  • Page 1 Owner’s Manual Manual Pemilik Read before you ride! Baca sebelum menunggang!
  • Page 2 This publication includes the latest production information available before printing. Honda Motor Co., Ltd. reserves the right to make changes at any time without notice and without incurring any obligation.
  • Page 3 Welcome Congratulations on your purchase of a new The following code in this manual ● Honda vehicle. Your selection of a Honda indicates the country. makes you part of a worldwide family of satisfied customers who appreciate Honda's Country Code...
  • Page 4 A Few Words About Safety DANGER Your safety, and the safety of others, is very important. Operating this vehicle safely is an You WILL be KILLED or SERIOUSLY HURT important responsibility. if you don’t follow instructions. To help you make informed decisions about safety, we have provided operating WARNING procedures and other information on safety...

  • Page 5: Table Of Contents

    Contents Vehicle Safety P. 2 Operation Guide P. 20 Maintenance P. 83 Troubleshooting P. 113 Information P. 135 Specifications P. 148...

  • Page 6: Vehicle Safety

    Vehicle Safety This section contains important information for safe riding of your vehicle. Please read this section carefully. Safety Guidelines ..........P. 3 Image Labels............P. 7 Safety Precautions..........P. 11 Riding Precautions ..........P. 13 Accessories & Modifications......P. 18 Loading ..............

  • Page 7: Safety Guidelines

    Safety Guidelines Safety Guidelines Before Riding Make sure that you are physically fit, mentally Follow these guidelines to enhance your safety: focused, and free of alcohol and drugs. Check Perform all routine and regular inspections ● that you and your passenger are both wearing specified in this manual.
  • Page 8 Safety Guidelines Ride Defensively Ride within Your Limits Always pay attention to other vehicles around Never ride beyond your personal abilities or you, and do not assume that other drivers see faster than conditions warrant. Fatigue and you. Be prepared to stop quickly or perform an inattention can impair your ability to use good evasive maneuver.
  • Page 9 Safety Guidelines Keep Your Honda in Safe Condition If You are Involved in a Crash It's important to keep your vehicle properly Personal safety is your first priority. If you or maintained and in safe riding condition. anyone else has been injured, take time to...
  • Page 10 Safety Guidelines WARNING Carbon Monoxide Hazard Exhaust contains poisonous carbon monoxide, a Running the engine of your vehicle colourless, odorless gas. Breathing carbon while in an enclosed or even partially monoxide can cause loss of consciousness and enclosed area can cause a rapid build- may lead to death.

  • Page 11: Image Labels

    Image Labels Image Labels The following pages describe the label Read instructions contained in Owner's meanings. Some labels warn you of Manual carefully. potential hazards that could cause serious injury. Others provide important safety Read instructions contained in Shop Manual information.
  • Page 12 Image Labels BATTERY LABEL DANGER • Keep flame and spark away from the battery. Battery produce explosive gas that can cause explosion. • Wear the eye protection and rubber gloves when handling the battery, or you can get burned or lose your eyesight by the battery electrolyte.
  • Page 13 Image Labels RADIATOR CAP LABEL DANGER NEVER OPEN WHEN HOT. Hot coolant will scald you. Relief pressure valve begins to open at 108 kPa. ABS INFORMATION LABEL This model equipped with an Anti-lock Brake System (ABS) on front wheel. Continued...
  • Page 14 Image Labels TYRE INFORMATION & CARGO LIMIT LABEL For your protection, always wear helmet, protective apparel. Cold tyre pressure: [Driver only] Front 200 kPa (2.00 kgf/cm , 29 psi) Rear 225 kPa (2.25 kgf/cm , 33 psi) [Driver and passenger] Front 200 kPa (2.00 kgf/cm , 29 psi)

  • Page 15: Safety Precautions

    Safety Precautions Safety Precautions Helmet Safety-standard certified, high-visibility, correct Ride cautiously and keep your hands on the size for your head ● handlebar and feet on the floor. Must fit comfortably but securely, with the ● Instruct your passenger to keep their hands chin strap fastened ●...
  • Page 16 Safety Precautions Gloves Full-finger leather gloves with high abrasion resistance Boots or Riding Shoes Sturdy boots with non-slip soles and ankle protection Jacket and Trousers Protective, highly visible, long-sleeved jacket and durable trousers for riding (or a protective suit)

  • Page 17: Riding Precautions

    Riding Precautions Riding Precautions Brakes Observe the following guidelines: Running-in Period Avoid excessively hard braking. ● Sudden braking can reduce the vehicle's During the first 500 km (300 miles) of running, stability. follow these guidelines to ensure your vehicle's Where possible, reduce speed before future reliability and performance.
  • Page 18 Riding Precautions Anti-lock Brake System (ABS) on Front Wet or Rainy Conditions Wheel Road surfaces are slippery when wet, and wet This model equipped with an Anti-lock Brake brakes further reduce braking efficiency. System (ABS) designed to help prevent the front Exercise extra caution when braking in wet brake from locking up during hard braking.
  • Page 19 To reduce the likelihood of theft, always lock ● Rear grip the handlebar, lock the ignition switch ( P. 51) and leave your vehicle while taking the Honda SMART Key with you. Deactivate the Honda SMART Key system if necessary. P. 46 Centre stand Use of an anti-theft device is also recommended.
  • Page 20 Riding Precautions Turn the handlebar fully to the left. Refuelling and Fuel Guidelines Turning the handlebar to the right Follow these guidelines to protect the engine, reduces stability and may cause the fuel system and catalytic converter: vehicle to fall. Use only unleaded petrol.
  • Page 21 Torque Control does not work during Always use the recommended tyres and the deceleration and will not prevent the rear wheel Honda Genuine Parts for drive system such as from skidding due to engine braking. Do not the drive belt and weight rollers, to ensure close the throttle suddenly, especially when correct Torque Control operation.

