Page 1 ADV750L...
Page 2 This publication includes the latest production information available before printing. Honda Motor Co., Ltd. reserves the right to make changes at any time without notice and without incurring any obligation.
Page 3 Congratulations on your purchase of a new The following codes in this manual ● Honda vehicle. Your selection of a Honda indicate each country. makes you part of a worldwide family of The illustrations here in are based on the ●...
Page 4 A Few Words About Safety Your safety, and the safety of others, is very DANGER important. Operating this vehicle safely is an You WILL be KILLED or SERIOUSLY important responsibility. HURT if you don’t follow instructions. To help you make informed decisions about safety, we have provided operating WARNING procedures and other information on safety...
Page 5: Table Of Contents
Contents Vehicle Safety P. 2 Operation Guide P. 20 Maintenance P. 121 Troubleshooting P. 167 Information P. 194 Specifications P. 216...
Page 6: Vehicle Safety
Vehicle Safety This section contains important information for safe riding of your vehicle. Please read this section carefully. Safety Guidelines ..........P. 3 Image Labels............P. 6 Safety Precautions..........P. 11 Riding Precautions ..........P. 12 Accessories & Modifications......P. 17 Loading ..............
Page 7: Safety Guidelines
Safety Guidelines Safety Guidelines Instruct your passenger on holding onto the grab rails or your waist, leaning with you in Follow these guidelines to enhance your safety: turns, and keeping their feet on the footpegs, Perform all routine and regular inspections even when the vehicle is stopped.
Page 8 Safety Guidelines Make Yourself Easy to See Keep Your Honda in Safe Condition Make yourself more visible, especially at night, It's important to keep your vehicle properly by wearing bright reflective clothing, positioning maintained and in safe riding condition. yourself so other drivers can see you, signaling...
Page 9 Safety Guidelines If you decide to continue riding, first turn the WARNING electrical system off, and evaluate the condition Running the engine of your vehicle of your vehicle. Inspect for fluid leaks, check the while in an enclosed or even partially tightness of critical nuts and bolts, and check enclosed area can cause a rapid build- the handlebar, control levers, brakes, and...
Page 10: Image Labels
Image Labels Image Labels FO, GS type The following pages describe the label Read instructions contained in Owner's meanings. Some labels warn you of Manual carefully. potential hazards that could cause serious injury. Others provide important safety Read instructions contained in Shop Manual information.
Page 11 Image Labels BATTERY LABEL DANGER • Keep flame and spark away from the battery. Battery produce explosive gas that can cause explosion. • Wear the eye protection and rubber gloves when handling the battery, or you can get burned or lose your eyesight by the battery electrolyte.
Page 12 Image Labels RADIATOR CAP LABEL DANGER NEVER OPEN WHEN HOT. Hot coolant will scald you. Relief pressure valve begins to open at 1.1 kgf/cm ACCESSORY STEP LABEL (When equipped with rider steps) WARNING Accessory rider steps are which assist a rider, that are not the equipment that allow to ride for the three persons.
Page 13 Image Labels REAR CUSHION LABEL GAS FILLED Do not open. Do not heat. TYRE INFORMATION & DRIVE CHAIN LABEL Cold tyre pressure: [Driver only] Front 250 kPa (2.50 kgf/cm , 36 psi) Rear 280 kPa (2.80 kgf/cm , 41 psi) [Driver and passenger] Front 250 kPa (2.50 kgf/cm...
Page 14 Image Labels SAFETY REMINDER LABEL For your protection, always wear helmet, protective apparel. FUEL LABEL Unleaded petrol only ETHANOL up to 10 % by volume CARGO LIMIT LABEL Do not exceed 5.0 kg (11.0 lb). CARGO LIMIT LABEL Do not exceed 0.5 kg (1.0 lb).
Page 15: Safety Precautions
Safety Precautions Safety Precautions Face shield with unobstructed field of vision ● or other approved eye protection Ride cautiously and keep your hands on the ● WARNING handlebar and feet on the step board. Not wearing a helmet increases the Keep passenger's hands onto the grab rails ●...
Page 16: Riding Precautions
Riding Precautions Riding Precautions Brakes Observe the following guidelines: Running-in Period Avoid excessively hard braking and ● downshifting. During the first 500 km (300 miles) of running, Sudden braking can reduce the vehicle's follow these guidelines to ensure your vehicle's stability.
Page 17 Riding Precautions Anti-lock Brake System (ABS) Engine Braking This model is equipped with an Anti-lock Brake Engine braking helps slow your vehicle down System (ABS) designed to help prevent the when you release the throttle. For further brakes from locking up during hard braking. slowing action, downshift to a lower gear.
Page 18 ( P. 79) and leave your Press down on the tip of the centre stand vehicle while taking the Honda SMART Key with your right foot and, simultaneously, pull with you. Deactivate the Honda SMART Key up and back.
Page 19 Refuelling and Fuel Guidelines Then, leave your vehicle while taking the Follow these guidelines to protect the engine, Honda SMART Key with you. Deactivate the fuel system and catalytic converter: Honda SMART Key system if necessary. Use only unleaded petrol.
Page 20 Torque Control may not compensate for rough Honda selectable torque control road conditions or rapid throttle operation. When the Honda selectable torque control Always consider road and weather conditions, (Torque Control) detects rear wheel spin during as well as your skills and condition, when acceleration, the system will limit the amount of applying throttle.
Page 21: Accessories & Modifications
We strongly advise that you do not add any these attachments, and their use can seriously accessories that were not specifically designed impair your vehicle's handling. for your vehicle by Honda or make modifications to your vehicle from its original When equipped with Honda genuine accessory rider steps design.
Page 22: Loading
Loading Loading WARNING Overloading or improper loading can Carrying extra weight affects your vehicle's ● cause a crash and you can be seriously handling, braking and stability. hurt or killed. Always ride at a safe speed for the load you are carrying.
Page 24: Parts Location
Parts Location USB socket Document bag (P.118) (P.115) Luggage box (P.116) Seat Tool kit (P.116) (P.118) Throttle grip (P.158) Parking brake (P.93) Front brake fluid reservoir (P.152) Front suspension spring preload adjuster (P.160) Front suspension rebound damping adjuster (P.161) Fairing pocket (P.120) Front lower cover (P.143)
Page 25 Wind screen (P.163) Front suspension spring preload adjuster (P.160) Rear brake lever (P.159) Rear brake fluid reservoir (P.152) Fuel fill cap (P.113) Battery (P.141) Main fuses (P.192) Left side cover (P.145) Fuse box A/B (P.190) Drive chain (P.156) Rear suspension spring preload adjuster (P.162) Side stand...
Page 26 Instruments FO type You can change the speed and mileage, and fuel mileage meter units. (P.45) (P.60) Do not operate the display functions for a long time with the engine stopped. It may result in a low (or dead) battery.
Page 27 Speedometer/Tachometer/Fuel gauge/Side stand indicator area (P.25) Status bar Indicator area (P.27) (P.29) RIDING MODE (P.94) RIDING MODE PARAMETER (P.94) Honda Smartphone Voice Control system area (P.90) INFO area Gear position indicator (P.30) (P.28) Pop-up information (P.69) Multi function display (P.112)
Page 28: Sel Switch
Instruments (Continued) Basic Operations You can operate and set the various functions of the display using the switches on the left handlebar. Function switch Sel switch When switching or setting the display, refer to the switch operation guide is displayed. Type of the switch operation guide: : Press on the sel switch...
Page 29 Speedometer/Tachometer/Fuel gauge/Side stand indicator area Display type: LOOP Side stand indicator Tachometer red zone Comes on when the side stand is down. (excessive engine rpm range) Speedometer Fuel gauge Remaining fuel when only 1st (E) segment starts flashing: approximately 2.5 L (0.66 US gal, 0.55 Imp gal) At the same time, the low fuel indicator is comes on.
