- Page 1 Installation Manual Dual Fuel Pro Range DOP30**40D* Install_DOP30T940DS_DA_DG68-01457A_EN.indd 1 Install_DOP30T940DS_DA_DG68-01457A_EN.indd 1 2022-10-11 오전 11:36:58 2022-10-11 오전 11:36:58...
- Page 2 ANTI-TIP DEVICE WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal WARNING injury or death. • DO NOT store or use gasoline or other flammable vapors and ALL RANGES CAN TIP, RESULTING IN PERSONAL INJURY. liquids in the vicinity of this or any other appliance.
-
Page 3: Table Of Contents
Contents Before you begin Tools and materials What’s in the box About this manual Important safety information Installation instructions Read all instructions before using this appliance Installing your Dual fuel Range Symbols used in this manual California Proposition 65 Warning Commonwealth of Massachusetts General safety Fire safety... -
Page 4: Before You Begin
Before you begin Important safety information About this manual Read all instructions before using this appliance Read these instructions completely and carefully. • All electrical and gas equipment with moving parts can be dangerous. Please read the important safety instructions for this appliance in this manual. The Important note to the installer instructions must be followed to minimize the risk of injury, death, or property damage. -
Page 5: California Proposition 65 Warning
California Proposition 65 Warning • Remove all packaging materials from the range before operating to prevent ignition of these materials. Keep all packaging materials out of children’s reach. Properly dispose the packaging materials after the range is unpacked. WARNING • Do not store any object of interest to children on the cooktop or backguard Cancer and Reproductive Harm - www.P65Warnings.ca.gov. -
Page 6: Fire Safety
Important safety information Fire safety Gas safety WARNING WARNING To reduce the risk of fire, electric shock, personal injuries, and/or death, obey the To reduce the risk of fire, electric shock, personal injuries, and/or death, obey the following precautions. following precautions. •... -
Page 7: Electrical And Grounding Safety
Electrical and grounding safety Installation safety WARNING WARNING To reduce the risk of fire, electric shock, personal injuries, and/or death, obey the To reduce the risk of fire, electric shock, personal injuries, and/or death, obey the following precautions. following precautions. •... -
Page 8: Location Safety
Important safety information • Make sure your range is correctly installed and adjusted by a qualified service • Select a location where a grounded, 3- prong outlet is easily accessible. technician or installer for the type of gas (natural or LP) you will use. For •... -
Page 9: Oven Safety
• This cooktop is designed to cook with a wok or wok ring attachment. If foods Oven safety are flamed, they should only be flamed under a ventilation hood that is on. • Before removing or changing cookware, turn off the burners. WARNING •... -
Page 10: Self-Cleaning Oven Safety
Important safety information Self-cleaning oven safety Storage drawer safety WARNING WARNING To reduce the risk of fire, electric shock, personal injuries, and/or death, obey the To reduce the risk of fire, electric shock, personal injuries, and/or death, obey the following precautions. following precautions. -
Page 11: Gas Range Components
Gas range components Dual Fuel range specifications MODEL DOP30**40D* Description Dual fuel Range Overall dimensions 29 15/16 in (W) × 36 11/16 in (H) × 26 3/8 in (D) 761 mm (W) × 932 mm (H) × 669 mm (D) Electrical Refer to the rating label. -
Page 12: Installation Requirements
Installation requirements Installation requirements Location requirements 13 in (33 cm) 30 in (76.2 cm) Overhead Clearances and dimensions Cabinet Depth 30 in (76.2 cm) NOTE • For OTR over Gas Stove, please follow local GAS CODE. 30 in (76.2 cm) 4 in* 6 in* 18 in... -
Page 13: Installation Guide
Minimum dimensions Installation guide CAUTION IMPORTANT: • If overhead cabinets are installed, a range hood should also be installed To eliminate the risk of burns or fire caused by reaching over heated surface units, and project horizontally a minimum of 5" (12.7 cm) beyond the front of the avoid having cabinet storage space located above the surface units. - Page 14 Installation requirements Recommended locations for gas piping and electrical outlets Optional rear filler kit WARNING Used to fill gap between the range back and wall. Adds a filler strip to the rear of the range. This kit can only be used when the opening in the countertop is 25” deep.
