Product Manual
Video 3.5 HDD
ST2000VM003
ST1000VM002
100633414
Rev. H
May 2013

Advertisement

Table of Contents
loading

Summary of Contents for Seagate ST3000VM002

  • Page 1 Product Manual Video 3.5 HDD ST2000VM003 ST1000VM002 100633414 Rev. H May 2013...
  • Page 2 In addition, some of the listed capacity is used for formatting and other functions, and thus will not be available for data storage. Seagate reserves the right to change, without...
  • Page 3: Table Of Contents

    Seagate Technology Support Services ........
  • Page 4 Video 3.5 HDD Product Manual, Rev. H...
  • Page 5 Figures Figure 1 Typical Current Profiles (5V) ..........16 Figure 2 Typical Current Profiles (12V) .
  • Page 6 Video 3.5 HDD Product Manual, Rev. H...
  • Page 7: Seagate Technology Support Services

    • Authorized Service Centers For information regarding Warranty Support, visit http://www.seagate.com/www/en-us/support/warranty_&_returns_assistance For information regarding data recovery services, visit http://www.i365.com For Seagate OEM and Distribution partner portal, visit https://direct.seagate.com/portal/system For Seagate reseller portal, visit http://spp.seagate.com Video 3.5 HDD Product Manual, Rev. H...
  • Page 8 Video 3.5 HDD Product Manual, Rev. H...
  • Page 9: Introduction

    1.0 Introduction ® This manual describes the functional, mechanical and interface specifications for the following Seagate Video ® 3.5 HDD (formerly Pipeline HD )SATA model drives: ST2000VM003 ST1000VM002 These drives provide the following key features: • 5900 RPM spindle speed •...
  • Page 10 Introduction www.seagate.com In addition, Serial ATA makes the transition from parallel ATA easy by providing legacy software support. Serial ATA was designed to allow you to install a Serial ATA host adapter and Serial ATA disk drive in your current system and expect all of your existing applications to work as normal.
  • Page 11: Drive Specifications

    2.0 Drive Specifications Unless otherwise noted, all specifications are measured under ambient conditions, at 25°C, and nominal power. For convenience, the phrases the drive and this drive are used throughout this manual to indicate the following drive models: ST2000VM003 ST1000VM002 2.1 Specification summary tables The specifications listed in the following tables are for quick reference.
  • Page 12 Drive Specifications www.seagate.com Table 1 Drive specifications summary for 2TB and 1TB models (continued) Drive Specification ST2000VM003 ST1000VM002 <17s <6s Standby to ready (max) <1.0ms read; <1.0ms read; Track-to-track seek time (typical) <1.2ms write <1.2ms write <8.5ms read; <8.5ms read;...
  • Page 13: Formatted Capacity

    Drive Specifications 2.2 Formatted capacity Formatted Guaranteed Model Bytes per sector capacity* sectors 4096 ST2000VM003 3,907,029,168 (512 bytes per sector emulated at the interface) 4096 ST1000VM002 1,953,525,168 (512 bytes per sector emulated at the interface) * One GB equals one billion bytes and 1TB equals one trillion bytes when referring to hard drive capacity. Accessible capacity may vary depending on operating environment and formatting.
  • Page 14: Physical Characteristics

    Drive Specifications www.seagate.com 2.5 Physical characteristics Maximum height 2TB model 26.1mm / 1.028 in 1TB model 20.20mm / 0.795 in Maximum width 101.6mm / 4.0 in (± 0.010 in) Maximum length 147.00mm / 5.78 in Typical weight 2TB model 535g / 1.18 lb 1TB model 415g / 0.915 lb...
  • Page 15: Power Specifications

    Drive Specifications 2.8 Power specifications The drive receives DC power (+5V or +12V) through a native SATA power connector. (Refer to Figure 3 2.8.1 Power consumption Power requirements for the drives are listed in . Typical power measurements are based on an Table 2 on page 15 average of drives tested, under nominal conditions, using 5.0V and 12.0V input voltage at 25°C ambient...
  • Page 16: Figure 1 Typical Current Profiles (5V)

    Drive Specifications www.seagate.com Figure 1 Typical Current Profiles (5V) Figure 2 Typical Current Profiles (12V) Video 3.5 HDD Product Manual, Rev. H...
  • Page 17: Conducted Noise