Page 30 Instruments (Continued) Speedometer/Tachometer/Fuel gauge/Side stand indicator area has four display types. The display and arrangement of speedometer, tachometer, fuel gauge and side stand indicator change depending on each display type. To change the display type: (P.45) (P.54) Display type: DESIGN Display type: ANALOG Display type: DIGITAL Tachometer...
Page 31 Status bar Status icon Displays the status of the Honda Smartphone Voice Control system. (P.90) Clock (12-hour or 24-hour display) To set the clock: (P.45) (P.59) Air temperature gauge Displays the ambient temperature. Display range: -12 ºC to 49 ºC Below -12ºC: “---”...
Page 32 Instruments (Continued) Gear position indicator The gear position is shown in the gear position indicator. The indicator may flash if: The front wheel leaves the ground. You turn the wheel while the vehicle is upright on the stand. This is normal. To operate the system again, turn the electrical system off and on again. If the “-”...
Page 33: Indicator Area
Indicator area High beam indicator High coolant temperature indicator If it comes on while riding: (P.169) Low oil pressure indicator Comes on when the electrical system is turned on. Goes off when the engine starts. If it comes on while engine is running: (P.170) DRL indicator (P.111)
Page 34 Instruments (Continued) INFO area To switch page of the INFO area The INFO area displays various vehicle To change page of the INFO area, push the information. sel switch in the direction of INFO page 1 The INFO area has four pages and displays four pieces of information on each page.
Page 35 The types of information item that can be VOLTAGE (P.38) displayed in the INFO area are as follows: DATE (P.38) TOTAL (P.32) User letter (P.38) TRIP A (P.32) Logo (P.38) TRIP A CONS. (P.33) SHIFT POINT (P.39) TRIP A AVG. CONS. (P.33) FUEL CONS.
Page 36 Instruments (Continued) Odometer [TOTAL] Tripmeter A [TRIP A] Total distance ridden. Distance ridden since the tripmeter A was reset. When “------” is displayed, go to your dealer for service. When “----.-” is displayed, go to your dealer for service. To reset the tripmeter A: (P.44)
Page 37 Tripmeter A fuel consumption [TRIP A Tripmeter A average fuel mileage CONS.] [TRIP A AVG. CONS.] Displays the tripmeter A fuel consumption Displays the average fuel mileage since the since the tripmeter A was reset. tripmeter A was reset. Display range: 0.0 to 299.9 L (GAL) The average fuel mileage will be calculated based on the value on tripmeter A.
Page 38 Instruments (Continued) Tripmeter B [TRIP B] Tripmeter B fuel consumption [TRIP B CONS.] Distance ridden since the tripmeter B was reset. Displays the tripmeter B fuel consumption since the tripmeter B was reset. Display range: 0.0 to 299.9 L (GAL) When “----.-”...
Page 39 Tripmeter B average fuel mileage Current fuel mileage [INST. CONS.] [TRIP B AVG. CONS.] Displays the current instant fuel mileage. Displays the average fuel mileage since the Display range: 0.0 to 299.9 km/L (L/100km, tripmeter B was reset. mile/GAL or mile/L) The average fuel mileage will be calculated When your speed is less than 7 km/h (5 ●...
Page 40 Instruments (Continued) Average fuel mileage [AVG. CONS.] Average speed [AVG. SPEED] Displays the average fuel mileage since the Displays the average speed since the average average fuel mileage was reset. speed was reset. Display range: 0.0 to 299.9 km/L (L/100km, Display range: 0 to 299 km/h (0 to 186 mph) mile/GAL or mile/L) Initial display: “---”...
Page 41 Elapsed time [ELAPSED] Numerical tachometer display [REV] Displays the engine operating time since the Displays the engine revolutions per minutes. elapsed time was reset. Display range: 0 to 99,990 r/min Display range: 00:00 to 99:59 (hours:minutes) Above 99:59: back to 00:00 ●...
Page 42 Instruments (Continued) Battery voltage [VOLTAGE] User letter Displays the current voltage. Displays the characters of user's choice. To set the USER LETTER: (P.45) (P.58) Date [DATE] Displays the date of today. Logo Displays the X-ADV logo. To set the date: (P.45) (P.59)
Page 43 SHIFT POINT set value [SHIFT POINT] Fuel consumption in this time [FUEL CONS. Displays the SHIFT POINT set value. Display range: 4,000 - 7,000 r/min Displays the fuel consumption since the electrical system was turned on. Display range: 0.0 to 50.0 L (GAL) Initial display: “--.-”...
Page 44 Instruments (Continued) Average fuel mileage in this time Average speed in this time [AVG. [AVG. CONS. SPEED Displays the average fuel mileage since the Displays the average speed since the electrical system was turned on. electrical system was turned on. Display range: 0.0 to 299.9 km/L (L/100km, Display range: 0 to 299 km/h (0 to 186 mph) mile/GAL or mile/L).
Page 45 Elapsed time in this time [ELAPSED Displays the engine operating time since the electrical system was turned on. Display range: 00:00 to 99:59 (hours:minutes) Above 99:59: back to 00:00. ● Initial display: “--:--” is displayed. ● When the electrical system is turned off, the elapsed time is reset.
Page 46 Instruments (Continued) Coolant temperature meter [WATER Reserve tripmeter [RES TRIP] TEMP.] Distance ridden since the low fuel indicator Displays the coolant temperature. lights. Display range: 35 ºC to 132 ºC Display range: 0.0 to 9999.9 km (mile) 34 ºC or less: “---” is displayed. Above 9999.9: back to 0.0.
Page 47 Reserve fuel consumption [RES FUEL Blank display CONS.] Display the blank. Displays the fuel consumption since the low fuel indicator lights. Display range: 0.0 to 299.9 L (GAL) When the low fuel indicator is off: "---.-" is ● displayed. When “---.-” is displayed except for the above-mentioned cases, go to your dealer for service.
Page 48 Instruments (Continued) Also, the tripmeter A, tripmeter A fuel To Reset the Information consumption and tripmeter A average fuel Select the page in the INFO area that mileage are automatically reset when only containing the item you want to reset with the reserve fuel remains in the fuel tank (the of the sel switch.
Page 49: Setting Mode
Setting mode To shift to the setting mode Push and hold the sel switch in the direction of To select the desired setting menu, operate the sel switch on the left handlebar. When switching to setting mode, the clock, indicators and speed are displayed at the top of the screen.
Page 50: Setting Flow
Instruments (Continued) Setting flow Ordinary display Setting mode RIDING MODE (P.50) SHIFT POINT (P.51) SELF-CANCELLING TURN FUNCTION (P.52) SIGNALS TRIP A AUTO RESET (P.52) ECON MODE (P.53) DISPLAY Push/Press Push and hold/Press and hold...
Page 51 FUNCTION DISPLAY TYPE (P.54) BRIGHTNESS (P.55) DISPLAY BACKGROUND (P.56) FAVORITE INFORMATION (P.57) USER LETTER (P.58) GENERAL Push/Press Push and hold/Press and hold Continued...
Page 52 Instruments (Continued) DISPLAY DATE & TIME (P.59) UNIT (P.60) GENERAL LANGUAGE (P.61) RESTORE DEFAULT (P.62) BLUETOOTH PAIRING RESET (P.63) SERVICE Push/Press Push and hold/Press and hold...
Page 53 GENERAL MAINTENANCE (P.64) EQUIPMENT SERVICE (P.67) (P.67) REGULATORY (P.68) Push/Press Push and hold/Press and hold Continued...
Page 54: Operation Guide
Instruments (Continued) RIDING MODE (P.94) To return to the initialize settings: You can change the setting value of the Push and hold the sel switch in the direction USER MODE. Reset the setting according to the switch Select the parameter ("P", "EB" "D", "T" or operation guide.
