- Page 1 SoLight 1 User Manual 2.4G+Bluetooth+Bluetooth Wireless Rechargeable Mouse...
-
Page 2: Product Features
Product Features Left Button Right Button Forward Button Backward Button Scroll Wheel DPI Button Charging / DPI Indicator TYPE-C Charging Port Power Switch 2.4G Indicator Wireless 1 Indicator Wireless 2 Indicator Switch Device Button... - Page 3 2.4G USB Connection 1. Turn on the power switch 2. Open the cover and take to ON. out the USB receiver. Notice: Buckle out the cover from behind first and then slide out the cover. 3. Press the mode switch button 4.
-
Page 4: Bluetooth Connection
Bluetooth Connection 1. Turn on the power switch 2. Press the mode switch to ON. button and switch to 2 or 3 mode, the white light flashes slowly. 3. Press and hold the mode switch button for 3~5 seconds until the white light flashes quickly, then the mouse enters the Bluetooth pairing mode. - Page 5 Windows 10 System Click “Bluetooth device”. Click “Add or remove a Bluetooth device”. Devices Bluetooth, printers, mouse Your computer will automatically search for "ProtoArc SoLight 1" and then click “pair”. Bluetooth ProtoArc SoLight 1 Ready to pair Bluetooth Pair...
- Page 6 "ProtoArc SoLight 1" is connected and can be used normally. ProtoArc SoLight 1 Connected Mac OS System Please complete the Bluetooth mode installation step 123 before pairing. Click "System Preferences" on Mac.
- Page 7 Click "Bluetooth" in "System Preferences". “forter” Mouse ProtoArc SoLight 1 Pair Your computer will automatically find "ProtoArc SoLight 1", then click “pair”, and you can use it after installation. ProtoArc SoLight 1 Connected “forter” Mouse iOS System Only the system above iOS 13 supports the mouse function.
- Page 8 Click Settings on your device, then turn on Accessibility. Touch Accessibility Click Touch. Settings Accessibility Touch AssistiveToch Turn on Assistive Touch. Settings Touch AssistiveTouch AssistiveTouch...
- Page 9 “Pair”, complete pairing. ProtoArc SoLight 1 Connected Bluetooth Bluetooth Pairing Requset “ProtoArc SoLight 1” would like to pair with your iPad. Cancel Pair "ProtoArc SoLight 1" is connected and can be used normally. Bluetooth Settings Bluetooth DEVICES Bluetooth ProtoArc SoLight 1 Connected...
-
Page 10: Android System
Click Settings on the device, then turn on Bluetooth. Settings Bluetooth Your computer will automatically find "ProtoArc SoLight 1", then click “pair”, complete pairing. Bluetooth ProtoArc SoLight 1 "ProtoArc SoLight 1" is connected and can be used normally. Bluetooth ProtoArc SoLight 1 Connected... - Page 11 Charging Function Guide When the power is insufficient, the charging indicator and the corresponding channel indicator flash until it is turned off. Please connect the power supply for charging in time, and use the USB cable to connect the TYPE-C charging Port. Connect the charging cable to the USB port of the computer, the charging indicator is always on during charging, the charging time is about 1-3.5 hours and the indicator light turns off when...
- Page 12 How to switch connection mode After BT1, BT2 and 2.4G USB mode is connected, press the mode switch button on the top of the mouse to switch between multiple devices. Wireless 1 Device Connection 2.4G USB Wireless 2 Connection Device Connection Press the mode switch button on the top of the mouse to switch between 3 devices.
-
Page 13: Data Parameters
Data parameters Basic parameter: Chip: Nordic NRF51802W Movement Detection Technology: Optical Lithium battery Capacity: 300mA DPI: 1000-1600-2400 Click life: 3 million+ Dimension: 109.2*62.3*38.3mm Weight: 57g Bluetooth transmission parameters: Transmission distance: 10m Working Voltage: 3.7V Working current: 8mA Reaction rate: 125Hz System requirement: Bluetooth-enable device Windows 8, Windows 10 or higher version...