  • Page 22: Accessories & Modifications

    We strongly advise that you do not add any seriously hurt or killed. accessories that were not specifically designed for your vehicle by Honda or make Follow all instructions in this owner's modifications to your vehicle from its original manual regarding accessories and design.

  • Page 23: Loading

    Loading Loading WARNING Overloading or improper loading can Carrying extra weight affects your vehicle's ● cause a crash and you can be seriously handling, braking and stability. hurt or killed. Always ride at a safe speed for the load you are carrying.

  • Page 24: Parts Location

    Parts Location Document bag (P.81) Throttle grip (P.108) Front brake fluid reservoir (P.105) Windscreen (P.109) Front lid (P.100) Emergency seat opener (P.127) Front brake lever Tool kit (P.81) Coolant reserve tank (P.103) Centre compartment (P.81) Engine oil fill cap/dipstick (P.101)
  • Page 25 Rear brake lever Rear brake fluid reservoir (P.105) Fuel fill cap (P.75) Seat (P.79) Helmet holder (P.80) Battery cover (P.99) Battery (P.98) Fuse box (P.133) Centre stand (P.15) Side stand (P.107) Front box (P.82) USB socket (P.78)
  • Page 26 Instruments Speedometer Tachometer Tachometer red zone x 1000r/min AVG CONS.ELAPSED AB (excessive engine rpm L/100km km/L range) NOTICE Do not operate the engine in the tachometer red zone. Excessive engine speed can adversely affect engine life. Sel switch Display Check When the ignition switch is turned to the (On) position, initial animation will show.
  • Page 27 Clock Clock setting: (P.35) Battery voltage meter (P.29) Air temperature meter (P.29) x 1000r/min AVG CONS.ELAPSED AB Average fuel mileage L/100km km/L [AVG CONS. A/B] (P.27) Elapsed time [ELAPSED A/B] (P.29) Current fuel mileage Fuel gauge [CONS.] (P.28) (P.28) Odometer [TOTAL] (P.26) Tripmeter [TRIP A/B] Oil change indicator...
  • Page 28 Instruments (Continued) Switching the Display Info area C Select the info area Press the of the sel switch to move the cursor to a desired info area. Info area B Info area C Info area A Info area B Press the of the sel switch Info area A...

  • Page 29: Current Fuel Mileage

    Info area B Select the item Press the sel switch to the to a Average fuel Average fuel mileage A mileage B desired item. Info area A Tripmeter A Odometer Current fuel Elapsed time B HSTC information Tripmeter B mileage Elapsed time A Press sel switch to the...

  • Page 30: Trip Meter

    Instruments (Continued) Info area C Odometer Total distance ridden. Air temperature Battery voltage meter meter When “------” is displayed, go to your dealer for service. Tripmeter AVG CONS.ELAPSED AB AVG CONS.ELAPSED AB Distance ridden since tripmeter A or tripmeter B respectively were reset. Press sel switch to the When “-----.-”...
  • Page 31 HSTC information Average fuel mileage A/B You can switch Honda Selectable Torque Displays the average fuel mileage since the Control on/off while HSTC information is selected tripmeter was reset. selected. The average fuel mileage will be calculated To switch HSTC, press and hold the...

  • Page 32: Fuel Gauge

    Instruments (Continued) Current fuel mileage Fuel gauge Displays the current fuel mileage. Remaining fuel when only 1st (E) segment Display range: starts flashing: approximately 1.32 L (0.349 US 0.0 to 299.9 km/L (L/100 km) gal, 0.290 Imp gal) When the your speed is below 5 km/h (3 ●...
  • Page 33 Air temperature meter Elapsed time A/B Shows ambient temperature. Displays the elapsed time during the engine Display range: -10 to 50°C running since the selected tripmeter was Below -10°C: “---” is displayed reset. ● Above 50°C: 50°C flashes Display range: 00:00 to 199:59 ●...
  • Page 34 Instruments (Continued) To reset the tripmeter A, average fuel To reset the tripmeter B, average fuel mileage A, and elapsed time A mileage B, and elapsed time B Select the info area A. Select the info area A. (P.24) (P.24) Select the tripmeter A.
  • Page 35 If the oil is changed before the oil change Oil change indicator indicator comes on, be sure to reset the oil The indicator is turned on whenever the change indicator after changing the oil. running distance reaches the programmed oil change interval. To reset the oil change indicator When the oil change indicator is appeared, reset the indicator after changing the engine...
  • Page 36 Instruments (Continued) Press and hold the of the To check the remaining distance sel switch while turning the ignition switch to You can check the remaining distance to next the (On) position and keep holding them interval of the oil change and maintenance. until the oil change indicator distance starts When the of the...

  • Page 37: Display Setting

    Display Setting Ordinary display Following items to change sequentially. • Time format setting Time format setting • Clock setting • Backlight brightness adjustment Clock setting • Changing of fuel mileage meter unit Backlight brightness adjustment If the ignition switch is turned to the (Off) position or the button is not pressed for about 30 seconds, the control is...

  • Page 38: Time Format Setting

    Instruments (Continued) 1 Time format setting: Press the of the sel switch to select “12 hr” or “24 hr.” You can switch the time format between 12 hour format or 24 hour format. Turn the ignition switch to (On) position. Press and hold the of the sel switch, and the current time format starts...