Page 55 Select the "ON/OFF" or "SHIFT POINT" using SHIFT POINT of the sel switch. ON/OFF : You can activate or deactivate Select the desired setting according to the the shift up mode. switch operation guide. (P.24) SHIFT POINT : You can change the engine Return to the ordinary display to complete revolutions at which the the setting.
Page 56 Instruments (Continued) SELF-CANCELLING TURN SIGNALS TRIP A AUTO RESET You can enable or disable turn signal You can enable or disable the tripmeter A automatic cancellation. automatic reset mode. (P.76) (P.44) Select the "ON" or "OFF" using Select the "ON" or "OFF" using the sel switch.
Page 57 ECON MODE You can enable or disable the ECON mode. (P.71) Select the "ON" or "OFF" using the sel switch. Return to the ordinary display to complete the setting. (P.45) To continue setting, push the sel switch in the direction of to return to the upper hierarchy.
Page 58 Instruments (Continued) DISPLAY TYPE You can change the display type of speedometer / tachometer / fuel gauge / side stand indicator area. (P.25) Select the display type ("LOOP", "DESIGN" "ANALOG" or "DIGITAL") using the sel switch. Return to the ordinary display to complete the setting.
Page 59: Automatic Brightness Control
BRIGHTNESS You can adjust the backlight brightness to one of the eight levels or select the auto adjustment. Automatic brightness control: (P.201) The display can become dark when the display is very hot. If it does not restore the original brightness, contact your dealer. Select the backlight brightness using of the sel switch.
Page 60 Instruments (Continued) BACKGROUND You can change the setting of the background to one of the three colours or select the auto adjustment. Automatic Background Control: (P.201) Select the background colour using of the sel switch. Return to the ordinary display to complete the setting.
Page 61 FAVORITE INFORMATION You can change the information items displayed in the INFO area. (P.30) Select the page of the INFO area ("INFO1", "INFO2", "INFO3" or "INFO4" using of the sel switch. Select the desired setting according to the switch operation guide. (P.24) If you select the item that is already selected in another area, the previously...
Page 62 Instruments (Continued) USER LETTER You can edit the USER LETTER with up to 10 characters. Edit the USER LETTER. To select the character using the sel switch. To set the character using the function switch. Select the "OK", and then press the function switch.
Page 63 DATE & TIME Select the "24h or 12h", "YEAR", "MONTH - DAY", "HOUR - MINUTE" or "am / pm" using of the sel switch. Select the desired setting according to the switch operation guide. (P.24) When "24 / 12" is set to 24-hour indication, "am / pm"...
Page 64 Instruments (Continued) UNIT Except FO type "UNIT" is displayed but not selectable. FO type You can change the speed and mileage, and fuel mileage meter units. Select the "SPEED" or "FUEL CONS." using If you want to select "L/100km" or "km/L" for sel up or sel down switch.
Page 65 LANGUAGE Changes the system language. Select the language using of the sel switch. Return to the ordinary display to complete the setting. (P.45) To continue setting, push the sel switch in the direction of to return to the upper hierarchy. The set value is retained.
Page 66 Instruments (Continued) The following items are restored to their RESTORE DEFAULT default values: The set values can be returned to the default • DISPLAY TYPE settings. • SHIFT POINT • ECON MODE Reset the settings according to the switch • BRIGHTNESS operation guide.
Page 67 BLUETOOTH PAIRING RESET You can reset the pairing record of Bluetooth ® To connect the device (P.92) Reset the settings according to the switch operation guide. (P.24) If the pairing information remains in your smartphone even if the pairing information is deleted from the vehicle, the smartphone may be connected to the vehicle again.
Page 68: Maintenance
Instruments (Continued) MAINTENANCE KO type -----, 12,000 to -99,999 km You can check the next periodic inspection Pass 0 km: “-” mark is displayed. time and next engine oil change. You can change the setting of the next DATE: periodic inspection and next engine oil Month: ---, JAN to DEC change.
Page 69 When reaching any of the following, the pop-up information is appears in the ordinary display. (P.69) “500 km” (“300 mile”) from the next ● periodic inspection. “100 km” (“60 mile”) from the next engine ● oil change. One month before the set month. ●...
Page 70 Instruments (Continued) Next inspection setting Select the desired setting according to the Select “ ” (periodic inspection ) or “ ” switch operation guide. (engine oil change) using of the If you press and hold of the sel sel switch. switch while setting the “DISTANCE”, it will move every 1000.
Page 71 EQUIPMENT "EQUIPMENT" is displayed but not selectable. Displays a current problem with the vehicle. If your vehicle has problem, DTC index is displayed. Reduce speed and have your vehicle inspected by your dealer as soon as possible. DTC indexes Continued...
Page 72 Instruments (Continued) REGULATORY Displays the radio wave authentication screen.
Page 73 Pop-up information In the following cases, pop-up information is displayed at the INFO area. Maintenance information: ● When the inspection time of your vehicle is approaching. Helpful information: ● When your vehicle has helpful information. When your vehicle has multiple pieces of information, pop-up information display appears alternately.
Page 74 Helpful Information Indication Explanation Remedy Appears when Refer to “When the communication between Honda SMART Key your vehicle and Honda System Does Not SMART Key is Operate Properly.” interrupted after turning (P.177) on the electrical system. Appears when the Refer to “Replacing the...
Page 75 Tachometer colour function Shift Up Mode When shift up mode is ON, the tachometer ECON Mode colour changes according to the shift point When the ECON mode is ON, the setting. tachometer colour changes according to the To set the shift up mode (P.45) fuel mileage.
Page 76: Pgm-Fi (Programmed Fuel Injection)
Indicators If one of these indicators does not come on when it should, have your dealer check for problems. Refer to the "Instruments" about indicators appeared on the display: (P.29) Left turn signal indicator Right turn signal indicator Neutral indicator Comes on when the transmission is in Neutral.
Page 77 Comes on briefly when the electrical system ● turned on. Goes off when your speed is turned on. reaches approximately 5 km/h (3 mph) When the Honda SMART Key Indicator to indicate Torque Control is ready to Flashes: (P.174) work.
Page 78: On/Off Button
Answer back button This button is used to operate the answer back system. Answer Back System: (P.87) ON/OFF button This button is used to activate or deactivate the Honda SMART Key system, and also to confirm the activation status. (P.82)
Page 79 Ignition Switch (Lock) Locks steering. (P.79) Switches the electrical system on/off, locks the steering. Make sure that the Honda SMART Key is activated and enter the (P.82) (Off) Turns engine off. operating range. (P.83) Ignition switch knob (Off/Lock) (On) Turns electrical system on for starting/riding.
Page 80: Horn Button
Switches (Continued) Left handlebar switches Headlight dimmer/Passing light control switch Shift up switch (+) To shift up the gear. • : High beam (P.108) : DRL auto or off (low beam) • (P.111) • : Flashes the high beam headlight. Horn button Shift down switch (-) To shift down the gear.
Page 81: Function Switch
Used to operate and set the display. (P.24) Also used to set the DRL , riding mode. (P.111) and to operate the Honda Smartphone Voice (P.94) Control system (P.90) Hazard switch Switchable when the electrical system is on. Can be turned to off regardless of whether the electrical system is on or off.
Page 82: Start Button
Switches (Continued) Right handlebar switches Engine stop switch/ Start button Should normally remain in the (Run) position. In an emergency, switch to the (Stop) position to stop the engine. N-D switch To shift between Neutral and AT MODE. (P.107) A/M switch To shift between the AT MODE and MT MODE.
Page 83: Steering Lock
Steering Lock Locking Turn the ignition switch knob (Off/ Lock the steering when parking to help Lock) counterclockwise to turn off the prevent theft. electrical system. A U-shaped wheel lock or similar device is (P.75) Turn the handlebar all the way to the left. also recommended.
