruments (Continued) FAVORITE INFORMATION You can change the information items displayed in the INFO area and status mode. 1 line information You can change the information items displayed in the INFO area. (P.29) 1 line information setting: (P.55) Select the 1 line or 2 line information using on the sel switch.
Page 59 1 line information setting Select the desired information setting using on the sel switch. Select the 1 or 2 using on the sel Press on the sel switch, set the switch. information item. Items that have already been set are displayed with a green cursor.
Page 60 Instruments (Continued) 2 line information setting Select the upper or lower row using on the sel switch. Upper row Information Page item (Upper) Press on the sel switch to select the information items. Information Select the desired information item using item (Lower) on the sel switch.
Page 61 Press on the sel switch to complete the FAVORITE SWITCH setting. "TRIP RESET" is displayed but not selectable. Return to the ordinary display to complete the setting. (P.41) To continue setting, press on the sel switch to return to the upper hierarchy. Continued...
Page 62 Instruments (Continued) AIR TEMP You can display or hide the air temperature gauge. (P.27) Select the (On) or (Off) using on the sel switch. Press on the sel switch to complete the setting. Return to the ordinary display to complete the setting.
Page 63 DATE & TIME Select the "Day","Month", "Year", "Hour", "Minute", "24h or 12h" or "AM / PM" using on the sel switch. Select the desired setting using the sel switch. When "24 / 12" is set to 24-hour indication, "AM / PM" cannot be usable. Press on the sel switch to complete the Setting range...
Page 64 Instruments (Continued) UNIT You can change the speed and mileage, and fuel mileage meter units. Select the "SPEED" or "FUEL CONS." using on the sel switch. Select the desired setting using the sel switch. If you want to select "L/100km" or "km/L" for Press on the sel switch to complete the fuel consumption, "km/h"...
Page 65 Press on the sel switch. LANGUAGE Changes the system language. Select the 1 or 2 using on the sel switch. Select the language using on the sel switch. Press on the sel switch to select the language. Items that have already been set are displayed with a green cursor.
Page 66 Instruments (Continued) The following items are restored to their RESTORE DEFAULT default values: The set values can be returned to the default • RIDING MODE settings. • SHIFT POINT Select the “NO” (not restore) or “YES” • TRIP A AUTO RESET (restore) using the on the sel •...
Page 67 is deleted from the vehicle, the smartphone BLUETOOTH PAIRING RESET may be connected to the vehicle again. You can reset the pairing record of Bluetooth ® To connect the device (P.96) Select the “NO” (not reset) or “YES”(reset) using the on the sel switch.
Page 68 Instruments (Continued) MAINTENANCE PERIODIC MAINTENANCE (P.65) You can select the following: • PERIODIC MAINTENANCE (P.65) • OIL CHANGE OIL CHANGE (P.151) (P.67) • BATTERY VOLTAGE (P.69) • WATER TEMP (P.70) BATTERY VOLTAGE (P.69) • WARNING INFO (P.71) WATER TEMP (P.70) WARNING INFO (P.71) Press...
Page 69 PERIODIC MAINTENANCE Display range: You can check the next periodic inspection Distance: time. ------, 12,000 to -99,999 km (8,000 to You can program a reminder for the next -99,999 mile) periodic inspection time. Pass 0 km (0 mile): “-” mark is displayed. Changing the SPEED unit from "mile"...
Page 70 Instruments (Continued) Next inspection setting Available setting range of the distance: ------, 100 to 12,000 km (100 to 8,000 Select the distance, month or year using mile) on the sel switch. Initial setting:------ Available setting range of the date: Month:---, JAN to DEC Date Initial setting:--- Year: ----, 2020 to 2099...
Page 71 OIL CHANGE Display range: You can check the next engine oil change. Distance: You can program a reminder for the next ------, 12,000 to -99,999 km (8,000 to engine oil change. -99,999 mile) Pass 0 km (0 mile): “-” mark is displayed. Changing the SPEED unit from "mile"...
Page 72 Instruments (Continued) Next oil change setting Available setting range of the distance: ------, 100 to 12,000 km (100 to 8,000 Select the distance, month or year using mile) on the sel switch. Initial setting:------ Available setting range of the date: Month:---, JAN to DEC Date Initial setting:---...
Page 73 When reaching any of the following, the BATTERY VOLTAGE pop-up information is appears in the Displays the current voltage. ordinary display. (P.73) “500 km” (“300 mile”) from the next ● periodic inspection. “100 km” (“60 mile”) from the next engine ●...
Page 74 Instruments (Continued) WATER TEMP Above 132°C: ● Displays the current coolant temperature. High coolant temperature indicator and warning indicator come on. The high coolant temperature indicator is displayed in the warning information. (P.71) (P.75) “132°C” flashes. Even if the engine coolant temperature is ●...
Page 75: Helpful Information
WARNING INFO EQUIPMENT Displays a current maintenance information, "EQUIPMENT" is displayed but not selectable. helpful information and (or) warning information. (P.73) If your vehicle has warning information, have your vehicle inspected by your dealer as soon as possible. Helpful Warning information Information Maintenance information Continued...
Page 76 Instruments (Continued) SYSTEM INFORMATION Displays the software version and hardware information.
Page 77 Pop-up information In the following cases, pop-up information is displayed at the INFO area. Maintenance information: ● When the inspection time of your vehicle is approaching. Helpful information: ● When your vehicle has helpful information. Warning information: ● When your vehicle has warning information. When your vehicle has multiple pieces of information, pop-up information display appears alternately.
Page 78 Helpful Information Indication Explanation Remedy Appears when Refer to “When the communication between Honda SMART Key your vehicle and Honda System Does Not SMART Key is Operate Properly.” interrupted after turning (P.186) on the electrical system. Appears when the Refer to “Replacing the...
Page 79 Warning Information Indication Explanation Remedy Warning indicator Refer to “Low Oil When the oil pressure Pressure Indicator” in the engine is low. (P.178) Low oil pressure indicator Warning indicator When the coolant Refer to “Overheating” temperature becomes (P.177) high. High coolant temperature indicator You can hide the pop-up information by pushing either the sel switch while the...
