Pro Range Oven
Pro Range Oven
MODEL:
DOP36M86DL* / DOP48M86DL*
MODEL CODE: DOP36M86DL* / DOP48M86DL*
CONTENTS
1. PRECAUTIONS ··········································5
2. PRODUCT SPECIFICATIONS ·····················9
3. DISASSEMBLY AND REASSEMBLY ········18
4. PCB DIAGRAM / WIRING DIAGRAMS ····73
5. TROUBLESHOOTING ······························88
PRO RANGE RANGETOP
8" STEAM OVEN
0" BASIC OVEN FOR 48" PRO RANGE
30" STEAM OVEN
6. REFERENCE ········································ 120
FOR 36" PRO RANGE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DOP36M86DL Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dacor DOP36M86DL Series

Summary of Contents for Dacor DOP36M86DL Series

  • Page 1 Pro Range Oven MODEL: DOP36M86DL* / DOP48M86DL* MODEL CODE: DOP36M86DL* / DOP48M86DL* Pro Range Oven CONTENTS 1. PRECAUTIONS ··········································5 2. PRODUCT SPECIFICATIONS ·····················9 3. DISASSEMBLY AND REASSEMBLY ········18 4. PCB DIAGRAM / WIRING DIAGRAMS ····73 5. TROUBLESHOOTING ······························88 PRO RANGE RANGETOP 8”...

  • Page 2: Important Safety Notice

    Any attempt to repair a major appliance may result in personal injury and property damage. The manufacturer or dealer cannot be responsible for the interpretation of this information. Dacor Technical Service Guide Copyright ©2017...

  • Page 3: Table Of Contents

    Contents 1. Precaution ....................5 1-1 Forward .
  • Page 4 Contents 4. PCB Diagrams / Wiring Diagrams ............... . . 73 4-1 36”...

  • Page 5: Precaution

    1-1 Forward This Dacor Service Manual, “Built in electric wall oven” provides the technician with information on the operation and service of the built in electric wall oven. It is to be used as a training Service Manual. For specific information on the model being serviced, refer to the “Owner’s Manual”...

  • Page 6: Important Safety Instructions

    This document can not be used without Samsung’s authorization. 1. Precaution 1-3 Important Safety Instructions Read and follow all instructions before using or servicing the range to prevent death, personal injury, fire, explosion, and/or property damage. This guide does not cover every possible condition that may occur. For further assistance, contact a licensed technician or the manufacturer.

  • Page 7: Surface Burners

    This document can not be used without Samsung’s authorization. 1. Precaution SURFACE BURNERS • Use Proper Pan Size – This appliance is equipped with CAUTION one or more surface burners of different sizes. Select utensils having flat bottoms large enough to cover Do not store items of interest to children in the surface burner flames.

  • Page 8: Self-Clean Ovens

    This document can not be used without Samsung’s authorization. 1. Precaution SELF-CLEAN OVENS • Important Instruction – In the event the self-clean mode “F” code goes on or three long beeps sound, the oven is malfunctioning in the self-clean mode. Turn off or disconnect appliance from electrical and CAUTION gas supplies and have the appliance serviced by a...

  • Page 9: Pro Range 36"(Dop36M86Dl*)

    This document can not be used without Samsung’s authorization. 2-1 Pro range 36” (DOP36M86DL*) Modernist Pro range Model DOP36M86DL* Overall Colour *=S → Stainless Steel / *=M → Matte Black Control Type – Oven Touch + POP up Display (auto) Display Type 7”...
  • Page 10 This document can not be used without Samsung’s authorization. Modernist Pro range Model DOP36M86DL* Broil Heater 4,400 W Convection Heater 1,300 W + 1,300 W Convection Fan Steam Heater 500 W / 120 V Rack Position Interior Lamp New Halogen (yellow feel), 2 (VueLight™) Oven Steam Type...

  • Page 11: Pro Range 48"(Dop48M86Dl*)

    This document can not be used without Samsung’s authorization. 2-2 Pro range 48” (DOP48M86DL*) Modernist Pro range Model DOP48M86DL* Overall Colour *=S → Stainless Steel / *=M → Matte Black Control Type – Oven Touch + POP up Display (auto) Display Type 7”...
  • Page 12 This document can not be used without Samsung’s authorization. Modernist Pro range Model DOP48M86DL* 18”Steam oven DOP48M86DL* 30”Steam oven Broil Heater 2,400 W 4,400 W Convection Heater 2,000 W 1,300 W + 1,300 W Convection Fan Steam Heater 2,000 W Rack Position Interior Lamp New Halogen (yellow feel), 1...

  • Page 13: Accessory (48"Prorange (Dop48M86Dl*))

    This document can not be used without Samsung’s authorization. Center : DG98-01471A Grates Left : DG98-01468A Right : DG98-01470A Burner heads / caps Wire Racks DG67-00149A DG94-01849A Temp. Probe DG94-00674B ASSY WIRE RACK DG94-01747B...
  • Page 14 This document can not be used without Samsung’s authorization. WOK Ring DG98-01472A ASSY BRACKET DG94-05084A...

