OWNER'S MANUAL
MANUAL DEL USUARIO
Comet
Please write model number here for future reference:
Por favor, incluya el número del modelo aquí para futura refer-
encia:
ETL-ES-Comet Damp-WH25
Net Weight:
LBS
Peso Neto:
KGS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ETL-ES-Comet Damp-WH25 and is the answer not in the manual?

Questions and answers

Related Manuals for Westinghouse ETL-ES-Comet Damp-WH25

Summary of Contents for Westinghouse ETL-ES-Comet Damp-WH25

  • Page 1 ETL-ES-Comet Damp-WH25 OWNER'S MANUAL MANUAL DEL USUARIO Comet Please write model number here for future reference: Por favor, incluya el número del modelo aquí para futura refer- encia: Net Weight: Peso Neto:...

  • Page 2: Safety Tips

    ETL-ES-Comet Damp-WH25 SAFETY TIPS OBSERVE THE FOLLOWING: READ AND SAVE THESE INSTRUCTIONS WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR PERSONAL INJURY, MOUNT TO OUTLET BOX MARKED 'ACCEPTABLE FOR FAN SUPPORT OF 35 LBS (15.9 KG) OR LESS' AND USE MOUNTING SCREWS PROVIDED WITH THE OUTLET BOX AND/OR SUPPORT DIRECTLY FROM BUILDING STRUCTURE.

  • Page 3: Consejos De Seguridad

    ETL-ES-Comet Damp-WH25 CONSEJOS DE SEGURIDAD HAGA LO SIGUIENTE: LEA Y GUARDE ESTAS INSTRUCCIONES ADVERTENCIA: PARA REDUCIR EL RIESGO DE INCENDIO, DESCARGA ELÉCTRICA O HERIDAS GRAVES PERSONALES, MONTE EN UNA CAJA DE EMBUTIR ROTULADA 'ACCEPTABLE FOR FAN SUPPORT OF 35 LBS (15.9 KG) OR LESS' UTILIZANDO LOS TORNILLOS DE MONTAJE INCLUIDOS CON LA CAJA DE EMBUTIR Y/O MONTE DIRECTAMENTE EN LA ESTRUCTURA DEL EDIFICIO LA MAYORÍA DE LAS CAJAS DE EMBUTIR UTILIZADAS NORMALMENTE CON ARTEFACTOS DE ILUMINACIÓN NO SON ADECUADAS PARA VENTILADORES Y DEBERÍAN SER...
  • Page 4 ETL-ES-Comet Damp-WH25 FEATURES CARACTERÍSTICAS DOWNROD VAULTED CEILING INSTALLATION INSTALLATION INSTALACIÓN CON INSTALACIÓN PARA VARILLA VERTICAL TECHOS INCLINADOS Note: For pitched ceiling installation, please refer to westinghouselighting. com for specially designed canopy kit options. Nota: Para instalación en techos inclinados,visite westinghouselight- ing.com para obtener opciones sobre...
  • Page 5 ETL-ES-Comet Damp-WH25 PREPARING FOR INSTALLATION ANTES DE LA INSTALACIÓN Use metal outlet box suitable for fan support (must support 35 lbs). Before attaching fan to outlet box, ensure the outlet box is securely fastened by at least two points to a structural ceiling member (a loose box will cause the fan to wobble).
  • Page 6 ETL-ES-Comet Damp-WH25 MOUNTING BRACKET INSTALLATION INSTALACIÓN CON SOPORTE DE MONTAJE Remove the screws from the two mating holes (2) on the canopy. Loosen (do not remove) the screws in the mating slots (1) on the canopy. Rotate the mounting bracket and remove from the canopy.
  • Page 7 ETL-ES-Comet Damp-WH25 DOWNROD PREPARATION MOUNTING BRACKET INSTALLATION PREPARANDO LA VARILLA VERTICAL INSTALACIÓN CON SOPORTE DE MONTAJE Install mounting bracket to outlet box in ceiling using the screws and washers provided with the outlet box. Remove clamp pin (1) and cross pin (2) from downrod (3).
  • Page 8 ETL-ES-Comet Damp-WH25 NORMAL DOWNROD OPTION OPCIÓN CON VARILLA VERTICAL NORMAL Choose a MOUNTING OPTION, either Normal Downrod Option using the included downrod, or Extended Downrod Option using a longer downrod (purchased separately). Insert motor wires through the selected downrod and insert the downrod into the downrod coupling. Make sure to align the hole in the downrod with the hole in the downrod coupling.
  • Page 9 ETL-ES-Comet Damp-WH25 MOUNTING MONTAJE Carefully lift fan assembly onto mounting bracket. Rotate fan until notch on downrod ball (1) engages the ridge on the mounting bracket (2). This will allow for hands free wiring. With bracket holding fan assembly, make electrical connections using the fol- lowing step for wiring instructions.
  • Page 10 ETL-ES-Comet Damp-WH25 WIRING OPTIONS OPCIÓN DE CABLEADO WALL CONTROL WIRING OPTION PULL CHAIN WIRING OPTION AC IN N AC IN N Green Ground Green Ground Power Power Supply Supply AC IN L AC IN L Wall Wall Switch Control Follow diagram above to make wiring connections for wall control Follow diagram above to make wiring connections for fan pull chain operation.
  • Page 11 ETL-ES-Comet Damp-WH25 SECURE TO CEILING ASEGURE EL VENTILADOR AL TECHO The canopy has two mating slots (1) and two mating holes (2). Position both slots on canopy directly under and in line with two screws in the mounting bracket (3). Lift the canopy, allowing the two screws to slide into the mating slots.
  • Page 12 ETL-ES-Comet Damp-WH25 BLADE INSTALLATION INSTALACIÓN DE LAS ALETAS Check the motor for plastic shipping stabilizer tabs (1), and remove them if Attach the blade brackets onto the blades using the blade bracket screws (1), they are present. Attach blade assembly to motor using the noise-dampening fabric washers (2), metal washers (3), and hex nuts (4) in order.
  • Page 13 ETL-ES-Comet Damp-WH25 LIGHT FIXTURE INSTALLATION INSTALACIÓN DEL JUEGO DE LUZ Install light bulbs (Includes (2) 5.5W LED cande- labra base lamps). Screw in retaining disks to hold shade in place. Attach the molex plug from the fan to the molex from the Instale las bombillas de luz (incluido (2) bombil- Atornille los tornillos de retención para sostener...
  • Page 14 ETL-ES-Comet Damp-WH25 Assemble decorative fob and extension chains from hardware bag to fan pull chains by inserting end of chain into chain coupling. Confirm chains are held by lightly pulling both chains in coupling. Sujetar las cadenas largas de tiro con las piezas finales correspondientes, a las cade- nas del ventilador, introduciendo el extremo de la cadena larga en la pieza de unión.
  • Page 15 ETL-ES-Comet Damp-WH25 Appendix for alternate installation options EXTENDED DOWNROD OPTION (see page #16 to page #17) Apéndice para opciones de instalación alternativas OPCIÓN CON VARILLA VERTICAL MÁS LARGA (consulte a la página #16 a la página # 17)
  • Page 16 ETL-ES-Comet Damp-WH25 EXTENDED DOWNROD OPTION OPCIÓN CON VARILLA VERTICAL MÁS LARGA Slide downrod ball (1) off of downrod and remove pin (2). Loosen downrod ball (1) from downrod (2) by removing set screw (3). Deslice la bola de la varilla vertical (1) hasta separarla de la varilla vertical y quite el Afloje la bola de la varilla vertical (1) de la varilla vertical (2) pasador (2).
  • Page 17 ETL-ES-Comet Damp-WH25 EXTENDED DOWNROD OPTION OPCIÓN CON VARILLA VERTICAL MÁS LARGA Re-install pin into extended downrod, and slide downrod ball up to the top of the downrod. Re-install set screw to secure ball to downrod. Note: Some extended downrods have a pre-drilled set-screw hole. If a pre-drilled hole is present in the extended downrod, tighten the set screw into the pre-drilled hole in the extended downrod.
  • Page 18 ETL-ES-Comet Damp-WH25 EXTENDED DOWNROD OPTION OPCIÓN CON VARILLA VERTICAL MÁS LARGA Feed motor lead wires through downrod/canopy assembly and insert downrod into downrod yoke. Make sure to align hole in downrod with the hole in downrod yoke. Install yoke cross pin (1) through yoke and downrod. Insert clamp pin (2) into cross pin until it snaps into place. Tighten set screws (3) in yoke. PROCEED TO PAGE 8, STEP 6.

