Introduction
The
X-NUCLEO-67W61M1
prototypes with the ST67W series
Interfacing with the host is possible through SPI via the ARDUINO
stackable on Nucleo-64, Nucleo-144, and Discovery boards. The main hosts are the STM32U5, STM32H5, STM32H7, and
STM32N6 product families.
Powered by all-in-one 2.4 GHz Wi‑Fi
the processing capabilities, Wi‑Fi
For more details on the ST67W611M1 coprocessor module, refer to its datasheet at www.st.com.
Figure 1.
X-NUCLEO-67W61M1 top view
Pictures are not contractual.
UM3449 - Rev 1 - June 2025
For further information, contact your local STMicroelectronics sales office.
®
/Bluetooth
/802.15.4 connectivity expansion board based on the
ST67W611M1 module for STM32 Nucleo boards
expansion board provides an affordable and flexible way for users to try out new concepts and build
ST67W611M1
coprocessor module.
®
®
6/Bluetooth
combo SoC, the ST67W611M1 LGA module is purposely designed to pack
®
®
/Bluetooth
combo connectivity, and on-module memory into a single 32-pin LGA form factor.
®
Uno V3 or expansion connectors. This expansion board is
Figure 2.
X-NUCLEO-67W61M1 bottom view
UM3449
User manual