    Drive Specifications 2.8.2 Conducted noise Input noise ripple is measured at the host system power supply across an equivalent 80-ohm resistive load on the +12V line or an equivalent 15-ohm resistive load on the +5V line. • Using 12V power, the drive is expected to operate with a maximum of 120 mV peak-to-peak square-wave injected noise at up to 10MHz.
  • Page 18: Environmental Specifications

    Drive Specifications www.seagate.com 2.9 Environmental specifications 2.9.1 Drive case temperature This section provides the temperature, humidity, shock, and vibration specifications. Ambient temperature is defined as the temperature of the environment immediately surrounding the drive. Above 1000ft. (305 meters), the maximum temperature is derated linearly by 1°C every 1000 ft. Drive case temperature should be measured at the...
  • Page 19: Shock

    Drive Specifications 2.9.5 Shock All shock specifications assume that the drive is mounted securely with the input shock applied at the drive mounting screws. Shock may be applied in the X, Y or Z axis. 2.9.5.1 Operating shock These drives comply with the performance levels specified in this document when subjected to a maximum operating shock of 80 Gs based on half-sine shock pulses of 2ms during read operations.
  • Page 20: Acoustics

    Seagate follows the ECMA-74 standards for measurement and identification of PDTs. An exception to this process is the use of the absolute threshold of hearing. Seagate uses this threshold curve (originated in ISO 389- 7) to discern tone audibility and to compensate for the inaudible components of sound prior to computation of tone ratios according to Annex D of the ECMA-74 standards.
  • Page 21: Reliability - Annualized Failure Rate

    EN55022, Class B and the immunity levels are defined by EN55024. Drives are tested in representative end-user systems. Although CE-marked Seagate drives comply with the directives when used in the test systems, we cannot guarantee that all systems will comply with the directives.
  • Page 22: Fcc Verification

    As a subassembly, no Federal Communications Commission verification or certification of the device is required. Seagate has tested this device in enclosures as described above to ensure that the total assembly (enclosure,disk drive, motherboard, power supply, etc.) does comply with the limits for a Class B computing device, pursuant to Subpart J, Part 15 of the FCC rules.
  • Page 23: Corrosive Environment

    The silver, copper, nickel and gold films used in Seagate products are especially sensitive to the presence of sulfide, chloride, and nitrate contaminants. Sulfur is found to be the most damaging. In addition, electronic components should never be exposed to condensing water on the surface of the printed circuit board assembly (PCBA) or exposed to an ambient relative humidity greater than 95%.
  • Page 24 Drive Specifications www.seagate.com Video 3.5 HDD Product Manual, Rev. H...
  • Page 25: Configuring And Mounting The Drive

    3.0 Configuring and Mounting the Drive This section contains the specifications and instructions for configuring and mounting the drive. 3.1 Handling and static-discharge precautions After unpacking, and before installation, the drive may be exposed to potential handling and electrostatic discharge (ESD) hazards. Observe the following standard handling and static-discharge precautions: Caution: •...
  • Page 26: Drive Mounting

    Configuring and Mounting the Drive www.seagate.com Figure 3 Attaching SATA cabling Signal connector Power connector Signal cable Power cable Each cable is keyed to ensure correct orientation. Video 3.5 HDD drives support latching SATA connectors. 3.4 Drive mounting You can mount the drive in any orientation using four screws in the side-mounting holes or four screws in the bottom-mounting holes.
  • Page 27: Figure 4 Mounting Dimensions (2Tb Model)

    Configuring and Mounting the Drive Figure 4 Mounting dimensions (2TB model) Recommended case temperature measurement location Video 3.5 HDD Product Manual, Rev. H...
  • Page 28: Figure 5 Mounting Dimensions (1Tb Model)

    Configuring and Mounting the Drive www.seagate.com Figure 5 Mounting dimensions (1TB model) Recommended case temperature measurement location Video 3.5 HDD Product Manual, Rev. H...
  • Page 29: Serial Ata Interface

    4.0 Serial ATA Interface These drives use the industry-standard Serial ATA (SATA) interface that supports FIS data transfers. It supports ATA programmed input/output (PIO) modes 0 to 4; multiword DMA modes 0 to 2, and Ultra DMA modes 0 to 6. For detailed information about the Serial ATA interface, refer to the “Serial ATA: High Speed Serialized AT Attachment”...
  • Page 30: Supported Ata Commands