  • Page 39: Clock Setting

    2 Clock setting: Press the of the sel switch until the desired minute is displayed. Press the of the sel switch Press and hold the sel switch to the until the desired hour is displayed. to advance the minute fast. Press and hold the sel switch to the to advance the hour fast.
  • Page 40 Instruments (Continued) 3 Backlight brightness adjustment: 4 Changing of fuel mileage meter unit: You can adjust the brightness to one of five Press the of the sel switch to select “km/L” or “L/100km.” levels. Press the of the sel switch. AVG CONS.ELAPSED AB The brightness is switched.
  • Page 42 Honda SMART Key Indicator Comes on when vehicle and Honda SMART Key verification is complete, and the ignition switch can be operated. Goes off when the ignition switch is turned to the (On) position. When the Honda SMART Key indicator flashes:...
  • Page 43 Torque Control indicator • Comes on when the ignition switch is turned to the (On) position. Goes off when your speed reaches approximately 5 km/h (3 mph) to indicate Torque Control is ready to work. • Blinks when Torque Control is operating. If it comes on while riding: (P.118) PGM-FI (Programmed Fuel Injection) malfunction indicator lamp (MIL)
  • Page 44 Indicators (Continued) Battery Charging Condition indicator Right turn signal indicator If it comes on while riding: (P.116) x 1000r/min AVG CONS.ELAPSED AB L/100km km/L...

  • Page 45: Alarm Indicator

    Alarm indicator (P.53) Torque Control OFF indicator Comes on when the Torque Control is turned to off. Idling Stop Indicator Comes on when the idling stop system is on. Idling stop system: (P.65) ABS (Anti-lock Brake System) indicator Comes on when the ignition switch is turned to the (On) position. Goes off when your speed reaches approximately 10 km/h (6 mph).
  • Page 46 Switches Idling stop switch • (Idling Stop) : The Idling Stop system is on. • (Idling) : The Idling Stop system is off. Idling Stop system: (P.65) Turn signal switch Pressing the switch turns Hazard switch the turn signal off. Turn the hazard signal on/off.
  • Page 47 (Lock) Locks steering. (Off) ON/OFF button Turns engine off. This button is used to activate or deactivate the Honda SMART Key SEAT FUEL system, and also to confirm the Operates the fuel lid and activation status. (P.46) seat opener switch.
  • Page 48 Switches (Continued) Steering Lock Locking Turn the handlebar all the way to the left or Lock the steering when parking to help right. prevent theft. Push the ignition switch down, and turn it to A U-shaped wheel lock or similar device is (Lock) position.
  • Page 49 The system runs a two-way authentication between the vehicle and the Honda SMART Key to verify if it is the registered Honda SMART Key. The Honda SMART Key system uses low- intensity radio waves. It may affect medical equipment such as a cardiac pacemaker.
  • Page 50 (Continued) Switching the Honda SMART Key System To switch the Honda SMART Key system to activation or deactivation Press the ON/OFF button until the Honda SMART Key LED changes colour. To check the Honda SMART Key ON/OFF button system status Lightly press the ON/OFF button.
  • Page 51 The Honda SMART Key system uses low- intensity radio waves. Therefore, the operating range may be wider or narrower, or the Honda SMART Key system may not work properly in the following situations: When the Honda SMART Key battery is ●...
  • Page 52 (Continued) Anyone can unlock the ignition switch and When the ignition switch is locked: start the engine if your Honda SMART Key is The system can be operated within the within operating range of your vehicle, even shaded area shown in the illustration.
  • Page 53 ● You should always keep the Honda SMART Key on your person after you get on and off the vehicle or while riding. Do not store the Honda SMART Key in any compartment. Continued...

  • Page 54: Ignition Switch

    When the Honda SMART Key system does not work properly (P.125) To Unlock the Ignition Switch Make sure that the Honda SMART Key is If someone without the Honda SMART Key tries active. (P.46) to turn the ignition switch, the ignition switch To authenticate the Honda SMART Key rotates freely.
  • Page 55 ● on the Honda SMART Key. At the same time, the anti-theft alarm system is set. (P.54) Make sure that the Honda SMART Key indicator and ignition switch ring go off and the turn signals flash once. This indicates Continued...
  • Page 56 (Lock) position when Ignition Switch is Locked/Unlocked you leave your vehicle. Enable Deactivate the Honda SMART Key system. When the ignition switch is locked in the SEAT FUEL position, the ignition switch can (P.46) Lightly press the ON/OFF button. The red be turned (Off) only once.

  • Page 57: Anti-Theft Alarm System

    Anti-theft Alarm System The anti-theft alarm system is a device to reduce the likelihood of theft. When the sensor detects vibration or movement with the ignition switch in the (Off) or (Lock) position and the system is set, the alarm is activated.
  • Page 58 Anti-theft Alarm System (Continued) If the ignition switch is left in the (Off) or Setting the Anti-theft Alarm System (Lock) position for more than 10 days, the Turn the ignition switch to (Off) or anti-theft alarm system will no longer (Lock) position.
  • Page 59 (P.50) Press the answer back/alarm button on ● When the anti-theft alarm system is the Honda SMART Key. cancelled, the alarm indicator goes off and After stopping the anti-theft alarm activation, the anti-theft alarm system the buzzer rings 2 times.
  • Page 60 Push the ignition switch to authenticate the Press the answer back/alarm button on Honda SMART Key system. (P.50) the Honda SMART Key 4 times and the Press and hold the ignition switch for more ignition switch 1 time. than 4 seconds.
  • Page 61 When the answer back/alarm button is not pressed for 10 seconds, the Honda SMART Key indicator and ignition switch ring flash 3 times, and then the buzzer sounds, and the sensitivity level is set.
  • Page 62 Anti-theft Alarm System (Continued) If the Anti-Theft Alarm System Does Not Operate Properly If any of the following situations arise, battery ) in the vehicle is discharged or (P.98) there is a system problem. Remove the battery and see your dealer. The alarm does not ring.
  • Page 63 When the alarm button immobilizer is active and you press the Ignition answer back/alarm button on Honda SMART switch ring Key with the ignition switch is in the (Off) (Lock) position and the anti-theft alarm...