Page 80 Indicators If one of these indicators does not come on when it should, have your dealer check for problems. Refer to the "Instruments" about indicators appeared on the display: (P.27) (P.75) Left turn signal indicator Right turn signal indicator PGM-FI (Programmed Fuel Injection) malfunction indicator lamp (MIL) Comes on briefly when the electrical...
Page 81 If it comes on while riding: (P.181) Honda SMART Key indicator Comes on briefly when the electrical system is turned on. When the Honda SMART Key Indicator Flashes: (P.182) Steering lock indicator Comes on briefly while the steering lock is Torque Control OFF Indicator activating.
Page 82: On/Off Button
Answer back button This button is used to operate the answer back system. Answer Back System: (P.91) ON/OFF button This button is used to activate or deactivate the Honda SMART Key system, and also to confirm the activation status. (P.86)
Page 83 Ignition Switch (Lock) Locks steering. (P.83) Switches the electrical system on/off, locks the steering. Make sure that the Honda SMART Key is activated and enter the (P.86) (Off) Turns engine off. operating range. (P.87) Ignition switch knob (Off/Lock) (On) Turns electrical system on for starting/riding.
Page 84: Horn Button
Switches (Continued) Left handlebar switches Shift up switch (+) Headlight dimmer/Passing light control switch To shift up the gear. • : High beam (P.111) • : DRL auto or off (low beam) (P.119) • : Flashes the high beam headlight. Horn button Shift down switch (-) To shift down the gear.
Page 85 Used to operate and set the display. (P.41) Also used to set the riding mode and to (P.98) operate the Honda RoadSync. (P.94) Cruise control lever Push up or down to set the speed or adjust the set speed. (P.112)
Page 86: Hazard Switch
Switches (Continued) Right handlebar switches Engine stop switch/ Start button Should normally remain in the (Run) position. In an emergency, switch to the (Stop) position to stop the engine. N-D/M switch To shift between Neutral and AT MODE or MT MODE. (P.110) Cruise control main switch Press to activate the cruise control system.
Page 87: Steering Lock
Steering Lock Locking Turn the ignition switch knob (Off/ Lock the steering when parking to help Lock) counterclockwise to turn off the prevent theft. electrical system. A U-shaped wheel lock or similar device is (P.79) Turn the handlebar all the way to the left. also recommended.
Page 88 Switches (Continued) Turn and hold the ignition switch knob Unlocking (Off/Lock) counterclockwise. Make sure that the Honda SMART Key is The steering lock indicator comes on activated and enter the operating (P.86) briefly and the steering is automatically range. (P.87) locked.
Page 89 The system runs a two-way authentication between the vehicle and the Honda SMART Key to verify if it is the registered Honda SMART Key. The Honda SMART Key system uses low- intensity radio waves. It may affect medical equipment such as a cardiac pacemaker.
Page 90 (Continued) Switching the Honda SMART Key System To switch the Honda SMART Key system to activation or deactivation Press the ON/OFF button until the Honda SMART Key LED changes colour. To check the Honda SMART Key ON/OFF button system status Lightly press the ON/OFF button.
Page 91 Operating Range The system can be operated when the The Honda SMART Key system uses low- Honda SMART Key is within the shaded area intensity radio waves. Therefore, the shown in the illustration. operating range may be wider or narrower,...
Page 92 (Continued) Anyone can operate the ignition switch and Anyone in possession of the Honda SMART start the engine if your Honda SMART Key is Key can perform the following operations if within operating range of your vehicle, even the Honda SMART Key is within operating...
Page 93 To Activate the Electrical System have a verified Honda SMART Key. Make sure that the Honda SMART Key is Whenever you leave your vehicle, turn off the activated and enter the operating range for electrical system and lock the steering.
Page 94 Honda SMART Key System (Continued) To Turn Off the Electrical System Turn the ignition switch knob (Off/ Lock) counterclockwise. Leave the operating range with the Honda SMART Key or switch the Honda (P.87) SMART Key system to deactivation. (P.86) When the Honda SMART Key system does not work properly (P.186)
Page 95: Operation
The answer back system is a device to find Operation the location of your vehicle. When the Press the answer back button on the Honda immobilizer is active and you press the SMART Key. answer back button on the Honda SMART...
Page 96: Ignition (On)
Answer Back System (Continued) Wait for about 10 seconds until the Honda Adjusting the Answer Back Buzzer SMART Key indicator goes off. The sound Sound Volume Level volume level is set. You can select the buzzer sound volume The sound volume level is also set by from 3 levels.
Page 97 Wait for about 10 seconds until the Honda Changing the Answer Back Buzzer SMART Key indicator goes off. The sound Sound Pattern pattern is set. You can select buzzer sound from 3 patterns. The sound pattern is also set by turn the Lock the steering.
Page 98: Communication Range
® registered trademarks owned by Bluetooth SIG, Inc., and any use of such marks by Honda Motors Co., Ltd., is under license. Other trademarks and trade names are those of their respective owners. The dedicated application is not available in some regions/countries.
Page 99 ● WARNING compatible with the feature. We shall not be liable for any damages or Using the Honda RoadSync while riding ● trouble in the use of smartphone. can take your attention away from the When unable to connect your road, causing a crash in which you ●...
Page 100: Bluetooth ® Indicator
When the “YES” is selected Press and hold the on the sel switch. The may result in a decrease or cessation of Honda pairing record is reset. RoadSync functionality and services. After resetting, complete pairing while the...
Page 101: Parking Brake
Parking Brake Parking Brake Lever NOTICE Riding with the parking brake applied will Be sure the parking brake is applied while damage the rear brake components. parking and warming up the engine. Make sure the parking brake lever is released before riding. To apply the parking brake Push the parking brake lever to the right until it snaps into place.
Page 102: Riding Mode
Riding mode You can change the riding mode. Riding mode has 6 modes. The riding mode consists of the following Available riding modes: [STANDARD], [RAIN], parameters. [GRAVEL], [USER 1], [USER 2] and [SPORT] The level of each parameter changes according to the selected riding mode. STANDARD : Standard, all-round mode for a variety of situations.