  • Page 15: Accessory For Steam Oven (48"Prorange (Dop48M86Dl*))

    This document can not be used without Samsung’s authorization. 2-4 Accessory For steam oven (48” Prorange (DOP48M86DL*)) Item Description Code No. Q’ty Small rack DG67-00166A Steam Tray DG63-00512A Half steam tray DG63-00513A...

  • Page 16: Accessory (36"Prorange (Dop36M86Dl*))

    This document can not be used without Samsung’s authorization. Center : DG98-02345A Grates Left : DG98-01468A Right : DG98-01469A Burner heads / caps Wire Racks DG67-00149A DG94-01849A Temp. Probe DG94-00674B Glide Racks DG94-01747A...
  • Page 17 This document can not be used without Samsung’s authorization. Item Description Code No. Q’ty WOK Ring DG98-01472A ASSY BRACKET DG94-05084A...

  • Page 18: Disassembly And Reassembly

    This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly WARNING ELECTRICAL SHOCK HAZARD Disconnect power before servicing the oven. Replace all panels before operating oven. Failure to do so can result in death or electrical shock. 3-1 Preparation for Pro range removal Item How to use Pictures...

  • Page 19: Oven Door

    This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-2 Oven Door WARNING ELECTRICAL SHOCK HAZARD Disconnect power before servicing the range. Replace all panels before operating the range. Failure to do so can result in death or electrical shock. WARNING EXPLOSION, FIRE, AND ASPHYXIATION HAZARD Shut off the gas supply to the range before servicing.
  • Page 20 This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-2 Oven Door Parts Explanation Photo Explanation To replace door Firmly grasp both sides of the door at the top. Fully open the door. Note. If the door will not fully open, it means that the indentation Oven Door is not seated correctly in the...

  • Page 21: Removing Gasket-Door

    This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-3 Removing Gasket-Door WARNING ELECTRICAL SHOCK HAZARD Disconnect power before servicing the range. Replace all panels before operating the range. Failure to do so can result in death or electrical shock. WARNING EXPLOSION, FIRE, AND ASPHYXIATION HAZARD Shut off the gas supply to the range before servicing.

  • Page 22: Disassemble Rangetop

    This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-4 Disassemble RangeTop WARNING ELECTRICAL SHOCK HAZARD Disconnect power before servicing the range. Replace all panels before operating the range. Failure to do so can result in death or electrical shock. WARNING EXPLOSION, FIRE, AND ASPHYXIATION HAZARD Shut off the gas supply to the range before servicing.
  • Page 23 This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-4 Disassemble RangeTop Parts Explanation Photo Explanation Remove 2 screws from the front side of each side trim. Side trim Remove 3 screws from the outer side of each side trim, and remove side trim.
  • Page 24 This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-4 Disassemble RangeTop WARNING ELECTRICAL SHOCK HAZARD Disconnect power before servicing the range. Replace all panels before operating the range. Failure to do so can result in death or electrical shock. WARNING EXPLOSION, FIRE, AND ASPHYXIATION HAZARD Shut off the gas supply to the range before servicing.
  • Page 25 This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-4 Disassemble RangeTop Parts Explanation Photo Explanation Remove 2 screws from each side of rangetop. Side trim Lift the rangetop from the prorange with more than 2 members. Note.

  • Page 26: Disassemble Frame Cooktop

    This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-5 Disassemble Frame cooktop WARNING ELECTRICAL SHOCK HAZARD Disconnect power before servicing the range. Replace all panels before operating the range. Failure to do so can result in death or electrical shock. WARNING EXPLOSION, FIRE, AND ASPHYXIATION HAZARD Shut off the gas supply to the range before servicing.
  • Page 27 This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-5 Disassemble Frame cooktop Parts Explanation Photo Explanation Remove 4 ring type nuts from the burner cup by special tool Burner cup Remove 3 screws from the burner cup Remove 3 screws from the frame rear Burner cup and remove frame rear...
  • Page 28 This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-5 Disassemble Frame cooktop Parts Explanation Photo Explanation Remove 2 screws from the frame left / right. Frame left / right Remove the frame left / right. Remove 4 screws from the frame front Frame front and lift up frame front...
  • Page 29 This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-5 Disassemble Frame cooktop Parts Explanation Photo Explanation Disconnect 3 wire housing under the frame front Remove the frame front Push the frame cooktop under the Frame cooktop cooktop and lift up the frame cooktop...

  • Page 30: Disassemble Assy Panel Control

    This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-6 Disassemble Assy panel control Parts Explanation Photo Explanation Remove 2 screws from the trim up left side. Remove 2 screws from the trim up right Triim up side Remove the trim up.