  • Page 19: Operation And Maintenance

    ETL-ES-Comet Damp-WH25 OPERATION AND MAINTENANCE Operation Turn on the power and check operation of fan. The pull chain controls the fan speeds as follows: 1 pull - high; 2 pulls - medium; 3 pulls - low; 4 pulls - off. Speed settings for warm or cool weather depend on factors such as room size, ceiling height, number of fans and so on. The slide switch controls direction, forward or reverse.

  • Page 20: Operación Y Mantenimiento

    ETL-ES-Comet Damp-WH25 OPERACIÓN Y MANTENIMIENTO Operación Encienda el ventilador y verifique su funcionamiento. La cadenilla de tiro controla las velocidades del ventilador de la siguiente manera: 1 jalón – rápida; 2 jalones - mediana; 3 jalones - lenta; 4 jalones - apagado. Las velocidades para clima cálido o frío dependen de factores como el tamaño de la habitación, la altura del ventilador, el número de ventiladores, etc.

  • Page 21: Troubleshooting Guide

    ETL-ES-Comet Damp-WH25 TROUBLESHOOTING If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults, GUIDE please check this Trouble Shooting Chart.
  • Page 22 ETL-ES-Comet Damp-WH25 GUÍA PARA SOLUCIONAR Si tiene dificultades para hacer funcionar su nuevo ventilador, podría ser a causa del armado, instalación o cableado incorrectos. En algunos casos, estos errores de instalación podrían ser confundidos con defectos. Si experiencia algun fallo, consulte esta guía para PROBLEMAS solucionar problemas.

  • Page 23: Warranty

    GARANTÍA Este ventilador de Westinghouse Lighting se ofrece con una garantía limitada de por vida para el propietario original frente a defectos de material y de mano de obra. Esta garantía sustituye cualquier otra garantía expresa o implícita.
  • Page 24 ETL-ES-Comet Damp-WH25 PARTS LIST LISTA DE REPUESTOS ... Description ... Mounting Bracket ... Blade Bracket .
  • Page 25 ETL-ES-Comet Damp-WH25...
  • Page 26 ETL-ES-Comet Damp-WH25...
  • Page 27 ETL-ES-Comet Damp-WH25...
  • Page 28 ETL-ES-Comet Damp-WH25 Westinghouse Lighting, Philadelphia, PA 19154-1029, U.S.A. www.westinghouselighting.com and Westinghouse are trademarks of Westinghouse Electric Corporation. Used under license by Westinghouse Lighting. All Rights Reserved. Made in China...
