- Page 1 ETL-ES-Desoto-WH17 OWnEr'S ManuaL ManuaL DEL uSuariO Desoto Please write model number here for future reference: / Por favor, incluya el número del modelo aquí para futura referencia: net Weight: Peso neto:...
-
Page 2: Safety Tips
ETL-ES-Desoto-WH17 Safety tiPS OBSeRVe tHe fOLLOWiNG: ReaD aND SaVe tHeSe iNStRUCtiONS WaRNiNG: tO ReDUCe tHe RiSK Of fiRe, eLeCtRiC SHOCK, OR PeRSONaL iNJURy, MOUNt tO OUtLet BOX MaRKeD 'aCCePtaBLe fOR faN SUPPORt Of 35 lbs (15,9 kg) OR LeSS' aND USe MOUNtiNG SCReWS PROViDeD WitH tHe OUtLet BOX aND/OR SUPPORt DiReCtLy fROM BUiLDiNG StRUCtURe. -
Page 3: Consejos De Seguridad
ETL-ES-Desoto-WH17 CONSeJOS De SeGURiDaD HaGa LO SiGUieNte: Lea y GUaRDe eStaS iNStRUCCiONeS aDVeRteNCia: PaRa ReDUCiR eL RieSGO De iNCeNDiO, DeSCaRGa eLÉCtRiCa O HeRiDaS GRaVeS PeRSONaLeS, MONte eN UNa CaJa De eMBUtiR ROtULaDa “aDeCUaDa PaRa VeNtiLaDOReS De 15,9 KG (35 LB) O MeNOS”... - Page 4 ETL-ES-Desoto-WH17 featUReS CaRaCteRÍStiCaS DOWNROD SLOPED CEILING INSTALLATION INSTALLATION INSTALACIóN CON INSTALACIóN PARA VARILLA VERTICAL TECHOS INCLINADOS Note: For sloped ceiling installation, please refer to westinghouselighting.com for specially designed canopy kit options. Nota: Para instalación en techo inclinados, visite westinghouselighting.com para obtener información.
- Page 5 ETL-ES-Desoto-WH17 featUReS CaRaCteRÍStiCaS COMBO-BLADE Combo-Blades feature two high quality finishes on one blade. Select the one that best complements your decor, or change the style with just a flip of the blade. NOTE: Combo-Blade finishes vary, depending upon model. ASPAS DE DOBLE CARA Las aspas del rotor de doble cara presentan dos superficies con un acabado de alta calidad.
- Page 6 ETL-ES-Desoto-WH17 PRePaRiNG fOR iNStaLLatiON PRePaRaNDO PaRa La iNStaLaCiÓN Use metal outlet box suitable for fan support (must support 35 lbs). Before attaching fan to outlet box, ensure the outlet box is securely fastened by at least two points to a structural ceiling member (a loose box will cause the fan to wobble).
-
Page 7: Mounting Bracket Installation
ETL-ES-Desoto-WH17 MOUNtiNG BRaCKet iNStaLLatiON iNStaLaCiÓN CON SOPORte De MONtaJe Remove the screws from the two mating holes (1) on the canopy. Loosen (do not remove) the screws in the mating slots (2) on the canopy. Rotate the mounting bracket and remove from the canopy. -
Page 8: Mounting Options
ETL-ES-Desoto-WH17 MOUNtiNG BRaCKet iNStaLLatiON MOUNtiNG OPtiONS iNStaLaCiÓN CON SOPORte OPCiONeS De MONtaJe De MONtaJe Choose a MOunTinG OPTiOn Elija una OPCiÓn DE MOnTaJE nOrMaL DOWnrOD OPTiOn If installing downrod supplied with fan, proceed to page 9, step 6. OPCiÓn COn VariLLa VErTiCaL nOrMaL Si instala la varilla vertical incluida con el ventilador, proceda a la página 9, paso 6. - Page 9 ETL-ES-Desoto-WH17 NORMaL DOWNROD OPtiON OPCiÓN CON VaRiLLa VeRtiCaL NORMaL Remove clamp pin (1) and cross pin (2) from downrod (3). Quite el pasador tipo prensa (1) desde el pasador transversal (2) de la varilla vertical (3).
- Page 10 ETL-ES-Desoto-WH17 DOWNROD iNStaLLatiON iNStaLaCiON De La VaRiLLa VeRtiCaL Insert motor wires through the downrod and insert the downrod into the downrod coupling. Make sure to align the hole in the downrod with the hole in the downrod coupling. Install cross pin (1) removed in step 6 through coupling and downrod. Insert clamp pin (2) into cross pin until it snaps into place. Tighten set screws (3) in coupling. Slide coupling cover (4) onto the downrod.
- Page 11 ETL-ES-Desoto-WH17 eXteNDeD DOWNROD OPtiON OPCiÓN CON VaRiLLa VeRtiCaL MÁS LaRGa Loosen downrod ball (1) from downrod (2) by removing set screw (3). Afloje la bola (1) de la varilla vertical (2) quitando el tornillo de fijacion (3).
- Page 12 ETL-ES-Desoto-WH17 DOWNROD PRePaRatiON PRePaRaNDO La VaRiLLa VeRtiCaL Re-install pin into downrod, and slide downrod ball up to the top of the extended downrod. Re-install the set screw to secure ball to downrod. Note: Some extended down- rods have a pre-drilled set-screw hole. If a pre-drilled hole is present in the extended downrod, tighten the set screw into the pre-drilled hole in the extended downrod. If no pre-drilled hole exists in the extended downrod, tighten the screw against the downrod to secure the downrod ball.