  • Page 64: Operation

    Press the answer back/alarm button on the Honda SMART Key. You can select 3 buzzer sound volume levels. The answer back system will not function Make sure that the Honda SMART Key when the ignition switch is (On) position. system is active. (P.46)
  • Page 65 Repeat the following 3 times: the procedure again. Press the answer back/alarm button on If you press the answer back/alarm the Honda SMART Key 2 times and the button the wrong number of times ignition switch 1 time. before you repeat the procedure 3...
  • Page 66 2 seconds. The sound volume level is Sound Pattern set. You can select 3 buzzer sound patterns. The Honda SMART Key indicator and Make sure that the Honda SMART Key ignition switch ring turn off, and a buzzer system is active. (P.46) sounds once.
  • Page 67 Repeat the following 3 times: the procedure again. Press the answer back/alarm button on If you press the answer back/alarm the Honda SMART Key 3 times and the button the wrong number of times ignition switch 1 time. before you repeat the procedure 3...
  • Page 68 10 seconds, the Honda Press and hold the answer back/alarm button SMART Key indicator and ignition switch for about 2 seconds, the Honda SMART Key ring flash 3 times, and then the buzzer LED changes to red.

  • Page 69: Idling Stop System

    Idling Stop System Idling Stop system is designed to help reduce Activation of the Idling Stop System the fuel consumption and noise, by idling The Idling Stop system becomes ready to stop while making a stop such as waiting at stop the engine and Idling Stop indicator an intersection.
  • Page 70 Idling Stop System (Continued) Stopping the engine by the Idling Stop Safety Precaution for the Idling Stop System System Do not go away from the vehicle while the The engine stops and Idling Stop indicator Idling Stop indicator is flashing. When you go changes to flash after you close the throttle away from the vehicle, always turn the completely and stop the vehicle while the...
  • Page 71 Restarting the Engine NOTICE Check that the Idling Stop indicator is Headlights stay on after the engine is stopped by the Idling Stop system. The battery may flashing, and then open the throttle. discharge and you may not be able to restart If it is not flashing, you can't restart the engine.

  • Page 72: Starting The Engine

    If the Honda SMART Key is within the authentication range and authentication is This vehicle is equipped with a side stand disabled after a certain amount of time, the ignition cut-off system.
  • Page 73 Place the vehicle on its centre stand. Squeeze the rear brake lever. Turn the ignition switch to the (On) The starter motor will only work when position. the rear brake lever is squeezed and the To unlock the ignition switch. side stand is up.
  • Page 74 Starting the Engine (Continued) If you cannot start the engine: If the engine does not start: Place the vehicle on its centre stand and Open the throttle fully and press the start squeeze the rear brake lever. button for 5 seconds. Open the throttle slightly (about 3 mm, Repeat the normal starting procedure.

  • Page 75: Starting The Vehicle

    Riding Starting the Vehicle Acceleration and deceleration To accelerate: Open the throttle slowly. Push the vehicle forward off the centre stand. To decelerate: Close the throttle. Squeeze the rear brake lever. Keep throttle closed. Close (Decelerate) Open (Accelerate) Make sure the side stand and centre stand are up.
  • Page 76 Riding (Continued) Braking Close the throttle and apply the front and rear brake levers together. NOTICE To prevent clutch damage, do not use the throttle to keep the vehicle stopped at up hill. Rear brake lever Front brake lever...

  • Page 77: Emergency Stop Signal

    Emergency Stop Signal Emergency stop signal activates when the The emergency stop signal stops operating system detects hard braking about when: 50 km/h (31 mph) or above to alert drivers You release the brakes. ● behind you about sudden braking by rapidly The ABS is deactivated.
  • Page 78 Emergency Stop Signal (Continued) The emergency stop signal is not a system that can prevent a possible rear-end collision caused by your hard braking. It is always recommended to avoid hard braking unless it is absolutely necessary. The emergency stop signal does not activate with the hazard switch pressed in.

  • Page 79: Ignition Switch

    Refuelling Fuel type: Unleaded petrol only Opening the Fuel Fill Cap Fuel octane number: Your vehicle is Turn the ignition switch to the SEAT FUEL position. designed to use Research Octane Number To unlock the ignition switch (RON) 91 or higher. (P.50) Push the FUEL side of the fuel lid and seat Tank capacity: 8.1 L (2.14 US gal, 1.78 Imp...
  • Page 80 Refuelling (Continued) Turn the fuel fill cap counterclockwise and Put the removed fuel fill cap on the fuel fill remove the fuel fill cap. cap resting place. Fuel fill cap Arrow marks resting place Lower edge of filler neck Fuel fill cap Do not fill with fuel above the lower edge of the filler neck.
  • Page 81 Closing the Fuel Fill Cap Install and tighten the fuel fill cap firmly by turning it clockwise. Make sure that the arrow marks on the fuel fill cap and fuel tank are aligned. Close the fuel lid until it locks. Make sure that the fuel lid is closed securely.