Page 103 Initial setting D level STANDARD P level EB level T level ABS mode ON ROAD SPORT ON ROAD RAIN ON ROAD GRAVEL OFF ROAD USER 1 ON ROAD *1, 2 USER 2 ON ROAD *1, 2 Notes: *1 : Level can be changed. *2 : If off is selected, the level will change to 2 the next time the ignition is turned on.
Page 104 Riding mode (Continued) P level (Engine power output level) D level (DCT mode) P level has three setting levels. D level (DCT mode) has five setting levels. Available setting range: 1 to 3 Available setting range: Level 1 has the least power. 1 to 4 (1, 2, 3, 3G, 4) Level 3 has the most power.
Page 105 T level (Torque control level) ABS (ABS mode) T level has three setting levels or can be ABS (ABS mode) has two setting levels. turned off. Available setting range: Available setting range: 1 to 3, or Off ON ROAD or OFF ROAD Level 1 is the minimum Torque Control level.
Page 106 Riding mode (Continued) Selecting the riding mode STANDARD Stop the vehicle. Press the switch with the throttle MODE fully closed. SPORT Each time the electrical system is turned on RAIN the riding mode returns to STANDARD. switch MODE GRAVEL USER 1 USER 2 Press the switch...
Page 107: Parameter Setting
Setting the riding mode Select the desired parameter and setting level. To select the parameter, push the sel switch You can change the P, EB, D, T and ABS in the direction of levels on the USER of the riding mode. Press on the sel switch to select the setting level using...
Page 108 Riding mode (Continued) Press and hold the switch MODE Push the sel switch in the direction of Push the sel switch in the direction of Press on the sel switch Press on the sel switch Press and hold on the sel switch...
Page 109: Starting The Engine
10 seconds before trying to start the engine This vehicle is equipped with a Honda again to recover battery voltage. SMART Key system. Always keep Honda • Extended fast idling and revving the engine...
Page 110 Starting the Engine (Continued) If you cannot start the engine: If the engine starts, open the throttle slightly if idling is unstable. With the throttle slightly open (about 3 mm If the engine does not start, wait 10 seconds (0.1 in), without freeplay), press the start before trying steps a &...
Page 111: Shifting Gears
Shifting Gears Your vehicle is equipped with an The Dual Clutch Transmission system runs a automatically controlled 6-speed self check immediately after starting the transmission. It can be shifted automatically engine. (by AT MODE) or manually (by MT MODE). You cannot shift into gear for a few seconds. Dual Clutch Transmission D/M side on the N-D/M switch In order to respond to rider demands in a...
Page 112 Shifting Gears (Continued) Neutral (N): Neutral is selected When you can change between N and D automatically when you turn the electrical Vehicle is stopped and the engine is idling. Throttle is completely closed. It is not system on. possible to change from Neutral to D mode If neutral is not selected when the while the throttle is applied.
Page 113 AT MODE: In this mode, the gears are MT MODE (6-speed manual operation): shifted automatically according to your riding In this mode, you can choose between 6 conditions. gears. And also using the shift up switch (+) or shift down switch (−), you can temporarily shift up or down.
Page 114 Shifting Gears (Continued) Changing between Neutral and AT N-D/M switch MODE/MT MODE Changing from Neutral (N) to AT MODE Press the D/M side on the N-D/M switch (a). “1” is shown (b) in the gear position indicator and first gear is selected. Changing between AT MODE and MT MODE Press the D/M side on the N-D/M switch...
Page 115: Shift Limit
Riding in MT MODE Gear shift operation Shift up and down with the shift up switch (+) Shifting Up: and shift down switch (−). Press the shift up switch (+) (g). The selected gear is shown on the gear Shifting Down: position indicator.
Page 116: Cruise Control
Cruise Control The cruise control system allows you to Cruise control is intended for use only on maintain a steady speed within a specified straight, uncongested highways. Do not use range. cruise control on city streets, winding roads, The available speed setting range and during bad weather, or at any other time operating gears are listed below: when you need total control of the throttle.
Page 117 To Set Cruise Control Cruise control display Make sure the travelling speed and operating gear are conformed to the requirements of the system. Any speed other than the available range will not be memorized. Press the cruise control main switch (The cruise control display will be appeared).
Page 118 Cruise Control (Continued) The system will accelerate your vehicle To Change the Set Speed automatically. When you reach the To Fine Tune the Set Speed desired speed, release the cruise control To increase the set speed: tap the cruise lever. control lever to side.
Page 119 To Manually Increase the Set Speed To Manually Increase Vehicle Speed Use the throttle to accelerate until you reach Use the throttle in the normal manner to the desired speed. accelerate. Push and release the cruise control lever to To return to the set speed, close the throttle side.
Page 120 Cruise Control (Continued) To Temporarily Disengage the System To resume cruise control: If you are still travelling over 50 km/h Perform one of the following operations to ● disengage the system temporarily (The (30 mph), push and release the cruise colour of cruise control main indicator control lever to...
Page 121: Emergency Stop Signal
Emergency Stop Signal Emergency stop signal activates when the The emergency stop signal stops operating system detects hard braking about 50 km/h when: (31 mph) or above to alert drivers behind you You release the brakes. ● about sudden braking by rapidly flashing The ABS is deactivated.
Page 122 Emergency Stop Signal (Continued) The emergency stop signal is not a system that can prevent a possible rear-end collision caused by your hard braking. It is always recommended to avoid hard braking unless it is absolutely necessary. The emergency stop signal does not activate while the hazard switch is on.
Page 123 DRL (Daytime Running Light) When the headlight dimmer/passing light control switch is turned to the position and DRL is set to (Auto) (P.49) the headlights and DRL are switched automatically according to the ambient brightness. When it gets brighter, DRL lights up, and when it gets dark, low beam lights up and DRL decreases to the brightness of the position light.
Page 124 Tank capacity: 13.2 L (3.49 US gal, 2.90 Imp gal) Refuelling and Fuel Guidelines (P.14) Fuel lid opener switch Opening the Fuel Fill Cap Arrow marks Make sure that the Honda SMART Key is activated and enter the operating (P.86) Fuel lid range. (P.87) Push the fuel lid opener switch.
