FarmTek Premium CL112412S2X08T Manual

2' wide greenhouse bench w/trellis
Hide thumbs

Advertisement

Quick Links

Download this manual
2' Wide Premium Greenhouse Bench w/Trellis
©2024 FarmTek
®
All Rights Reserved. Reproduction
is prohibited without permission.
Revision date: 08.16.24
Premium Greenhouse Bench with Stationary Top
STK#
DIMENSIONS
CL112412S2X08T
2' W x 3' H x 8' L
CL112412S2X10T
2' W x 3' H x 10' L
CL112412S2X12T
2' W x 3' H x 12' L
*
Actual bench may differ from example shown.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Premium CL112412S2X08T and is the answer not in the manual?

Questions and answers

Related Manuals for FarmTek Premium CL112412S2X08T

Summary of Contents for FarmTek Premium CL112412S2X08T

  • Page 1 2' Wide Premium Greenhouse Bench w/Trellis Premium Greenhouse Bench with Stationary Top STK# DIMENSIONS CL112412S2X08T 2' W x 3' H x 8' L ©2024 FarmTek ® CL112412S2X10T 2' W x 3' H x 10' L All Rights Reserved. Reproduction CL112412S2X12T 2' W x 3' H x 12' L is prohibited without permission.
  • Page 2 Important Information READ THIS DOCUMENT BEFORE YOU BEGIN Thank you for purchasing this premium greenhouse bench. When properly assembled and maintained, this product will provide years of reliable service. These instructions include helpful hints and important information needed to safely assemble and properly maintain the bench. Please read these instructions before you begin.
  • Page 3 Important Information PICTORIAL GUIDE The following graphics and photos will help identify the different parts of your bench. (Some parts may not be shown.) 102921B FALB10B FAG102B FA4482B 108553 Wafer QH1070 Pipe Neo-Bonded 1/4" Nut 1/4" x 3/4" Bolt Tek Screw Head Screw Strap Washer...
  • Page 4 Assembly Instructions ASSEMBLE BENCH TOP SUPPORTS Use the photos and information that follows to construct the bench top frame supports. The 12' bench has four (4) support assemblies. The 8' and 10' benches each have three (3) supports. Gather the parts required to complete one (1) support assembly: •...
  • Page 5 Assembly Instructions 6. Tighten 1/4" bolts. 7. Check square tube position. 8. Install one FA4482B Tek screw in center. 9. Check assembly for square. 10. Secure bracket in place using two (2) 11. Flip assembly over and repeat Steps 8-10 more Tek screws.
  • Page 6 Assembly Instructions ATTACH PIPE STRAPS Use the photos and information that follows to attach the QH1070 straps. Attach two QH1070 straps to each bench top support assembly. QH1070 1. Measure 15-3/4" from the bottom of each leg 2. Have an assistant hold the assembly and 3.
  • Page 7 Assembly Instructions ASSEMBLE SUPPORT FRAME FOR BENCH TOP For best results, assemble the support frame on a flat, level surface. Gather the parts for the support frame: • (4) 105118L0295 struts • (6) QH1400 band clamps; eight (8) for the 12' bench. •...
  • Page 8 Assembly Instructions ASSEMBLE SUPPORT FRAME FOR BENCH TOP—continued 7. Tighten the pipe strap mounting bolts of 8. Check that six (6) band clamps are in position 9. Take one corner leg strut (105118L0295) and the mid support. Tighten until snug. Do not on the horizontal pipes–eight (8) for the 12' attach it to one band clamp in the corner.
  • Page 9 Assembly Instructions ASSEMBLE SUPPORT FRAME FOR BENCH TOP—continued 13. Move to the lower strut connection and 14. Using a level, verify that the support leg is 15. Repeat to attach the other corner leg strut for reposition band clamp as needed. plumb/vertical.
  • Page 10 Assembly Instructions • (2) 1.25" x 1.25" square tubes (See Quick Start section for ID.) INSTALL LONG BENCH TOP SUPPORT TUBES • 112431 aluminum angle clips (Bench length determines quantity.) Actual length may differ. Measure and adjust as needed. 1. Set one long 1.25" x 1.25" square tube on the 2.
  • Page 11 Assembly Instructions ATTENTION: Frame shown may differ from INSTALL LONG BENCH TOP SUPPORT TUBES—CONTINUED actual frame. Assembly steps are the same. 8. Remove the clamp and move to the opposite 9. Next, move to the mid support assembly and 7. Take another Tek screw and secure the clip to the long support tube.
  • Page 12 Assembly Instructions ATTENTION: Top shown may differ from ASSEMBLE BENCH TOP actual top. Assembly steps are similar. For best results, assemble the bench top frame with an assistant on a flat, level surface. Gather the parts for the support frame: •...
  • Page 13 Assembly Instructions ASSEMBLE BENCH TOP—continued NOTE: Same frame shown. Size and number of support tubes may differ from your frame. See diagrams for your frame near the back of this guide. 8. Move to the end rails and attach side rails as 9.
  • Page 14 Assembly Instructions 102921B FA4482B ASSEMBLE BENCH TOP—continued Neo-Bonded Tek Screw Washer ATTENTION: Actual bench may differ from what is shown. Consult the Quick Start Guide for your bench details. 13. With assistance, carefully lift the expanded 14. Lower the expanded metal top into the frame. NOTE: Use a block of wood or small hammer metal top and carry it to the assembled frame.
  • Page 15 Assembly Instructions 102921B FA4482B ASSEMBLE BENCH TOP—continued Neo-Bonded Tek Screw Washer 18. Continue to install Tek screws and washers NOTE: Install screws in a position that best Photo shows a Tek screw and washer installed SIDE RAIL along the side rail at each support tube. secures both the expanded metal top and the through the side rail and into the support tube.
  • Page 16 Assembly Instructions ATTENTION: Actual bench may differ from what is shown. SECURE TOP TO THE MAIN SUPPORT FRAME Consult the Quick Start Guide for your bench details. 1. Square the bench top on the support frame. 2. Move to a bench top support closest to the 3.
  • Page 17 Quick Start Guide 2' x 8' Premium Bench – Stationary Top CL112412S2X08T 2' x 10' Premium Bench – Stationary Top CL112412S2X10T 2' x 12' Premium Bench – Stationary Top CL112412S2X12T WARNING: Evenly distribute weight when using bench. Never stand on bench top or allow anyone to stand on bench.
  • Page 18 2' x 8' (CL112412S2X08T) Premium Bench – Stationary Top See next page for 2' x 8' bench top parts. FALB10B FAG102B Bolt 112391 Bolt Clamp S125P096G14 FA4482B Tek Screw S125P018 QH1070 Pipe Strap 112431 Angle Clip S125P096G14 112391 Bolt Clamp 131P072 S125P03175 QH1070...