- Page 13 ETL-ES-Desoto-WH17 MOUNtiNG MONtaJe Carefully lift fan assembly onto mounting bracket. Rotate fan until notch on down- rod ball (1) engages the ridge on the mounting bracket (2). This will allow for hands free wiring. With bracket holding fan assembly, make electrical connections using the following Levante con cuidado el conjunto del ventilador hasta el soporte de montaje.
- Page 14 ETL-ES-Desoto-WH17 WiRiNG OPtiONS OPCiÓN De CaBLeaDO PuLL CHain WirinG OPTiOn WaLL COnTrOL WirinG OPTiOn Follow diagram above to make wiring connections for fan pull chain control. Follow diagram above to make wiring connections for wall control operation. OPCiÓn DE CaBLEaDO Para CaDEniLLa DE TirO OPCiÓn DE CaBLEaDO Para COnTrOL DE ParED...
- Page 15 ETL-ES-Desoto-WH17 SeCURe tO CeiLiNG aSeGURe eL VeNtiLaDOR aL teCHO For downrod fans, slide the canopy up to the mounting bracket. Para ventiladores con varilla vertical, deslice el dosel hacia arriba hasta el soporte de montaje. The canopy has two mating slots (1) and two mating holes (2). Position both slots on canopy directly under and in line with two screws in the mounting bracket (3). Lift the canopy, allow- ing the two screws to slide into the mating slots.
-
Page 16: Blade Installation
ETL-ES-Desoto-WH17 BLaDe iNStaLLatiON iNStaLaCiÓN De LaS aLetaS Attach blade brackets to blades by inserting the blade bracket screws (1) Insert the blades trough the slots on the motor housing as shown, and use the and fabric washers (2) through the blade brackets and blades. Then thread provided blade screws and spring washers to tighten the blades to the motor. -
Page 17: Light Fixture Installation
ETL-ES-Desoto-WH17 LiGHt fiXtURe iNStaLLatiON iNStaLaCiÓN DeL aRtefaCtO LUMiNOSO Remove one of the screws on the switch housing plate (1), and loosen, (do not remove) the other two (2). Connect the wire plugs from the motor (3) to the wire plugs from the light kit (4), white to white, and blue to black. - Page 18 ETL-ES-Desoto-WH17 LiGHt fiXtURe iNStaLLatiON iNStaLaCiÓN DeL aRtefaCtO LUMiNOSO The light kit has 2 keyhole slots. Align the slots on the light kit to the protruding screws from the switch housing plate. Raise the light kit allowing the protruding screws from the switch housing plate to enter the keyhole slots on the light kit. Rotate the light kit clockwise to engage the slots. Insert the screw that was removed in step 17 into the third hole on light kit and tighten screws to secure the light kit.
- Page 19 ETL-ES-Desoto-WH17 LiGHt fiXtURe iNStaLLatiON iNStaLaCiÓN DeL aRtefaCtO LUMiNOSO Locate the indentations on the neck of the glass and align with the protrusions on the inside of the light kit. Lift the glass up allowing the protrusions to engage the indentations of the glass, and twist the glass clockwise to lock into place.
- Page 20 ETL-ES-Desoto-WH17 Assemble decorative fob and extension chains from hardware bag to fan pull chains by inserting end of chain into chain coupling. Confirm chains are held by lightly pulling both chains in coupling. Arma las cadenas largas de tiro con las piezas finales correspondientes, a las cadenas del ventilador, introduciendo el extremo de la cadena larga en la pieza de unión.
-
Page 21: Operation And Maintenance
ETL-ES-Desoto-WH17 OPEraTiOn anD MainTEnanCE Operation Turn on the power and check operation of fan. The pull chain controls the fan speeds as follows: 1 pull - high; 2 pulls - medium; 3 pulls - low; 4 pulls - off. Speed settings for warm or cool weather depend on factors such as room size, ceiling height, number of fans and so on. The slide switch controls direction, forward or reverse. -
Page 22: Operación Y Mantenimiento
ETL-ES-Desoto-WH17 OPEraCiÓn y ManTEniMiEnTO Operación Encienda el ventilador y verifique su funcionamiento. La cadenilla de tiro controla las velocidades del ventilador de la siguiente manera: 1 jalón – rápida; 2 jalones - mediana; 3 jalones - lenta; 4 jalones - apagado. -
Page 23: Troubleshooting Guide
ETL-ES-Desoto-WH17 If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or wiring. In some cases, these TrOuBLESHOOTinG GuiDE installation errors may be mistaken for defects. If you experience any faults, please check this troubleshooting Chart. If a problem cannot be remedied, please consult with your qualified electrician and do not attempt any electrical repairs yourself. - Page 24 ETL-ES-Desoto-WH17 Si tiene dificultades para hacer funcionar su nuevo ventilador, podría ser a causa del armado, instalación o cableado incorrectos. En algunos Guía Para SOLuCiOnar PrOBLEMaS casos, estos errores de instalación podrían ser confundidos con defectos. Si experimenta alguna falla, consulte esta guía para solucionar problemas.
-
Page 25: Parts List
ETL-ES-Desoto-WH17 PaRtS LiSt LiSta De RePUeStOS Description 1 ..Mounting Bracket (assembled with Canopy) 2 ..Blade Bracket (qty 4) 3 ..Blade (qty 4) 4 ..Glass shade 5 ..Capacitor 6 ..Hardware pack 7 ..Down Rod Assembly (includes down rod ball, cross pins, clamp pin) 8 .. - Page 26 ETL-ES-Desoto-WH17...
- Page 27 ETL-ES-Desoto-WH17...
- Page 28 ETL-ES-Desoto-WH17 Westinghouse Lighting, Philadelphia, PA 19154-1029, U.S.A. www.westinghouselighting.com , WESTINGHOUSE, and INNOVATION YOU CAN BE SURE OF are trademarks of Westinghouse Electric Corporation Used under license by Westinghouse Lighting All rights reserved. Made in China...