Page 125 Closing the Fuel Fill Cap Install and tighten the fuel fill cap firmly by turning it clockwise. Make sure that the arrow marks on the cap and fuel tank are aligned. Close the fuel lid. WARNING Petrol is highly flammable and explosive.
Page 126: Usb Socket
Use USB devices at your own risk. In no event NOTICE shall Honda be liable for any damage to your • Using any heat-generating USB devices or USB device when in use. improperly rated USB devices can damage the socket.
Page 127: Storage Equipment
Storage Equipment Open Luggage Box Make sure that the Honda SMART Key is activated and enter the operating (P.86) range. (P.87) Push the seat opener switch. Pull up the rear of the seat. Close Push down the rear of the seat until it locks in place.
Page 128 Storage Equipment (Continued) A helmet can be stored in the luggage box. Set in the front of the helmet upward. Helmet Some helmets may not fit in the compartment due to their size or design.
Page 129: Document Bag
Tool Kit Document Bag The tool kit is stored in the luggage box by The document bag is stored reverse side of the rubber strap. the seat. Document bag Tool kit Rubber strap Opening the seat (P.123) Rubber strap Opening the seat (P.123) Continued...
Page 130 Storage Equipment (Continued) Helmet Holder WARNING The helmet holder is located under the seat. Riding with a helmet attached to the A helmet set wire is in the tool kit. holder can interfere with your ability to safely operate the vehicle and could Helmet holder lead to a crash in which you can be seriously hurt or killed.
Page 131 Fairing Pocket Fairing pocket Fairing pocket lid Never exceed the maximum weight limit. Maximum Weight: 0.5 kg (1.0 lb) Open To open the fairing pocket, pull the fairing pocket lid. Close Push the fairing pocket lid until it is firmly closed.
Page 132: Maintenance
Adjusting the Windscreen Height ....P. 171 Front Lower Cover ..........P. 150 Other Replacement......... P. 173 Maintenance Lid..........P. 151 Replacing the Honda SMART Key Battery .. P. 173 Left Side Cover ..........P. 152 Engine Oil ............P. 155 Coolant .............. P. 157...
Page 133: Importance Of Maintenance
Importance of Maintenance Importance of Maintenance Maintenance Safety Keeping your vehicle well-maintained is Always read the maintenance instructions absolutely essential to your safety and to before you begin each task and make sure that protect your investment, obtain maximum you have the tools, parts, and skills required. performance, avoid breakdowns, and reduce air We cannot warn you of every conceivable pollution.
Page 134: Maintenance Schedule
Maintenance work should be performed in new owner. accordance with Honda's standards and specifications by properly trained and equipped Honda recommends that your dealer should technicians. Your dealer meets all of these road test your vehicle after each periodic requirements. Keep an accurate record of maintenance is carried out.
Page 135 Inspect (clean, adjust, lubricate, or replace, if necessary) dealer, unless you have the necessary tools and are Lubricate mechanically skilled. Replace Procedures are provided in an official Honda Shop Manual. Clean : Technical. In the interest of safety, have your vehicle serviced by your dealer. Continued...
Page 136 Maintenance Schedule Frequency Pre-ride Refer Annual Regular Items Check × 1,000 km Check Replace P. 135 page × 1,000 mi Every 1,000 km (600 mi): Drive Chain Drive Chain Slider Brake Fluid 2 Years Brake Pads Wear Brake System Brake Lock Operation Headlight Aim –...
Page 137 : Intermediate. We recommend service by your dealer, unless Inspect (clean, adjust, lubricate, or replace, if necessary) you have the necessary tools and are mechanically skilled. Replace Procedures are provided in an official Honda Shop Lubricate Manual. Clean : Technical. In the interest of safety, have your vehicle serviced by your dealer.
Page 138 Maintenance Schedule Frequency Pre-ride Annual Regular Refer to Items Check × 1,000 km Check Replace page P. 135 × 1,000 mi Every 1,000 km (600 mi): Drive Chain Drive Chain Slider Brake Fluid 2 Years Brake Pads Wear Brake System Brake Lock Operation Headlight Aim –...
Page 139: Maintenance Fundamentals
Maintenance Fundamentals Drive chain - Check condition and slack, Pre-ride Inspection ● adjust and lubricate if necessary P. 163 To ensure safety, it is your responsibility to Brakes - Check operation; ● perform a pre-ride inspection and make sure Front and Rear: check brake fluid level and that any problem you find is corrected.
Page 140 Maintenance Fundamentals WARNING Replacing Parts Always use Honda Genuine Parts or their Installing non-Honda parts may make equivalents to ensure reliability and safety. your vehicle unsafe and cause a crash in KO, II KO type which you can be seriously hurt or When ordering coloured components, specify killed.
Page 141 Maintenance Fundamentals Battery NOTICE An improperly disposed of battery can be Your vehicle has a maintenance-free type harmful to the environment and human health. battery. You do not have to check the battery Always confirm local regulations for proper electrolyte level or add distilled water. Clean the battery disposal instruction.
Page 142 Maintenance Fundamentals What to do in an emergency WARNING If any of the following occur, immediately see The battery gives off explosive your doctor. hydrogen gas during normal operation. Electrolyte splashes into your eyes: ● Wash your eyes repeatedly with cool water for at least 15 minutes.
Page 143 Always replace the battery with another maintenance-free battery of the same type. NOTICE Installing non-Honda electrical accessories can NOTICE overload the electrical system, discharging the Replacing a fuse with one that has a higher battery and possibly damaging the system.
Page 144 For recommended engine oil, see or “Resource Conserving” on the circular API “Specifications.” P. 226 service symbol. If you use non-Honda engine oil, check the label to make sure that the oil satisfies all of the following standards: JASO T 903 standard : MA ●...
Page 145: Recommended Brake Fluid
Brake fluid can damage plastic and painted surfaces. Wipe up spills immediately and wash thoroughly. Recommended brake fluid: Normal Worn Damaged Honda DOT 4 Brake Fluid or equivalent (GOOD) (REPLACE) (REPLACE) Drive Chain NOTICE Use of a new chain with worn sprockets will cause The drive chain must be inspected and rapid chain wear.