  • Page 31: Disassembly And Reassembly

    This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-6 Disassemble Assy panel control Parts Explanation Photo Explanation Remove all tubes from each valves. Remove 2 screws from the trim up right side Assy panel control Disconnect all of wire harness.
  • Page 32 This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-6 Disassemble Assy panel control Parts Explanation Photo Explanation Remove the knob Remove 2 screws from knob holder Holder knob Pull slightly knob holder griddle Disconnect the LED wire.
  • Page 33 This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-6 Disassemble Assy panel control Parts Explanation Photo Explanation Remove 2 screws from the Assy panel control side (left/right) Assy panel control Remove assy panel control...

  • Page 34: Disassemble Pop-Up Display

    This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-7 Disassemble POP-up display Parts Explanation Photo Explanation Remove 2 screws from the Assy panel control side (left/right) Assy control (pop-up display) Remove 2 screws from the POP-up display eash side.

  • Page 35: Disassemble Pcb / Electric Parts (Rangetop)

    This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-8 Disassemble PCB / Electric parts (RangeTop) WARNING ELECTRICAL SHOCK HAZARD Disconnect power before servicing the range. Replace all panels before operating the range. Failure to do so can result in death or electrical shock. WARNING EXPLOSION, FIRE, AND ASPHYXIATION HAZARD operating the range.
  • Page 36 This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-8 Disassemble PCB / Electric parts (RangeTop) Parts Explanation Photo Explanation Remove screws from the PCB and replacing it.

  • Page 37: Disassemble Tube / Burners / Valves / Etc

    This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-9 Disassemble tube / burners / valves / etc WARNING ELECTRICAL SHOCK HAZARD Disconnect power before servicing the range. Replace all panels before operating the range. Failure to do so can result in death or electrical shock.
  • Page 38 This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-9 Disassemble tube / burners / valves / etc Parts Explanation Photo Explanation Disconnect all tubes from the assy valve. Assy valve Replace assy valve after remove 1 screw by ¼”...

  • Page 39: Disassemble Oven

    This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-10 Disassemble Oven WARNING ELECTRICAL SHOCK HAZARD Disconnect power before servicing the range. Replace all panels before operating the range. Failure to do so can result in death or electrical shock. WARNING EXPLOSION, FIRE, AND ASPHYXIATION HAZARD Shut off the gas supply to the range before servicing.
  • Page 40 This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-10 Disassemble Oven Parts Explanation Photo Explanation Remove 3 screws from the bottom chassis. Bottom chassis Remove the bottom chassis...
  • Page 41 This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-10 Disassemble Oven Parts Explanation Photo Explanation Remove 1 screw from the bottom of the front trim Front trim Inter-oven panel Remove the front trim and inter-onve panel Disconnect 1 wire connector on the rear side of the range.
  • Page 42 This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-10 Disassemble Oven Parts Explanation Photo Explanation Remove 2 screws from the lower bracket and bracket. Remove 3 screws from the front bottom of steam oven. Remove 4 screws from the rear bottom side of steam oven.
  • Page 43 This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-10 Disassemble Oven Parts Explanation Photo Explanation Remove 3 screws from the front bottom side of steam oven. Lift the steam oven from the base part with more than 2 members.
  • Page 44 This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-10 Disassemble Oven Parts Explanation Photo Explanation Remove 3 screws from the bottom trim of basic oven and remove bottom trim. Remove 3 screws from the rear bottom side of basic oven and remove bracket also.
  • Page 45 This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-10 Disassemble Oven Parts Explanation Photo Explanation Remove 3 screws from the bottom trim of basic oven and remove bottom trim. Lift the basic oven from the base part with more than 2 members.

  • Page 46: Replacing Temp Probe In 18" Steam Oven (48" Prorange)

    This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-11 Replacing temp probe in 18” steam oven (48” Prorange) WARNING ELECTRICAL SHOCK HAZARD Disconnect power before servicing the range. Replace all panels before operating the range. Failure to do so can result in death or electrical shock.

  • Page 47: Replacing Lamp Part In 18" Steam Oven (48" Prorange)

    This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-12 Replacing lamp part in 18” steam oven (48” Prorange) WARNING ELECTRICAL SHOCK HAZARD Disconnect power before servicing the range. Replace all panels before operating the range. Failure to do so can result in death or electrical shock.

  • Page 48: Replacing Pcb Part In 18" Steam Oven (48" Prorange)

    This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-13 Replacing PCB part in 18” steam oven (48” Prorange) WARNING ELECTRICAL SHOCK HAZARD Disconnect power before servicing the range. Replace all panels before operating the range. Failure to do so can result in death or electrical shock.
  • Page 49 This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-13 Replacing PCB part in 18” steam oven (48” Prorange) Parts Explanation Photo Explanation Lift up the case up. PCB Parts Replacing PCB part.