    Serial ATA Interface www.seagate.com Table 6 Serial ATA connector pin definitions (continued) Segment Pin Function Definition 3.3V power 3.3V power 3.3V power, pre-charge, 2nd mate Ground 1st mate Ground 2nd mate Ground 2nd mate 5V power, pre-charge, 2nd mate 5V power...
  • Page 31 Serial ATA Interface Table 7 Supported ATA commands (continued) Command name Command code (in hex) Device Configuration Identify / C2 Device Configuration Restore / C0 Device Configuration Set / C3 Device Reset Download Microcode Execute Device Diagnostics Flush Cache...
  • Page 32 Serial ATA Interface www.seagate.com Table 7 Supported ATA commands (continued) Command name Command code (in hex) Security Erase Prepare Security Erase Unit Security Freeze Security Set Password Security Unlock Seek Set Features Set Max Address Note: Individual Set Max Address...
  • Page 33: Identify Device Command

    Serial ATA Interface Table 7 Supported ATA commands (continued) Command name Command code (in hex) Write Multiple Write Multiple Extended Write Multiple FUA Extended Write Sectors Write Sectors Without Retries Write Sectors Extended Write Stream DMA Extended Write Stream Extended Write Uncorrectable 4.3.1 Identify Device command...
  • Page 34 Serial ATA Interface www.seagate.com Table 8 Identify Device commands (continued) Word Description Value (Bits 7–0) Maximum sectors per interrupt on Read multiple and 8010 Write multiple (16) Reserved 0000 Standard Standby timer, IORDY supported and may be disabled 2F00 ATA-reserved...
  • Page 35 Serial ATA Interface Table 8 Identify Device commands (continued) Word Description Value Minor version number 0028 Command sets supported 346B Command sets supported 7D69 Command sets support extension 4133 See Word 108-111 (see note following this table) note. (4133...
  • Page 36 Serial ATA Interface www.seagate.com Automatic Acoustic Management (AAM) features are not supported. Note See the bit descriptions below for words 63, 84, and 88 of the Identify Drive data. Note Table 9 Bit Descriptions Description (if bit is set to 1) Word 63 Multiword DMA mode 0 is supported.
  • Page 37: Set Features Command

    Serial ATA Interface Table 9 Bit Descriptions (continued) Ultra DMA mode 6 is supported. Ultra DMA mode 0 is currently active. Ultra DMA mode 1 is currently active. Ultra DMA mode 2 is currently active. Ultra DMA mode 3 is currently active.
  • Page 38: Commands

    Serial ATA Interface www.seagate.com Table 10 Set Features command values (continued) 07H PUIS feature set device spin-up Enable use of SATA features Disable read look-ahead (read cache) feature. Disable write cache. Disable the PUIS feature set. Disable use of SATA features.
  • Page 39 Index Electrostatic discharge 20 Electrostatic discharge (ESD) 25 ACA 22 EN 55022, Class B 21 Acceleration 19 EN 55024 21 Acoustics 20 EN60950 21 Active 17 Enclosures 22 Active mode 17 Environmental specifications 18 Agency certification 21 EPRML 9 Altitude 18 Error-correction algorithms 9 Ambient temperature 14 ESD 25...
  • Page 40 Read Verify Sectors Without Retries 31 Read/write heads 13 Latency 14 Read/write power 15 LBA mode 13 Recalibrate 31 Length 14 Recording density 13 Logical geometry 13 Recording method 13 Recording technology 13 Relative humidity 18 Master/slave 10 Reliability 21 Mounting 26 RF 20 Mounting screws 19...
  • Page 41 Standby mode 15 Standby timer 17 Standby to Ready 14 Start/stop times 14 Static-discharge 25 Subassembly 22 Surge immunity 20 Temperature 14 Temperature gradient 18 Timer 17 Timers 17 Track density 13 Track-to-track 14 Track-to-track seek time 14 Tunneling magnetoresistive (TMR) recording heads 9 UL60950-1 21 Vibration 19 Voltage 15...
  • Page 42 Video 3.5 HDD Product Manual, Rev. H...
