- Page 1 SDI2FIBER User Manual Ver. 1.2...
-
Page 2: Table Of Contents
Content Feature .................. 3 Front Panel ................4 Rear Panel ................4 Side Panel ................5 SFP Connector ................ 6 Button/LED Indicate .............. 7 Installation ................7 Package Contents ..............8 Specifications ..............9 Firmware Upload ..............10 Update List ................. 12... -
Page 3: Feature
Feature SDI Supports HD formats : 720p50 & 60 1080i50 & 60 1080p24, 25, 30, 50 & 60 SDI Support 525i & 625i SD D1 format Auto 3G/HD/SD-SDI detection Cable equalization to ensure signal integrity. ... -
Page 4: Front Panel
Front Panel Component Function Fiber Output From your Fiber Cable plug into port this port The LEDs is indicate Output Format LEDs indicate (SD/HD/3G) Input Source Select Input Source Form your SDI Display Device plug SDI Output Port into this port Rear Panel Component Function... -
Page 5: Side Panel
Side Panel Component Function Usb port Upgrade firmware... -
Page 6: Sfp Connector
SFP Connector 1. TX XXX-XX-XXXX-T0 It is indicate the trasmitter SFP 2. RX XXX-XX-XXXX-RO It is indicate the Reciver SFP 3. SPF Installation Diagram: TC1331T-10D... -
Page 7: Button/Led Indicate
Button/LED Indicate 1. Input Source Select. LED Indicate Function SDI Un-Locked ● SDI Locked ● 2. Input Format LED Indicate LED Indicate Function NO SIGNAL ○○ ○● ●○ ●● Installation SDI2FIBER installation consists of the following: 1. Disconnect +12DC adaptor to converter. 2. -
Page 8: Package Contents
Package Contents The SDI2FIBER package contains the following items: User Manual x 1 +12 DC Adapter x 1 SDI2FIBER Converter x 1 SFP( TX and RX ) x 1... -
Page 9: Specifications
Specifications DESCRIPTION SDI Format SD-SDI, HD-SDI & 3G-SDI SDI Transition Rate 2.970Gb/s, 1.485Gb/s and 270Mb/s Coaxial Cable Type RG6/RG59(75Ω) 3G: 120m of RG6/ 100m of RG59 HD: 200m of RG6/ 140m of RG59 SD: 400m of RG6/ 280m of RG59 Cable Equalization *1 RG6: CANARE L-5CFB Cable / RG59: Belden 9275 Cable... -
Page 10: Firmware Upload
Firmware Upload Firmware is upgradable in the field using the integrated USB port How to Firmware upgrade: Step 1. Open Upload Firmware Program tools.exe and connect box to PC by USB Cable. Step 2. Plug and un-plug “DC adapter” to power on/off the converter box (the connection check status will be changed to “Connect”) - Page 11 Step 3. Plug and un-plug “DC adapter” again (the connection check status will be changed to “Connected”) and Please click the Open File button to select the firmware bin file. Step 4. Please click “Start’ Button to proceed with new firmware programming.
-
Page 12: Update List
Update List Data Version Command 2013.07.29 V1.0 1. Release...