  • Page 50: Replacing Cooling Motor In 18" Steam Oven (48" Prorange)

    This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-14 Replacing cooling Motor in 18” steam oven (48” Prorange) WARNING ELECTRICAL SHOCK HAZARD Disconnect power before servicing the range. Replace all panels before operating the range. Failure to do so can result in death or electrical shock.
  • Page 51 This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-14 Replacing cooling Motor in 18” steam oven (48” Prorange) Parts Explanation Photo Explanation Remove 4 screws from the cover back. Disassemble cover back. Cooling motor Disassemble 2 screw from the bottom of cooling motor, and replacing cooling motor.

  • Page 52: Replacing Broil Heater In 18" Steam Oven (48" Prorange)

    This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-15 Replacing Broil heater in 18” steam oven (48” Prorange) WARNING ELECTRICAL SHOCK HAZARD Disconnect power before servicing the range. Replace all panels before operating the range. Failure to do so can result in death or electrical shock.

  • Page 53: Replacing Convection Fan In 18" Steam Oven (48" Prorange)

    This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-16 Replacing convection fan in 18” steam oven (48” Prorange) WARNING ELECTRICAL SHOCK HAZARD Disconnect power before servicing the range. Replace all panels before operating the range. Failure to do so can result in death or electrical shock.

  • Page 54: Replacing Convection Heater In 18" Steam Oven (48" Prorange)

    This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-17 Replacing convection heater in 18” steam oven (48” Prorange) WARNING ELECTRICAL SHOCK HAZARD Disconnect power before servicing the range. Replace all panels before operating the range. Failure to do so can result in death or electrical shock.

  • Page 55: Replacing Assy Steamer In 18" Steam Oven (48" Prorange)

    This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-18 Replacing assy steamer in 18” steam oven (48” Prorange) WARNING ELECTRICAL SHOCK HAZARD Disconnect power before servicing the range. Replace all panels before operating the range. Failure to do so can result in death or electrical shock.
  • Page 56 This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-18 Replacing assy steamer in 18” steam oven (48” Prorange) Parts Explanation Photo Explanation Remove 4 screws from steam generator each side. Steam generator Disconnect wires and tubes then replacing steam generator.

  • Page 57: Replacing Bake Heater In 18" Steam Oven (48" Prorange)

    This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-19 Replacing bake heater in 18” steam oven (48” Prorange) WARNING ELECTRICAL SHOCK HAZARD Disconnect power before servicing the range. Replace all panels before operating the range. Failure to do so can result in death or electrical shock.

  • Page 58: Replacing Pcb Part In 30" Basic Oven (48" Prorange)

    This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-20 Replacing PCB part in 30” basic oven (48” Prorange) WARNING ELECTRICAL SHOCK HAZARD Disconnect power before servicing the range. Replace all panels before operating the range. Failure to do so can result in death or electrical shock.
  • Page 59 This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-20 Replacing PCB part in 30” basic oven (48” Prorange) Parts Explanation Photo Explanation Lift up the case up and disconnect wire. PCB Parts Replacing PCB main, SMPS, EMI filter...

  • Page 60: Replacing Broil Heater In 30" Basic Oven (48" Prorange)

    This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-21 Replacing Broil heater in 30” basic oven (48” Prorange) WARNING ELECTRICAL SHOCK HAZARD Disconnect power before servicing the range. Replace all panels before operating the range. Failure to do so can result in death or electrical shock.

  • Page 61: Replacing Bake Heater In 30" Basic Oven (48" Prorange)

    This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-22 Replacing bake heater in 30” basic oven (48” Prorange) WARNING ELECTRICAL SHOCK HAZARD Disconnect power before servicing the range. Replace all panels before operating the range. Failure to do so can result in death or electrical shock.
  • Page 62 This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-22 Replacing bake heater in 30” basic oven (48” Prorange) Parts Explanation Photo Explanation Remove 1 screw from back side of bake heater. Bake heater Pull the bake heater and replacing it.

  • Page 63: Replacing Convection Fan In 30" Basic Oven (48" Prorange)

    This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-23 Replacing convection fan in 30” basic oven (48” Prorange) WARNING ELECTRICAL SHOCK HAZARD Disconnect power before servicing the range. Replace all panels before operating the range. Failure to do so can result in death or electrical shock.

  • Page 64: Replacing Convection Heater In 30" Basic Oven (48" Prorange)

    This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-24 Replacing convection heater in 30” basic oven (48” Prorange) WARNING ELECTRICAL SHOCK HAZARD Disconnect power before servicing the range. Replace all panels before operating the range. Failure to do so can result in death or electrical shock.

