INSTALLATION
MANUAL
COPYRIGHT
2021 CANON INC.
©
imageRUNNER
ADVANCE DX
6780i/6765i/6755i
Canon
October 27, 2021
Rev. 2
CANON imageRUNNER ADVANCE DX 6700 Series Rev. 2 PRINTED IN U.S.A.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the imageRUNNER ADVANCE DX 6755i and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Canon imageRUNNER ADVANCE DX 6755i

Summary of Contents for Canon imageRUNNER ADVANCE DX 6755i

  • Page 1 ADVANCE DX 6780i/6765i/6755i INSTALLATION MANUAL Canon October 27, 2021 Rev. 2 COPYRIGHT 2021 CANON INC. CANON imageRUNNER ADVANCE DX 6700 Series Rev. 2 PRINTED IN U.S.A. ©...

  • Page 2: Important Notices

    When changes occur in applicable products or in the contents of this manual, Canon will release technical information as the need arises. In the event of major changes in the contents of this manual over a long or short period, Canon will issue a new edition of this manual.

  • Page 3: Description On The Parts Included In The Package

    Important Notices Copyright The copyright of this document belongs to Canon Inc. This document may not be copied, reproduced or translated into another language, in whole or in part, without the prior consent of Canon Inc. Copyright CANON INC. 2021 Caution Use of this manual should be strictly supervised to avoid disclosure of confidential information.

  • Page 4: Table Of Contents

    Contents Contents Safety Precautions....................1 Toner Safety............................2 About Toner............................2 Handling Adhered Toner........................2 Checking the Installation Environment....................2 Checking the Installation Environment....................2 Points to Note Before Servicing......................2 Essential Items to Be Performed Before Installation.................3 Checking Installation Space........................3 illustrations............................4 1. Product Lineup....................5 Scanning System Options........................
  • Page 5 Contents 4. Host Machine Options................. 136 Upright Control Panel-J1......................... 137 Installation Procedure........................137 Pre-checks............................184 NFC Kit-E1/E2..........................188 Points to Note before Installation......................188 Checking the Contents........................188 Essential Items to Be Performed Before Installation................188 Points to Note When Turning ON/OFF the Main Power................189 Installation Outline Drawing........................189 Installation Procedure........................
  • Page 6 Contents Points to Note When Turning ON/OFF the Main Power................262 Installation Outline Drawing........................263 Installation Procedure........................263 Checking after Installation........................274 Operation Check..........................274 Voice Guidance Kit-G1........................275 Points to Note at Installation.......................275 Checking the Contents........................275 Essential Items to Be Performed Before Installation................276 Points to Note When Turning ON/OFF the Main Power................276 Installation Outline Drawing........................277 Installation Procedure........................
  • Page 7 Contents Points to Note When Turning ON/OFF the Main Power................359 Installation Outline Drawing........................359 Checking the Contents........................360 Installation Procedure........................361 Checking the Operation........................376 Super G3 3rd/4th Line Fax Board-AS1................... 378 Product Name...........................378 Points to Note at Installation.......................378 Essential Items to Be Performed Before Installation................378 Points to Note When Turning ON/OFF the Main Power................378 Installation Outline Drawing........................379 Checking the Contents........................
  • Page 8 Contents Essential Items to Be Performed Before Installation................483 Installation Procedure........................483 6. Paper Output Options..................490 Shift Tray-F1............................491 Points to Note before Installation......................491 Checking the Contents........................491 Essential Items to Be Performed Before Installation................492 Points to Note When Turning ON/OFF the Main Power................492 Installation Outline Drawing........................492 Installation Procedure........................

  • Page 9: Safety Precautions

    Safety Precautions Toner Safety..........2 Checking the Installation Environment ............2...

  • Page 10: Toner Safety

    Safety Precautions Toner Safety About Toner Toner is a nontoxic matter composed of plastic, iron and a trace of pigments. CAUTION: Never throw toner in flames to avoid explosion. Handling Adhered Toner • Use dry tissue paper to wipe off toner adhered to skin or clothes and wash in water. •...

  • Page 11: Essential Items To Be Performed Before Installation

    Safety Precautions Essential Items to Be Performed Before Installation • Turn OFF the main power of the host machine, and disconnect the power plug from the outlet. WARNING: • If performing work without disconnecting the power plug of the host machine, it may cause electrical shock. •...

  • Page 12: Illustrations

    Safety Precautions 3. To install the host machine, install it in a well-ventilated place. Especially when there are multiple host machine s, be sure to locate the machine where the machine is free from direct exhaust of other machines. Be sure to keep the machine away from the air-inlet duct which is used for ventilation of the room.

  • Page 13: Product Lineup

    Product Lineup Scanning System Options.....6 Function Expansion System Options ............7 Pickup/Delivery System Options... 9...

  • Page 14: Scanning System Options

    1. Product Lineup Scanning System Options Reader Heater Unit-P1 Printer Cover-H2 ADF Access Handle-A1 Required Options and Conditions Product name Required options, conditions, etc. “Reader Heater-P1” on page 112 Option for Reader Unit ADF Access Handle-A1 It is the handle to support opening and closing the Feeder.

  • Page 15: Function Expansion System Options

    1. Product Lineup Function Expansion System Options Hardware Products Product name Required options, conditions, etc. “Numeric Keypad-A1/A2” on page 217 No particular options and conditions are required. “Upright Control Panel-J1” on page 137 No particular options and conditions are required. “NFC Kit-E1/E2”...

  • Page 16: Option Combination Table

    1. Product Lineup Product name Required options, conditions, etc. Fiery Compose No particular options and conditions are required. Fiery Impose No particular options and conditions are required. Fiery Impose and Compose No particular options and conditions are required. Fiery imageViewer No particular options and conditions are required.

  • Page 17: Pickup/Delivery System Options

    1. Product Lineup Pickup/Delivery System Options Copy Tray-R2 POD Deck Lite-C1 Shift Tray-F1 Staple Finisher-AC1 * 3 /Booklet Finisher-AC1 * 3 Paper Deck Unit-E1 Document Insertion / Folding Unit-J1 *1: 2/3, 2/4, 4 Hole Puncher Unit-A1 are available as an option. Pickup System Required Options/Conditions Pickup System Required Options/Conditions Product name...
  • Page 18 1. Product Lineup Pickup System Required Options/Conditions Pickup System Required Options/Conditions Product name Required options, conditions, etc. “Shift Tray-F1” on page 491 Using with delivery-related options is not available. Paper size: Ppaper available for the host machine Paper weight: 52 to 256 g/m Tray capacity: 500 sheets (64 g/m Copy Tray-R2 Using with delivery-related options is not available.

  • Page 19: Host Machine

    Host Machine How to Utilize This Installation Procedure........12 Checking before Installation....13 Installation of Host Machine....15...

  • Page 20: How To Utilize This Installation Procedure

    2. Host Machine How to Utilize This Installation Procedure Description on the Parts Included in the Package The parts with a diagonal line in the contents list will not be used. Symbols The frequently-performed operations are described with symbols in this procedure. Screw Tighten Loosen...

  • Page 21: Checking Before Installation

    2. Host Machine Checking before Installation Following shows requirements for the installation site. Therefore, it is desirable to see the installation site in advance before bringing in the machine to the user's site. Checking the Power Supply 1. Be sure to connect the power plug exclusively to an outlet that compiles with the following. •...
  • Page 22 2. Host Machine 5. Installation of the Printer Cover (Only for Machines Equipped with the Printer Cover) 6. Installation of the Covers 7. Installation of the Developing Assembly 8. Installation of the Pickup Assembly 9. Installing the Fixing Assembly 10. Installation of Toner Container 11.

  • Page 23: Installation Of Host Machine

    2. Host Machine Installation of Host Machine NOTE: The pictures and illustrations used may be different from the product in front of you, but the procedure is the same. Unpacking CAUTION: • The host machine weighs about 217 kg (including the DADF). For safety, be sure to work carefully to move and install the machine.
  • Page 24 2. Host Machine 2. Unpack the host machine. 3. Bring down the Package Box from the pallet. 4. Pull the plastic bag all the way down. 5. Open 4 Handle Covers. Hold the handles at the right side of the host machine and lift the host machine to remove the pad. Put the plastic bag aside in the direction of the arrow.
  • Page 25 2. Host Machine 6. Hold the handles at the left side of the host machine and lift the host machine to remove the pad and the plastic bag. CAUTION: Be sure not to lift the host machine too much. Otherwise, it will lose the balance. Handle Plastic Bag 7.
  • Page 26 2. Host Machine 9. Hold the handles at the right side of the host machine, and then, while supporting the corner of the host machine, fit the casters to the center of the Slope Plate to slowly bring the machine down. CAUTION: Be careful not to make the casters off from the Slope Plate.
  • Page 27 2. Host Machine 11. Remove tapes on the exterior surface of the host machine. CAUTION: Do not remove the Scanner Fixation Member until you proceed to “Installing the Scanner(Only for Machines Equipped with the Image Reader Unit) ” on page 26.
  • Page 28 2. Host Machine < Front side > NOTE: • When the tape is removed from the Image Reader Unit, the DADF will open. Do not close it in this step. • Do not remove 5 tapes for tags and a tape for the Filter Cover at this step. These tapes will be removed later on.
  • Page 29 2. Host Machine 12. Open the DADF and remove tapes on the exterior surface of the host machine. (Only for machines equipped with the Image Reader Unit.) NOTE: Remove the Scanner Fixation Member and the Scanner Fixation Screw when you proceed to “Installing the Scanner(Only for Machines Equipped with the Image Reader Unit) ”...
  • Page 30 2. Host Machine 15. Remove the tape securing the tag and remove the package material. 16. Close the HDD Lid. • 1 Screw 17. Close the Right Rear Cover 1.

  • Page 31: Checking The Contents

    2. Host Machine Checking the Contents Developing [2] Toner Container X 1 Assembly X 1 Only for China, Korea and Taiwan Exhaust Filter X 1 Left Upper Cover Right Upper Cover Upper Rear Cover Service Book Finisher Connector Holder X 1 Cover X 2 Cleaning Tool X 1 [10] Cord Guide X 1...
  • Page 32 2. Host Machine [14] IC Card Reader [15] Cushion X 2 Sheet X 1 [16] Double-sided Tape [17] Wire Saddle X 1 [18] Paper Size Label [19] Paper Size Label (Deck) X 1 (Cassette) Asia / Oceania X 2 USA X 1 EUR X 1 [20] JAM Label X1 [21] Control Panel...
  • Page 33 2. Host Machine NOTE: • [16]: Use this if necessary when installing the IC Card Reader. • [19]: Number of labels attached to the sheet varies according to location/area. • [21]: Give this to the user as the user may affix it if necessary (See the User's Guide for the procedure). •...

