All manuals and user guides at all-guides.com Front Panel Component Function SDI Output Port From your SDI Display Device plug into this ports Mode Buttons Select Format/Output Port Power Jack The Power adapter plug into here Rear Panel Component Function Phone Jack Form you Audio Device plug into this port Component/CVBS/S-Video...
All manuals and user guides at all-guides.com Top Panel Component Function Input Source LED The LEDs are indicate Input source Power and Lock LED The LEDs is indicate power and signal locked. Main Format LED The LEDS are indicate output format Side Panel Component Function...
All manuals and user guides at all-guides.com Button/LED Indicate 1. Firmware Mode: Hold on the 1 and 2 button, the display is showed firmware version on display of left upper. FIRMWARE VERSION 0.1.0.1 2. Default Mode: Pull all button (1, 2 and 3) at same time, the box auto reset to default. 3.
Page 7
All manuals and user guides at all-guides.com 4. Output Format Mode: 1 2 3 Pull button 1 change to format mode, frame rate and Fraction by button 2 and 3. Button 1 Button 2 Button 3 720x480 59.94i 720x576 59.94p 1280x720 59.94i 59.94p...
Page 8
All manuals and user guides at all-guides.com 720x576 i50 1280x720 p60 12080 x720 p59 1280x720 p50...
Page 9
All manuals and user guides at all-guides.com 1280x720 p30 1280x 720 p25 1920x1080 i60 1920x1080 i59...
Page 10
All manuals and user guides at all-guides.com 1920x1080 i50 1920x1080 p60 1920x1080 p59 1920x1080 p50...
Page 11
All manuals and user guides at all-guides.com 1920x1080 p30 1920x1080 p29 1920x1080 p25 1920x1080 p24...
Page 12
All manuals and user guides at all-guides.com 1920x1080 p23 4. Aspect Ratio Mode: Check the button 3 , the box will be seting to Aspect Ratio Mode Mode Display 16:9 (Default) (dot by dot)
Page 13
All manuals and user guides at all-guides.com 5. Function Button Mode: Hold on the button 4 until show the Func button Mod FUNCTION BUTTON UN-LOCK/LOCK 6. Auto Phase Mode: When input souce is DVI-A (VGA) and Hold on the button 1 will be start auto phase function.
Page 14
All manuals and user guides at all-guides.com 1. DVI-D + L/R Audio: DVI-D + L/R Audio 2. DVI-A+ L/R Audio: DVI-A + L/R Audio...
Page 15
All manuals and user guides at all-guides.com 3. YPbPr + L/R Audio: YPbPr + L/R Audio 4. Composite (CVBS) + L/R Audio: Composite(CVBS) + L/R Audio...
Page 16
All manuals and user guides at all-guides.com 5. S-VIDEO + L/R Audio Composite(CVBS) + L/R Audio...
2. Connect Video Source to the Input Connector. 3. Connect Display Equipment to the output’s connector 4. Connect the +12DC adaptor to the converter. Package Contents The MULTI2SDI -S package contains the following items: User Manual x 1 ...
All manuals and user guides at all-guides.com Specifications DESCRIPTION SDI Format SD-SDI, HD-SDI & 3G-SDI SDI Transition Rate 2.970Gb/s, 10485Gb/s and 270Mb/s 8-Channel (L/R Audio only 2 channel splitter to 8 Audio Support channel) Re-Sample Clock Auto Resample audio clock to 48Khz RG6/RG59(75Ω...
All manuals and user guides at all-guides.com Firmware Upload Firmware is upgradable in the field using the integrated USB port How to Firmware upgrade: Step1. Open Upload Firmware Program tools.exe and connect box to PC by USB Cable. Step2. Plug and un-plug “DC adapter” to power on/off the converter box (the connection check status will be changed to “Connect”)
Page 20
All manuals and user guides at all-guides.com Step3. Plug and un-plug “DC adapter” again (the connection check status will be changed to “Connected”) and Please click the Open File button to select the firmware bin file. Step4. Please click “Start’ Button to proceed with new firmware programming. PASS message will appear when the procedures finished.