Page 84 Switches (Continued) Turn and hold the ignition switch knob Unlocking (Off/Lock) counterclockwise. Make sure that the Honda SMART Key is The steering lock indicator comes on activated and enter the operating (P.82) briefly and the steering is automatically range. (P.83) locked.
Page 85 The system runs a two-way authentication between the vehicle and the Honda SMART Key to verify if it is the registered Honda SMART Key. The Honda SMART Key system uses low- intensity radio waves. It may affect medical equipment such as a cardiac pacemaker.
Page 86 (Continued) Switching the Honda SMART Key System To switch the Honda SMART Key system to activation or deactivation Press the ON/OFF button until the Honda SMART Key LED changes colour. To check the Honda SMART Key ON/OFF button system status Lightly press the ON/OFF button.
Page 87 Operating Range The system can be operated when the The Honda SMART Key system uses low- Honda SMART Key is within the shaded area intensity radio waves. Therefore, the shown in the illustration. operating range may be wider or narrower,...
Page 88 (Continued) Anyone can operate the ignition switch and Anyone in possession of the Honda SMART start the engine if your Honda SMART Key is Key can perform the following operations if within operating range of your vehicle, even the Honda SMART Key is within operating...
Page 89 To Activate the Electrical System have a verified Honda SMART Key. Make sure that the Honda SMART Key is Whenever you leave your vehicle, turn off the activated and enter the operating range for electrical system and lock the steering.
Page 90 Honda SMART Key System (Continued) To Turn Off the Electrical System Turn the ignition switch knob (Off/ Lock) counterclockwise. Leave the operating range with the Honda SMART Key or switch the Honda (P.83) SMART Key system to deactivation. (P.82) When the Honda SMART Key system does not work properly (P.177)
Page 91: Operation
The answer back system is a device to find Operation the location of your vehicle. When the Press the answer back button on the Honda immobilizer is active and you press the SMART Key. answer back button on the Honda SMART...
Page 92: Ignition (On)
Answer Back System (Continued) Wait for about 10 seconds until the Honda Adjusting the Answer Back Buzzer SMART Key indicator goes off. The sound Sound Volume Level volume level is set. You can select the buzzer sound volume The sound volume level is also set by from 3 levels.
Page 93 Wait for about 10 seconds until the Honda Changing the Answer Back Buzzer SMART Key indicator goes off. The sound Sound Pattern pattern is set. You can select buzzer sound from 3 patterns. The sound pattern is also set by turn the Lock the steering.
Page 94: Communication Range
® see the following URL: registered trademarks owned by Bluetooth https://global.honda/voice-control-system/ SIG, Inc., and any use of such marks by Honda Motors Co., Ltd., is under license. Other trademarks and trade names are those of their respective owners.
Page 95 Some smartphones may not be ● WARNING compatible with the feature. We shall not be liable for any damages or Using the Honda Smartphone Voice ● trouble in the use of smartphone. Control system while riding can take When unable to connect your your attention away from the road, ●...
Page 96: Bluetooth ® Indicator
Reset the pairing information according to Voice Control system functionality and services. the switch operation guide. (P.24) After resetting, complete pairing while the Honda cannot and does not provide any Bluetooth indicator flashing by operated ® warranty or guarantee of future Honda the application on your smartphone.
Page 97: Parking Brake Lever
Parking Brake Parking Brake Lever Be sure the parking brake is applied while parking and warming up the engine. Make sure the parking brake lever is released before riding. To apply the parking brake Push the parking brake lever to the right until it snaps into place.
Page 98: Riding Mode
Riding mode You can change the riding mode. Current riding mode The riding mode consists of the following P level D level parameters. (Engine power (DCT mode) output level) P: Engine power output level EB: Engine brake level D: DCT mode T: Torque control level ABS: ABS mode EB level...
Page 99: Initial Setting
Riding mode has 5 modes. [SPORT] : This mode is suitable for sports Available riding modes: [STANDARD], [RAIN], riding. You can feel the higher engine [GRAVEL], [USER] and [SPORT] response compared to STANDARD. [STANDARD] : Standard, all-round mode Each initial setting level cannot be changed. for a variety of situations.
Page 100 Riding mode (Continued) P level (Engine power output level) EB level (Engine brake level) P level has three setting levels. EB level has three setting levels. Available setting range: 1 to 3 Available setting range: 1 to 3 Level 1 has the least power. Level 1 has the weakest engine braking Level 3 has the most power.
Page 101 D level (DCT mode) D level (DCT mode) has five setting levels. Available setting range: AT MODE: 1 to 4 (1, 2, 3, 3G, 4) MT MODE: Current level or 3G Higher engine revolution can be used by increasing the level. Level 1 has the lowest engine revolution.
Page 102 Riding mode (Continued) Selecting the riding mode STANDARD Stop the vehicle. Press the switch with the throttle MODE fully closed. RAIN Each time the electrical system is turned on the riding mode returns to STANDARD. GRAVEL USER SPORT Press the switch MODE switch...
Page 103 Setting the riding mode In MT MODE, the D level can only be You can change the P, EB, D, T and ABS selected between the current level or 3G. If the current level is 3G, the D level can levels on the USER of the riding mode.
Page 104 Riding mode (Continued) AT MODE MT MODE Current level...
Page 105 Press and hold the switch MODE Push the sel switch in the direction of Push the sel switch in the direction of Press on the sel switch Press on the sel switch Press and hold on the sel switch...
Page 106: Starting The Engine
10 is cold or warm. seconds before trying to start the engine This vehicle is equipped with a Honda again to recover battery voltage. SMART Key system. Always keep Honda • Extended fast idling and revving the engine can SMART Key on you when you ride the damage the engine, and the exhaust system.
Page 107 If you cannot start the engine: When you stop the engine With the throttle slightly open (about 3 mm To stop the engine, shift the transmission to (0.1 in), without freeplay), press the start Neutral ( indicator comes on). button. If you turn the electrical system off when the vehicle in gear, the engine will shut About 3 mm (0.1 in), without...
Page 108: Shifting Gears
Shifting Gears Your vehicle is equipped with an The Dual Clutch Transmission system runs a automatically controlled 6-speed self check immediately after starting the transmission. It can be shifted automatically engine. (by AT MODE) or manually (by MT MODE). You cannot change AT MODE (D) for a few seconds.
Page 109 Neutral (N): Neutral is selected When you can change between N and D automatically when you turn the electrical Vehicle is stopped and the engine is idling. Throttle is completely closed. It is not system on. possible to change from Neutral to D mode If neutral is not selected when the while the throttle is applied.
Page 110 Shifting Gears (Continued) AT MODE: In this mode the gears are MT MODE: MT MODE (6-speed manual shifted automatically according to your riding operation) You can choose between 6 gears conditions. in this mode. And also using the shift up switch (+) or shift down switch (−), you can temporarily shift up or down.
Page 111 Changing between Neutral and AT N-D switch MODE/MT MODE Changing from Neutral (N) to AT MODE Press the D on the N-D switch (a). A/M switch Parameter display changes to D (b), “1” is shown in the gear position indicator and first gear is selected.
Page 112: Shift Limit
Shifting Gears (Continued) Riding in MT MODE Gear shift operation Shift up and down with the shift up switch (+) Shifting Up: and shift down switch (−). Press the shift up switch (+) (h). The selected gear is shown on the gear Shifting Down: position indicator.
Page 113: Emergency Stop Signal
Emergency Stop Signal Emergency stop signal activates when the The emergency stop signal stops operating system detects hard braking about 50 km/h when: (31 mph) or above to alert drivers behind you You release the brakes. ● about sudden braking by rapidly flashing The ABS is deactivated.