  • Page 65: Replacing Temp Probe In 30" Basic Oven (48" Prorange)

    This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-25 Replacing temp probe in 30” basic oven (48” Prorange) WARNING ELECTRICAL SHOCK HAZARD Disconnect power before servicing the range. Replace all panels before operating the range. Failure to do so can result in death or electrical shock.
  • Page 66 This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-25 Replacing temp probe in 30” basic oven (48” Prorange) Parts Explanation Photo Explanation Disconnect temp probe. Temp probe Disassemble by tubing wrench and replacing temp probe part.

  • Page 67: Replacing Pcb Parts In 30" Steam Oven (36" Prorange)

    This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-26 Replacing PCB parts in 30” steam oven (36” Prorange) WARNING ELECTRICAL SHOCK HAZARD Disconnect power before servicing the range. Replace all panels before operating the range. Failure to do so can result in death or electrical shock.
  • Page 68 This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-26 Replacing PCB parts in 30” steam oven (36” Prorange) WARNING ELECTRICAL SHOCK HAZARD Disconnect power before servicing the range. Replace all panels before operating the range. Failure to do so can result in death or electrical shock.

  • Page 69: Replacing Steam Set In 30" Steam Oven (36" Prorange)

    This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-27 Replacing steam set in 30” steam oven (36” Prorange) WARNING ELECTRICAL SHOCK HAZARD Disconnect power before servicing the range. Replace all panels before operating the range. Failure to do so can result in death or electrical shock.

  • Page 70: Replacing Assy Steamer In 30" Steam Oven (36" Prorange)

    This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-28 Replacing assy steamer in 30” steam oven (36” Prorange) WARNING ELECTRICAL SHOCK HAZARD Disconnect power before servicing the range. Replace all panels before operating the range. Failure to do so can result in death or electrical shock.
  • Page 71 This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-28 Replacing assy steamer in 30” steam oven (36” Prorange) Parts Explanation Photo Explanation Remove 4 screws from steam generator each side. Steam generator Disconnect wires and tubes then replacing steam generator.

  • Page 72: Motor Ac Pump

    This document cannot be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-29 Motor AC Pump WARNING ELECTRICAL SHOCK HAZARD Disconnect power before servicing the range. Replace all panels before operating the range. Failure to do so can result in death or electrical shock. Parts Explanation Photo Explanation...

  • Page 73: Pcb Diagrams / Wiring Diagrams

    This document can not be used without Samsung’s authorization. 4. PCB Diagrams / Wiring Diagrams 4. PCB Diagrams / Wiring Diagrams 4-1 36” / 48” pro range - rangetop pcb diagram / schematic diagram (LCD SUB) Parts Number Part Name Function and Rule CNS170 HASS Connector...

  • Page 74: 36" / 48" Pro Range - Rangetop Pcb Diagram / Schematic Diagram (Dimming)

    This document can not be used without Samsung’s authorization. 4. PCB Diagrams / Wiring Diagrams 4-2 36” / 48” pro range - rangetop pcb diagram / schematic diagram (DIMMING) Parts Number Part Name Function and Rule Sub Communication Connector This is connector which is connected with LCD SUB PCB to communicate. Knob Light Connector This is connector which is connected with 4th, 5th Knob Light module.

  • Page 75: 36" / 48" Rangetop Control Pcb

    This document can not be used without Samsung’s authorization. 4. PCB Diagrams / Wiring Diagrams 4-3 36” / 48” rangetop control pcb Parts Number Part Name Function and Rule CNS170 HASS Connector This is connector for HASS. CNS200 Main Communication Connector This is connector which is connected with Main PCB to communicate.
  • Page 76 This document can not be used without Samsung’s authorization. 4. PCB Diagrams / Wiring Diagrams 4-3 36” / 48” rangetop control pcb Parts Number Part Name Function and Rule Sub Communication Connector This is connector which is connected with LCD SUB PCB to communicate. Knob Light Connector This is connector which is connected with 4th, 5th Knob Light module.

  • Page 77: 48" Rangetop Schematic Diagram

    This document can not be used without Samsung’s authorization. 4. PCB Diagrams / Wiring Diagrams 4-4 48” rangetop schematic diagram...

  • Page 78: 36" Rangetop Schematic Diagram

    This document can not be used without Samsung’s authorization. 4. PCB Diagrams / Wiring Diagrams 4-5 36” rangetop schematic diagram...

  • Page 79: 18" Steam Oven Pcb Diagrams / Schematic Diagram (For 48" Pro Range)

    This document can not be used without Samsung’s authorization. 4. PCB Diagrams / Wiring Diagrams 4-6 18” Steam oven pcb diagrams / schematic diagram (for 48” pro range) 26 27 28 Parts Number Part Name Function and Rule RY201 RY-Source Relay This is relay which control source of DLB, Bake, Broil relay.
  • Page 80 This document can not be used without Samsung’s authorization. 4. PCB Diagrams / Wiring Diagrams Parts Number Part Name Function and Rule CN204 Relay Connector WATER PUMP, DRAIN PUMP CN203 Relay Connector CONV FAN, OVEN LAMP, DOOR LOCK, AC120V_LINE WATER TANK MOTOR-CW, WATER TANK MOTOR-CCW, PYROFREE-PUMP2, LIVE (Not use in this CN200 Relay Connector model)

  • Page 81: 48" Prorange Small Cavity Schematic Diagram

    This document can not be used without Samsung’s authorization. 4. PCB Diagrams / Wiring Diagrams 4-7 48” prorange small cavity schematic diagram...