  • Page 34: Installation Procedure

    2. Host Machine ■ Printer Cover (Only for Machines Equipped with the Printer Cover) [1] Printer Cover X 1 [2] Right Cover         Support Plate X 3 Reader Fixation Plate L Reader Fixation Plate R Screw Screw (Binding; M4x6) X 5 Tightening;...
  • Page 35 2. Host Machine...
  • Page 36 2. Host Machine NOTE: Be sure to keep the Scanner Fixation Member in a safe place for moving the machine. NOTE: The removed Scanner Fixation Member will be stored in step 8.
  • Page 37 2. Host Machine NOTE: Be sure to keep the Scanner Fixation Member in a safe place for moving the machine. NOTE: The removed Scanner Fixation Member will be stored in step 10.
  • Page 38 2. Host Machine NOTE: The removed Scanner Fixation Member will be stored in step 9.
  • Page 39 2. Host Machine...
  • Page 40 2. Host Machine...
  • Page 41 2. Host Machine CAUTION: If the White Plate is pressed downward, it is placed on the Index Sheet, so be sure to press it upward.
  • Page 42 2. Host Machine 15. Close the ADF. NOTE: • Be sure that there is no gap (for reference, 0.3 mm or less) between the White Plate and the Index Sheet. • Check that the White Plate is not placed on the Index Sheet. White Plate Index Sheet Reader Unit...
  • Page 43 2. Host Machine ■ Installation of the Printer Cover (Only for Machines Equipped with the Printer Cover) 1. Install the Reader Fixation Plate L. • 2 Bosses • 1 Screw (Binding: M4x6) Binding; M4x6 2. Open the Multi-purpose Tray, and install the Reader Fixation Plate R. •...
  • Page 44 2. Host Machine 3. Install the 3 Right Cover Support Plates. • 2 Hooks each • 1 Screw each (Binding; M4x6) Binding; M4x6...
  • Page 45 2. Host Machine 4. Install the Printer Cover. • 4 Screws (P Tightening; M4x10) • 1 Screw (TP: M4x8) P Tightening; M4x10 TP M4x8 5. Close the Multi-purpose Tray.
  • Page 46 2. Host Machine ■ Installation of the Covers NOTE: The installation procedure is the same between the Flat Control Panel model and the Upright Control Panel model. 1. Install the Upper Rear Cover. • 3 Protrusions • 2 Claws 2. Open the covers. •...
  • Page 47 2. Host Machine 3. Install the 4 Rubber Caps to the Right Upper Cover. 4. Install the Right Upper Cover by fitting its hole onto the boss of the Upper Rear Cover. • 3 Protrusions • 2 Screws (RS Tightening; M4x10) RS Tightening;...
  • Page 48 2. Host Machine 6. Remove the Left Rear Cover. • 1 Claw • 1 Hook 7. Install the Left Upper Cover in the direction of the arrow. • 3 Protrusions • 3 Hooks • 3 Screws (RS Tightening; M4x10) CAUTION: When installing the Left Upper Cover, be careful not to secure it while it is being slided fully toward the front.
  • Page 49 2. Host Machine 8. Install the Left Rear Cover. • 1 Hook • 1 Claw 9. Close the Toner Replacement Cover. ■ Installation of the Developing Assembly CAUTION: How to Hold the Developing Assembly • When holding the Developing Assembly, be sure to hold the handle of the Developing Assembly as shown in the figure.
  • Page 50 2. Host Machine 2. Check if there are any scratches on the cylinder while rotating the gear manually in the direction of the arrow. CAUTION: • Do not damage and touch the cylinder. • Do not turn the gear inversely. 3.
  • Page 51 2. Host Machine CAUTION: • Before installing the Developing Assembly, be sure to check that the Buffer Shutter is not opened. • If forcedly inserting the Developing Assembly while the Buffer Shutter is open, the Buffer Shutter may get damage. When the Buffer Shutter is open, be sure to close it by pulling it toward the front. •...
  • Page 52 2. Host Machine 5. Hold the Developing Assembly as shown in the figure, and align the protrusions at both sides of the assembly with the rails on the host machine. • 2 Protrusions each Rail Protrusion Protrusion Rail Protrusion...
  • Page 53 2. Host Machine 6. Along the rails, insert the Developing Assembly horizontally. • 1 Connector 7. Close the Developing Assembly Pressure Cover and return the Lock Lever to the original position. Secure with the Screw (Binding; M4x6). Binding; M4x6 8. Close the Right Cover.
  • Page 54 2. Host Machine ■ Installation of the Pickup Assembly 1. Remove tapes securing tags from the Vertical Path Cover. 2. Open the Vertical Path Cover and remove 2 Pressure Release Spacers at pickup slot for each cassette. 3. Close the Vertical Path Cover. 4.
  • Page 55 2. Host Machine 6. Loosen the screw and slide the Deck Pressure Plate in the direction of the arrow. Check that the screw position is at the engraved mark '1', and then tighten the screw. Deck Pressure Engraved Mark Plate Screw 7.
  • Page 56 2. Host Machine 2. Turn the Fixing Feed Unit Release Lever in the direction of the arrow and pull the Fixing Feed Unit all the way out. NOTE: In the case that the Fixing Nip Pressure Release Screw is hard to be removed, release the lock by pressing the Lock Springs at both rails, and pull out the Fixing Feed Unit further until it stops.
  • Page 57 2. Host Machine 4. Open the Inner Delivery Unit, and remove the 2 Fixing Nip Pressure Release Screws. Fixing Nip Pressure Fixing Nip Pressure Release Screw Release Screw Inner Delivery Unit 5. Close the Inner Delivery Unit. 6. Remove the ETB Spacer.
  • Page 58 2. Host Machine 7. Return the Fixing Feed Unit and lock the Fixing Feed Unit Release Lever. NOTE: In the case of pulling out the Fixing Feed Unit further, be sure to return the Fixing Feed Unit while releasing the Lock Spring. CAUTION: Points to Note when Inserting the Fixing Feed Unit While pressing the Release Springs, slowly push the Fixing Feed Unit in so that the fingers do not get caught.
  • Page 59 2. Host Machine NOTE: How to push the Fixing Feed Unit in 1. Release the Release Springs [A] on the side of either rail. Slowly push the Fixing Feed Unit in by approximately 5 mm while keeping it level. approx. 5 mm 2.
  • Page 60 2. Host Machine 8. Affix the Jam Label of the appropriate language over the existing label on the Fixing Front Cover. 9. Close the Front Cover. ■ Installation of Toner Container 1. Open the Toner Replacement Cover, and turn the Lock Lever in the direction of the arrow to release.
  • Page 61 2. Host Machine 2. Unpack the Toner Container and shake it approx. 10 times horizontally. Only for China, Korea and Taiwan 3. Remove the cap of the Toner Container. 4. Set the Toner Container to the host machine, and turn the Lock Lever in the direction of the arrow to secure the Toner Container in place.

  • Page 62: Installing The Exhaust Filter

    2. Host Machine ■ Installing the Exhaust Filter 1. Remove the tape, and remove the Filter Cover. 2. Hold the Exhaust Filter as shown in the figure, and install it to the Main Body. CAUTION: When installing the Exhaust Filter, be sure to install it straight. If it is installed askew, the Filter Cover does not fit properly.
  • Page 63 2. Host Machine 3. Install the Filter Cover. • Screw (RS Tightening; M4x10) RS Tightening; M4x10 ■ Setting the Environment Heater Switch 1. Check that the Leakage Breaker is ON. 2. Turn ON the Environment Heater Switch and the Cassette Heater Switch in accordance with the installation environment.

  • Page 64: Turning On The Main Power

    2. Host Machine ■ Turning ON the Main Power CAUTION: Since the automatic adjustment of the ADF reading position will be executed when the main power is turned ON for the first time, remove all objects on the copyboard glass and close the ADF. 1.
  • Page 65 2. Host Machine ■ Registration of Installation Date Information CAUTION: Be sure that [Date/Time Settings] is completed. (There are items in Setup Guide.) 1. Enter the following service mode, and execute "Batch Set Installation Date Info". COPIER > FUNCTION > INSTALL > INSTDTST NOTE: •...
  • Page 66 2. Host Machine 2. Use a screwdriver to turn the adjusters in the direction of the arrow to make them secured. NOTE: Securing of the adjuster is not earthquake resistant. ■ Other Installation Work ● Service Book Holder 1. Remove the double-sided tape on back side of the Service Book Holder, and affix the holder on the Base Plate of the host machine.

  • Page 67: Cleaning Tool

    2. Host Machine ● Finisher Connector Cover 1. Install the 2 Finisher Connector Covers to the left side of the host machine. • 1 Protrusion each • 1 Claw each ● Cleaning Tool 1. Store the cleaning tool on the inside of the Right Deck to use for maintenance. (Hook it on the back side of the Deck Cover.)
  • Page 68 2. Host Machine ● Storing the Cleaning Cloth (Only for Machines Equipped with the Image Reader Unit) 1. Place the Cleaning Cloth in the space shown in the figure. ■ Affixing the Labels on the Reader Assembly (Only for Machines Equipped with the Image Reader Unit) 1.
  • Page 69 2. Host Machine ■ Checking the K paper settings (Only for CHINA) Check the following service mode, and change the setting value if different. 1. Enter service mode. 2. Check that the setting value of COPIER > OPTION > FNC-SW > MODEL-SZ is "0". 3.
  • Page 70 2. Host Machine 3. Put the specified size of papers in the Left/Right Deck, and push the Left/Right Deck in. 4. Affix Paper Size Labels (for Deck) according to the paper size, with the edge of each label aligned with the edge of the cassette number label.
  • Page 71 2. Host Machine ■ Setting the Paper Cassette 1. Pull out the Cassette to the front. 2. Hold the lever of the Side Guide Plate, and adjust the plate to the specified size. Adjust the Trailing Edge Guide Plate in the same way. Side Guide Plate Trail Edge Side Guide...
  • Page 72 2. Host Machine 5. Affix Paper Size Labels (for Cassette) according to the paper size, with the right edge aligned with the right edge of the number label, approx. 5 mm away from the number label. NOTE: • Be sure to check with the user whether or not to affix the Paper Size Label, and then affix it at the recommended position. •...
  • Page 73 2. Host Machine 2. Check that the left edge margin of the image (L1) is within 2.5 +/- 1.5mm. When the result is out of the specified range, perform adjustment by following the following procedure. Feeding direction of paper image 3.
  • Page 74 2. Host Machine 8. Check the Cassette position by the scale of the Cassette Button Link Unit. Cassette Button Link Unit Scale 9. Loosen the 4 screws of the Cassette Button Link Unit. Cassette Button Link Unit...
  • Page 75 2. Host Machine 10. According to the scale in which the position was checked in step 8, adjust the position of the Cassette Button Link Button. NOTE: • In the case of larger margin at the rear side, move the Cassette Button Link Unit to the rear side. •...

  • Page 76: Leading Edge Margin Adjustment (1St Side)

    2. Host Machine 13. When moving the Cassette Button Link Unit, adjust the left side of the Cassette Front Cover by shifting it with the same shifting amount of the unit. Scale Cassette Front Cover Scale 14. Once the position of the Cassette Front Cover is confirmed, tighten the 4 screws (which have been loosened in step 12).
  • Page 77 2. Host Machine 2. Check that the leading edge margin of the image (L2) is within 2.5 +1.5/-0.5 mm. When the result is out of the specified range, perform adjustment by following the following procedure. Feeding direction of paper image 3.
  • Page 78 2. Host Machine 2. Check that the left edge margin (L1) and leading edge margin (L2) are within the range indicated below. When the result is out of the specified range, perform adjustment by following the following procedure. • left edge margin L1: 2.5 +/-1.5 mm •...
  • Page 79 2. Host Machine 2. Check that the left edge margin (L1) and leading edge margin (L2) are within the range indicated below. When the result is out of the specified range, perform adjustment by following the following procedure. • left edge margin L1: 2.5 +/-1.5 mm •...
  • Page 80 2. Host Machine 8. Loosen the screw and adjust the position of the Slide Guide by referring to the scale. • In the case of larger margin at the rear side, move the Slide Guide to the front side. • In the case of larger margin at the front side, move the Slide Guide to the rear side. Scale 9.
  • Page 81 2. Host Machine NOTE: Even if the above adjustment is performed, if a fixed skew or image shift occurs, the image is manually adjusted according to the state of the printed image • Adjustment of leading edge margin of the scanned image for the corrected image Amount of Change per:0.1mm FEEDER >...
  • Page 82 2. Host Machine Adjustment of the White Plate...
  • Page 83 2. Host Machine CAUTION: If the White Plate is pressed downward, it is placed on the Index Sheet, so be sure to press it upward.
  • Page 84 2. Host Machine NOTE: • Be sure that there is no gap (for reference, 0.3 mm or less) between the White Plate and the Index Sheet. • Check that the White Plate is not placed on the Index Sheet. White Plate Index Sheet Reader Unit White Plate...
  • Page 85 2. Host Machine Checking the Height Height Check Sheet Preparation or Creation 1. Prepare the check sheet used for height adjustment. Height check sheet NOTE: Points to Note when Creating the Check Sheet • Output with A4 (paper size) or LTR (paper size). •...
  • Page 86 2. Host Machine Checking the Height of the Height Adjustment Boss 1. Put a sheet of paper on the place where the protrusions touch the Stream Reading Glass, and check whether there is any resistance of the paper when closing the ADF. <The Left Front Side>...
  • Page 87 2. Host Machine <The Left Rear Side> 2. If there is no resistance, perform the height adjustment.
  • Page 88 2. Host Machine Height Adjustment Procedure 1. Adjust by turning the Fixation Screw on the upper side of Hinge. • If both front and rear side (or only front side) are not installed properly: Turn the Right Hinge Fixation Screw clockwise (black arrow) to correctly locate it at the front.
  • Page 89 2. Host Machine Automatic Adjustment of the Stream Reading Position (Automatic Adjustment of the Reading Position at ADF Reading) NOTE: • If the DADF is opened during adjustment, restart the adjustment. • Enter the value after adjustment on the Service Label (on the back of the Reader Front Cover or Printer Front Cover). The adjustment result is reflected to COPIER >...
  • Page 90 2. Host Machine 1. Use a chart of a service parts of a Automatic Front/Back Side Difference Correction Adjustment, or using A4 or LTR paper, the leading edge and the side edge of the front/back side in the feeding direction are painted black with magic, and a chart for Automatic Front/Back Side Difference Correction Adjustment is prepared.
  • Page 91 2. Host Machine 4. Remove the release paper, and affix the Cord Guide to the area indicated in the figure. 5. Put the network cable through the Cord Guide, and install the cover of the Cord Guide. 6. Inform the system administrator at the installation site that installation of the Host Machine is complete, and then, ask for the network setting.

