  • Page 1 SDI2MULTI User Manual Rev1.1...

  • Page 2: Table Of Contents

    Content Feature ................... 3 Front Panel ................4 Rear Panel ................4 Top Panel ................. 5 Side Panel ................5 Button/LED Indicate ..............6 Installation ................16 Package Contents ..............16 Specifications ................17 Firmware Upload ..............18 Update List ................20 Appendix Table A ..............

  • Page 3: Feature

    Feature  SDI Supports HD formats :  720p50 & 60  1080i50 & 60  1080p24, 25, 30, 50 & 60  SDI Support 525i & 625i SD D1 format  Auto 3G/HD/SD-SDI detection  Can be split one 3G-SDI displays simultaneously. ...

  • Page 4: Front Panel

    Front Panel Component Function SDI Input Port From your SDI Source plug into these ports SDI Output Port From your SDI Display Device plug into this ports Mode Buttons Select Format/Output Port Power Jack The Power adapter plug into here Rear Panel Component Function...

  • Page 5: Top Panel

    Top Panel Component Function Output Source LED The LEDs are indicate main output of source Power and Lock LED The LEDs is indicate power and signal locked. Main Format LED The LEDS are indicate main output of format Side Panel Component Function USB Port...

  • Page 6: Button/Led Indicate

    Button/LED Indicate 1. Firmware Mode: Hold on the 3 and 2 button, the display is showed firmware version on display of left upper. FIRMWARE VERSION 0.1.0.1 2. Default Mode: Pull all button (1, 2 and 3) at same time, the box auto reset to default. 3.
  • Page 7 a. DVI-D Output: (DVI-D + YPbPr) 1 2 3 Pull button 1 change to format mode, frame rate and Fraction by button 2 and 3. Button 1 Button 2 Button 3 59.94i 720x480 59.94p 720x576 59.94p 1280x720 59.94i 59.94p 1920x1080 29.97p 23.98p...
  • Page 8 b. DVI-A Output: (DVI-D + DVI-A) Pull button 1 change to format mode, button 1 and 2 is change format Button 1 Format Button 2 1920x1080 p60 1680x1050 p60 1600x1200 p60 1440x900 p60 1400x1050 p60 1366x768 p60 1280x1024 p60 1024x768 p60 800x600 p60...
  • Page 9 c. YPbPr Output：(YPbPr + DVI-D) 1 2 3 Pull button 1 change to format mode, frame rate and Fraction by button 2 and 3. Button 1 Button 2 Button 3 59.94i 720x480 59.94p 720x576 59.94p 1280x720 59.94i 59.94p 1920x1080 29.97p 23.98p...
  • Page 10 d. CVBS/S-VIDEO Output： 1 2 3 Pull button 1 change to format mode, frame rate and Fraction by button 2 and 3. Button 1 Button 2 Button 3 CVBS/SVIDEO 59.94i 720x480 NTSC 59.94p 720x576 59.94p NTSC 1280x720 59.94i NTSC 59.94p NTSC 1920x1080 29.97p...
  • Page 11 a. LED indicator: 720x480 59.94i 720x576 i50 1280x720 p60 12080 x720 p59...
  • Page 12 1280x720 p50 1280x720 p30 1280x 720 p25 1920x1080 i60...
  • Page 13 1920x1080 i59 1920x1080 i50 1920x1080 p60 1920x1080 p59...
  • Page 14 1920x1080 p50 1920x1080 p30 1920x1080 p29 1920x1080 p25...
  • Page 15 1920x1080 p24 1920x1080 p23...

  • Page 16: Installation

    2. Connect Video Source (SDI) to the SDI Connector. 3. Connect Equipment to the output’s connector 4. Connect the +12DC adaptor to the converter. Package Contents The SDI2MULTI package contains the following items:  User Manual x 1  +12 DC Adapter x 1 ...

  • Page 17: Specifications

    Specifications DESCRIPTION SDI Format SD-SDI, HD-SDI & 3G-SDI SDI Transition Rate 2.970Gb/s, 10485Gb/s and 270Mb/s Audio Support Stereo 2-Channel (L/R Audio) RG6/RG59(75Ω ) Coaxial Cable Type 3G: 100m of RG6/ 86m of RG59 HD: 170m of RG6/ 120m of RG59 SD: 400m of RG6/ 280m of RG59 Cable Equalization *1 RG6: CANARE L-5CFB Cable / RG59: Belden 9275 Cable...

  • Page 18: Firmware Upload

    Firmware Upload Firmware is upgradable in the field using the integrated USB port How to Firmware upgrade: Step1. Open Upload Firmware Program tools.exe and connect box to PC by USB Cable. Step2. Plug and un-plug “DC adapter” to power on/off the converter box (the connection check status will be changed to “Connect”)
  • Page 19 Step3. Plug and un-plug “DC adapter” again (the connection check status will be changed to “Connected”) and Please click the Open File button to select the firmware bin file. Step4. Please click “Start’ Button to proceed with new firmware programming. PASS message will appear when the procedures finished.

  • Page 20: Update List

    Update List Data Version Command 2012.11.05 V1.0 File established 2013.10.08 V1.1 1. Rename to SDI2Multi 2. Add Pattern Generator Function...

  • Page 21: Appendix Table A

    Appendix Table A Support Input Format: SDI Mode 720x480 i59.94 720x576 i50 1280x720 p60 1280x720 p59.94 1280x720 p50 1920x1080 i60 1920x1080 i59.94 1920x1080 i50 1920x1080 p60 1920x1080 p59.94 1920x1080 p50 1920x1080 p30 1920x1080 p29.97 1920x1080 p25 1920 x 1080 p24 1920 x 1080 p23.98 Support Output Format (DVI-A): DVI-A Mode...