  • Page 82: Usb Socket

    Use USB devices at your own risk. In no event down or cause damage to the USB socket. shall Honda be liable for any damage to your To prevent entry of foreign matter into the USB device when in use.

  • Page 83: Storage Equipment

    Storage Equipment Seat Open Turn the handlebar pointed straight ahead. Fuel lid and seat Seat Turn the ignition switch to the SEAT FUEL opener switch position. Ignition switch To unlock the ignition switch. (P.50) Push the SEAT side of the fuel lid and seat opener switch.
  • Page 84 Storage Equipment (Continued) WARNING Helmet Holder The helmet holders are located under the Riding with a helmet attached to the seat. holder can interfere with your ability to Use the helmet holder only when parked. safely operate the vehicle and could Helmet holders lead to a crash in which you can be seriously hurt or killed.
  • Page 85 Centre Compartment Tool Kit/Document Bag A helmet can be stored in the centre The tool kit and document bag are located compartment. underside of the seat by the rubber strap. Set in the front of the helmet forward. Document bag Some helmets may not fit in the compartment due to their size or design.
  • Page 86 Storage Equipment (Continued) Front Box Open Push the front box lid, then open the front box lid. Push Close Open Close the front box lid by pressing the front box lid. The maximum allowable load in the front box shall be no more than Front box lid 1 kg (2.2 lb) Make sure that the front box lid is closed...

  • Page 87: Maintenance

    Adjusting the Windscreen Height ....P. 109 Maintenance Schedule........P. 85 Other Replacement......... P. 110 Maintenance Fundamentals ......P. 88 Replacing the Honda SMART Key Battery .. P. 110 Tools ..............P. 97 Removing & Installing Body Components.. P. 98 Battery ..............P. 98 Battery Cover............

  • Page 88: Importance Of Maintenance

    Importance of Maintenance Importance of Maintenance Maintenance Safety Keeping your vehicle well-maintained is Always read the maintenance instructions absolutely essential to your safety and to before you begin each task and make sure that protect your investment, obtain maximum you have the tools, parts, and skills required. performance, avoid breakdowns, and reduce air We cannot warn you of every conceivable pollution.

  • Page 89: Maintenance Schedule

    Maintenance work should be performed in new owner. accordance with Honda's standards and specifications by properly trained and equipped Honda recommends that your dealer should technicians. Your dealer meets all of these road test your vehicle after each periodic requirements. Keep an accurate record of maintenance is carried out.
  • Page 90 Inspect (clean, adjust, lubricate, or replace, if necessary) dealer, unless you have the necessary tools and are Replace mechanically skilled. Clean Procedures are provided in an official Honda Shop Manual. : Technical. In the interest of safety, have your vehicle serviced by your dealer.
  • Page 91 Maintenance Schedule Frequency Pre-ride Annual Regular Refer to Items Check × 1,000 km Check Replace page P. 88 × 1,000 mi Drive Belt – Final Drive Oil 2 Years – Battery Brake Fluid 2 Years Brake Pads Wear Brake System Headlight Aim –...

  • Page 92: Maintenance Fundamentals

    Maintenance Fundamentals Check the following items before you get on Pre-ride Inspection your vehicle: To ensure safety, it is your responsibility to Fuel level - Fill fuel tank when necessary ● perform a pre-ride inspection and make sure P. 75 that any problem you find is corrected.
  • Page 93 Maintenance Fundamentals Replacing Parts Battery Always use Honda Genuine Parts or their Your vehicle has a maintenance-free type equivalents to ensure reliability and safety. battery. You do not have to check the battery electrolyte level or add distilled water. Clean the...
  • Page 94 Maintenance Fundamentals What to do in an emergency WARNING If any of the following occur, immediately see The battery gives off explosive your doctor. hydrogen gas during normal operation. Electrolyte splashes into your eyes: ● Wash your eyes repeatedly with cool water for at least 15 minutes.
  • Page 95 Always replace the battery with another maintenance-free battery of the same type. NOTICE Installing non-Honda electrical accessories can NOTICE overload the electrical system, discharging the Replacing a fuse with one that has a higher battery and possibly damaging the system.
  • Page 96 “Resource Conserving” on the circular API For recommended engine oil, see service symbol. “Specifications.” P. 149 If you use non-Honda engine oil, check the label to make sure that the oil satisfies all of the following standards: JASO T 903 standard : MB ●...

  • Page 97: Recommended Brake Fluid

    Using coolant not specified for aluminium engines or tap/mineral water can cause corrosion. Recommended brake fluid: Crankcase Breathers Honda DOT 3 or DOT 4 Brake Fluid or equivalent Service more frequently when riding in rain, at full throttle, or after the vehicle is washed or overturned.
  • Page 98 Maintenance Fundamentals Inspecting for Abnormal Wear Tyres (Inspecting/Replacing) Checking the Air Pressure Inspect the tyres for Visually inspect your tyres and use an air signs of abnormal wear pressure gauge to measure the air pressure at on the contact surface. least once a month or any time you think the tyres look low.
  • Page 99 Maintenance Fundamentals Inspecting Tread Depth WARNING Inspect the tread wear indicators. If they Riding on tyres that are excessively become visible, replace the tyres immediately. worn or improperly inflated can cause a For safe riding, you should replace the tyres crash in which you can be seriously hurt when the minimum tread depth is reached.
  • Page 100 Maintenance Fundamentals Have your tyres replaced by your dealer. WARNING For recommended tyres, air pressure, and Installing improper tyres on your minimum tread depth, see “Specifications.” vehicle can adversely affect handling P. 149 and stability, and can cause a crash in Follow these guidelines whenever you replace tyres: which you can be seriously hurt or...