  • Page 92: Network Troubleshooting

    2. Host Machine ● Checking by the Remote Host Address Using the remote host address to execute Ping can check whether connection to the network is enabled or not. Remote host address: IP address of PC terminal connected/running on TCP/IP network environment that connects to this equipment.
  • Page 93 2. Host Machine ■ Installing the IC Card Reader NOTE: • When installing the IC Card Reader, the IC Card Reader (sales company's option) is required. • Use the shorter cable of the IC Card Reader. • When installing the IC Card Reader and Numeric Keypad at the same time, install the Numeric Keypad first. If the main power switch of the host machine is ON, turn it OFF.
  • Page 94 2. Host Machine NOTE: Be sure to change the number of cushions according to the thickness of the Card Reader. If it makes the Control Panel Upper Right Cover difficult to install, using one or no cushions is allowed.
  • Page 95 2. Host Machine NOTE: If any paste is remaining on the removed surface, clean with alcohol (to prevent the non-level surface from forming when affixing the Device Port Sheet). NOTE: Store the excess length of the cable in the position as shown in the figure.
  • Page 96 2. Host Machine < When installing with the Numeric Keypad at the same time > NOTE: Store the excess length of the cable in the position as shown in the figure.
  • Page 97 2. Host Machine...

  • Page 98: Operation When Using Uniflow Online

    2. Host Machine Connect the power plug to the outlet. Turn ON the main power switch. ■ Operation when using uniFLOW Online When using uniFLOW Online*, follow the setup procedures on the uniFLOW* Online First Steps Guide (http://www.nt-ware.com/ uFO_FS). * China version of "uniFLOW" is called "mdsFLOW".

  • Page 99: Image Reading System Options

    Image Reading System Options Printer Cover-H2......... 92 Reader Heater-P1......112...

  • Page 100: Printer Cover-H2

    3. Image Reading System Options Printer Cover-H2 Points to Note before Installation • After installation of the Printer Cover, be sure to change the setting of the following service mode to "0" before turning OFF the power of the host machine. Otherwise, an error may occur when turning ON the power. COPIER >...

  • Page 101: Installation Procedure

    3. Image Reading System Options Installation Procedure ■ Removing the Covers...
  • Page 102 3. Image Reading System Options CAUTION: Be careful not to let the 2 bosses of the Side Cover come off from the 2 mounting holes of the Right Rear Cover 1.
  • Page 103 3. Image Reading System Options...
  • Page 104 3. Image Reading System Options...

  • Page 105: Removing The Adf

    3. Image Reading System Options ■ Removing the ADF...
  • Page 106 3. Image Reading System Options NOTE: When performing following procedures, using ADF in the book mode as necessary makes the work easy. The book mode is released by opening the ADF.
  • Page 107 3. Image Reading System Options...
  • Page 108 3. Image Reading System Options CAUTION: Be careful not to drop the ADF.

  • Page 109: Removing The Reader Unit

    3. Image Reading System Options ■ Removing the Reader Unit...
  • Page 110 3. Image Reading System Options...
  • Page 111 3. Image Reading System Options...
  • Page 112 3. Image Reading System Options NOTE: Removed screw will be used in step 1 of "Installing the Printer Cover".
  • Page 113 3. Image Reading System Options NOTE: Removed screw will be used in step 2 of "Installing the Printer Cover".
  • Page 114 3. Image Reading System Options ■ Installing the Printer Cover NOTE: Use screw removed in step 6 of "Removing the Reader Unit". NOTE: Use screw removed in step 7 of "Removing the Reader Unit".

  • Page 115: Installing The Covers

    3. Image Reading System Options P Tightening; M4x10 TP; M4x8 ■ Installing the Covers...
  • Page 116 3. Image Reading System Options CAUTION: When installing the Left Upper Cover, be careful not to secure it while it is being slided fully toward the front. Otherwise, the Left Upper Cover may interfere with the Toner Replacement Cover and the magnet cannot work.
  • Page 117 3. Image Reading System Options...

  • Page 118: Operation Check

    3. Image Reading System Options Operation Check 1. Connect the power plug of the host machine to the outlet.
  • Page 119 3. Image Reading System Options 2. Turn ON the main power switch. CAUTION: If "E732-0023" is displayed after turning ON the main power switch, turn OFF and then ON the main power switch, and then perform the following steps. 3. A message is displayed prompting to check that the Reader Unit Cable is connected properly. 4.

  • Page 120: Reader Heater-P1

    3. Image Reading System Options Reader Heater-P1 Points to Note before Installation The pictures and illustrations used may be different from the product in front of you, but the procedure is the same. Checking the Contents Binding; M4x4 Middle 1x Small 5x Large 2x Large 3x...

  • Page 121: Installation Outline Drawing

    3. Image Reading System Options Installation Outline Drawing Installation Procedure ■ Installing the Covers...
  • Page 122 3. Image Reading System Options...
  • Page 123 3. Image Reading System Options CAUTION: When installing the Left Upper Cover, be careful not to secure it while it is being slided fully toward the front. Otherwise, the Left Upper Cover may interfere with the Toner Replacement Cover and the magnet cannot work.
  • Page 124 3. Image Reading System Options...

  • Page 125: Installing The Reader Heater

    3. Image Reading System Options ■ Installing the Reader Heater...
  • Page 126 3. Image Reading System Options CAUTION: • Soiling on the glass surface and the White Plate affects reading. When removing or installing the Copyboard Glass, be sure not to touch the glass surface and the White Plate. • If soiling is attached, clean it with lint-free paper. White Plate...
  • Page 127 3. Image Reading System Options NOTE: When performing following procedures, using ADF in the book mode as necessary makes the work easy. The book mode is released by opening the ADF.
  • Page 128 3. Image Reading System Options...
  • Page 129 3. Image Reading System Options...
  • Page 130 3. Image Reading System Options Middle...
  • Page 131 3. Image Reading System Options Binding; M4x4...
  • Page 132 3. Image Reading System Options Small...
  • Page 133 3. Image Reading System Options...
  • Page 134 3. Image Reading System Options...
  • Page 135 3. Image Reading System Options CAUTION: Be sure to hold down the Reader Heater Harness because it may interfere with moving of the Scanner Box if it is not connected properly.
  • Page 136 3. Image Reading System Options CAUTION: Be sure to hold down the Reader Heater Harness because it may interfere with moving of the Scanner Box if it is not connected properly.
  • Page 137 3. Image Reading System Options CAUTION: Move the Scanner Box to the right edge, and check if the underside of the Scanner Box and the HP Sensor Flag Plate do not interfere with the Reader Heater harness.
  • Page 138 3. Image Reading System Options...
  • Page 139 3. Image Reading System Options CAUTION: • Soiling on the glass surface and the White Plate affects reading. When removing or installing the Copyboard Glass, be sure not to touch the glass surface and the White Plate. • If soiling is attached, clean it with lint-free paper. White Plate...
  • Page 140 3. Image Reading System Options ■ Installing the Covers...
  • Page 141 3. Image Reading System Options CAUTION: When installing the Left Upper Cover, be careful not to secure it while it is being slided fully toward the front. Otherwise, the Left Upper Cover may interfere with the Toner Replacement Cover and the magnet cannot work.
  • Page 142 3. Image Reading System Options...
  • Page 143 3. Image Reading System Options Turn ON the Environment Heater Switch. Connect the power plug to the outlet. Turn ON the main power switch.

  • Page 144: Host Machine Options

    Host Machine Options Upright Control Panel-J1....137 NFC Kit-E1/E2........188 Connection Kit-A2/A3 for Bluetooth LE..........207 Numeric Keypad-A1/A2.....217 Utility Tray-B1........228 Copy Card Reader-F1.......235 Serial Interface Kit-K3 / Copy Control Interface Kit-A1 ......252 Voice Operation Kit-D1..... 261 Voice Guidance Kit-G1......275 HDD-related Option......288 Super G3 FAX Board-AS1....323 Super G3 FAX Board-AS2....

  • Page 145: Upright Control Panel-J1

    4. Host Machine Options Upright Control Panel-J1 Installation Procedure ■ Removing the Covers...
  • Page 146 4. Host Machine Options...
  • Page 147 4. Host Machine Options CAUTION: Be careful not to let the 2 bosses of the Side Cover come off from the 2 mounting holes of the Right Rear Cover 1.
  • Page 148 4. Host Machine Options...
  • Page 149 4. Host Machine Options...
  • Page 150 4. Host Machine Options Remove the ADF and Reader Unit or the Printer Cover. • When removing the ADF and Reader Unit: After performing the “Removing the ADF” on page 143, proceed to “Removing the Reader Unit” on page 146. •...
  • Page 151 4. Host Machine Options ■ Removing the ADF...
  • Page 152 4. Host Machine Options NOTE: When performing following procedures, using ADF in the book mode as necessary makes the work easy. The book mode is released by opening the ADF.
  • Page 153 4. Host Machine Options...
  • Page 154 4. Host Machine Options CAUTION: Be careful not to drop the ADF. Next, perform “Removing the Reader Unit” on page 146. ■ Removing the Reader Unit...
  • Page 155 4. Host Machine Options...
  • Page 156 4. Host Machine Options ■ Removing the Printer Cover...
  • Page 157 4. Host Machine Options ■ Removing the Flat Control Panel...
  • Page 158 4. Host Machine Options NOTE: 3 of removed screws will be used in step 8 and 1 will be used in step 13 of "Installing the Upright Arm".
  • Page 159 4. Host Machine Options...
  • Page 160 4. Host Machine Options...
  • Page 161 4. Host Machine Options...
  • Page 162 4. Host Machine Options ■ Installing the Upright Arm RS Tightening; M4x10 NOTE: Remove tapes, and insert the Upright Arm vertically into the round hole of the Frame Base.
  • Page 163 4. Host Machine Options TP; M4x8 TP; M4x8...
  • Page 164 4. Host Machine Options Middle...
  • Page 165 4. Host Machine Options...
  • Page 166 4. Host Machine Options NOTE: Use screws removed in step 3 of "Removing the Flat Control Panel". NOTE: When the NFC Kit will be installed at the same time, make sure to pass the NFC Cable through together. (Refer to the Service Manual of host machine for the installation procedure.)
  • Page 167 4. Host Machine Options TP; M3x6...
  • Page 168 4. Host Machine Options Small...
  • Page 169 4. Host Machine Options NOTE: Be careful to hold down the connector of Relay Cable so that it is securely fitted. NOTE: When the NFC Kit will be installed at the same time, make sure to connect the NFC Cable. (Refer to the Service Manual of host machine for the installation procedure.)
  • Page 170 4. Host Machine Options NOTE: Use screws removed in step 3 of "Removing the Flat Control Panel".
  • Page 171 4. Host Machine Options Install the removed Reader Unit and ADF or the Printer Cover. • When installing the Reader Unit and ADF: After performing the “Installing the Reader Unit” on page 164, proceed to “Installing the ADF” on page 166.
  • Page 172 4. Host Machine Options ■ Installing the Reader Unit...
  • Page 173 4. Host Machine Options Next, perform “Installing the ADF” on page 166.