  • Page 82: 30" Basic Oven Pcb Diagrams / Schematic Diagram (For 48" Pro Range)

    This document can not be used without Samsung’s authorization. 4. PCB Diagrams / Wiring Diagrams 4-8 30” basic oven pcb diagrams / schematic diagram (for 48” pro range) 26 27 28 Parts Number Part Name Function and Rule RY201 RY-Source Relay This is relay which control source of DLB, Bake, Broil, Warming Drawer relay.
  • Page 83 This document can not be used without Samsung’s authorization. 4. PCB Diagrams / Wiring Diagrams Parts Number Part Name Function and Rule T211 Steam Heater This is connector which is connected with Steam Heater. (use only in 36” model) T210 Convection Heater This is connector which is connected with Convection Heater.

  • Page 84: 48" Prorange Bigl Cavity Schematic Diagram

    This document can not be used without Samsung’s authorization. 4. PCB Diagrams / Wiring Diagrams 4-9 48” prorange bigl cavity schematic diagram NOTE COLOR HEATING ELECMENTS CIRCUIT SHOWN WITH ALL CONTROL BLUE COMPONENTS INPUT WATTAGE SET TO OFF BLACK ORANGE BROIL HEATER 240 V 2400 W...

  • Page 85: 30" Steam Oven Pcb Diagram / Schematic Diagram (For 36" Pro Range)

    This document can not be used without Samsung’s authorization. 4. PCB Diagrams / Wiring Diagrams 4-10 30” steam oven pcb diagram / schematic diagram (for 36” pro range) 26 27 28 Parts Number Part Name Function and Rule RY201 RY-Source Relay This is relay which control source of DLB, Bake, Broil, Warming Drawer relay.
  • Page 86 This document can not be used without Samsung’s authorization. 4. PCB Diagrams / Wiring Diagrams Parts Number Part Name Function and Rule T211 Steam Heater This is connector which is connected with Steam Heater. (use only in 36” model) T210 Convection Heater This is connector which is connected with Convection Heater.

  • Page 87: 36" Prorange Big Cavity Schematic Diagram

    This document can not be used without Samsung’s authorization. 4. PCB Diagrams / Wiring Diagrams 4-11 36” prorange big cavity schematic diagram...

  • Page 88: Troubleshooting - 36" / 48" Pro Range - Rangetop

    This document can not be used without Samsung’s authorization. 5. Troubleshooting ― 36” / 48” pro range - rangetop 5. Troubleshooting ― 36” / 48” pro range - rangetop 5-1 Error Trouble Shooting Symptom Diagnosis Remedy * Plug in the power cord and/or reset the * Smell Gas but no spark ignition.
  • Page 89 This document can not be used without Samsung’s authorization. 5. Troubleshooting ― 36” / 48” pro range - rangetop 5-1 Error Trouble Shooting Symptom Diagnosis Remedy * Soft blue flames are normal flames for Cooktop burner NG operation. flames are soft * This is normal.
  • Page 90 This document can not be used without Samsung’s authorization. 5. Troubleshooting ― 36” / 48” pro range - rangetop 5-1 Error Trouble Shooting Symptom Diagnosis Remedy * If no voltage is measured, replace the All cooktop * Check the terminals on the SMPS for voltage. SMPS PCB.

  • Page 91: Control Parts

    This document can not be used without Samsung’s authorization. 5. Troubleshooting ― 36” / 48” pro range - rangetop 5-2 Control parts 5-2-1 knob LED does not light up Not light Make sure that power cord is Insert the power cord connected Check the voltage of the Power Replace the Power cord.
  • Page 92 This document can not be used without Samsung’s authorization. 5. Troubleshooting ― 36” / 48” pro range - rangetop 5-2-2 Cooktop burner not lighted [Gas malfunction] None of the cooktop burners will light Make sure the gas supply valve Fully open the gas supply valve. to the cooktop is fully open.
  • Page 93 This document can not be used without Samsung’s authorization. 5. Troubleshooting ― 36” / 48” pro range - rangetop 5-2-3 Cooktop burner not lighted [Electric malfunction] No cooktop Burners will light Plug in the power cord and Make sure there is power to or reset the circuit breaker for the the cooktop range.
  • Page 94 This document can not be used without Samsung’s authorization. 5. Troubleshooting ― 36” / 48” pro range - rangetop 5-2-4 One cooktop burner not lighted [Electric malfunction] One cooktop burner will not light. Check whether the burner head Assemble the burner head and and cap is properly assembled.
  • Page 95 This document can not be used without Samsung’s authorization. 5. Troubleshooting ― 36” / 48” pro range - rangetop 5-2-5 Gas Leak Gas Leak Still smell Turn off the cooktop valve and main Evacuate everyone from the shut off valve and check if there is building and call your gas supplier from a neighbor’s phone.
  • Page 96 This document can not be used without Samsung’s authorization. 5. Troubleshooting ― 36” / 48” pro range - rangetop 5-2-6 The flame looks abnormal. [Yellow tip / Lift flame] Check whether the burner heads Place the burner heads and and caps are properly caps properly.
  • Page 97 This document can not be used without Samsung’s authorization. 5. Troubleshooting ― 36” / 48” pro range - rangetop 5-2-7 Flame size is too big or too small Flame size is too big or small Regulate the pressure supplied Check the manifold pressure and to the regulator refer to the table line pressure whether it is normal.