Page 146 Maintenance Fundamentals Cleaning and Lubricating Do not use a steam cleaner, a high pressure cleaner, a wire brush, volatile solvent such as After inspecting the slack, clean the chain and petrol and benzene, abrasive cleaner, chain sprockets while rotating the rear wheel. Use a dry cleaner or lubricant NOT designed specifically cloth with chain cleaner designed specifically for for O-ring chains as these can damage the...
Page 147: Recommended Coolant
Recommended Coolant NOTICE Using coolant not specified for aluminium KO, II KO type engines or tap/mineral water can cause Pro Honda HP Coolant is a pre-mixed solution corrosion. of antifreeze and distilled water. Concentration: 50% antifreeze and 50% distilled water...
Page 148 Maintenance Fundamentals Inspecting for Damage Tyres (Inspecting/Replacing) Checking the Air Pressure Inspect the tyres for Visually inspect your tyres and use an air cuts, slits, or cracks that pressure gauge to measure the air pressure at expose fabric or cords, least once a month or any time you think the or nails or other tyres look low.
Page 149 Maintenance Fundamentals Inspecting Tread Depth WARNING Inspect the tread wear indicators. If they Riding on tyres that are excessively become visible, replace the tyres immediately. worn or improperly inflated can cause a For safe riding, you should replace the tyres crash in which you can be seriously hurt when the minimum tread depth is reached.
Page 150 Installing improper tyres on your equivalents of the same size, construction, speed rating, and load range. vehicle can adversely affect handling Have the wheel balanced with Honda and stability, and can cause a crash in ● Genuine balance weights or equivalent after which you can be seriously hurt or the tyre is installed.
Page 151: Tools
Tools The tool kit is stored under the seat. P. 123 You can perform some roadside repairs, minor adjustments and parts replacement with the provided tools. 10 x 14 mm Open end wrench ● 12 x 14 mm Open end wrench ●...
Page 152: Removing & Installing Body Components
Removing & Installing Body Components Battery Disconnect the positive + terminal from the battery. Negative terminal Positive terminal Remove the battery, taking care not to drop the terminal nuts. Remove the battery by pulling the battery strap with one hand while supporting the battery with the other.
Page 153: Clip
Removing & Installing Body Components Clip Clip Removal Press down on the centre pin to release the lock. Pull the clip out of the hole. Centre Installation Push the bottom of the centre pin. Insert the clip into the hole. Press down on the centre pin to lock the clip.
Page 154: Front Lower Cover
Removing & Installing Body Components Front Lower Cover Front Lower Cover Front lower cover Clips Clip Bolt B Bolt A Bolts Skid plate Remove the bolt A, bolt B and clips. Removal P. 149 Remove the skid plate by removing the Remove the front lower cover.
Page 155: Maintenance Lid
Removing & Installing Body Components Maintenance Lid Maintenance Lid Removal Open the seat. P. 123 Remove the tool kit. Maintenance lid Remove the clips ( P. 149) and maintenance lid. Installation Install the parts in the reverse order of removal. Clips...
Page 156: Left Side Cover
Removing & Installing Body Components Left Side Cover Left Side Cover Release the tabs from slots. Carefully release the tabs from the slots. Removal Pull the side cover slightly back to release the hooks from the slots. Open the seat. P.
Page 157 Removing & Installing Body Components Left Side Cover Installation Slots Grab rail Hooks Pull the left side cover back slightly and attach the hooks into the slots. Left side cover To attach the hooks securely, push the Insert the left side cover on the back of left side cover forward.
Page 158 Removing & Installing Body Components Left Side Cover Tabs Tabs Slots Insert the tabs into the slots. Insert the prongs into the grommets. Install the bolt and clip. Close the seat.
Page 159: Checking The Engine Oil
Engine Oil Checking the Engine Oil Upper level If the engine is cold, idle the engine for 3 to 5 minutes. Turn off the electrical system and wait for 2 to 3 minutes. Lower level Place your vehicle on its centre stand on a firm, level surface.
Page 160: Adding Engine Oil
Engine Oil Adding Engine Oil Adding Engine Oil Securely reinstall the oil fill cap/dipstick. NOTICE If the engine oil is below or near the lower Overfilling with oil or operating with insufficient level mark, add the recommended engine oil. oil can cause damage to your engine. Do not mix P.
Page 161: Checking The Coolant
Coolant Checking the Coolant UPPER level Check the coolant level in the reserve tank while the engine is cold. Place your vehicle on a firm, level surface. Hold your vehicle in an upright position. Check that the coolant level is between the UPPER level and LOWER level marks on the reserve tank.
Page 162 Coolant Adding Coolant Remove the front lower cover. P. 150 Reserve tank cap Remove the reserve tank cap and add fluid while monitoring the coolant level. Do not overfill above the UPPER level mark. Make sure no foreign objects enter the reserve tank opening.
Page 163: Brakes
Brakes Checking Brake Fluid If the brake fluid level in either reservoir is below the LOWER level mark or both the brake levers freeplay becomes excessive, Place your vehicle in an upright position inspect the brake pads for wear. on a firm, level surface. If the brake pads are not worn, you most Check that the brake fluid reservoir is likely have a leak.
Page 164: Inspecting The Brake Pads
Brakes Inspecting the Brake Pads Inspecting the Brake Pads Inspect the brake pads from in front Front of the brake caliper. Always inspect both left and right Check the condition of the brake pad wear brake calipers. indicators. Inspect the brake pads from the rear The pads need to be replaced if a Rear Front...
Page 165: Checking The Parking Brake
Brakes Checking the Parking Brake Checking the Parking Brake Check that the front edge of the parking brake lever is within the adjustment range (between the index marks), when the Front edge of parking brake lever brake begins to take hold. Index marks If the brake begins to take hold at out of the adjustment range, have the brake adjusted...
Page 166: Checking The Side Stand
Side Stand Checking the Side Stand Start the engine and press the D/M side on the N-D/M switch to switch the transmission into D mode. Lower the side stand all the way. The engine should stop as you lower the side stand.