  • Page 174: Installing The Adf

    4. Host Machine Options ■ Installing the ADF...
  • Page 175 4. Host Machine Options...
  • Page 176 4. Host Machine Options ■ Installing the Printer Cover ■ Installing the Covers...
  • Page 177 4. Host Machine Options...
  • Page 178 4. Host Machine Options CAUTION: When installing the Left Upper Cover, be careful not to secure it while it is being slided fully toward the front. Otherwise, the Left Upper Cover may interfere with the Toner Replacement Cover and the magnet cannot work.
  • Page 179 4. Host Machine Options...
  • Page 180 4. Host Machine Options CAUTION: • Turn the Panel Base to make the protrusions [A] come to the upper side. • Be sure to tighten the screws to secure the wire [B] simultaneously when installing the Panel Base. W Sems; M4x12 TP;...
  • Page 181 4. Host Machine Options TP; M4x8 P Tightening; M3x8...
  • Page 182 4. Host Machine Options P Tightening ; M3x8...
  • Page 183 4. Host Machine Options ■ Installing the Upright Control Panel Remove the packing tape from the Upright Control Panel. NOTE: If the language of the Control Panel Sheet is not appropriate for the country, perform steps 2 to 11 and replace the Control Panel Sheet.
  • Page 184 4. Host Machine Options Remove the Protection Sheet from the Upright Control Panel.
  • Page 185 4. Host Machine Options CAUTION: Disconnect the claws one by one in the direction of the arrow.
  • Page 186 4. Host Machine Options NOTE: Place the appropriate Control Panel Sheet on the Upright Control Panel, and remove the Protection Sheet from the Control Panel Sheet.
  • Page 187 4. Host Machine Options...
  • Page 188 4. Host Machine Options NOTE: When installing the Upright Control Panel, be sure to tighten the screws from the upper part. TP; M4x8...
  • Page 189 4. Host Machine Options Large...
  • Page 190 4. Host Machine Options CAUTION: • Check that the white tape of the Control Panel Cables is completely outside the Pipe Cover. • If not, adjust the cables to positions where the white tape is outside the cover.
  • Page 191 4. Host Machine Options P Tightening; M3x8 Connect the power plug to the outlet.

  • Page 192: Pre-Checks

    4. Host Machine Options If the Protection Sheet has not been removed from the Control Panel, remove it. Turn ON the main power switch. Check that the Upright Control Panel is displayed. If a message prompting the user to update the version appears, press [Update] to automatically update the version of this equipment.
  • Page 193 4. Host Machine Options ■ Checking the Contents...
  • Page 194 4. Host Machine Options Large 1x Middle 4x Small 4x W Sems; M4x12 TP; M4x8 RS Tightening; M4x10 TP; M3x6 P Tightening ; M3x8 *1 : With the iR-ADV DX C7780/C7770/C7765 Series, 2 wire saddles (middle) are used. *2 : With the iR-ADV DX C7780/C7770/C7765 Series, 3 wire saddles (middle) are used. *3 : With the iR-ADV DX 8705/8795/8786 Series and the iR-ADV DX 6780/6765/6755 Series, the Harness Band is not used.
  • Page 195 4. Host Machine Options ■ Installation Outline Drawing...

  • Page 196: Nfc Kit-E1/E2

    4. Host Machine Options NFC Kit-E1/E2 Points to Note before Installation The pictures and illustrations used may be different from the product in front of you, but the procedure is the same. Checking the Contents Only for E2 Large 1x Small 1x TP;...

  • Page 197: Points To Note When Turning On/Off The Main Power

    4. Host Machine Options Points to Note When Turning ON/OFF the Main Power The following message is displayed. 1. When a message prompting to turn OFF and then ON the main power appears, turn OFF and then ON the main power switch.
  • Page 198 4. Host Machine Options TP; M3x6...
  • Page 199 4. Host Machine Options CAUTION: Connect the cable end which is not wrapped with black tape. TP; M3x6...
  • Page 200 4. Host Machine Options CAUTION: Make sure to affix the shield sheet flat against the cover wall [A] without a gap between the shield sheet and the cover. Static electricity from the gap in the Control Panel Left Upper Cover may cause damage to the NFC PCB. TP;...
  • Page 201 4. Host Machine Options ■ Connecting the NFC Cable (for the Flat Control Panel) NOTE: The removed screw will be used in step 10.
  • Page 202 4. Host Machine Options...
  • Page 203 4. Host Machine Options...
  • Page 204 4. Host Machine Options CAUTION: Make sure to check if any connectors are disconnected by pushing again all the connectors connected to the Flat Control Panel Unit.
  • Page 205 4. Host Machine Options NOTE: Use the screws removed in step 2.
  • Page 206 4. Host Machine Options Next, proceed to “Affixing the NFC Labels” on page 203. ■ Connecting the NFC Cable (for the Upright Control Panel) NOTE: The removed screw will be used in step 11.
  • Page 207 4. Host Machine Options NOTE: Slightly pull the Front Tray Lower Unit without pulling out the cables that pass through it. NOTE: The removed screw will be used in step 8.
  • Page 208 4. Host Machine Options...
  • Page 209 4. Host Machine Options NOTE: Use the screws removed in step 4.
  • Page 210 4. Host Machine Options NOTE: Use the screws removed in step 1. Next, proceed to “Affixing the NFC Labels” on page 203.
  • Page 211 4. Host Machine Options ■ Affixing the NFC Labels...
  • Page 212 4. Host Machine Options < When installing with the NFC Kit >...
  • Page 213 4. Host Machine Options < When installing with the Connection Kit-A2 for Bluetooth LE at the same time > NOTE: If "Bluetooth" Label is already affixed there, remove the label and wipe off the glue with alcohol. ■ Setting after Installation 1.
  • Page 214 4. Host Machine Options 6. When a message prompting the version update is displayed, press [Update] and automatically update the version of this equipment. CAUTION: It may take time to display the update screen. (Approx. 1 to 2 min.) During this time, do not operate the screen. 7.

  • Page 215: Connection Kit-A2/A3 For Bluetooth Le

    4. Host Machine Options Connection Kit-A2/A3 for Bluetooth LE Points to Note before Installation The pictures and illustrations used may be different from the product in front of you, but the procedure is the same. Checking the Contents Only for A3 17.9 mm TP;...

  • Page 216: Points To Note When Turning On/Off The Main Power

    4. Host Machine Options Points to Note When Turning ON/OFF the Main Power The following message is displayed. 1. When a message prompting to turn OFF and then ON the main power appears, turn OFF and then ON the main power switch.
  • Page 217 4. Host Machine Options NOTE: The removed screw will be used in a next step.
  • Page 218 4. Host Machine Options CAUTION: Replace the removed Wi-Fi PCB with the optional Bluetooth PCB. Be sure to mount the correct one. NOTE: Use the screw removed in the previous step.
  • Page 219 4. Host Machine Options...
  • Page 220 4. Host Machine Options < When installing with the Connection Kit-A2 for Bluetooth LE >...
  • Page 221 4. Host Machine Options < When installing with the NFC Kit at the same time > NOTE: If "Bluetooth" Label is already affixed there, remove the label and wipe off the glue with alcohol before affixing the new label. • When the Target Sheet for the NFC Kit is available...
  • Page 222 4. Host Machine Options • When the Target Sheet for the NFC Kit is not available 6.0 mm...
  • Page 223 4. Host Machine Options ■ Affixing the Wireless LAN Approval Label NOTE: In countries other than the following countries, it is not necessary to affix the Approval Label. < For US > Affix it over the number on the Wireless LAN Approval Label. <...

  • Page 224: Setting After Installation

    4. Host Machine Options Setting after Installation 1. Connect the power plug of the host machine to the outlet. 2. Turn ON the main power switch. 3. In the following Service Mode, set the value to "1." COPIER > FUNCTION > INSTALL > BLE-USE NOTE: When [System Manager Information Settings] is set, it is required to log in as a system manager in accordance with instructions of the user administrator.

  • Page 225: Numeric Keypad-A1/A2

    4. Host Machine Options Numeric Keypad-A1/A2 Points to Note before Installation • When installing the Numeric Keypad and the IC Card Reader at the same time, be sure to install the Numeric Keypad first. • The pictures and illustrations used may be different from the product in front of you, but the procedure is the same. Checking the Contents P Tightening;...

  • Page 226: Points To Note When Turning On/Off The Main Power

    4. Host Machine Options Points to Note When Turning ON/OFF the Main Power The following message is displayed. 1. When a message prompting to turn OFF and then ON the main power appears, turn OFF and then ON the main power switch.
  • Page 227 4. Host Machine Options...
  • Page 228 4. Host Machine Options CAUTION: Be sure to check that the 2 bosses are fitted securely. Installing the Control Panel Right Upper Cover while the bosses are not fitted securely will cause rattling. P Tightening; M3x8...
  • Page 229 4. Host Machine Options Small TP; M3x6...
  • Page 230 4. Host Machine Options NOTE: Attach the first core along with the white tape affixed to the Numeric Keypad cable. Fold the cable as shown in the figure, and attach the second core in a line-symmetric position with respect to the core attached first.
  • Page 231 4. Host Machine Options Large...
  • Page 232 4. Host Machine Options...
  • Page 233 4. Host Machine Options < When installing the Numeric Keypad only > NOTE: Store the excess length of the cable in the position as shown in the figure. < When installing with the IC Card Reader at the same time > NOTE: Store the excess length of the cable in the position as shown in the figure.
  • Page 234 4. Host Machine Options TP; M3x6 CAUTION: Place the Core in the position as shown in the figure.
  • Page 235 4. Host Machine Options Connect the power plug to the outlet. Turn ON the main power switch.

  • Page 236: Utility Tray-B1

    4. Host Machine Options Utility Tray-B1 Points to Note at Installation • The pictures and illustrations used may be different from the product in front of you, but the procedure is the same. • Refer to "Table of Options Combination" when installing this equipment before operation. Table of Options Combination Voice Operation Voice Guidance Kit...

  • Page 237: Installation Procedure

    4. Host Machine Options Installation Procedure Remove packing tapes.
  • Page 238 4. Host Machine Options CAUTION: To avoid damage, do not pull the Utility Tray too much.
  • Page 239 4. Host Machine Options CAUTION: To avoid damage, do not pull the Utility Tray too much.
  • Page 240 4. Host Machine Options CAUTION: Points to Note at Installation If the holes are marked as shown below, align the holes marked with B, G and P with the holes in the host machine TP ; M4x14...
  • Page 241 4. Host Machine Options TP ; M4x10...
  • Page 242 4. Host Machine Options ■ When Installing the USB Keyboard...

  • Page 243: Copy Card Reader-F1

    4. Host Machine Options Copy Card Reader-F1 Points to Note at Installation • To install this equipment, the Copy Card Reader Attachment is required. • After installing the Copy Card Reader, input the card number to be used in service mode. Otherwise the card cannot be recognized even though it is inserted.