  • Page 19: Bench Top

    2' x 8' (CL112412S2X08T) Bench Top – Exploded View FA4482B 108553 Wafer 102921B Tek Screw Head Screw Neo-Bonded Washer 2' x 8' Bench Top CL112412S2X08T S125P024 Support Tube FA4482B Tek Screw and 102921B Neo- Bonded Washer 112815 Poly Bench Corner 113153 Rivets (6 per corner)
  • Page 20 2' x 8' (CL112412S2X08T) Bench Top – Installation 112431 Angle Clips Secure the bench top to the support tubes of the main frame using Tek screws and 112431 angle clips. See Procedure 6. Install one 112431 clip at each corner of the bench top. 105118L0295 Corner Strut QH1400...
  • Page 21 PAGE RESERVED FOR CUSTOMER NOTES AND RECORDS Revision date: 08.16.24...
  • Page 22 2' x 10' (CL112412S2X10T) Premium Bench – Stationary Top See next page for 2' x 10' bench top parts. FA4482B Tek Screw FALB10B FAG102B Bolt QH1070 112391 Pipe Strap Bolt Clamp S125P072 S125P072 S125P018 S10P012GA16 Splice S125P048 FA4482B Tek Screws S125P048 112431 Angle Clip...
  • Page 23 2' x 10' (CL112412S2X10T) Bench Top – Exploded View 113524Z2X5 & EXPANDED METAL 113524Z2X5 EXPANDED METAL 102921B FA4482B 113153 Rivet 113236Z024 Neo-Bonded Tek Screw & 2' x 10' Washer Bench Top CL112412S2X10T FA4482B Tek Screw and 102921B Neo-Bonded Washer S125P024 Support Tube 112815 Poly EXTRUSION CONNECTION...
  • Page 24 2' x 10' (CL112412S2X10T) Bench Top – Installation 112431 Angle Clips 105118L0295 Secure the bench top to the Corner Leg Strut support tubes of the main frame (all four corners) using Tek screws and 112431 angle clips. See Procedure 6. Install one 112431 clip at each QH1400 corner of the bench top.
  • Page 25 PAGE RESERVED FOR CUSTOMER NOTES AND RECORDS Revision date: 08.16.24...
  • Page 26 2' x 12' (CL112412S2X12T) Premium Bench – Stationary Top NUT 1/4" - 20 SS (FALB10B) X4 1/4" X 3/4" See next page for 2' x 12' bench top parts. CAP SCREW SS (FAG102B) X4 S125P084 FA4482B Tek Screw FALB10B S10P012GA16 Splice LEG ASSEMBLY BENCH LEG...
  • Page 27 2' x 12' (CL112412S2X12T) Bench Top – Exploded View 107016Z2X6 & EXPANDED METAL & 107016Z2X6 EXPANDED METAL 113153 Rivet 113236Z024 2' x 12' & Bench Top CL112412S2X12T FA4482B Tek Screw and 102921B Neo-Bonded Washer FA4482B Tek Screw S125P024 Support Tube 102921B Neo-Bonded ATTENTION: Evenly...
  • Page 28 2' x 12' (CL112412S2X12T) Bench Top – Installation 112431 Angle Clips 105118L0295 Corner Leg Strut (all four corners) Secure the bench top to the support tubes of the main frame using Tek screws and 112431 angle clips. See Procedure 6. Install one 112431 clip at each corner of the bench top.
  • Page 29 PAGE RESERVED FOR CUSTOMER NOTES AND RECORDS Revision date: 08.16.24...
  • Page 30 GREENHOUSE BENCH TRELLIS DIMENSIONS 2' x 8' 2' x 10' 2' x 12' 4' x 8' ©2024 FarmTek ® 4' x 10' All Rights Reserved. Reproduction *Actual length may differ from example shown. Bench is not included. 4' x 12' is prohibited without permission.
  • Page 31 Important Information READ BEFORE YOU BEGIN Thank you for purchasing this greenhouse bench trellis. When properly assembled and maintained, this product will provide years of reliable service. These instructions include helpful hints and important information needed to safely assemble and properly maintain the trellis. Please read these instructions before you begin.