Page 167: Drive Chain
Drive Chain Inspecting the Drive Chain Check the slack in the lower half of the drive chain midway between the Slack sprockets. While depressing the drive chain, Check the drive chain slack at several points measure the distance from the bottom along the chain.
Page 168 Drive Chain Inspecting the Drive Chain Slack Rotate the rear wheel and check that the Swingarm Drive chain chain moves smoothly. Inspect the sprockets. P. 141 Clean and lubricate the drive chain. P. 142 Push Drive chain slack Drive chain slack...
Page 169 Drive Chain Checking the Drive Chain Slider Checking the Drive Chain Slider Check the condition of the drive chain slider. The drive chain slider will need to be replaced if the chain slider is worn to the wear limit line. If necessary, have the drive chain slider replaced by your dealer.
Page 170: Throttle
Throttle Checking the Throttle With the engine off, check that the throttle rotates smoothly from fully closed to fully open. If the throttle does not move smoothly or close automatically, have the vehicle inspected by your dealer. Throttle...
Page 171: Other Adjustments
Other Adjustments Adjusting the Brake Lever Brake lever You can adjust the distance between the Forward brake lever and handle grip. Adjustment method Turn the adjuster until the numbers align with the index mark while pushing the lever forward in the desired position. After adjustment, check that the lever Adjuster operates correctly before riding.
Page 172: Adjusting The Front Suspension
Other Adjustments Adjusting the Front Suspension Adjusting the Front Suspension Spring Preload You can adjust the spring preload by the adjuster to suit the load or the road surface. Turn the adjuster using the box end wrench Adjuster Adjuster provided in the tool kit. P.
Page 173: Rebound Damping
Other Adjustments Adjusting the Front Suspension Rebound Damping BFR adjuster You can adjust the rebound damping by the Reference adjuster to suit the load or the road surface. punch mark The rebound damping adjuster has 3 turns or more. Turn the adjuster using the BFR adjuster provided in the tool kit.
Page 174: Adjusting The Rear Suspension
Other Adjustments Adjusting the Rear Suspension Adjusting the Rear Suspension Pin spanner 1 2 3 4 5 6 Spring Preload You can adjust the spring preload by the adjuster to suit the load or the road surface. Turn the adjuster using the pin spanner and extension bar provided in the tool kit.
Page 175: Adjusting The Windscreen Height
Other Adjustments Adjusting the Windscreen Height Adjusting the Windscreen Windscreen Height You can adjust the windscreen height 1 of 5 positions. Windscreen height indicator shows the windscreen height. The standard position is 1. Do not adjust the windscreen while riding. Down Pull the windscreen lock lever outward until it snaps into place.
Page 176 Other Adjustments Adjusting the Windscreen Height Align the windscreen height indicator with If the windscreen does not move smoothly the index mark at the desired position. after flushing the sliding parts, have your Push the windscreen lock lever back to vehicle inspected by your dealer.
Page 177: Other Replacement
Key Battery with a protective cloth into the slit. Wrap a coin or a screwdriver with a If the Honda SMART Key indicator flashes 5 protective cloth to prevent scratching times when the electrical system is turned on, the Honda SMART Key.
Page 178 Other Replacement Replacing the Honda SMART Key Battery Snap the two halves of the remote CAUTION transmitter back together. • Danger of explosion if battery is Make sure that upper and lower cases incorrectly replaced. Replace only with the are set in the right position.
Page 179: Troubleshooting
Engine Will Not Start........P. 176 Coolant Temperature Failure Indication..P. 185 Overheating (High coolant temperature/ When the Honda SMART Key System Does Not warning indicators are on)......P. 177 Operate Properly........... P. 186 Warning Indicators On or Flashing..... P. 178 Unlock the Seat in an Emergency ....
Page 180: Engine Will Not Start
Engine Will Not Start Starter Motor Operates But Starter Motor Does Not Engine Does Not Start Operate Check the following items: Check the following items: Check the correct engine starting Check the correct engine starting ● ● sequence. P. 105 sequence.
Page 181: Overheating (High Coolant Temperature/Warning Indicators Are On)
Overheating (High coolant temperature/warning indicators are on) The engine is overheating when the following Check that the radiator fan is operating, occurs: and then turn the electrical system off. High coolant temperature indicator and If the fan is not operating: ●...
Page 182: Warning Indicators On Or Flashing
Warning Indicators On or Flashing Low Oil Pressure Indicator If the low oil pressure indicator and the warning indicator stay on when the oil level is at the proper level, stop the engine and If the low oil pressure indicator and the contact your dealer.
Page 183: Pgm-Fi (Programmed Fuel Injection) Malfunction Indicator Lamp (Mil)
Warning Indicators On or Flashing PGM-FI (Programmed Fuel Injection) Malfunction Indicator Lamp (MIL) PGM-FI (Programmed Fuel What to do when the indicator lamp comes on Injection) Malfunction Avoid high speeds and immediately get your Indicator Lamp (MIL) vehicle inspected at a dealer. NOTICE Except KO, II KO type If you drive with the malfunction indicator lamp...
Page 184: Abs (Anti-Lock Brake System) Indicator
Warning Indicators On or Flashing ABS (Anti-lock Brake System) Indicator ABS (Anti-lock Brake System) If the ABS indicator stays on, your brakes will continue to work as a conventional system, Indicator but without the anti-locking function. If the indicator operates in one of the The ABS indicator may flash if you turn the following ways, you may have a serious rear wheel while the rear wheel is lifted off...
Page 185: Torque Control Indicator
Warning Indicators On or Flashing Torque Control Indicator Torque Control Indicator Even when the Torque Control indicator is on, your vehicle will have normal riding ability without Torque Control function. If the indicator operates in one of the When the indicator comes on while the following ways, you may have a serious Torque Control is in operation, you will problem with the Torque Control.
Page 186: Honda Smart Key Indicator
It is probably caused by the following: Strong radio waves or noise are affecting ● If you do not have the Honda SMART Key, the system the electrical system can be activated in You lose the Honda SMART Key while another way.