  • Page 244: Installation Outline Drawing

    4. Host Machine Options Installation Outline Drawing Checking the Contents <Copy Card Reader-F1> [2] Toothed washer X 1 [1] Card Reader Unit X 1 [3] Screw (RS tight; M4x10) X 1...
  • Page 245 4. Host Machine Options <Copy Card Reader Attachment- A4> [1] Card Reader [2] Card Reader Mounting Plate X 1 Mounting Plate X 1 Used only for the Used only for the Flat Control Panel Upright Control Panel [4] Card Reader External [3] Card Reader Relay Relay Harness X 1...

  • Page 246: Installation Procedure

    4. Host Machine Options [11] Screw [12] Screw (Binding; M3x6) X 1 (TP; M4x12) X 1 Used only for the Upright Control Panel [13] Screw [14] Screw (RS tight; M4x8) X 1 (Binding; M4x20) X 1 Used only for the Used only for the Flat Control Panel Upright Control Panel...
  • Page 247 4. Host Machine Options 2. Remove the Right Upper Cover. • 2 Screws • 3Protrusions • 1Boss 3. Close the Right Cover. 4. Remove the Right Rear Cover 2. • 1 Screw • 1 Protrusion Protrusion...

  • Page 248: Installing The Card Reader

    4. Host Machine Options 5. Install the Card Reader Mounting Plate. • 1 Screw (Binding; M4x6) Binding; M4x6 6. Install the Right Rear Cover 2 (1 Screw). 7. Open the Right Cover, and then install the Right Upper Cover (2 Screws). 8.
  • Page 249 4. Host Machine Options CAUTION: Be careful not to let the 2 bosses of the Side Cover come off from the 2 mounting holes of the Right Rear Cover 1. 2. Hold the handle to remove the Main Controller PCB 1. •...
  • Page 250 4. Host Machine Options 3. Remove the Face Cover. (The removed Face Cover will not be used.) • 2 Screws(The removed screws will be used in step 5) 4. Remove the screw, and install the PCB Spacer. (The removed screws will not be used.)
  • Page 251 4. Host Machine Options 5. Install the Card Reader Reply Unit. • 1 Connector • 2 Screws (Use the screws removed in step 3.) • 1 Screw (Binding; M3x6) Binding; M3x6 6. Insert the Main Controller PCB 1 until it stops. •...
  • Page 252 4. Host Machine Options 7. Connect the Card Reader External Relay Harness. 8. Remove the Screw ( The removed screws will be used at next step.)
  • Page 253 4. Host Machine Options 9. Install the Connector Cover to the Card Reader External Relay Harness. • 1 Screw ( Use the screw removed at previous step.) CAUTION: • Install the screw to the [A] part. • When installing the Connector Cover, be sure to place the tie-wrap on the Card Reader External Relay Harness on the inside of the Connector Cover.
  • Page 254 4. Host Machine Options 11. Close the Right Rear Cover 1. 12. Remove the Lower Cover of the Card Reader Unit, and change the position of the cable. • 1 Claw • 1 Screw Lower Cover Claw Groove Claw...
  • Page 255 4. Host Machine Options 13. Disconnect the Short Connector on the Card Reader. (The removed Short Connector will not be used.)
  • Page 256 4. Host Machine Options 14. Install the Card Reader. <In the Case of Upright Control Panel> 14-1. Install the Card Reader to the Card Reader Mounting Plate. • 2 Bosses • 1 Toothed Washer • 1 Screw (RS Tightening; M4x8) RS tight;...
  • Page 257 4. Host Machine Options Binding ; M4x20 Boss 15. If the Upright Control Panel is installed, put the connector of the Card Reader Unit through the hole on the Card Reader Mounting Plate. NOTE: While pictures of the Upright Control Panel model are used for explaining the steps 16 and 17, the procedure is the same for the Flat Control Panel model.
  • Page 258 4. Host Machine Options tie-wrap tie-wrap NOTE: While pictures of the Flat Control Panel model are used for explaining the following steps, the procedure is the same for the Upright Control Panel model. 18. Remove the cover of Cord Guide, and affix it to the area indicated in the figure. 19.

  • Page 259: Checking After Installation

    4. Host Machine Options 20. Push the Card Reader External Relay Harness in the Right Rear Cover 1. Checking after Installation 1. Connect the power plug of the host machine to the power outlet. 2. Turn the main power switch ON. 3.

  • Page 260: Serial Interface Kit-K3 / Copy Control Interface Kit-A1

    4. Host Machine Options Serial Interface Kit-K3 / Copy Control Interface Kit-A1 Points to Note at Installation When installing this equipment, be sure to install it by referring to "Table of Options Combination". Table of Options Combination Copy Control Interface Voice Opera- Voice Guidance Copy Card...

  • Page 261: Essential Items To Be Performed Before Installation

    4. Host Machine Options [9] RS Conversion [10] RS Conversion Cable (Long) X 1 Cable X 1 <Copy Control Interface Kit-A1> [1] CC-VI Cable X 1 [2] D-SUB Support Plate [3] Washer (large) X 2 [4] IA Harness Protection Sheet X 1 [5] Hexagonal Screw (Spring Washer (Small) ,Nut) X 2 Do not use a Nut Essential Items to Be Performed Before Installation...

  • Page 262: Installation Outline Drawing

    4. Host Machine Options 2. If a message prompting the user to update the version appears, press [Update] to automatically update the version of this equipment. If [Skip] is selected, a message prompting the user to update the version will appear every time the host machine is started. In the service mode (Lv.
  • Page 263 4. Host Machine Options CAUTION: Be careful not to let the 2 bosses of the Side Cover come off from the 2 mounting holes of the Right Rear Cover 1. 2. Hold the handle to remove the Main Controller PCB 1. •...
  • Page 264 4. Host Machine Options ■ Installing the Serial Interface Kit 1. Remove the screw, and install the PCB Spacer (The removed screw will be used in step 3).
  • Page 265 4. Host Machine Options 2. Connect the RS Conversion Cable (short) to the Serial RS Conversion Board. 3. Install the Serial RS Conversion Board. • 1 Screw (Use the screw removed in step1) • 2 Washers • 2 Hexagon Screws •...
  • Page 266 4. Host Machine Options ■ Installing the Copy Control interface Kit 1. Put the CC-VI Cable through the D-SUB Support Plate. CAUTION: Install the extruded side of the D-SUB Support Plate as shown in the figure. Inside D-SUB Support Plate CC-VI Cable 2.
  • Page 267 4. Host Machine Options Connector Handle CAUTION: Be sure to push [A] part hard to install it, otherwise the connector may not be connected properly.
  • Page 268 4. Host Machine Options 2. Install the Side Cover, and then Close the Right Rear Cover 1. • 1Hook • 2 Screws CAUTION: Be careful not to let the 2 bosses of the Side Cover come off from the 2 mounting holes of the Right Rear Cover 1. Hook 3.

  • Page 269: Voice Operation Kit-D1

    4. Host Machine Options Voice Operation Kit-D1 Points to Note Before Installation • The pictures and illustrations used may be different from the product in front of you, but the procedure is the same. • When installing this equipment, the option Numeric Keypad is required. Refer to the Installation Procedure for the Numeric Keypad when installing the Numeric Keypad.

  • Page 270: Essential Items To Be Performed Before Installation

    4. Host Machine Options [10] Screw [9] Screw (TP; M3x6) X 2 (Bind; M4x14) X 2 Use only 1 of them [12] Wire Saddle X 3 [11] Ring Core X 1 [13] Screw [14] Screw (Bind; M4x20) X 2 (Bind ; M3x14) X 1 [7]: Use 6 of them for the Flat Control Panel model.

  • Page 271: Installation Outline Drawing

    4. Host Machine Options Installation Outline Drawing Installation Procedure 1. Open the Right Rear Cover 1, and then remove the Side Cover. • 2 Screws • 1 Hook Hook CAUTION: Be careful not to let the 2 bosses of the Side Cover come off from the 2 mounting holes of the Right Rear Cover 1.
  • Page 272 4. Host Machine Options 2. Hold the handle to remove the Main Controller PCB 1. • 1 Connector Connector Handle CAUTION: Be sure to place the removed Main Controller PCB 1 flatly. Reason: Due to the protruded plate, the PCB may be deformed if work is performed while it is placed at an angle.
  • Page 273 4. Host Machine Options 4. Install the Voice Operation Board Unit to the Main Controller PCB 1. • 1 Connector • 2 Screws (Use the screw removed at previous step) • 1 Screw (TP; M3x6) NOTE: Check that the connector is connected properly. TP M3x6 Connector...
  • Page 274 4. Host Machine Options 5. Insert the Main Controller PCB 1 until it stops. • 1 Connector Connector Handle CAUTION: Be sure to push [A] part hard to install it, otherwise the connector may not be connected properly. 6. Be sure to push [A] part hard to install it, otherwise the connector may not be connected properly. NOTE: When cutting off the part, be sure not to make burrs .
  • Page 275 4. Host Machine Options 7. Install the Side Cover. • 1 Hook • 2 Screws CAUTION: Be careful not to let the 2 bosses of the Side Cover come off from the 2 mounting holes of the Right Rear Cover 1. Hook 8.
  • Page 276 4. Host Machine Options 9. Pass the DVI Cable through the hole of the Side Cover, and connect the DVI Cable to the Voice Operation Board Unit. 10. Close the Right Rear Cover 1. 11. Remove the 2 Rubber Caps from the Right Upper Cover. (The removed Rubber Caps will not be used.)
  • Page 277 4. Host Machine Options 12. Remove the Speaker Unit (Lower) from the Speaker Unit. • 2 Screws (The removed screw will be used in step 14) Speaker Unit (Lower) 13. Install the Speaker Unit (Lower). • 2 Screws (Binding; M4x20) Binding M4x20...
  • Page 278 4. Host Machine Options 14. Install the Speaker Unit (Upper). • 2 Screws (Use the screw removed in step 12.) 15. Remove the cover of Cord Guide, and affix it to the area indicated in the figure. < In the Case of Flat Control Panel> NOTE: Even when this kit is used in combination with a Copy Card Reader, the positions to install the Cord Guides are the same.
  • Page 279 4. Host Machine Options <Rear side> NOTE: Be sure to affix them on the extension lines of [A] and [B]. Screw Rear Cover 2 < In the Case of Upright Control Panel> NOTE: Even when this kit is used in combination with a Copy Card Reader, the positions to install the Cord Guides are the same. •...
  • Page 280 4. Host Machine Options Screw holes <Rear side > NOTE: [Be sure to affix them on the extension lines of [A] and [B]. Screw Rear Cover 2 16. Connect the DVI Cable to the Speaker Unit.
  • Page 281 4. Host Machine Options 17. Put the Speaker Cable through the Cord Guide, and install the cover of the cord guide. CAUTION: Be sure to slack off [A] par for not interfering to open/close the Right Rear Cover1. < In the Case of Flat Control Panel > •...

  • Page 282: Checking After Installation

    4. Host Machine Options Checking after Installation NOTE: When changing the settings upon user’s request, it is required to log in as a system manager in accordance with instructions from the user administrator. 1. Connect the power plug of the host machine to the outlet. 2.

  • Page 283: Voice Guidance Kit-G1

    4. Host Machine Options Voice Guidance Kit-G1 Points to Note at Installation • The pictures and illustrations used may be different from the product in front of you, but the procedure is the same. • When installing this equipment, the option Numeric Keypad is required. Refer to the Installation Procedure for the Numeric Keypad when installing the Numeric Keypad.

  • Page 284: Essential Items To Be Performed Before Installation

    4. Host Machine Options [10] Screw [9] Screw (TP ; M3x6) X 4 (Binding ; M4x16) X 2 Use 3 of them [12] Voice Guidance Board [11] Screw Support Plate X 1 (Binding ; M3x16) X 1 [13] Cable Face Seal X 1 [14] Card Spacer X 1 <Others>...