Page 114 Emergency Stop Signal (Continued) The emergency stop signal is not a system that can prevent a possible rear-end collision caused by your hard braking. It is always recommended to avoid hard braking unless it is absolutely necessary. The emergency stop signal does not activate with the hazard switch pressed in.
Page 115 DRL (Daytime Running Light) When the headlight dimmer/passing light control switch is turned to the position and DRL is set to "AUTO" (P.112) the headlights and DRL are switched automatically according to the ambient brightness. When it gets brighter, DRL lights up, and when it gets dark, low beam lights up and DRL decreases to the brightness of the position light.
Page 116 DRL (Daytime Running Light) (Continued) To select the DRL auto and off Start the engine. Press the function switch. Multi function display of DRL appears on the INFO area. Select the [AUTO] or [OFF] of the DRL using of the sel switch. If the DRL indicator is off when DRL is set to "AUTO", “AUTO”...
Page 117 Tank capacity: 13.2 L (3.49 US gal, 2.90 Imp gal) Refuelling and Fuel Guidelines (P.15) Fuel lid opener switch Opening the Fuel Fill Cap Arrow marks Make sure that the Honda SMART Key is activated and enter the operating (P.82) range. (P.83) Push the fuel lid opener switch.
Page 118 Refuelling (Continued) Closing the Fuel Fill Cap Install and tighten the fuel fill cap firmly by turning it clockwise. Make sure that the arrow marks on the cap and fuel tank are aligned. Close the fuel lid. WARNING Petrol is highly flammable and explosive.
Page 119: Usb Socket
Use USB devices at your own risk. In no event NOTICE shall Honda be liable for any damage to your • Using any heat-generating USB devices or USB device when in use. improperly rated USB devices can damage the socket.
Page 120: Storage Equipment
Storage Equipment Open Luggage Box Make sure that the Honda SMART Key is activated and enter the operating (P.82) range. (P.83) Push the seat opener switch. Pull up the rear of the seat. Close Push down the rear of the seat until it locks in place.
Page 121 A helmet can be stored in the luggage box. Set in the front of the helmet upward. Helmet Some helmets may not fit in the compartment due to their size or design. Continued...
Page 122 Storage Equipment (Continued) Tool Kit Document Bag The tool kit is stored in the luggage box by The document bag is stored reverse side of the rubber strap. the seat. Rubber strap Document bag Tool kit Rubber strap Opening the seat (P.116) Opening the seat (P.116)
Page 123 Helmet Holder WARNING The helmet holder is located under the seat. Riding with a helmet attached to the A helmet set wire is in the tool kit. holder can interfere with your ability to safely operate the vehicle and could Helmet holder lead to a crash in which you can be seriously hurt or killed.
Page 124 Storage Equipment (Continued) Fairing Pocket Fairing pocket Fairing pocket lid Never exceed the maximum weight limit. Maximum Weight: 0.5 kg (1.0 lb) Open To open the fairing pocket, pull the fairing pocket lid. Close Push the mark of the fairing pocket lid until it is firmly closed.
Page 125: Maintenance
Adjusting the Windscreen Height ....P. 163 Front Lower Cover ..........P. 143 Other Replacement......... P. 165 Maintenance Lid..........P. 144 Replacing the Honda SMART Key Battery .. P. 165 Left Side Cover ..........P. 145 Engine Oil ............P. 148 Coolant .............. P. 150...
Page 126: Importance Of Maintenance
Importance of Maintenance Importance of Maintenance Maintenance Safety Keeping your vehicle well-maintained is Always read the maintenance instructions absolutely essential to your safety and to before you begin each task, and make sure that protect your investment, obtain maximum you have the tools, parts, and skills required. performance, avoid breakdowns, and reduce air We cannot warn you of every conceivable pollution.
Page 127: Maintenance Schedule
Maintenance work should be performed in new owner. accordance with Honda's standards and specifications by properly trained and equipped Honda recommends that your dealer should technicians. Your dealer meets all of these road test your vehicle after each periodic requirements. Keep an accurate record of maintenance is carried out.
Page 128 Inspect (clean, adjust, lubricate, or replace, if necessary) dealer, unless you have the necessary tools and are Lubricate mechanically skilled. Replace Procedures are provided in an official Honda Shop Manual. Clean : Technical. In the interest of safety, have your vehicle serviced by your dealer.
Page 129 Maintenance Schedule Frequency Pre-ride Refer Annual Regular Items Check × 1,000 km Check Replace P. 128 page × 1,000 mi Drive Chain Every 1,000 km (600 mi): Drive Chain Slider – Brake Fluid 2 Years Brake Pads Wear Brake System Brake Lock Operation Headlight Aim –...
Page 130 : Intermediate. We recommend service by your dealer, unless Inspect (clean, adjust, lubricate, or replace, if necessary) you have the necessary tools and are mechanically skilled. Replace Procedures are provided in an official Honda Shop Lubricate Manual. Clean : Technical. In the interest of safety, have your vehicle...
Page 131 Maintenance Schedule Frequency Pre-ride Annual Regular Refer to Items Check × 1,000 km Check Replace page P. 128 × 1,000 mi Drive Chain Every 1,000 km (600 mi): Drive Chain Slider – Brake Fluid 2 Years Brake Pads Wear Brake System Brake Lock Operation Headlight Aim –...
Page 132: Maintenance Fundamentals
Maintenance Fundamentals Drive chain - Check condition and slack, Pre-ride Inspection ● adjust and lubricate if necessary. P. 156 To ensure safety, it is your responsibility to Brakes - Check operation; ● perform a pre-ride inspection and make sure Front and Rear: check brake fluid level and that any problem you find is corrected.
Page 133 Maintenance Fundamentals WARNING Replacing Parts Always use Honda Genuine Parts or their Installing non-Honda parts may make equivalents to ensure reliability and safety. your vehicle unsafe and cause a crash in KO type which you can be seriously hurt or When ordering coloured components, specify killed.
Page 134 Maintenance Fundamentals Battery NOTICE An improperly disposed of battery can be Your vehicle has a maintenance-free type harmful to the environment and human health. battery. You do not have to check the battery Always confirm local regulations for proper electrolyte level or add distilled water. Clean the battery disposal instruction.
Page 135 Maintenance Fundamentals What to do in an emergency WARNING If any of the following occur, immediately see The battery gives off explosive your doctor. hydrogen gas during normal operation. Electrolyte splashes into your eyes: ● Wash your eyes repeatedly with cool water for at least 15 minutes.
Page 136 Always replace the battery with another maintenance-free battery of the same type. NOTICE Installing non-Honda electrical accessories can NOTICE overload the electrical system, discharging the Replacing a fuse with one that has a higher battery and possibly damaging the system.
Page 137 Conserving” or “Resource Conserving” on the “Specifications.” P. 217 circular API service symbol. If you use non-Honda engine oil, check the label to make sure that the oil satisfies all of the following standards: JASO T 903 standard : MA ●...
Page 138: Recommended Brake Fluid
Brake fluid can damage plastic and painted surfaces. Wipe up spills immediately and wash thoroughly. Recommended brake fluid: Normal Worn Damaged Honda DOT 4 Brake Fluid or equivalent (GOOD) (REPLACE) (REPLACE) Drive Chain NOTICE Use of a new chain with worn sprockets will cause The drive chain must be inspected and rapid chain wear.
Page 139 Maintenance Fundamentals Cleaning and Lubricating Do not use a steam cleaner, a high pressure cleaner, a wire brush, volatile solvent such as After inspecting the slack, clean the chain and petrol and benzene, abrasive cleaner, chain sprockets while rotating the rear wheel. Use a dry cleaner or lubricant NOT designed specifically cloth with chain cleaner designed specifically for for O-ring chains as these can damage the...
Page 140: Recommended Coolant
Recommended Coolant NOTICE Using coolant not specified for aluminium GS, KO type engines or tap/mineral water can cause Pro Honda HP Coolant is a pre-mixed solution corrosion. of antifreeze and distilled water. Concentration: 50% antifreeze and 50% distilled water Crankcase Breather...
