- Page 1 EM05 User Manual 2.4G+Bluetooth+Bluetooth Wireless Vertical RGB Trackball Mouse support@protoarc.com www.protoarc.com United States: (+1) 866-287-6188 Monday-Friday: 10am-1pm, 2pm-7pm (Eastern Time) *Closed during Holidays...
-
Page 2: Table Of Contents
CONTENTS Product Features 2.4G USB Connection Bluetooth Connection Switch Connection Channel Charging Guide Data Parameters Packing List - 1 -... -
Page 3: Product Features
Product Features Left Button Right Button Forward Button Backward Button Trackball Led Rim Light Charging Indicator Scroll Wheel Light Switch Button TYPE-C Charging Port Bluetooth 2 Indicator Bluetooth 1 Indicator 2.4G Indicator Channel Switch Button DPI Indicator DPI Button Power Switch USB Receiver - 2 -... - Page 4 DPI Button Press the DPI button to adjust the cursor sensitivity. A single flash of indicator light corresponds to DPI level 200, two to 400, three to 800, four to 1200, and five to 1600. Light Mode: When the mouse is connected to the device normally, the light will be off when the mouse is not in use for 30 seconds, and the light will light up again when the mouse is awakened.
-
Page 5: 2.4G Usb Connection
2.4G USB Connection 1. Turn on the power switch 2. Take out the receiver. to ON. 3. Press the channel switch 4. Insert the usb receiver button until the white light into your computer’s usb on and enter 2.4G USB channel. port. -
Page 6: Bluetooth Connection
Bluetooth paring mode. Settings Bluetooth ProtoArc EM05 ProtoArc EM05 Connected 3. Turn on the Bluetooth settings on your device, search or select "ProtoArc EM05" and start Bluetooth pairing until the connection is completed. - 5 -... - Page 7 Charging Guide 1. When the mouse power is low, the charging indicator and the corresponding channel indicator flash until turned off. 2. Insert the Type-C charging cable into the mouse, the red light stays on during charging. 3. The charging time is about 1-3.5 hours and the indicator light will turn green after being fully charged.
-
Page 8: Switch Connection Channel
Switch Connection Channel After BT1, BT2 and 2.4G USB channel is connected, press the channel switch button on the bottom of the mouse to switch between multiple devices. Bluetooth 1 Device Connection 2.4G USB Bluetooth 2 Connection Device Connection Press the channel switch button on the bottom of the mouse to switch between 3 devices. -
Page 9: Data Parameters
Data Parameters Basic parameter: Movement Detection Technology: Optical Lithium battery Capacity: 930mA DPI: 200-400-800-1200-1600 Click life: 3 million+ Dimension: 5.78 * 3.95 * 2.66 in Weight: 5.9 oz (168g) Bluetooth transmission parameters: Transmission distance: 10m Working voltage: 3.7V Working current: 12.5mA (light on) 3.5mA (light off) Reaction rate: 115Hz System requirement: Bluetooth-enable device...