  • Page 285: Installation Outline Drawing

    4. Host Machine Options Installation Outline Drawing Installation Procedure 1. Open the Right Rear Cover 1, and remove the Side Cover. • 2 Screws • 1 Hook Hook CAUTION: Be careful not to let the 2 bosses of the Side Cover come off from the 2 mounting holes of the Right Rear Cover 1.
  • Page 286 4. Host Machine Options 2. Hold the handle to remove the Main Controller. • 1 Connector Connector Handle CAUTION: Be sure to place the removed Main Controller PCB 1 flatly. Reason: Due to the protruded plate, the PCB may be deformed if work is performed while it is placed at an angle.
  • Page 287 4. Host Machine Options 4. Install the Voice Guidance Board Unit to the Main Controller PCB 1. • 1 Connector • 3 Screws (TP; M3x6) NOTE: Check that the connector is connected properly. TP M3x6 Connector...
  • Page 288 4. Host Machine Options 5. Insert the Main Controller PCB 1 until it stops. • 1 Connector Connector Handle CAUTION: Be sure to push [A] part hard to install it, otherwise the connector may not be connected. 6. Cut off [A] part of the Side Cover with nippers. NOTE: When cutting off the part, be sure not to make burrs.
  • Page 289 4. Host Machine Options 7. Install the Side Cover. • 1 Hook • 2 Screws CAUTION: Be careful not to let the 2 bosses of the Side Cover come off from the 2 mounting holes of the Right Rear Cover 1. Hook...
  • Page 290 4. Host Machine Options 8. Attach the 2 Ring Cores to both ends of the Speaker Cable. NOTE: < In the Case of Upright Control Panel> <In the Case of Upright Control Panel> When installing the Card Reader at the same time, be sure to install a Ring Core only to one end of the Speaker Cable.
  • Page 291 4. Host Machine Options 10. Retrieve the Speaker Cable from the position shown in the figure, and close the Right Rear Cover 1. 11. Remove the 2 Rubber Caps from the Right Upper Cover. (The removed Rubber Caps will not be used.)
  • Page 292 4. Host Machine Options 12. Install the Speaker Unit (Lower). • 2 Screws (Binding; M4x20) Binding M4x20 13. Install the Speaker Unit (Upper). • 1 Screw (Binding; M4x6) Binding M4x6 14. Connect the Speaker Cable to the Speaker Unit. 15. Remove the 4 covers from the Cord Guides, and affix them as shown in the figure.
  • Page 293 4. Host Machine Options 16. Pass the Speaker Cable through the Cord Guides, and fit the 4 covers on the Cord Guides. Screw 150 mm NOTE: When using together with the Copy Card Reader < In the Case of Upright Control Panel> 1.

  • Page 294: Checking After Installation

    4. Host Machine Options Screw 150 mm < In the Case of Flat Control Panel> 1. Connect the Speaker Cable to the Speaker Unit. 2. Remove the 4 covers from the Cord Guides, and affix them as shown in the figure. 3.

  • Page 295: Operation Check

    4. Host Machine Options Operation Check NOTE: Perform the following check from the Voice Recognition button on the numeric keypad. ■ When Using 1. Press the Voice Guidance Start button. 2. Once the indication on the screen is framed in red, the "Voice Guidance Kit" becomes enabled. ■...

  • Page 296: Hdd-Related Option

    4. Host Machine Options HDD-related Option Pre-checks ■ Points to Note at Installation CAUTION: • For TYPE2 to TYPE3, be sure to perform the procedure of each TYPE after performing “Removing the HDD Box Unit” on page 289. • When using the mirroring function, be sure to install 2 HDDs of the same capacity. •...

  • Page 297: Removing The Hdd Box Unit

    4. Host Machine Options ■ Points to Note When Turning ON/OFF the Main Power The following message is displayed. 1. When a message prompting to turn OFF and then ON the main power appears, turn OFF and then ON the main power switch.
  • Page 298 4. Host Machine Options 3. Remove the HDD. NOTE: When replacing with the Option HDD (1TB), the removed HDD will not be used. 4. Close the HDD Lid. NOTE: Do not tighten the screw here.
  • Page 299 4. Host Machine Options 5. Remove the Side Cover. • 2 Screws • 1 Hook Hook CAUTION: Be careful not to let the 2 bosses of the Side Cover come off from the 2 mounting holes of the Right Rear Cover 1. 6.
  • Page 300 4. Host Machine Options 7. Remove the HDD Box Unit. • 2 Connectors • 2 Screws • 2 Hooks Hook 8. Open the HDD Lid, and remove the HDD Outside Cover. • 4 Screws • 1 Protrusion Protrusion 9. Remove the HDD Unit. •...

  • Page 301: [Type-1] Option Hdd (1Tb)

    4. Host Machine Options 10. Remove the HDD Side Cover. • 4 Screws • 4 Bosses Boss Boss [TYPE-1] Option HDD (1TB) ■ Checking the Contents [1] HDD X 1 [2] HDD Case X 1 [3] HDD Holder Hinge X 1 [4] HDD Case Hinge Base X 1 [5] Screw...
  • Page 302 4. Host Machine Options ■ Essential Items to Be Performed Before Installation • Turn OFF the main power of the host machine, and disconnect the power plug from the outlet. WARNING: • If performing work without disconnecting the power plug of the host machine, it may cause electrical shock. •...
  • Page 303 4. Host Machine Options 2. Open the HDD Lid. • 1 Screw (will be used in step 7) 3. Remove the HDD. (The removed HDD will not be used.)
  • Page 304 4. Host Machine Options 4. Fit the Hinge Pin of the HDD Holder Hinge with the groove of the HDD Case Hinge Base to install it to the HDD Case. • 2 Bosses • 2 Screws (P Tightening; M3x8) Boss P Tightening ;...

  • Page 305: Hdd Initialization Procedure

    4. Host Machine Options 6. Install the Option HDD to the host machine. 7. Close the HDD Lid. • 1 Screw (screws removed in step 2) 8. Close the Right Rear Cover 1. ■ HDD Initialization Procedure 1. Requirements 1. PC Service Support Tool in the version that supports this host machine must be installed.
  • Page 306 4. Host Machine Options 2. Preparing for the Installation of the System Software of Host machine 1. If both PC and the machine are on, turn them off. 2. Connect the PC and the host machine using an Cross Ethernet cable. (when SST is used) 3.

  • Page 307: [Type-2] Standard Hdd + Option Hdd (250Gb) + Hdd Mirroring Kit

    4. Host Machine Options [TYPE-2] Standard HDD + Option HDD (250GB) + HDD Mirroring Kit ■ Checking the Contents <Option HDD (250 GB)> [1] HDD X 1 [2] HDD Case X 1 [3] HDD Holder Hinge X 1 [4] HDD Case Hinge Base X 1 [5] Screw [6] Screw...
  • Page 308 4. Host Machine Options <HDD Mirroring Kit> CAUTION: Although the red cable shown below may sometimes be supplied in lieu of the HDD Cable 2 (Blue), the procedure for connecting the red cable is the same as that for the blue cable. When connecting the cable to the Controller PCB, make sure to first confirm that the sticker [B] is attached to the cable and then connect the cable to the Controller PCB.
  • Page 309 4. Host Machine Options 2. If a message prompting the user to update the version appears, press [Update] to automatically update the version of this equipment. If [Skip] is selected, a message prompting the user to update the version will appear every time the host machine is started. In the service mode (Lv.
  • Page 310 4. Host Machine Options 2. Install the assembled HDD Case to the HDD. • 4 Screws (Sems; M3x4) Sems; M3x4 3. Install the Option HDD to the Slot 2 (Right). 4. Close the HDD Lid. • 1 Screw (Use the removed screws)
  • Page 311 4. Host Machine Options 5. Close the Right Rear Cover 1. ■ Installing the HDD Mirroring Kit 1. Remove the HDD Wrong Insertion Prevention Plate. (The removed parts will not be used.) • 1 Screw • 1 Protrusion Protrusion...
  • Page 312 4. Host Machine Options 2. Assemble the HDD Cable 2 (Blue or Red) and the HDD Connector Support Plate. • 2 Bosses • 2 Screws (TP; M3x8 Black) Boss TP; M3x8 Black 3. Install the assembled HDD Cable 2 Unit to the HDD Unit. •...
  • Page 313 4. Host Machine Options 4. Installing the HDD Side Cover. • 4 Bosses • 4 Screws (Use the removed screws) Boss Boss 5. Put the 4 cables through the hole, and install the HDD Unit according to the marking lines. •...
  • Page 314 4. Host Machine Options 6. Install the HDD Outside Cover, and close the HDD Lid. • 1 Protrusion • 4 Screws (Use the removed screws) Protrusion 7. Put the 4 cables through the hole, and install the HDD Box Unit. •...
  • Page 315 4. Host Machine Options 9. Connect the HDD Cable 2 (Blue) or the HDD Cable 2 (Red) with a sticker labeled [B] to [B] on the Controller PCB. • 2 Connectors < When using the HDD Cable 2 (Blue) > <...
  • Page 316 4. Host Machine Options 10. Insert the Main Controller PCB 1 until it stops. • 1 Connector Connector Handle CAUTION: Be sure to push [A] part hard to install it, otherwise the connector may not be connected properly. 11. Install the Side Cover. Do not close the Right Rear Cover 1 yet here. •...
  • Page 317 4. Host Machine Options 12. Open the HDD Lid. 13. Return the HDD removed from the host machine to the Slot 1 (Left). ■ Setting the Mirroring 1. Set the setting value for the mirroring to "1" in the following service mode. COPIER >...

  • Page 318: [Type-3] 2 Option Hdds (1Tb) + Hdd Mirroring Kit

    4. Host Machine Options CAUTION: Rebuild process starts after setting "1" for W/RAID. If an error occurs during the rebuild process at the initial installation the hard disk needs to be replaced. (Call service rep.), reexecute the process with the following procedure. 1.
  • Page 319 4. Host Machine Options <HDD Mirroring Kit> CAUTION: Although the red cable shown below may sometimes be supplied in lieu of the HDD Cable 2 (Blue), the procedure for connecting the red cable is the same as that for the blue cable. When connecting the cable to the Controller PCB, make sure to first confirm that the sticker [B] is attached to the cable and then connect the cable to the Controller PCB.
  • Page 320 4. Host Machine Options 2. If a message prompting the user to update the version appears, press [Update] to automatically update the version of this equipment. If [Skip] is selected, a message prompting the user to update the version will appear every time the host machine is started. In the service mode (Lv.
  • Page 321 4. Host Machine Options 3. Install the assembled HDD Cable 2 Unit to the HDD Unit. • 2 Bosses • 2 Screws (TP; M3x6) TP; M3x6 Boss Boss 4. Install the HDD Side Cover. • 4 Bosses • 4 Screws (Use the removed screws) Boss Boss...
  • Page 322 4. Host Machine Options 5. Put the 4 cables through the hole, and install the HDD Unit according to the marking lines. • 4 Screws (Use the removed screws) Marking Line 6. Install the HDD Outside Cover, and close the HDD Lid. •...
  • Page 323 4. Host Machine Options 7. Put the 4 cables through the hole, and install the HDD Box Unit. • 2 Hooks • 2 Screws (Use the removed screws) Hook CAUTION: Be sure to connect the communication cable to the correct port. The HDD error occurs. 8.
  • Page 324 4. Host Machine Options 9. Connect the HDD Cable 2 (Blue) or the HDD Cable 2 (Red) with a sticker labeled [B] to [B] on the Controller PCB. • 2 Connectors < When using the HDD Cable 2 (Blue) > <...
  • Page 325 4. Host Machine Options 10. Insert the Main Controller PCB 1 until it stops. • 1 Connector Connector Handle CAUTION: Be sure to push [A] part hard to install it, otherwise the connector may not be connected properly. 11. Install the Side Cover. Do not close the Right Rear Cover 1 yet here. •...
  • Page 326 4. Host Machine Options 12. Open the HDD Lid. ● Assembling and Installing the Option HDD 1. Fit the Hinge Pin of the HDD Holder Hinge with the groove of the HDD Case Hinge Base to install it to the HDD Case. •...
  • Page 327 4. Host Machine Options 2. Install the assembled HDD Case to the HDD. • 4 Screws (Sems; M3x4) Sems; M3x4 3. Install the First Option HDD to the Slot 1 (Left). 4. Assemble the Second Option HDD with same steps of Step 1 to Step 2. 5.
  • Page 328 4. Host Machine Options 6. Close the HDD Lid. • 1 Screw (Use the removed screws) 7. Close the Right Rear Cover 1. ■ HDD Initialization Procedure 1. Requirements 1. PC Service Support Tool in the version that supports this host machine must be installed. 2.
  • Page 329 4. Host Machine Options 4. Initializing HDD <In case of SST> 1. Start the host machine with download mode in safe mode. 2. Start the SST. 3. Select the model. Then, select [Single] and click [Start]. 4. Click [Format HDD]. 5.