Page 141 Maintenance Fundamentals Inspecting for Damage Tyres (Inspecting/Replacing) Checking the Air Pressure Inspect the tyres for Visually inspect your tyres and use an air cuts, slits, or cracks that pressure gauge to measure the air pressure at exposes fabric or least once a month or any time you think the cords, or nails or other tyres look low.
Page 142 Maintenance Fundamentals Inspecting Tread Depth WARNING Inspect the tread wear indicators. If they Riding on tyres that are excessively become visible, replace the tyres immediately. worn or improperly inflated can cause a For safe riding, you should replace the tyres crash in which you can be seriously hurt when the minimum tread depth is reached.
Page 143 Installing improper tyres on your of the same size, construction, speed rating, and load range. vehicle can adversely affect handling Have the wheel balanced with Honda ● and stability, and can cause a crash in Genuine balance weights or equivalent after which you can be seriously hurt or the tyre is installed.
Page 144: Tool
Tool The tool kit is stored under the seat. P. 116 You can perform some roadside repairs, minor adjustments and parts replacement with the provided tools. 10 x 14 mm Open end wrench ● 12 x 14 mm Open end wrench ●...
Page 145: Removing & Installing Body Components
Removing & Installing Body Components Battery Disconnect the positive + terminal from the battery. Negative terminal Positive terminal Remove the battery taking care not to drop the terminal nuts. Remove the battery by pulling the battery strap with one hand while supporting the battery with the other.
Page 146: Clip
Removing & Installing Body Components Clip Clip Removal Press down on the centre pin to release the lock. Pull the clip out of the hole. Centre Installation Push the bottom of the centre pin. Insert the clip into the hole. Press down on the centre pin to lock the clip.
Page 147: Front Lower Cover
Removing & Installing Body Components Front Lower Cover Front Lower Cover Front lower cover Clip Bolt A Clip Bolt B Clips Bolts Skid plate Remove the bolt A, bolt B and clips. Removal P. 142 Remove the skid plate by removing the Remove the front lower cover.
Page 148: Maintenance Lid
Removing & Installing Body Components Maintenance Lid Maintenance Lid Removal Open the seat. P. 116 Remove the tool kit. Maintenance lid Remove the clips ( P. 142) and maintenance lid. Installation Install the parts in the reverse order of removal. Clips...
Page 149: Left Side Cover
Removing & Installing Body Components Left Side Cover Left Side Cover Release the tabs from slots. Carefully release the tabs from the slots. Removal Pull the side cover slightly back to release the hooks from the slots. Open the seat. P.
Page 150 Removing & Installing Body Components Left Side Cover Installation Slots Hooks Grab rail Pull the left side cover back slightly and attach the hooks into the slots. Left side cover Left side cover To attach the hooks securely, push the Insert the left side cover on the back of left side cover forward.
Page 151 Removing & Installing Body Components Left Side Cover Tabs Tabs Slots Insert the tabs into the slots. Insert the prongs into the grommets. Install the bolt and clip. Close the seat.
Page 152: Checking The Engine Oil
Engine Oil Checking the Engine Oil Upper level If the engine is cold, idle the engine for 3 to 5 minutes. Turn off the electrical system and wait for 2 to 3 minutes. Lower level Place your vehicle on its centre stand on a firm, level surface.
Page 153: Adding Engine Oil
Engine Oil Adding Engine Oil Adding Engine Oil Securely reinstall the oil fill cap/dipstick. NOTICE If the engine oil is below or near the lower Overfilling with oil or operating with insufficient level mark, add the recommended engine oil. oil can cause damage to your engine. Do not mix P.
Page 154: Checking The Coolant
Coolant Checking the Coolant UPPER level Check the coolant level in the reserve tank while the engine is cold. Place your vehicle on a firm, level surface. Hold your vehicle in an upright position. Check that the coolant level is between the UPPER level and LOWER level marks on the reserve tank.
Page 155 Coolant Adding Coolant Remove the front lower cover. P. 143 Reserve tank cap Remove the reserve tank cap and add fluid while monitoring the coolant level. Do not overfill above the UPPER level mark. Make sure no foreign objects enter the reserve tank opening.
Page 156: Brakes
Brakes Checking Brake Fluid If the brake fluid level in either reservoir is below the LOWER level mark or both the brake levers freeplay becomes excessive, Place your vehicle in an upright position inspect the brake pads for wear. on a firm, level surface. If the brake pads are not worn, you most Check that the brake fluid reservoir is likely have a leak.
Page 157: Inspecting The Brake Pads
Brakes Inspecting the Brake Pads Inspecting the Brake Pads Inspect the brake pads from in front Front of the brake caliper. Always inspect both left and right Check the condition of the brake pad wear brake calipers. indicators. Inspect the brake pads from the rear The pads need to be replaced if a Rear Front...
Page 158: Checking The Parking Brake
Brakes Checking the Parking Brake Checking the Parking Brake Check that the front edge of the parking brake lever is within the adjustment range (between the index marks), when the Front edge of parking brake lever brake begins to take hold. Index marks If the brake begins to take hold at out of the adjustment range, have the brake adjusted...
Page 159: Checking The Side Stand
Side Stand Checking the Side Stand Start the engine and press the D on the N-D switch to switch the transmission into D mode. Lower the side stand all the way. The engine should stop as you lower the side stand.
Page 160: Drive Chain
Drive Chain Inspecting the Drive Chain Check the slack in the lower half of the drive chain midway between the sprockets. Slack While depressing the drive chain, measure the distance from the bottom Check the drive chain slack at several points of the swingarm to the drive chain.
Page 161 Drive Chain Inspecting the Drive Chain Slack Rotate the rear wheel and check that the Swingarm Drive chain chain moves smoothly. Inspect the sprockets. P. 134 Clean and lubricate the drive chain. P. 135 Push Drive chain slack Drive chain slack...
Page 162: Throttle
Throttle Checking the Throttle With the engine off, check that the throttle rotates smoothly from fully closed to fully open. If the throttle does not move smoothly, close automatically, have the vehicle inspected by your dealer. Throttle...
Page 163: Other Adjustments
Other Adjustments Adjusting the Brake Lever Brake lever You can adjust the distance between the tip Forward of the brake lever and handle grip. Adjustment method Turn the adjuster until the numbers align with the index mark while pushing the lever forward in the desired position.
Page 164: Adjusting The Front Suspension
Other Adjustments Adjusting the Front Suspension Adjusting the Front Suspension Spring Preload You can adjust the spring preload by the adjuster to suit the load or the road surface. Turn the adjuster using the box end wrench Adjuster Adjuster provided in the tool kit. P.
Page 165: Rebound Damping
Other Adjustments Adjusting the Front Suspension Rebound Damping BFR adjuster You can adjust the rebound damping by the Reference adjuster to suit the load or the road surface. punch mark The rebound damping adjuster has 3 turns or more. Turn the adjuster using the BFR adjuster provided in the tool kit.
Page 166: Adjusting The Rear Suspension
Other Adjustments Adjusting the Rear Suspension Adjusting the Rear Suspension Pin spanner 1 2 3 4 5 6 Spring Preload You can adjust the spring preload by the adjuster to suit the load or the road surface. Turn the adjuster using the pin spanner and extension bar provided in the tool kit.
Page 167: Adjusting The Windscreen Height
Other Adjustments Adjusting the Windscreen Height Adjusting the Windscreen Height Windscreen You can adjust the windscreen height 1 of 5 positions. Windscreen height indicator shows the windscreen height. The standard position is 1. Do not adjust the windscreen while riding. Pull the windscreen lock lever outward Windscreen adjustment handle until it snaps into place.
