- Page 1 EM01 NL User Manual 2.4G+Bluetooth+Bluetooth Wireless Rechargeable Trackball Mouse www.protoarc.com US: support@protoarc.com UK: support-uk@protoarc.com United States: (+1) 866-287-6188 Monday-Friday: 10am-1pm, 2pm-7pm (Eastern Time) *Closed during Holidays 2024A1...
-
Page 2: Product Features
Product Features Left Button Right Button Forward Button Backward Button Trackball DPI + Button DPI - Button Charging / DPI Indicator Scroll Wheel Channel Switch Button 2.4G Indicator Bluetooth 1 Indicator Bluetooth 2 Indicator TYPE-C Charging Port Power Switch USB Receiver - 1 -... - Page 3 DPI +/- Button The factory default DPI value is 400, press the DPI+ or DPI- button to adjust the DPI. A single flash of the red indicator light corresponds to a DPI level of 200, two flashes indicate 400, three flashes indicate 800, four flashes indicate 1200, and five flashes indicate 1600.
- Page 4 2.4G USB Connection 1. Turn on the power switch 2. Take out the receiver. to ON. 3. Press the channel switch 4. Insert the usb receiver button until the white light ① is into your computer’s usb on and enter 2.4G USB channel. port.
-
Page 5: Bluetooth Connection
Bluetooth paring mode. Settings Bluetooth EM01 NL EM01 NL Connected 3. Turn on the Bluetooth settings on your device, search or select "EM01 NL" and start Bluetooth pairing until the connection is completed. - 4 -... -
Page 6: Charging Guide
Charging Guide 1. When the battery is low, the charging indicator light will flash red until it turns off. 2. Insert the Type-C charging cable into the mouse, and the red light will remain on while charging. 3. The charging time is about 1-3.5 hours and the indicator light turns off when fully charged. - Page 7 Switch Connection Channel After BT1, BT2 and 2.4G USB channel is connected, press the channel switch button on the top of the mouse to switch between multiple devices. Bluetooth 1 Device Connection 2.4G USB Bluetooth 2 Connection Device Connection Press the channel switch button on the top of the mouse to switch between 3 devices.
-
Page 8: Data Parameters
Data Parameters Basic parameter: Movement Detection Technology: Optical Lithium battery Capacity: 900mAh DPI: 200-400-800-1200-1600 Click life: 3 million+ Dimension: 4.92*2.5*1.55in Weight: 6.74oz (191g) Bluetooth transmission parameters: Transmission distance: 10m Working Voltage: 3.7V Working current: 4mA Reaction rate: 125Hz System requirement: Bluetooth-enable device Windows 8, Windows 10 or higher version Mac OS x 10.10 or higher version... -
Page 9: Safety Warning
Safety Warning IMPORTANT: To reduce risk of fire, electric shock, or injury, follow these safety instructions. Charging Safely: Use only the provided cable. Charge in a well-ventilated, dry area away from inflammable materials. Battery Handling: Do not attempt to replace the item’s lithium battery. Battery replacement should be conducted by qualified personnel to prevent hazards. -
Page 10: Fcc Statement
FCC STATEMENT This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference, and This device must accept any interference received, including interference that may cause undesired operation. -
Page 11: Eu Declaration Of Conformity
EU Declaration of Conformity Declared Object: 2.4G+Bluetooth+Bluetooth Wireless Rechargeable Trackball Mouse Model: EM01 NL Rating: 3.7V 10mA Input: 250mA Place of Production: Made in China Manufacturer: Dongguan Dianxuntong Electronics Technology Co., Ltd sales05@dxtchina.com Email: Address: 3F, BLDG A, Guanhui Intelligent Science and Technology...