  • Page 330: Executing Auto Gradation Adjustment

    4. Host Machine Options CAUTION: Rebuild process starts after setting "1" for W/RAID. If an error occurs during the rebuild process at the initial installation the hard disk needs to be replaced. (Call service rep.), reexecute the process with the following procedure. 1.

  • Page 331: Super G3 Fax Board-As1

    4. Host Machine Options Super G3 FAX Board-AS1 Product Name Safety regulations require the product's name to be registered. In some regions where this product is sold, the following name may be registered instead. • F632501 Points to Note at Installation •...

  • Page 332: Checking The Contents

    4. Host Machine Options Checking the Contents [1] FAX Unit X 1 [2] Screw [3] Modular Label [4] Fax Approval Labele (TP; M3x4 Black) X 1 Included for USA and Taiwan [5] Telephone Cord [6] Telephone Cord [7] PTT Cable [8] PTT Plug (2 Contact type) X 1 (6 Contact type)
  • Page 333 4. Host Machine Options 2. Remove the Rear Cover 2. • 3 Screws • 2 Protrusions Protrusion 3. Remove the Face Cover. (The removed parts will not be used.) • 1 Screw (used in the next step only in EUR) •...
  • Page 334 4. Host Machine Options NOTE: This step is only for Europe. 4. Install the Modular Cover. • 1 Protrusion • 1 Screw (use the screw removed in the previous step) 5. Remove the tape and, install the Fax Unit. • 2 Protrusions •...
  • Page 335 4. Host Machine Options 6. Connect the 2 cables of the FAX Unit. • 2 Connectors 7. Affix the following FAX Approval Label. • [A] For USA • [B] For Taiwan 8. Affix the appropriate Modular Label to the place shown in the figure.
  • Page 336 4. Host Machine Options NOTE: This step is only for Europe. Do not connect the Telephone Cord (2 contact type) with the PTT Plug. 9. Connect the PTT Plug matched the field or area to the PTT Cable (6 contact type). 10.

  • Page 337: Checking The Operation

    4. Host Machine Options 11. Install the Rear Cover 2. • 2 Protrusions • 3 Screws Protrusion 12. Install the Left Rear Cover. • 1 Hook • 1 Claw Claw Hook 13. Connect the Power Plug to the outlet. 14. Turn ON the main power switch. CAUTION: If the machine does not recognize this equipment, unplug and then plug the power plug after turning OFF the main power switch, or turn OFF the main power switch and then turn it ON within 20 seconds.
  • Page 338 4. Host Machine Options 2. Confirm that service mode parameter below is "0". In the case, parameter is "1", change to "0". COPIER > OPTION > DSPLY-SW > SDTM-DSP NOTE: To change parameter to "0" makes no show below [Settings/Registration > Preferences > Time/Energy Settings > Auto Shutdown Time] and auto shut down is not available.

  • Page 339: Super G3 Fax Board-As2

    4. Host Machine Options Super G3 FAX Board-AS2 Product Name Safety regulations require the product's name to be registered. In some regions where this product is sold, the following name may be registered instead. • F632501 Points to Note at Installation •...

  • Page 340: Checking The Contents

    4. Host Machine Options Checking the Contents [1] FAX Unit X 1 [2] Screw (TP; M3x4 Black) X 1 [3] Modular Label [4] Fax Approval Labele [5] Telephone Cord (2 Contact type) X 1 < Others > • Including guides Installation Procedure 1.
  • Page 341 4. Host Machine Options 2. Remove the Rear Cover 2. • 3 Screws • 2 Protrusions Protrusion 3. Remove the Face Cover. (The removed parts will not be used.) • 1 Screw • 1 Protrusion...
  • Page 342 4. Host Machine Options 4. Remove the tape and, install the Fax Unit. • 2 Protrusions • 1 Screw (TP; M3x4: Black) CAUTION: • Be careful not to damage the [A] part of the speaker as the wiring may be broken. •...
  • Page 343 4. Host Machine Options 6. Affix the following FAX Approval Label. 7. Affix the appropriate Modular Label to the place shown in the figure. 8. Connect the end of the Telephone Cord to the modular jack on the Host machine, and connect the other end to the modular jack on the wall.

  • Page 344: Checking The Operation

    4. Host Machine Options 9. Install the Rear Cover 2. • 2 Protrusions • 3 Screws Protrusion 10. Install the Left Rear Cover. • 1 Hook • 1 Claw Claw Hook 11. Connect the Power Plug to the outlet. 12. Turn ON the main power switch. CAUTION: If the machine does not recognize this equipment, unplug and then plug the power plug after turning OFF the main power switch, or turn OFF the main power switch and then turn it ON within 20 seconds.
  • Page 345 4. Host Machine Options 2. Confirm that service mode parameter below is "0". In the case, parameter is "1", change to "0". COPIER > OPTION > DSPLY-SW > SDTM-DSP NOTE: To change parameter to "0" makes no show below [Settings/Registration > Preferences > Time/Energy Settings > Auto Shutdown Time] and auto shut down is not available.

  • Page 346: Super G3 2Nd Line Fax Board-As1

    4. Host Machine Options Super G3 2nd Line Fax Board-AS1 Product Name Safety regulations require the product's name to be registered. In some regions where this product is sold, the following name may be registered instead. • F632502 Points to Note at Installation When installing the Super G3 FAX Board and this equipment at the same time, be sure to install them by referring to this document after checking "Checking the Contents"...

  • Page 347: Checking The Contents

    4. Host Machine Options Checking the Contents [1] G3FAX Expansion [2] Modular PCB X 1 PCB X 1 [3] USB Cable X 1 [4] Modular Cable X 1 [5] Signal Cable X 1 [6] FAX Shield Plate X 1 [7] FAX Board Fixed Plate [8] PCB Spacer (Long) [9] PCB Spacer (Short) [10] Modular Label X 1...
  • Page 348 4. Host Machine Options Screw (TP; M3x4) [11] Dust Cover X 2 [12] [13] Screw [14] Fax Approval Labele (Binding; M4x4) X 1 (only for Taiwan) X 1 [15] Telephone Cord [16] Telephone Cord (2 Contact type) X 1 (6 Contact type) (only for Europe) X 1 [17] PTT Cable [18] PTT Plug...

  • Page 349: Installation Procedure

    4. Host Machine Options Installation Procedure ■ Preparation 1. Remove the Left Rear Cover. • 1 Claw • 1 Hook Claw Hook 2. Remove the Rear Cover 2. • 3 Screws • 2 Protrusions Protrusion NOTE: • When the Super G3 FAX Board is installed: Perform steps 3 and 4, and proceed to step 7. •...
  • Page 350 4. Host Machine Options 3. Disconnect the Telephone Cord of the FAX (1-Line). 4. Remove the FAX Unit. • 2 Connectors • 1 Screw • 2 Protrusions CAUTION: Be careful not to damage the [A] part of the speaker as the wiring may be open circuit. Protrusion...
  • Page 351 4. Host Machine Options 5. Remove the Face Cover of the FAX (1-Line). (The removed parts will not be used.) • 1 Screw (used in the next step only in EUR) • 1 Protrusion NOTE: This step is only for Europe. 6.

  • Page 352: Installing The Equipment

    4. Host Machine Options 7. Remove the Face Cover of the FAX (2-Line). (The removed parts will not be used.) • 1 Screw • 1 Protrusion ■ Installing the Equipment 1. Free the Cable from the Wire Saddle.
  • Page 353 4. Host Machine Options 2. Install the Signal Cable to the FAX Unit. • 3 Cable Guides 3. Install the Modular Cable to the Modular PCB.
  • Page 354 4. Host Machine Options 4. Install the Modular PCB to the FAX Unit. • 2 Screws (TP; M3x4) TP; M3x4...
  • Page 355 4. Host Machine Options 5. Install the FAX Unit to the Host Machine. • 2 Protrusions • 1 Screw (TP; M3x4 Black) (Use the removed screw or those included with the Super G3 FAX Board) CAUTION: • Be careful not to damage the [A] part of the speaker as the wiring may be broken. •...
  • Page 356 4. Host Machine Options 7. Remove the 2 Screws. (will be used in next step) 8. Install the FAX Shield Plate. • 2 Screws (screws removed in the previous step)
  • Page 357 4. Host Machine Options 9. Install the FAX Board Fixed Plate. • 2 Bosses • 1 Screw (Binding; M4x4) Binding; M4x4 Boss...
  • Page 358 4. Host Machine Options 10. Remove the Screw and install the PCB Spacer (Short). (The removed screw will not be used.) PCB Spacer (Short)
  • Page 359 4. Host Machine Options 11. Install the 3 PCB Spacers (Long). PCB Spacer (Long) 12. Install the G3FAX Expansion PCB. • 6 Screws (TP; M3x4) NOTE: Because the 4 screws [A] need to be removed when installing the Super G3 3rd/4th Line Fax Board at the same time, it is efficient not to tighten them here.
  • Page 360 4. Host Machine Options 13. Install the Signal Cable, Power Supply Cable and USB Cable to the G3FAX Expansion PCB. • 1 Wire Saddle NOTE: Because [A] of the USB Cable needs to be disconnected when installing the Super G3 3rd/4th Line Fax Board at the same time, it is efficient not to connect it here.
  • Page 361 4. Host Machine Options NOTE: When installing the Super G3 3rd/4th Line Fax Board at the same time, the following step is not necessary. 15. Secure the cable with the Wire Saddle. ■ Subsequent Work NOTE: The following work is required only when installing the Super G3 FAX Board at the same time. 1.
  • Page 362 4. Host Machine Options NOTE: This step is only for Taiwan. 2. Affix the following FAX Approval Label. NOTE: When installing the Super G3 3rd/4th Line Fax Board at the same time, the following step is not necessary. 3. Affix the appropriate Modular Label. If a label is already affixed, remove it and then affix the appropriate label.
  • Page 363 4. Host Machine Options 4. Connect the PTT Cable or Telephone Cord of the FAX (1-Line). When installing this equipment at the same time, connect the other end to the modular jack on the wall. 5. Connect the end of the PTT Cable or Telephone Cord to the modular jack on the Host machine, and connect the other end to the modular jack on the wall.
  • Page 364 4. Host Machine Options NOTE: When performing the following steps, it is efficient to install the cover after installing the Super G3 3rd/4th Line Fax Board in case of installing the fax board at the same time. 7. Install the Rear Cover 2. •...

  • Page 365: Checking The Operation

    4. Host Machine Options 11. If a message prompting the user to update the version appears, press [Update] to automatically update the version of this equipment. NOTE: If [Skip] is selected, a message prompting the user to update the version will appear every time the host machine is started. In the service mode (Lev.
  • Page 366 4. Host Machine Options 3. Send and receive a test original between the equipment and a remote unit with which a communication test can be performed and check if it can be sent and receive correctly. 1. Press [Status Monitor/Cancel] > [Send] > [Job Log] and select [Fax] from pull down menu. 2.