Page 168 Other Adjustments Adjusting the Windscreen Height Align the windscreen height indicator with If the windscreen does not move smoothly, the index mark at the desired position, flush the sliding parts with water to remove push the windscreen adjustment handle dust. inward to lock the windscreen.
Page 169: Other Replacement
Key Battery with a protective cloth into the slit. Wrap a coin or a screwdriver with a If the Honda SMART Key indicator flashes 5 protective cloth to prevent scratching times when the electrical system is turned on, the Honda SMART Key.
Page 170 Other Replacement Replacing the Honda SMART Key Battery Snap the two halves of the remote transmitter back together. Make sure that upper and lower cases are set in the right position. WARNING Chemical Burn Hazard: do not swallow battery. If swallowed, the battery can cause severe internal burns and even death.
Page 171: Troubleshooting
Troubleshooting Engine Will Not Start........P. 168 When the Honda SMART Key System Does Not Overheating (High coolant temperature Operate Properly........... P. 177 indicator is on) ..........P. 169 Unlock the Seat in an Emergency ....P. 179 Warning Indicators On or Flashing..... P. 170 Activating the Electrical System in an Low Oil Pressure Indicator ......
Page 172: Engine Will Not Start
Engine Will Not Start Starter Motor Operates But Starter Motor Does Not Engine Does Not Start Operate Check the following items: Check the following items: Check the correct engine starting Check the correct engine starting ● ● sequence. P. 102 sequence.
Page 173: Overheating (High Coolant Temperature Indicator Is On)
Overheating (High coolant temperature indicator is on) The engine is overheating when the following If the fan is not operating: Suspect a fault. Do not start the engine. occurs: Transport your vehicle to your dealer. High coolant temperature indicator ● comes on.
Page 174: Warning Indicators On Or Flashing
Warning Indicators On or Flashing Low Oil Pressure Indicator If the engine oil level goes down rapidly, your vehicle may have a leak or another serious problem. Have your vehicle inspected by If the low oil pressure indicator comes on, your dealer.
Page 175: Pgm-Fi (Programmed Fuel Injection) Malfunction Indicator Lamp (Mil)
Warning Indicators On or Flashing PGM-FI (Programmed Fuel Injection) Malfunction Indicator Lamp (MIL) PGM-FI (Programmed Fuel What to do when the indicator lamp comes on Injection) Malfunction Avoid high speeds and immediately get your Indicator Lamp (MIL) vehicle inspected at a dealer. What to do when the indicator lamp Except KO type blinks...
Page 176: Abs (Anti-Lock Brake System) Indicator
Warning Indicators On or Flashing ABS (Anti-lock Brake System) Indicator ABS (Anti-lock Brake System) If the ABS indicator stays on, your brakes will continue to work as a conventional system, Indicator but without the anti-locking function. If the indicator operates in one of the The ABS indicator may flash if you turn the following ways, you may have a serious rear wheel while the rear wheel is lifted off...
Page 177: Torque Control Indicator
Warning Indicators On or Flashing Torque Control Indicator Torque Control Indicator Even when the Torque Control indicator is on, your vehicle will have normal riding ability without Torque Control function. If the indicator operates in one of the When the indicator comes on while the following ways, you may have a serious Torque Control is in operation, you will problem with the Torque Control.
Page 178: Honda Smart Key Indicator
It is probably caused by the following: Strong radio waves or noise are affecting ● If you do not have the Honda SMART Key, the system the electrical system can be activated in You lose the Honda SMART Key while another way.
Page 179: If The "-" Indicator Is Blinking In The Gear Position Window While Riding
If the “–” Indicator is Blinking in the Gear Position Window While Riding If the “–” indicator is blinking while riding, you If you still cannot start the engine: may have a serious problem with the Dual Start the engine while applying the front or Clutch Transmission system.
Page 180: Other Warning Indications
Other Warning Indications Fuel Gauge Failure Indication If the fuel system has an error, the fuel gauge indicators will be displayed as shown in the illustration. If this occurs, see your dealer as soon as possible.
Page 181: When The Honda Smart Key System Does Not Operate Properly
When the Honda SMART Key System Does Not Operate Properly When the Honda SMART Key system does Check that there is no communication ● not work properly, perform the following. failure in the Honda SMART Key system. Check that the Honda SMART Key system The Honda SMART Key system uses low- ●...
Page 182 When the Honda SMART Key System Does Not Operate Properly Check that a registered Honda SMART Check the battery condition and battery ● ● Key is used. lead in your vehicle. Use a registered Honda SMART Key. Check the battery and battery terminals. If The Honda SMART Key system cannot be the battery is weak, contact your dealer.
Page 183: Unlock The Seat In An Emergency
Unlock the Seat in an Emergency The seat lock can be unlocked by using the emergency key. Emergency seat opener Open Remove the emergency seat opener cap. Insert the emergency key into the emergency seat opener, and turn the key counterclockwise.
Page 184: Activating The Electrical System In An Emergency
Activating the Electrical System in an Emergency The electrical system can be activated by Use the emergency key to open the seat. inputting the ID number. P. 179 Remove the left side cover. P. 145 Pull out the EM mode connector (white) Set up to ID number input mode from the rubber dust cover.
Page 185 Activating the Electrical System in an Emergency Push and hold the ignition (On) switch Ignition (On) switch for more than 4 seconds within 60 seconds after reconnecting the white dummy coupler. The steering lock indicator comes on, the buzzer sounds and the system enters the ID number input mode.
Page 186 Activating the Electrical System in an Emergency ID number input While inputting the ID number, if the button is not pressed for about 60 seconds, the You can input your ID number by pushing inputted ID number is cancelled and the the ignition (On) switch and Turn the system returns to the state before disconnect ignition switch knob...
Page 187 Activating the Electrical System in an Emergency Example: To input “1”, push the ignition (On) ● To input “0”, turn the ignition switch knob switch once, and then turn the ignition ● (Off/Lock) counterclockwise without switch knob (Off/Lock) pushing the ignition (On) switch, and counterclockwise to input the next digit.
Page 188 Activating the Electrical System in an Emergency Reinstall the parts in reverse order of ID number input success After the last digit of the ID number is removal, before riding. inputted, ID number is authenticated, the steering lock indicator will flash every 2 You can turn off the engine and electrical seconds.
Page 189 Activating the Electrical System in an Emergency ID number input failure ID number input cancel If the ID number is not authenticated after If you input the wrong number, you can inputting, the buzzer sounds and the steering cancel ID number input by not operating the lock indicator goes off.
Page 190: Tyre Puncture
Tyre Puncture Repairing a puncture or removing a wheel WARNING requires special tools and technical expertise. Riding your vehicle with a temporary We recommend you have this type of service tyre repair can be risky. If the temporary performed by your dealer. repair fails, you can crash and be After an emergency repair, always have the seriously injured or killed.
Page 191: Smartphone Pairing Trouble
Smartphone Pairing Trouble Symptom Cause/remedy Some smartphones you use may be incompatible with the vehicle and/or the operable functions may be limited. Check that the vehicle and smartphone are both in pairing mode. P. 92 Check your surroundings to make sure no other device being paired is present before re-pairing.
Page 192 Smartphone Pairing Trouble Symptom Cause/remedy Depending on the smartphone you use, it may take some time for the vehicle to connect to a smartphone and to start using a dedicated application. The connection may be temporarily disconnected when starting the engine, which is normal and not a malfunction. The smartphone will be reconnected after the engine is started.
Page 193: Electrical Trouble
Electrical Trouble Battery Goes Dead Burned-out Light Bulb Charge the battery using a motorcycle All light bulbs on the vehicle are LEDs. If battery charger. there is an LED which is not turned on, see Remove the battery from the vehicle before your dealer for servicing.