  • Page 101: Tools

    Tools The tool kit is stored underside of the seat. P. 81 You can perform some roadside repairs, minor adjustments and parts replacement with the provided tools. Spark plug wrench ● 10 × 14 mm Open end wrench ● Standard/Phillips screwdriver ●...

  • Page 102: Removing & Installing Body Components

    Removing & Installing Body Components Battery Removal Make sure the ignition switch is in the (Off) position. Positive terminal Negative terminal Remove the battery cover. P. 99 Remove the rubber strap from the hook. Disconnect the negative - terminal from the battery.

  • Page 103: Installation

    Removing & Installing Body Components Battery Cover Battery Cover Installation Install the parts in the reverse order of removal. Always connect the positive + Tabs terminal first. Make sure bolts and nuts are tight. Make sure the clock information is correct after the battery is reconnected.

  • Page 104: Front Lid

    Removing & Installing Body Components Front Lid Front Lid Removal Pull out the front lid backward while pushing the side of the front lid. Installation Install the part in the reverse order of removal. Make sure that all tabs are installed securely in position.

  • Page 105: Checking The Engine Oil

    Engine Oil Checking the Engine Oil Upper level Check the engine oil with the Idling Stop switch at (Idling). If the engine is cold, idle the engine for 3 to 5 minutes. Turn the ignition switch to the (Off) position and wait for 2 to 3 minutes. Place your vehicle on its centre stand on a Lower level firm, level surface.

  • Page 106: Adding Engine Oil

    Engine Oil Adding Engine Oil Adding Engine Oil For the recommended oil and oil selection guidelines, see “Maintenance Fundamentals.” P. 92 If the engine oil is below or near the lower level mark, add the recommended engine oil. P. 92, P.

  • Page 107: Checking The Coolant

    Coolant Checking the Coolant If the coolant level is dropping noticeably or the reserve tank is empty, you likely have a serious leak. Have your vehicle inspected by Check the coolant level in the reserve tank your dealer. while the engine is cold. Place your vehicle on its centre stand on a firm, level surface.

  • Page 108: Adding Coolant

    Coolant Adding Coolant Adding Coolant Pull the floor mat off. Remove the reserve tank lid by inserting a flat head screwdriver covered with a If the coolant level is below the LOWER level protective cloth into the slit on the right mark, add the recommended coolant side floor.

  • Page 109: Brakes

    Brakes Checking Brake Fluid Front Front brake fluid reservoir Place your vehicle in an upright position on a firm, level surface. Check that the brake fluid reservoir is horizontal and that the fluid level is above the LWR level mark. If the brake fluid level in either reservoir is below the LWR level mark or both the brake LWR mark...

  • Page 110: Inspecting The Brake Pads

    Brakes Inspecting the Brake Pads Inspecting the Brake Pads Inspect the brake pads from in front Front of the brake caliper. Inspect the brake pads from the rear Check the condition of the brake pad wear Rear right of the vehicle. indicators.

  • Page 111: Checking The Side Stand

    Side Stand Checking the Side Stand Place your vehicle on its centre stand on a firm, level surface. Check that the side stand operates smoothly. If the side stand is stiff or squeaky, clean the pivot area and lubricate the pivot bolt with clean grease. Check the spring for damage or loss of tension.

  • Page 112: Throttle

    Throttle Checking the Throttle With the engine off, check that the throttle rotates smoothly from fully closed to fully open in all steering positions and throttle freeplay is correct. If the throttle does not move smoothly or close automatically, or if the cable is damaged, have the vehicle inspected by your dealer.

  • Page 113: Other Adjustments

    Other Adjustments Adjusting the Windscreen Height Down The windscreen can be adjusted to 2 positions. Windscreen adjusting knob Do not adjust the windscreen while riding. Pull the windscreen adjusting knobs and move the windscreen up or down. Make sure the windscreen is locked Windscreen securely by slighly moving the windscreen up or down.

  • Page 114: Other Replacement

    Key Battery with a protective cloth into the slit. Wrap a coin or a screwdriver with a If the Honda SMART Key indicator flashes 5 protective cloth to prevent scratching times when the ignition switch is turned the Honda SMART Key.
  • Page 115 Other Replacement Replacing the Honda SMART Key Battery WARNING Upper case CHEMICAL BURN HAZARD Battery The battery that powers the Honda SMART Key can cause severe internal Protective burns and can even lead to death if cloth swallowed. Keep new and used batteries away from children.
  • Page 116 Other Replacement Replacing the Honda SMART Key Battery CAUTION • Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type. • Do not exposed to excessive heat such as sunshine, fire or the like, that can result in...

  • Page 117: Troubleshooting

    Warning Indicators On or Flashing..... P. 116 Opened ............. P. 124 PGM-FI (Programmed Fuel Injection) When the Honda SMART Key System Does Not Malfunction Indicator Lamp (MIL)....P. 116 Operate Properly........... P. 125 Battery Charging Condition indicator ..P. 116 Unlock the Seat in an Emergency ....

  • Page 118: Engine Will Not Start

    P. 89). your dealer as soon as possible. Check the condition of the battery. ● P. 132 Check the Honda SMART Key indicator. ● If it is flashing, start the engine by the normal procedure after pressing the ignition switch again.

  • Page 119: Overheating (High Coolant Temperature Indicator Is On)

    Overheating (High coolant temperature indicator is on) The engine is overheating when the following If the fan is not operating: occurs: Suspect a fault. Do not start the engine. High coolant temperature indicator Transport your vehicle to your dealer. ● comes on.

