- Page 1 INSTALLATION MANUAL 9 series...
-
Page 2: Table Of Contents
1. Introduction General This is the installation manual for the Thetford SHB949. The manual is meant for qualified installers who will install the appliance in a caravan, camper or holiday home. Read the information and instructions carefully and follow them strictly to install the appliance safely and correctly. -
Page 3: Safety
Attention. Important information. Note. Additional information. Video. Additional instruction video available. 2. Safety READ THESE INSTRUCTIONS FOR USE CAREFULLY . FAMILIARISE YOURSELF WITH THE APPLIANCE. KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE. General Risk of serious injury through burning, explosion, clamping, electrocution, suffocation and poisoning or damage to the product. - Page 4 ■ The surrounding surfaces must be able to withstand the allowable temperature rise of 65°C above ambient temperature, as specified in the EN30-1-1 standard and in accordance with the design of this unit. ■ The temperature of the surrounding surfaces may rise if there are other additional devices besides the appliance.
-
Page 5: Serviceability
In terms of serviceability, this means that a dealer or authorised Thetford service partner must be able to remove and re-install the Thetford product within the time that is allowed according to the Thetford time-list, using standard tools and equipment. -
Page 6: Technical Specifications
4. Technical specifications Table 1: Burner specifications SHB949 Gas input Injector g/hr Gas burners 4 x 1.49 4 x 107 0.61 Total 5.96 Electrical 12V DC supply Table 2: Dimensions and weight SHB949 Dimensions Appliance weight 10kg This appliance is suitable for use with LPG [Liquefied Petroleum Gas] and should... -
Page 7: Before Installation
Table 3: Gas category Class 3 Appliance Gas category & Pressure CAT I CAT I 3 + (28-30/37) 3 B/P (30) BUTANE (G30) 28 – 30mbar BUTANE (G30) 30mbar PROPANE (G31) 37mbar PROPANE (G31) 30mbar For installation in BE, CH, CY, CZ, ES, FR, GB, AT, BE*, CH, CY, CZ, DE, DK, GR, IE, IT, LT, PT, SI, TR EE, FI, FR, GB*, GR, HR, HU,... -
Page 8: Cabinet Requirements
Cabinet requirements The location must provide: ■ Wood cabinetry and worktop ■ Support for at least the weight of the appliance as stated in Technical specifications plus any items placed on top. The total weight placed on top of the hob should not exceed 10kg. ■... -
Page 9: Installation Dimensions
Cabinetry ventilation and protection dimensions Maintain provision for the dispersal of unburnt gas beneath the appliance. Ensure any gas drop hole is located away from the burners. The gas drop hole must vent to the outside of the leisure vehicle. 1. - Page 10 SHB94999 cut-out: R10mm 75mm 75mm 440mm 25mm 490mm Schematic overview of surface mounting the appliance into the cabinet 1. Locate the threaded studs and nuts (x4). 2. Position the nut on the stud at 4mm from the top. 3. Screw the stud into the threaded fixing on the underside of hob.
-
Page 11: Installation
6. Installation Read the applicable instructions in chapter Safety first. Prepare See Technical specifications and Before installation for more information. ■ Prepare the cabinet and worktop for the appliance. ■ Ensure the air gaps are according to specifications. ■ Ensure the gas dispersion hole has the correct size and is not blocked. Install the appliance ■... -
Page 12: After Installation
Attach labels ■ Attach a warning label next to the unit that meets the requirements of EN721, Annex ■ Attach a warning notice next to the gas dispersal hole, with the text: Warning! Under no circumstances should the gas dispersion hole be obstructed. 7. -
Page 13: Service & Questions
For our warranty clause, please refer to the conditions mentioned on www.thetford.com. Declaration of Conformity Thetford hereby declares that this product is in compliance with the essential requirements and other relevant provisions of the applicable Regulations, Directives and Standards. A copy of the Declaration of Conformity can be found at www.thetford.com. - Page 14 T +61 3 9358 0700 T +86 755 8627 1393 T +46 31 336 35 80 F not available F +86 755 8627 1673 F not available E infoaus@thetford.com.au E info@thetford.cn E infos@thetford.eu www.thetford.com.au www.thetford.cn Copyright 2016-2025 Thetford B.V. All rights reserved. SINS2306/0125-V02...