  • Page 32: Warnings And Cautions

    Important Information PICTORIAL GUIDE WARNINGS AND CAUTIONS The following graphics and photos help identify different trellis parts. (Some parts are not shown.) • BENCH THAT SUPPORTS TRELLIS TO BE FULLY ASSEMBLED AND ANCHORED BEFORE LOADING AND OPERATING TOP. • TRELLIS IS NOT A TOY! NEVER CLIMB OR HANG ON TRELLIS. •...
  • Page 33 General Assembly Steps ATTENTION: FOR BEST RESULTS, ASSEMBLE TRELLIS ON FULLY ASSEMBLED AND ANCHORED BENCH. Here is one way to assemble the trellis: 1. Construct each frame support (end and mid) using details found in diagrams contained in Quick Start section of this guide. NOTE: End frame supports include 3-way connectors at each lower corner;...

  • Page 34: Quick Start

    Quick Start QUICK START GUIDE FRAME SUPPORT – MID Trellis — Frame Components (Quantity depends on bench length.) BRACKET PAIR FRAME SUPPORT – END (dashed line) 24" TOP OF BENCH SIDE TUBE 24" ATTENTION: HEIGHT OF HORIZONTAL TUBE IS 24" UP FROM BENCH TOP WHEN TRELLIS IS ASSEMBLED AND POSITIONED ON BENCH.
  • Page 35 CONNECTIONS — MAIN FRAME NOTE: Width and length of trellis frame shown is generic for illustration purposes. Consult table ATTENTION: FOR BEST RESULTS, below for Horizontal Cross Bar part numbers of specific purchased bench. Consult Side Profile ASSEMBLE TRELLIS ON FULLY pages for Side Rail Tube part numbers and dimensions.
  • Page 36 CONNECTION DETAILS — MAIN FRAME ATTENTION: FOR BEST RESULTS, ASSEMBLE TRELLIS ON FULLY ASSEMBLED AND ANCHORED BENCH. 1" SQUARE TUBE CROSS CONNECTOR (115849) X2 S10P048 SIDE RAIL TUBE S10P066GA16 S10P012GA16 END CAP 3-WAY TUBE NUT 1/4" - 20 SS 1/4" X 3/4" (115857) CONNECTOR (FALB10B) X4...
  • Page 37 SIDE PROFILE: 8' LONG 2' WIDE & 4' WIDE S10P090GA16 Side Rail Tube FRAME FRAME 45" 45" ATTENTION: ON-CENTER DIMENSIONS ARE APPROXIMATE. ADJUST SUPPORT LEG SPACING AS NEEDED TO PREVENT CONFLICTS WITH SIDE RAIL TUBE SPLICE(S). 116285TRL5_18_30_42_54_66 Revision date: 08.16.24...
  • Page 38 SIDE PROFILE: 10' LONG 2' WIDE & 4' WIDE Side Rail S10P0445GA16 S10P066GA16 Tube Splice Side Rail Tube Side Rail Tube FRAME FRAME 57" 57" ATTENTION: ON-CENTER DIMENSIONS ARE APPROXIMATE. ADJUST SUPPORT LEG SPACING AS NEEDED TO PREVENT CONFLICTS WITH SIDE RAIL TUBE SPLICE(S). Revision date: 08.16.24 116285TRL5_18_30_42_54_66...
  • Page 39 SIDE PROFILE: 12' LONG 2' WIDE, 4' WIDE & 5' WIDE Side Rail S10P066GA16 S10P072GA16 Tube Splice Side Rail Tube Side Rail Tube FRAME 46" 46" 46" ATTENTION: ON-CENTER DIMENSIONS ARE APPROXIMATE. ADJUST SUPPORT LEG SPACING AS NEEDED TO PREVENT CONFLICTS WITH SIDE RAIL TUBE SPLICE(S). 116285TRL5_18_30_42_54_66 Revision date: 08.16.24...
  • Page 40 NOTES Revision date: 08.16.24 116285TRL5_18_30_42_54_66...