  • Page 120: Warning Indicators On Or Flashing

    Warning Indicators On or Flashing PGM-FI (Programmed Fuel Battery Charging Condition Injection) Malfunction indicator Indicator Lamp (MIL) If the indicator comes on while riding, you may have a condition of low battery voltage If the indicator comes on while riding, you or battery performance degradation.

  • Page 121: Abs (Anti-Lock Brake System) Indicator

    Warning Indicators On or Flashing ABS (Anti-lock Brake System) Indicator ABS (Anti-lock Brake System) If the ABS indicator stays on, your brakes will continue to work as a conventional system, Indicator but without the anti-locking function. If the indicator operates in one of the The ABS indicator may flash if you turn the following ways, you may have a serious rear wheel while the rear wheel is lifted off...

  • Page 122: Torque Control Indicator

    Warning Indicators On or Flashing Torque Control Indicator Torque Control Indicator Even when the Torque Control indicator is on, your vehicle will have normal riding ability without Torque Control function. If the indicator operates in one of the When the indicator comes on while the following ways, you may have a serious Torque Control is in operation, you will problem with the Torque Control.

  • Page 123: Honda Smart Key Indicator

    Replacing the Honda SMART Key when communication between your vehicle Battery P. 110 and Honda SMART Key stops after turning If the Honda SMART Key indicator is the ignition switch to the (On) position. flashing rapidly while the ignition It is probably caused by the following:...
  • Page 124 2 seconds. After the flashing and ringing stop, the ignition switch is locked. If you do not have the Honda SMART Key, the ignition switch can be unlocked in another way. P. 128...

  • Page 125: Other Warning Indications

    Other Warning Indications Fuel Gauge Failure Indication If the fuel system has an error, the fuel gauge indicators will be displayed as shown in the illustrations. If this occurs, see your dealer as soon as possible.

  • Page 126: When The Idling Stop System Does Not Operate Properly

    When the Idling Stop System Does Not Operate Properly Idling Stop Indicator Does Not If PGM-FI malfunction indicator lamp (MIL) lights: Come On When the PGM-FI malfunction indicator lamp (MIL) lights, the Idling Stop system does not When the Idling Stop indicator does not operate for protection of the engine.

  • Page 127: Engine Is Not Stopped By The Idling Stop System While The Idling Stop Indicator Is On

    When the Idling Stop System Does Not Operate Properly Engine is Not Stopped by the Idling Stop System While the Idling Stop Indicator is On Engine is Not Stopped by the Idling Stop System While the Idling Stop Indicator is On When the engine is not stopped by the Idling Stop system while the Idling Stop indicator is on, perform the followings.

  • Page 128: Engine Does Not Start Even If The Throttle Is Opened

    When the Idling Stop System Does Not Operate Properly Engine Does Not Start Even If the Throttle is Opened Engine Does Not Start Even If If the Idling Stop switch is at (Idling): While the engine is stopping by the Idling the Throttle is Opened Stop system, if you press the Idling Stop switch to...

  • Page 129: When The Honda Smart Key System Does Not Operate Properly

    When the Honda SMART Key System Does Not Operate Properly When the Honda SMART Key system does Check that there is no communication ● not work properly, perform the following. failure in the Honda SMART Key system. Check that the Honda SMART Key system The Honda SMART Key system uses low- ●...
  • Page 130 When the Honda SMART Key System Does Not Operate Properly Check that a registered Honda SMART Check the battery condition and battery ● ● Key is used. lead in your vehicle. Use a registered Honda SMART Key. Check the battery and battery terminals. If The Honda SMART Key system cannot be the battery is weak, contact your dealer.

  • Page 131: Unlock The Seat In An Emergency

    Unlock the Seat in an Emergency The seat lock can be unlocked by using the Emergency seat opener emergency key. Open Remove the front lid. P. 100 Align the projection of the emergency key with the slot of the emergency seat opener, and turn the emergency key Projection counterclockwise.

  • Page 132: Unlock The Ignition Switch In An Emergency

    4 seconds. (Off), (Lock) and SEAT FUEL position. The ignition switch ring and the Honda Input the ID number on the ID tag in order SMART Key indicator flash. from the left in turn by pressing the ignition Press the ignition switch while the ignition switch.
  • Page 133 After the last ID number is input, the ignition ● pushing the ignition switch when the switch ring and the Honda SMART Key ignition switch ring comes on. indicator go off, and when they come on To input “1”, push the ignition switch once again the ignition switch is unlocked.
  • Page 134 Emergency” procedure. P. 128 • Do not press the ignition switch, just wait for the ignition switch ring and the Honda SMART Key indicator to turn off. Redo the “Unlock the Ignition Switch in an Emergency” procedure. P. 128...

  • Page 135: Tyre Puncture

    Tyre Puncture Repairing a puncture or removing a wheel WARNING requires special tools and technical expertise. Riding your vehicle with a temporary We recommend you have this type of service tyre repair can be risky. If the temporary performed by your dealer. repair fails, you can crash and be After an emergency repair, always have the seriously injured or killed.

  • Page 136: Electrical Trouble

    Electrical Trouble Battery Goes Dead Burned-out Light Bulb Charge the battery using a motorcycle All light bulbs on the vehicle are LEDs. If battery charger. there is an LED which is not turned on, see Remove the battery from the vehicle before your dealer for servicing.

  • Page 137: Blown Fuse

    Electrical Trouble Blown Fuse Blown Fuse Remove the battery cover. P. 99 Open the fuse box cover. Pull the main fuse and other fuses out Before handling fuses, see “Inspecting and one by one with the fuse puller located Replacing Fuses.” P.