Page 187: If The "-" Indicator Is Blinking In The Gear Position Window While Riding
If the “–” Indicator is Blinking in the Gear Position Window While Riding If the “–” indicator is blinking while riding, you If you still cannot start the engine: may have a serious problem with the Dual Start the engine while applying the front or Clutch Transmission system.
Page 188: Other Warning Indications
Other Warning Indications Fuel Gauge Failure Indication If the fuel system has an error, the fuel gauge indicators will be displayed as shown in the illustration. If this occurs, see your dealer as soon as possible.
Page 189: Coolant Temperature Failure Indication
Other Warning Indications Coolant Temperature Failure Indication Coolant Temperature Failure Indication If the cooling system has an error, coolant temperature “---” flashes. If this occurs, see your dealer as soon as possible.
Page 190: When The Honda Smart Key System Does Not Operate Properly
When the Honda SMART Key System Does Not Operate Properly When the Honda SMART Key system does Check that there is no communication ● not work properly, perform the following. failure in the Honda SMART Key system. Check that the Honda SMART Key system The Honda SMART Key system uses low- ●...
Page 191 When the Honda SMART Key System Does Not Operate Properly Check that a registered Honda SMART Check the battery condition and battery ● ● Key is used. lead in your vehicle. Use a registered Honda SMART Key. Check the battery and battery terminals. If The Honda SMART Key system cannot be the battery is weak, contact your dealer.
Page 192: Unlock The Seat In An Emergency
Unlock the Seat in an Emergency The seat lock can be unlocked by using the emergency key. Emergency seat opener Open Remove the emergency seat opener cap. Insert the emergency key into the emergency seat opener, and turn the key counterclockwise.
Page 193: Activating The Electrical System In An Emergency
Activating the Electrical System in an Emergency The electrical system can be activated by Use the emergency key to open the seat. inputting the ID number. P. 188 Remove the maintenance lid. P. 151 Push the tab to remove the data link Set up to ID number input mode connector from the connector suspension.
Page 194 Activating the Electrical System in an Emergency Push and hold the ignition (On) switch Ignition (On) switch for more than 4 seconds within 60 seconds after reconnecting the white dummy coupler. The steering lock indicator comes on, the buzzer sounds and the system enters the ID number input mode.
Page 195 Activating the Electrical System in an Emergency ID number input While inputting the ID number, if the button is not pressed for about 60 seconds, the You can input your ID number by pushing inputted ID number is cancelled and the the ignition (On) switch and Turn the system returns to the state before disconnect ignition switch knob...
Page 196 Activating the Electrical System in an Emergency Example: To input “1”, push the ignition (On) ● To input “0”, turn the ignition switch knob switch once, and then turn the ignition ● (Off/Lock) counterclockwise without switch knob (Off/Lock) pushing the ignition (On) switch, and counterclockwise to input the next digit.
Page 197 Activating the Electrical System in an Emergency Reinstall the parts in reverse order of ID number input success After the last digit of the ID number is removal, before riding. inputted, ID number is authenticated, the steering lock indicator will flash every 2 You can turn off the engine and electrical seconds.
Page 198 Activating the Electrical System in an Emergency ID number input failure ID number input cancel If the ID number is not authenticated after If you input the wrong number, you can inputting, the buzzer sounds and the steering cancel ID number input by not operating the lock indicator goes off.
Page 199: Tyre Puncture
Tyre Puncture Repairing a puncture or removing a wheel WARNING requires special tools and technical expertise. Riding your vehicle with a temporary We recommend you have this type of service tyre repair can be risky. If the temporary performed by your dealer. repair fails, you can crash and be After an emergency repair, always have the seriously injured or killed.
Page 200: Smartphone Pairing Trouble
Smartphone Pairing Trouble Symptom Cause/remedy Some smartphones you use may be incompatible with the vehicle and/or the operable functions may be limited. Check that the vehicle and smartphone are both in pairing mode. P. 96 Check your surroundings to make sure no other device being paired is present before re-pairing.
Page 201 Smartphone Pairing Trouble Symptom Cause/remedy Depending on the smartphone you use, it may take some time for the vehicle to connect to a smartphone and to start using a dedicated application. The connection may be temporarily disconnected when starting the engine, which is normal and not a malfunction. The smartphone will be reconnected after the engine is started.
Page 202: Electrical Trouble
Electrical Trouble Battery Goes Dead Burned-out Light Bulb Charge the battery using a motorcycle All light bulbs on the vehicle are LEDs. If battery charger. there is an LED which is not turned on, see Remove the battery from the vehicle before your dealer for servicing.
Page 203: Blown Fuse
Electrical Trouble Blown Fuse Blown Fuse Remove the left side cover. P. 152 Remove the fuse box cover. Pull the fuses out one by one with the Before handling fuses, see “Inspecting and fuse puller in the tool kit ( P.
Page 204 Electrical Trouble Blown Fuse Fuse Box B Fuses Remove the left side cover. P. 152 Open the fuse box cover. Pull the fuses out one by one with the Fuse box cover fuse puller in the tool kit ( P. 125) and check for a blown fuse.
Page 205 Electrical Trouble Blown Fuse Main Fuses Remove the maintenance lid. P. 151 Push the tab to remove the data link connector from the connector Starter magnetic switch connector suspension. Push the tab to disconnect the starter magnetic switch connector from the starter magnetic switch.
Page 206 Electrical Trouble Blown Fuse kit ( P. 125) and check for a blown fuse. Always replace a blown fuse with a spare fuse of the same rating. Spare main fuse is in the fuse box B. P. 200 Reinstall parts in the reverse order of removal.
Page 207: Information
Information Service Diagnostic Recorders....... P. 204 Keys..............P. 205 Instruments, Controls, & Other Features... P. 209 Caring for Your Vehicle........P. 214 Storing Your Vehicle........P. 218 Transporting Your Vehicle ......P. 219 You & the Environment ......... P. 220 Serial Numbers ..........
Page 208: Service Diagnostic Recorders
However this data may be accessed by Honda, its authorised dealers and authorised repairers, employees, representatives and contractors only for the purpose of the technical diagnosis,...
Page 209: Keys
Keys Keys Emergency key Key tag Emergency Key This vehicle has emergency keys and a key tag with a key number and a bar code. Store the key tag in a safe location. To make a duplicate key, take the key and key tag to your dealer or a locksmith.