  • Page 98: Troubleshooting - 18" Steam Oven

    This document can not be used without Samsung’s authorization. 6. Troubleshooting ― 18” Steam oven 6. Troubleshooting ― 18” Steam oven 6-1 Parts Checking Method FIGURE TESTS MEASURE RESULTS Measure resistance values of Approx : 22 ~ 25Ω heater’s terminal after taking off (at the room temperature) harness from heater.
  • Page 99 This document can not be used without Samsung’s authorization. 6. Troubleshooting ― 18” Steam oven 6-1 Parts Checking Method FIGURE TESTS MEASURE RESULTS First of all, make sure that lamp filament is disconnected or not. Approx : ∞Ω Measure resistance socket’s terminal Terminal voltage of lamp socket : after separating harness from heater 120V...
  • Page 100 This document can not be used without Samsung’s authorization. 6. Troubleshooting ― 18” Steam oven 6-1 Parts Checking Method FIGURE TESTS MEASURE RESULTS Check whether the resistance values of oven sensor is same with a chart’s Approx one . at the room temperature :1080Ω . Check whether wire or housing has been loosen or disconnected .
  • Page 101 This document can not be used without Samsung’s authorization. 6. Troubleshooting ― 18” Steam oven 6-2 Sensor Failure code CAUSE SOLUTION Check whether connector at the main pcb Oven sensor opened has been inserted. Check whether connector at the sensor has been inserted.
  • Page 102 This document can not be used without Samsung’s authorization. 6. Troubleshooting ― 18” Steam oven 6-2 Sensor Failure code CAUSE SOLUTION Check whether connector at the main pcb has been inserted. Check whether connector at the sensor has The steam sensor is open when the steam been inserted.

  • Page 103: Display-Failure

    This document can not be used without Samsung’s authorization. 6. Troubleshooting ― 18” Steam oven 6-3 Display-Failure Safety error "C-20" Disconnect power Measure sensor resistance. Replace oven sensor (1080Ω at the room temperature) Check the connecting condition of harness (Oven sensor and CN320 of main PCB) * reconnect * repair damaged harness replace.
  • Page 104 This document can not be used without Samsung’s authorization. 6. Troubleshooting ― 18” Steam oven 6-3 Display-Failure "C-21" Disconnect power and Main PCB * Repair damaged circuit board or * Check the DLB, Bake and Broil relay. (Normal:∞ Ω) replace main PCB * Check main PCB for damage.
  • Page 105 This document can not be used without Samsung’s authorization. 6. Troubleshooting ― 18” Steam oven 6-3 Display-Failure "C-F0" *Disconnect power. *Unplug connectors from Sub PCB and Wall main PCB. * Repair damaged harness or replace. * Check wire harness between Wall main, and Sub PCB.
  • Page 106 This document can not be used without Samsung’s authorization. 6. Troubleshooting ― 18” Steam oven 6-3 Display-Failure Troubleshooting (Power) No Power Check terminal block voltage. Check the circuit breaker. (240V,60Hz) Check the terminal block connections Check the wiring. Replace or Repair the wiring Check the votage of PCB, SMPS -input : 120V -output : 12V,5V...