  • Page 138: Unstable Engine Operation Occurs Intermittently

    Unstable Engine Operation Occurs Intermittently If the fuel pump filter is clogged, unstable engine operation will occur intermittently while riding. Even if this symptom occurs, you can continue to ride your vehicle. If unstable engine operation occurs even if sufficient fuel is available, have your vehicle inspected by your dealer as soon as possible.

  • Page 139: Information

    Information Keys..............P. 136 Instruments, Controls, & Other Features... P. 139 Caring for Your Vehicle........P. 140 Storing Your Vehicle........P. 143 Transporting Your Vehicle ......P. 144 You & the Environment ......... P. 144 Serial Numbers ..........P. 145 Fuels Containing Alcohol ......

  • Page 140: Keys

    Keys Keys Emergency Key The emergency key is used for an emergency. To unlock the seat. P. 127 ● Do not store the emergency key in any compartment. Emergency key...
  • Page 141 ● Protect the Honda SMART Key from direct ● sunlight, high temperature, and high The ID number of the Honda SMART Key is on humidity. the ID tag. You can also unlock the ignition Do not scratch or puncture. ●...
  • Page 142 Keys If fuel, wax, or grease adhere to the Honda To get an additional Honda SMART Key, take ● SMART Key, wipe it off immediately to avoid the Honda SMART Key and the vehicle to your cracking or warping. dealer.

  • Page 143: Instruments, Controls, & Other Features

    Instruments, Controls, & Other Features Instruments, Controls, & Tripmeter Other Features Each tripmeter resets to 0.0 when the trip mileage exceeds 9,999.9. Ignition Switch Average fuel mileage A/B and elapsed time A/B are reset at the same time. Leaving the ignition switch in the (On) position with the engine stopped will drain the battery.

  • Page 144: Caring For Your Vehicle

    Frequent cleaning and polishing is important to After the vehicle dries, lubricate any moving ensure the life of your Honda. A clean vehicle parts. makes it easier to spot potential problems.
  • Page 145 Caring for Your Vehicle Do not direct water at the air cleaner: Washing Precautions ● Water in the air cleaner can prevent the Follow these guidelines when washing: engine from starting. Do not use high-pressure washers: ● Do not direct water near the headlight: High-pressure water cleaners can ●...

  • Page 146: Aluminium Components

    Caring for Your Vehicle Aluminium Components Windscreen Using plenty of water, clean the windscreen with Aluminium will corrode from contact with dirt, a soft cloth or sponge. (Avoid using detergents mud, or road salt. Clean aluminium parts or any kind of chemical cleaner on the regularly and follow these guidelines to avoid windscreen.) Dry with a soft, clean cloth.

  • Page 147: Storing Your Vehicle

    Storing Your Vehicle Storing Your Vehicle Exhaust Pipe and Muffler If the exhaust pipe and muffler are painted, do If you store your vehicle outdoors, you should not use a commercially available abrasive consider using a full-body cover. kitchen cleaning compound. Use a neutral If you won't be riding for an extended period, detergent to clean the painted surface on the follow these guidelines:...

  • Page 148: Transporting Your Vehicle

    Transporting Your Vehicle Transporting Your Vehicle You & the Environment If your vehicle needs to be transported, it Owning and riding a vehicle can be enjoyable, but should be carried on a motorcycle trailer or a you must do your part to protect the environment. flatbed truck or trailer that has a loading ramp or lifting platform and motorcycle tie-down Choose Sensible Cleaners...

  • Page 149: Serial Numbers

    Serial Numbers Serial Numbers Frame number The frame and engine serial numbers uniquely identify your vehicle and are required in order to register your vehicle. They may also be required when ordering replacement parts. To check the frame number, open the seat. P.

  • Page 150: Fuels Containing Alcohol

    Fuels Containing Alcohol Fuels Containing Alcohol The use of petrol containing more than 10% ethanol may: Some conventional fuels blended with alcohol Damage the painting of the fuel tank. ● are available in some locales to help reduce Damage the rubber tubes of the fuel line. ●...

  • Page 151: Catalytic Converter

    A defective catalytic converter contributes to air pollution and can impair your engine's performance. A replacement unit must be an original Honda part or equivalent.

  • Page 152: Specifications

    Specifications Main Components ■ Displacement 156.93 cm (9.573 cu-in) Overall length 1,950 mm (76.8 in) 60.000 x 55.502 mm (2.3622 x 2.1851 Bore x stroke Overall width 763 mm (30.0 in) Compression ratio 12.0:1 Windscreen position Unleaded petrol Overall height High 1,270 mm (50.0 in) Fuel...
  • Page 153 0.13 L (0.14 US qt, 0.11 Imp qt) disassembly Tyre air Front 200 kPa (2.00 kgf/cm , 29 psi) Recommended pressure Honda DOT 3 or DOT 4 Brake Fluid brake fluid (Driver and Rear 225 kPa (2.25 kgf/cm , 33 psi) Cooling passenger) system 0.50 L (0.53 US qt, 0.44 Imp qt)
  • Page 154 Specifications Bulbs ■ Headlight Brakelight/Taillight Front turn signal Rear turn signal License plate light Position light Fuses ■ Main fuse 30 A Other fuse 15 A, 10 A, 5 A...
  • Page 155 Boon Siew Honda Sdn. Bhd. 32K0WF100 00X32-K0W-F100 (200401038385 / 676896-A)

This manual is also suitable for:

Adv160 2022

Table of Contents
