Panasonic EXC24CE/CF Manual

Common Mode Noise Filters
EXC24CE/CF type
Features
● Elimination of radiation noises from high-speed differential transmissions
● Strong multilayer structure, excellent reflow resistance and high mounting reliability
● Magnetic shield type with no leakage
● High-Q impedance : EXC24CF
● Small and thin（L 1.25 mm×W 1.00 mm×H 0.50 mm）
● RoHS compliant
Recommended applications
● AV equipment (LCD-TV, DVD/Blu-ray drives), Information equipment (PCs, HDD, Printers),
Communications equipment (Mobile phones, Smartphones)
● Noise suppression of high-speed differential data lines such as USB 2.0 and LVDS
Explanation of part numbers
1 2
E X
Product code Code Dimensions (mm)
Noise filter
1.25×1.00×0.50
2
(L)×(W)×(H)
Construction
Ferrite
Electrode
Dimensions in mm (not to scale)
Part No.
(inch size)
EXC24CE (0504)
1.25 ± 0.15
EXC24CF (0504)
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
3 4 5
C 2 4
Number of
terminals
4 Terminals
Inner conductor
C
B
A B
1.00 ± 0.15
6 7 8
C E 9
Code Type Code Characteristics
High speed
Coupled
C
Differential
type
E
transmission
(for Mbps)
High speed
Differential
F
transmission
(for Mbps)
High-Q type
Circuit configuration (No polarity)
※ The pin numbers shown here are for reference purposes only.
E
D
F
A
Dimensions
C D
0.50 ± 0.10 0.20 ± 0.15
9 10 11
0 0 U
Nominal impedance
The first two digits are
significant figure of
impedance value, and
the third one denotes
the number of zeros
following.
4 3 4 3
1 2 1 2
E F
0.55 ± 0.10 0.30 ± 0.10
12
Suffix
Code Packing form
Embossed
carrier taping
U
4 mm pitch,
5,000 pcs
Mass (Weight)
(mg/ pc.)
3.0
20-Jan-23