Page 194: Blown Fuse
Electrical Trouble Blown Fuse Blown Fuse Remove the left side cover. P. 145 Remove the fuse box cover. Pull the fuses out one by one with the Before handling fuses, see “Inspecting and fuse puller in the tool kit and check for a Replacing Fuses.”...
Page 195 Electrical Trouble Blown Fuse Fuse Box B Fuses Remove the left side cover. P. 145 Open the fuse box cover. Pull the fuses out one by one with the Fuse box cover fuse puller in the tool kit and check for a blown fuse.
Page 196 Electrical Trouble Blown Fuse Main Fuses Remove the maintenance lid. P. 144 Push the tab to remove the data link connector from the connector Wire connector suspension. Push the tab to disconnect the wire connector from the starter magnet switch. Connector suspension Data link connector...
Page 197 Electrical Trouble Blown Fuse kit and check for a blown fuse. Always replace a blown fuse with a spare fuse of the same rating. Spare main fuse is in the fuse box B. P. 191 Reinstall parts in the reverse order of removal.
Page 198: Information
Information Service Diagnostic Recorders....... P. 195 Keys..............P. 196 Instruments, Controls, & Other Features... P. 200 Caring for Your Vehicle........P. 206 Storing Your Vehicle........P. 210 Transporting Your Vehicle ......P. 211 You & the Environment ......... P. 212 Serial Numbers ..........
Page 199: Service Diagnostic Recorders
However this data may be accessed by Honda, its authorised dealers and authorised repairers, employees, representatives and contractors only for the purpose of the technical diagnosis,...
Page 200: Keys
Keys Keys Emergency key Key tag Emergency Key This vehicle has emergency keys and a key tag with a key number and a bar code. Store the key tag in a safe location. To make a duplicate key, take the key and key tag to your dealer or a locksmith.
Page 201 Do not scratch or puncture. ● The ID number of the Honda SMART Key is on Do not store near any magnetized products ● the ID tag. You can also activate the electrical such as a magnetized key chain.
Page 202 Keys If fuel, wax, or grease adhere to the Honda The battery in the Honda SMART Key system ● SMART Key, wipe it off immediately to avoid normally lasts about 2 years. cracking or warping. Do not disassemble the Honda SMART Key Do not keep mobile phones or other radio ●...
Page 203 Keys Taiwan only...
Page 204: Instruments, Controls, & Other Features
Instruments, Controls, & Other Features Instruments, Controls, & Tripmeter Other Features The tripmeters return to 0.0 when each read- out exceeds 9,999.9. Ignition Switch Document Bag Leaving the electrical system on with the engine The owner’s manual, registration, and insurance stopped will drain the battery.
Page 205 Instruments, Controls, & Other Features Throttle by Wire System DRL, Automatic Brightness Control and Background Control This model is equipped with a Throttle by Wire System. Ambient brightness is detected by the Do not put magnetized items or items photosensor. susceptible to magnetic interference near the Do not damage or cover the photosensor.
Page 206 Instruments, Controls, & Other Features determined stop shipping till the Honda Smartphone Voice Control system product is improved. Taiwan only This device may not cause harmful interference, and this device must accept any interference received, 1. Product name: Digital Cluster with...
Page 207 Instruments, Controls, & Other Features Continued...
Page 208 Instruments, Controls, & Other Features GCC countries only Korea only 인증번호: R-R-VC1-2WCluster 인증 받은 자의 상호: Visteon Corporation 기자재의 명칭/ 모델명: 2WCluster 제조연월일: 별도표기 제조자/제조국가: Visteon/USA...
Page 209 Instruments, Controls, & Other Features Thailand only...
Page 210: Caring For Your Vehicle
Frequent cleaning and polishing is important to After the vehicle dries, lubricate any moving ensure the life of your Honda. A clean vehicle parts. makes it easier to spot potential problems.
Page 211 Caring for Your Vehicle Do not direct water at the air cleaner: Washing Precautions ● Water in the air cleaner can prevent the Follow these guidelines when washing: engine from starting. Do not use high-pressure washers: ● Do not direct water near the headlight: High-pressure water cleaners can ●...
Page 212: Aluminium Components
Caring for Your Vehicle Aluminium Components Windscreen Aluminium will corrode from contact with dirt, Using plenty of water, clean the windscreen with mud, or road salt. Clean aluminium parts a soft cloth or sponge. (Avoid using detergents regularly and follow these guidelines to avoid or any kind of chemical cleaner on the scratches: windscreen.) Dry with a soft, clean cloth.
Page 213: Exhaust Pipe And Muffler
Caring for Your Vehicle When the exhaust pipe and muffler are painted, Exhaust Pipe and Muffler do not use a commercially available abrasive The exhaust pipe and muffler are stainless steel kitchen cleaning compound. Use a neutral but may become stained by mud or dust. detergent to clean the painted surface on the exhaust pipe and muffler.
Page 214: Storing Your Vehicle
Storing Your Vehicle Storing Your Vehicle After removing your vehicle from storage, inspect all maintenance items required by the If you store your vehicle outdoors, you should Maintenance Schedule. consider using a full-body cover. If you won't be riding for an extended period, follow these guidelines: Wash your vehicle and wax all painted ●...
Page 215: Transporting Your Vehicle
Transporting Your Vehicle Transporting Your Vehicle If your vehicle needs to be transported, it should be carried on a motorcycle trailer or a flatbed truck or trailer that has a loading ramp or lifting platform, and motorcycle tie-down straps. Never try to tow your vehicle with a wheel or wheels on the ground.
Page 216: You & The Environment
You & the Environment You & the Environment Recycle Wastes Put oil and other toxic wastes in approved Owning and riding a vehicle can be enjoyable, containers and take them to a recycling centre. but you must do your part to protect the Call your local or state office of public works or environment.
Page 217: Serial Numbers
Serial Numbers Serial Numbers The frame and engine serial numbers uniquely identify your vehicle and are required in order to register your vehicle. They may also be required when ordering replacement parts. The engine number is stamped on the right rear side of the crankcase.
Page 218: Fuels Containing Alcohol
Fuels Containing Alcohol Fuels Containing Alcohol The use of petrol containing more than 10% ethanol may: Some conventional fuels blended with alcohol Damage the painting of the fuel tank. ● are available in some locales to help reduce Damage the rubber tubes of the fuel line. ●...
Page 219: Catalytic Converter
A defective catalytic converter contributes to air pollution and can impair your engine's performance. A replacement unit must be an original Honda part or equivalent.
Page 220: Specifications
Specifications Main Components ■ Bore x stroke 77.0 x 80.0 mm (3.03 x 3.15 in) ADV750 2,215 mm (87.2 in) Compression ratio 10.7 : 1 Overall length Unleaded petrol ADV750L 2,200 mm (86.6 in) Fuel Recommended: 91 RON or higher Overall width 940 mm (37.0 in) Windscreen position...
Page 221 Idle speed 1,200 ± 100 rpm Honda DOT 4 Brake Fluid brake fluid Cooling system 1.44 L (1.52 US qt, 1.27 Imp qt) capacity GS, KO type Pro Honda HP Coolant Recommended FO, MA, TH coolant HONDA PRE-MIX COOLANT type...
Page 222 Specifications Bulbs ■ Drive chain lubricant designed specifically Recommended for O-ring chains drive chain Headlight lubricant If not available, use SAE 80 or 90 gear oil. ADV750 45 - 50 mm (1.8 - 2.0 in) Brakelight/Taillight Drive chain slack ADV750L 40 - 45 mm (1.6 - 1.8 in) Front turn signal DID520V0...
Page 223 Thailand only HELMET CAUTION LABEL...
Page 224 XXXX. 2021.XX.J 42MKT800 PRINTED IN XXXX 00X42-MKT-8000...

Honda ADV750L 2021 Owner's Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Honda ADV750L 2021

Summary of Contents for Honda ADV750L 2021

Table of Contents