Page 210 Do not scratch or puncture. ● The ID number of the Honda SMART Key is on Do not store near any magnetized products ● the ID tag. You can also activate the electrical such as a magnetized key chain.
Page 211 Keys If fuel, wax, or grease adhere to the Honda The battery in the Honda SMART Key system ● SMART Key, wipe it off immediately to avoid normally lasts about 2 years. cracking or warping. Do not disassemble the Honda SMART Key Do not keep mobile phones or other radio ●...
Page 212 Keys Taiwan only...
Page 213: Instruments, Controls, & Other Features
Instruments, Controls, & Other Features Instruments, Controls, & Tripmeter Other Features Each tripmeter resets to 0.0 when the trip mileage exceeds 9,999.9. Ignition Switch Document Bag Leaving the electrical system on with the engine The owner’s manual, registration, and insurance stopped will drain the battery.
Page 214 Instruments, Controls, & Other Features Throttle by Wire System DRL, Automatic Brightness Control and Background Control This model is equipped with a Throttle by Wire System. Ambient brightness is detected by the Do not put magnetized items or items photosensor. susceptible to magnetic interference near the Do not damage or cover the photosensor.
Page 215 Instruments, Controls, & Other Features Honda RoadSync Korea only Continued...
Page 216 Instruments, Controls, & Other Features Taiwan only...
Page 217 Instruments, Controls, & Other Features Thailand only...
Page 218: Caring For Your Vehicle
Frequent cleaning and polishing is important to Clean the windscreen, headlight lens, ensure the life of your Honda. A clean vehicle panels, and other plastic components makes it easier to spot potential problems.
Page 219 Caring for Your Vehicle Keep the wax clear of the tyres and brakes. Washing Precautions If your vehicle has any mat painted parts, Follow these guidelines when washing: do not apply a coat of wax to the mat Do not use high-pressure washers: ●...
Page 220: Aluminium Components
Caring for Your Vehicle Do not direct water at the air cleaner: Aluminium Components ● Water in the air cleaner can prevent the Aluminium will corrode from contact with dirt, engine from starting. mud, or road salt. Clean aluminium parts Do not direct water near the headlight: ●...
Page 221: Exhaust Pipe And Muffler
Caring for Your Vehicle Windscreen Exhaust Pipe and Muffler Using plenty of water, clean the windscreen with The exhaust pipe and muffler are stainless steel a soft cloth or sponge. (Avoid using detergents but may become stained by mud or dust. or any kind of chemical cleaner on the windscreen.) Dry with a soft, clean cloth.
Page 222: Storing Your Vehicle
Storing Your Vehicle Storing Your Vehicle If the exhaust pipe and muffler are painted, do not use a commercially available abrasive If you store your vehicle outdoors, you should kitchen cleaning compound. Use a neutral consider using a full-body cover. detergent to clean the painted surface on the If you won't be riding for an extended period, exhaust pipe and muffler.
Page 223: Transporting Your Vehicle
Transporting Your Vehicle Transporting Your Vehicle After removing your vehicle from storage, inspect all maintenance items required by the If your vehicle needs to be transported, it Maintenance Schedule. should be carried on a motorcycle trailer or a flatbed truck or trailer that has a loading ramp or lifting platform and motorcycle tie-down straps.
Page 224: You & The Environment
You & the Environment You & the Environment Recycle Wastes Put oil and other toxic wastes in approved Owning and riding a vehicle can be enjoyable, containers and take them to a recycling centre. but you must do your part to protect the Call your local or state office of public works or environment.
Page 225: Serial Numbers
Serial Numbers Serial Numbers The frame and engine serial numbers uniquely identify your vehicle and are required in order to register your vehicle. They may also be required when ordering replacement parts. The engine number is stamped on the right rear side of the crankcase.
Page 226: Fuels Containing Alcohol
Fuels Containing Alcohol Fuels Containing Alcohol If you notice any undesirable operating symptoms or performance problems, try a different brand of petrol. Some conventional fuels blended with alcohol are available in some locales to help reduce emissions to TH, II TH type The following fuel blends can be used in your vehicle: meet clean air standards.
Page 227: Catalytic Converter
A defective catalytic converter contributes to air pollution and can impair your engine's performance. A replacement unit must be an original Honda part or equivalent.
Page 228: Specifications
Specifications Main Components ■ 237 kg (522 lb) ADV750 2,215 mm (87.2 in) ADV750 Except KO, II KO type Overall length Curb weight 237 kg (522 lb) 2,200 mm (86.6 in) ADV750L ADV750L KO, II KO type Overall width 940 mm (37.0 in) 235 kg (518 lb) Windscreen position 204 kg (450 lb)
Page 229 Specifications Service Data ■ Except TH, II TH type ETHANOL up to 10 % by volume Fuel containing Front 120/70R17M/C 58H Tyre size alcohol TH, II TH type Rear 160/60R15M/C 67H ETHANOL up to 20 % by volume Tyre type Radial, tubeless Tank capacity 13.2 L (3.49 US gal, 2.90 Imp gal)
Page 230 Specifications Honda 4-stroke motorcycle oil API Service Drive chain lubricant designed specifically Recommended Classification SJ or higher, excluding oils for O-ring chains drive chain Recommended marked as “Energy Conserving” or “Resource lubricant If not available, use SAE 80 or 90 gear oil.
Page 231 Specifications Bulbs ■ Headlight Brakelight/Taillight Front turn signal Rear turn signal License plate light Fuses ■ Main fuse 30 A Other fuse 30 A, 15 A, 10 A...
Page 232 Thailand only HELMET CAUTION LABEL...
Page 233 Online Owner’s Manual https://www.hondamotopub.com/ 32MKT900 1800.2024.10.S 英 00X32-MKT-9000 00X32-MKT-9000 PRINTED IN JAPAN...

This manual is also suitable for:

Adv750l 2024

Honda ADV750 2024 Owner's Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Honda ADV750 2024

Summary of Contents for Honda ADV750 2024

This manual is also suitable for:

Table of Contents