-
Page 15: To Remove Safely From The Pallet
To remove safely from the pallet To avoid breakage Remove the screws from the bottom CAUTION bracket on either side of the unit. • Please DO NOT push the unit strongly when you install. These actions can cause the damage to the unit. Press the bracket on either side to pull •... -
Page 16: Gas Requirements
Installation requirements Gas requirements CAUTION Do NOT lift or handle the unit by the cooktop frame. Provide adequate gas supply The counter top around the cut-out should be flat and leveled (See hatched This range is designed to operate at a pressure of 5 in (13 cm) of water column on area on Fig. -
Page 17: Special Gas Requirements (Gas Models Sold In Massachusetts)
Special gas requirements (gas models sold in Massachusetts) Electrical requirements WARNING COMMONWEALTH OF MASSACHUSETTS REQUIREMENTS: To reduce the risk of fire, electric shock, or personal injury: WARNING All ranges Gas leaks may occur in your system, creating a dangerous situation. •... - Page 18 Installation requirements Grounding Usage situations where appliance power cord will be disconnected frequently • All ranges must be grounded for personal safety. Do not use an adapter plug in these situations because disconnecting of the power • All gas models have a power cord with an equipment-grounding conductor cord places under strain on the adapter and leads to eventual failure of the adapter and a grounding plug.
-
Page 19: Tools And Materials
Tools and materials What’s in the box NOTE • Make sure you have received all of the supplied parts shown above. • If your range was damaged during shipping or you do not have all of the Parts supplied supplied parts, contact your local retailer. Parts needed Grates (2) Burner heads (4) and... -
Page 20: Installation Instructions
Installation instructions Installation instructions Installing your Dual fuel Range Step 2. Meeting electrical connection requirements CAUTION NOTE For personal safety, do not use an extension cord with this appliance. Remove • IMPORTANT: Please read the following instructions, as well as the Important house fuse or open circuit breaker before beginning installation. - Page 21 A 50 amp range cord is not recommended but if used, it should be marked for Specified power-supply-cord kit rating use with nominal 1⅜" diameter connection openings. Care should be taken to Diameter (inches) of range center the cable and strain relief within the knockout hole to keep the edge from Range rating, watts Specified rating connection opening...
- Page 22 Installation instructions Installing a 3-wire power cord Installing a 4-wire power cord WARNING WARNING The neutral or ground wire of the power cord must be connected to the neutral The neutral wire of the supply circuit must be connected to the neutral terminal terminal located in the center of the terminal block.
- Page 23 Step 5. Installing the conduit Installing a 3-wire conduit • Aluminum building wire may be used but it must be rated for the correct Remove the conduit connection plate from the rear of the drawer body and rotate amperage and voltage to make the connection. Connect wires according to it as shown below.
- Page 24 Installation instructions Installing a 4-wire conduit Step 6. Replacing the access cover • Aluminum building wire may be used but it must be rated for the correct Replace the access cover on the range back. To replace the wire cover, insert amperage and voltage to make the connection.
- Page 25 Step 7. Connect the range to gas supply Install a manual gas line shut-off valve in the gas line in an easily accessed location outside of the range. Shut off the main gas supply valve before disconnecting the old range and leave Make sure everyone operating the range knows where and how to shut off it off until the new hookup has been completed.
- Page 26 All new ranges are shipped from the factory set up to use natural gas. Do not exceed 25 ft-lbs of torque when making gas line connections. This Dacor range can be converted to use LP gas. Overtightening may crack the pressure regulator resulting in gas leak.
- Page 27 Step 10. Plug in and place *approximately Anti-Tip WARNING ” (16.5 mm) bracket • BEFORE OPERATING OR TESTING, follow the grounding requirements on pages 17–18 in this manual. Improper connection of the grounding plug can result in a risk of electric shock. Please review "Electrical requirements"...
- Page 28 Installation instructions Step 11. Moving and placing the range If range is next to or between cabinets, make sure the cooktop (without the Due to the weight, heavy equipment surface burner grates) is level with the movers such as Air Sled should be used countertops.
- Page 29 Step 12. Assemble the surface burners Step 13. Check the ignition of surface burners Check the operation of all cooktop burners after the range has been installed and CAUTION assembled, gas supply lines have been carefully checked for leaks, and electrical Do not operate the surface burners without all burner parts in place.
- Page 30 Call Small the stem of the valve, until it hits Dacor for service. Normal burner flames Screwdriver the simmer set screw. Make sure the shall look like 1 or 2, depending on the gas screwdriver flathead is seated into the type you use.
- Page 31 4. What is your household income? Please rest assured that under no conditions will Dacor sell your name or any of the ‰ A. Under $75,000 ‰ D. $150,000 – $200,000 information on this form for mailing list purposes.
- Page 32 DG68-01457A-00 Dacor ∙ 14425 Clark Avenue, City of Industry, CA 91745 ∙ Phone: 833-35-ELITE (833-353-5483) ∙ Fax: (626) 403-3130 ∙ www.dacor.com Install_DOP30T940DS_DA_DG68-01457A_EN.indd 32 Install_DOP30T940DS_DA_DG68-01457A_EN.indd 32 2022-10-11 오전 11:37:06 2022-10-11 오전 11:37:06...