  • Page 107: Troubleshooting - 30" Basic Oven (For 48" Pro Range)

    This document can not be used without Samsung’s authorization. 7. Troubleshooting ― 30” basic oven (for 48” pro range) 7-1 Failure Display Codes There is a check code. Possible check codes during use can be checked before service. 1. Touch UPPER and LOWER for 5 seconds. Information is Cavity_1 Cavity_2 displayed on screen.
  • Page 108 This document can not be used without Samsung’s authorization. 7. Troubleshooting ― 30” basic oven (for 48” pro range) 7-2 Sensor Failure code CAUSE SOLUTION Disconnect power. Check whether harness has been connected with door lock switch and motor. Confirm whether resistance value of door lock motor is to be normal one or not.
  • Page 109 This document can not be used without Samsung’s authorization. 7. Troubleshooting ― 30” basic oven (for 48” pro range) 7-2 Sensor Failure code CAUSE SOLUTION Check the ground wire on the steam generator. The Drain system-related problem. When the water level sensor sensed Check the pump motor operation and wire C-72 the water is remained after max time...
  • Page 110 This document can not be used without Samsung’s authorization. 7. Troubleshooting ― 30” basic oven (for 48” pro range) 7-2 Sensor Failure code CAUSE SOLUTION Check whether connector of LCD sub pcb has been inserted. This code occurs if communication If there is not a problem occurred with between the wall main and TSP are connector on LCD sub pcb, replace the LCD...

  • Page 111: Display-Failure

    This document can not be used without Samsung’s authorization. 7. Troubleshooting ― 30” basic oven (for 48” pro range) 7-3 Display-Failure “C-20” Big cavity Small cavity Disconnect power Measure sensor resistance. Replace oven sensor (1080Ω at the room temperature) Check the connecting condition of harness (Oven sensor and CN320 of main PCB) * reconnect * repair damaged...
  • Page 112 This document can not be used without Samsung’s authorization. 7. Troubleshooting ― 30” basic oven (for 48” pro range) 7-3 Display-Failure “C-21” Disconnect power and Main PCB * Check the DLB, Bake and Broil relay. (Normal:∞ Ω) Repair damaged circuit board or * Check main PCB for damage.
  • Page 113 This document can not be used without Samsung’s authorization. 7. Troubleshooting ― 30” basic oven (for 48” pro range) 7-3 Display-Failure “C-d1” *Disconnect power. *Disconnect harness connected to Lock motor. * Check micro switch (com-NC => closed, when door is unlocked) Wall Main PCB * Measure resistance of Lock motor Coil.(1750~1850Ω...
  • Page 114 This document can not be used without Samsung’s authorization. 7. Troubleshooting ― 30” basic oven (for 48” pro range) 7-3 Display-Failure “C-F0” CN470 CN470 CNS200 CN460 *Disconnect power. LCD Sub PCB Wall Main PCB#1 Wall Main PCB#2 *Unplug connectors from LCD Sub PCB, Wall main PCB(s) * Replace micro switch or Lock motor.
  • Page 115 This document can not be used without Samsung’s authorization. 7. Troubleshooting ― 30” basic oven (for 48” pro range) 7-3 Display-Failure “C-F2” *Disconnect power. *Unplug connector on LCD sub pcb and TSP. CNS240 * Check wire harness between TSP and LCD sub PCB.
  • Page 116 This document can not be used without Samsung’s authorization. 7. Troubleshooting ― 30” basic oven (for 48” pro range) 7-3 Display-Failure "C-d0" * Disconnect power. * Remove keypad cable from sub PCB. * Check for shorted cable connectors and * Repair sub pcb if circuit is shorted or damaged damage to LCD pcb * Make sure whether between keypad and cable Have a short circuit.
  • Page 117 This document can not be used without Samsung’s authorization. 7. Troubleshooting ― 30” basic oven (for 48” pro range) 7-3 Display-Failure Troubleshooting (Power) No Power Check terminal block voltage. Check the circuit breaker. (240V,60Hz) Check the terminal block connections Check the wiring. Replace or Repair the wiring Check the votage of PCB, SMPS -input : 120V...

  • Page 118: Troubleshooting - 30" Steam Oven (For 36" Pro Range)

    This document can not be used without Samsung’s authorization. 8. Troubleshooting ― 30” steam oven (for 36” pro range) 8-1 Electrical Malfunction Component testing procedures WARNING ELECTRICAL SHOCK HAZARD Disconnect power before servicing the range. Replace all panels before operating range. Failure to do so can result in death or electrical shock.
  • Page 119 This document can not be used without Samsung’s authorization. 8. Troubleshooting ― 30” steam oven (for 36” pro range) 8-1 Electrical Malfunction FIGURE TESTS MEASURE RESULTS Lock motor Resistance : 1600~2200Ω (at room temperature) Measure operation of the micro voltage : 120V switch and the motor after removing wire harness from terminals.

  • Page 120: Reference

    This document can not be used without Samsung’s authorization. 9. Reference 9. Reference 9-1 Checkpoints before service request Symptom Diagnosis Remedy * check circuit breaker. * Measure an input voltage. (240/120V or 208/120V) * Make sure that the state of wire is * Measure an input voltage of terminal block.
  • Page 121 This document can not be used without Samsung’s authorization. 9. Reference 9-1 Checkpoints before service request Symptom Diagnosis Remedy * Make sure that keypad cable on LCD PCB is in * Replace after confirming whether it Keypad is not normal state. has been loosen or disconnected.
  • Page 122 Printed in Korea...