  • Page 367: Super G3 2Nd Line Fax Board-As2

    4. Host Machine Options Super G3 2nd Line Fax Board-AS2 Product Name Safety regulations require the product's name to be registered. In some regions where this product is sold, the following name may be registered instead. • F632502 Points to Note at Installation When installing the Super G3 FAX Board and this equipment at the same time, be sure to install them by referring to this document after checking "Checking the Contents"...

  • Page 368: Checking The Contents

    4. Host Machine Options Checking the Contents [1] G3FAX Expansion [2] Modular PCB X 1 PCB X 1 [3] USB Cable X 1 [4] Modular Cable X 1 [5] Signal Cable X 1 [6] FAX Shield Plate X 1 [7] FAX Board Fixed Plate [8] PCB Spacer (Long) [9] PCB Spacer (Short) [10] Modular Label X 1...

  • Page 369: Installation Procedure

    4. Host Machine Options Screw (TP; M3x4) [11] Dust Cover X 2 [12] [13] Screw [14] Telephone Cord (Binding; M4x4) X 1 (2 Contact type) X 1 Installation Procedure ■ Preparation 1. Remove the Left Rear Cover. • 1 Claw •...
  • Page 370 4. Host Machine Options 2. Remove the Rear Cover 2. • 3 Screws • 2 Protrusions Protrusion NOTE: • When the Super G3 FAX Board is installed: Perform steps 3 and 4, and proceed to step 6. • When installing the Super G3 FAX Board at the same time: Proceed to step 5. 3.
  • Page 371 4. Host Machine Options 4. Remove the FAX Unit. • 2 Connectors • 1 Screw • 2 Protrusions CAUTION: Be careful not to damage the [A] part of the speaker as the wiring may be open circuit. Protrusion 5. Remove the Face Cover of the FAX (1-Line). (The removed parts will not be used.) •...
  • Page 372 4. Host Machine Options 6. Remove the Face Cover of the FAX (2-Line). (The removed parts will not be used.) • 1 Screw • 1 Protrusion ■ Installing the Equipment 1. Free the Cable from the Wire Saddle.
  • Page 373 4. Host Machine Options 2. Install the Signal Cable to the FAX Unit. • 3 Cable Guides 3. Install the Modular Cable to the Modular PCB.
  • Page 374 4. Host Machine Options 4. Install the Modular PCB to the FAX Unit. • 2 Screws (TP; M3x4) TP; M3x4...
  • Page 375 4. Host Machine Options 5. Install the FAX Unit to the Host Machine. • 2 Protrusions • 1 Screw (TP; M3x4 Black) (Use the removed screw or those included with the Super G3 FAX Board) CAUTION: • Be careful not to damage the [A] part of the speaker as the wiring may be broken. •...
  • Page 376 4. Host Machine Options 7. Remove the 2 Screws. (will be used in next step) 8. Install the FAX Shield Plate. • 2 Screws (screws removed in the previous step)
  • Page 377 4. Host Machine Options 9. Install the FAX Board Fixed Plate. • 2 Bosses • 1 Screw (Binding; M4x4) Binding; M4x4 Boss...
  • Page 378 4. Host Machine Options 10. Remove the Screw and install the PCB Spacer (Short). (The removed screw will not be used.) PCB Spacer (Short)
  • Page 379 4. Host Machine Options 11. Install the 3 PCB Spacers (Long). PCB Spacer (Long) 12. Install the G3FAX Expansion PCB. • 6 Screws (TP; M3x4) NOTE: Because the 4 screws [A] need to be removed when installing the Super G3 3rd/4th Line Fax Board at the same time, it is efficient not to tighten them here.
  • Page 380 4. Host Machine Options 13. Install the Signal Cable, Power Supply Cable and USB Cable to the G3FAX Expansion PCB. • 1 Wire Saddle NOTE: Because [A] of the USB Cable needs to be disconnected when installing the Super G3 3rd/4th Line Fax Board at the same time, it is efficient not to connect it here.
  • Page 381 4. Host Machine Options NOTE: When installing the Super G3 3rd/4th Line Fax Board at the same time, the following step is not necessary. 15. Secure the cable with the Wire Saddle. ■ Subsequent Work NOTE: The following work is required only when installing the Super G3 FAX Board at the same time. 1.
  • Page 382 4. Host Machine Options NOTE: When installing the Super G3 3rd/4th Line Fax Board at the same time, the following step is not necessary. 2. Affix the appropriate Modular Label to the place shown in the figure. 3. Connect the Telephone Cord of the FAX (1-Line).When installing this equipment at the same time,connect the other end to the modular jack on the wall.
  • Page 383 4. Host Machine Options NOTE: When installing the Super G3 3rd/4th Line Fax Board at the same time, the following step is not necessary. 5. Install the Dust Cover. NOTE: When performing the following steps, it is efficient to install the cover after installing the Super G3 3rd/4th Line Fax Board in case of installing the fax board at the same time.

  • Page 384: Checking The Operation

    4. Host Machine Options 7. Install the Left Rear Cover. • 1 Hook • 1 Claw Claw Hook 8. Connect the Power Plug to the outlet. 9. Turn ON the main power switch. CAUTION: If the machine does not recognize this equipment, unplug and then plug the power plug after turning OFF the main power switch, or turn OFF the main power switch and then turn it ON within 20 seconds.

  • Page 385: Basic Settings

    4. Host Machine Options ■ Basic Settings NOTE: When "System Manager Information Settings" is set, be sure to follow the direction of user administrator in order to log in as an administrator. In this section, make only minimum settings required for FAX communication. 1.

  • Page 386: Super G3 3Rd/4Th Line Fax Board-As1

    4. Host Machine Options Super G3 3rd/4th Line Fax Board-AS1 Product Name Safety regulations require the product's name to be registered. In some regions where this product is sold, the following name may be registered instead. • F632503 Points to Note at Installation •...

  • Page 387: Installation Outline Drawing

    4. Host Machine Options Installation Outline Drawing...

  • Page 388: Checking The Contents

    4. Host Machine Options Checking the Contents [1] G3FAX Expansion [2] FAX Shield Plate X 1 PCB X 1 [3] FAX Board Fixed [4] PCB Spacer X 2 Plate X 1 [5] Resin Spacer X 1 [6] Modular Label X 1 [7] Modular Label X 1 [8] Telephone Cord X 2 [9] PTT Cable X 2...

  • Page 389: Installation Procedure

    4. Host Machine Options Installation Procedure ■ Preparation 1. Remove the Left Rear Cover. • 1 Claw • 1 Hook Claw Hook 2. Remove the Rear Cover 2. • 3 Screws • 2 Protrusions Protrusion 3. Disconnect the USB Cable of the G3FAX Expansion PCB side.
  • Page 390 4. Host Machine Options 4. Free the Modular Cable from the Wire Saddle. (Close the Wire Saddle.) 5. Remove the 4 Screws. (will be used in Installing the Equipment)
  • Page 391 4. Host Machine Options ■ Installing the Equipment 1. Install the FAX Shield Plate. • 2 Screws (Use the removed screws or TP; M3x4 included with the FAX (2-Line)) 2. Install the FAX Board Fixed Plate. • 1 Boss • 1 Screw (TP; M3x4) TP;...
  • Page 392 4. Host Machine Options 3. Install the 2 PCB Spacers and Resin Spacer. 4. Install the G3FAX Expansion PCB. • Upper Side: 2 Screws (Use the removed screws or TP; M3x4 included with the FAX (2-Line)) • Lower Side: 1 Screw (TP; M3x4) •...
  • Page 393 4. Host Machine Options 5. Connect the USB Cable. ■ Subsequent Work 1. Install the Rear Cover 2. • 2 Protrusions • 3 Screws Protrusion...
  • Page 394 4. Host Machine Options NOTE: This step is only for Taiwan. 2. Affix the following FAX Approval Label. 3. Affix the appropriate Modular Label. If a label is already affixed, remove it and then affix the appropriate label.
  • Page 395 4. Host Machine Options 4. Remove the 2 Dust Covers if installed. CAUTION: Do not insert a screwdriver, etc. into the modular terminal. NOTE: Keep the removed Dust Cover. 5. Connect one of the 2 Telephone Cords or the 2 PTT Cables to the modular jack on the host machine and the other cord to the modular jack on the wall.

  • Page 396: Checking The Operation

    4. Host Machine Options 6. Install the Left Rear Cover. • 1 Hook • 1 Claw Claw Hook 7. Connect the power plug to the outlet. 8. Turn ON the main power switch. CAUTION: If the machine does not recognize this equipment, unplug and then plug the power plug after turning OFF the main power switch, or turn OFF the main power switch and then turn it ON within 20 seconds.
  • Page 397 4. Host Machine Options ■ Basic Settings NOTE: When "System Manager Information Settings" is set, be sure to follow the direction of user administrator in order to log in as an administrator. In this section, make only minimum settings required for FAX communication. 1.

  • Page 398: Super G3 3Rd/4Th Line Fax Board-As2

    4. Host Machine Options Super G3 3rd/4th Line Fax Board-AS2 Product Name Safety regulations require the product's name to be registered. In some regions where this product is sold, the following name may be registered instead. • F632503 Points to Note at Installation •...

  • Page 399: Installation Outline Drawing

    4. Host Machine Options Installation Outline Drawing...

  • Page 400: Checking The Contents

    4. Host Machine Options Checking the Contents [1] G3FAX Expansion [2] FAX Shield Plate X 1 PCB X 1 [3] FAX Board Fixed [4] PCB Spacer X 2 Plate X 1 [5] Resin Spacer X 1 [6] Modular Label X 1 [7] Modular Label X 1 [8] Telephone Cord X 2 [9] PTT Cable X 2...

  • Page 401: Installation Procedure

    4. Host Machine Options Installation Procedure ■ Preparation 1. Remove the Left Rear Cover. • 1 Claw • 1 Hook Claw Hook 2. Remove the Rear Cover 2. • 3 Screws • 2 Protrusions Protrusion 3. Disconnect the USB Cable of the G3FAX Expansion PCB side.
  • Page 402 4. Host Machine Options 4. Free the Modular Cable from the Wire Saddle. (Close the Wire Saddle.) 5. Remove the 4 Screws. (will be used in Installing the Equipment)
  • Page 403 4. Host Machine Options ■ Installing the Equipment 1. Install the FAX Shield Plate. • 2 Screws (Use the removed screws or TP; M3x4 included with the FAX (2-Line)) 2. Install the FAX Board Fixed Plate. • 1 Boss • 1 Screw (TP; M3x4) TP;...
  • Page 404 4. Host Machine Options 3. Install the 2 PCB Spacers and Resin Spacer. 4. Install the G3FAX Expansion PCB. • Upper Side: 2 Screws (Use the removed screws or TP; M3x4 included with the FAX (2-Line)) • Lower Side: 1 Screw (TP; M3x4) •...
  • Page 405 4. Host Machine Options 5. Connect the USB Cable. ■ Subsequent Work 1. Install the Rear Cover 2. • 2 Protrusions • 3 Screws Protrusion 2. Affix the appropriate Modular Label. If a label is already affixed, remove it and then affix the appropriate label.
  • Page 406 4. Host Machine Options 3. Remove the 2 Dust Covers if installed. CAUTION: Do not insert a screwdriver, etc. into the modular terminal. NOTE: Keep the removed Dust Cover. 4. Connect one of the 2 Telephone Cords or the 2 PTT Cables to the modular jack on the host machine and the other cord to the modular jack on the wall.

  • Page 407: Checking The Operation

    4. Host Machine Options 5. Install the Left Rear Cover. • 1 Hook • 1 Claw Claw Hook 6. Connect the power plug to the outlet. 7. Turn ON the main power switch. CAUTION: If the machine does not recognize this equipment, unplug and then plug the power plug after turning OFF the main power switch, or turn OFF the main power switch and then turn it ON within 20 seconds.
  • Page 408 4. Host Machine Options ■ Basic Settings NOTE: When "System Manager Information Settings" is set, be sure to follow the direction of user administrator in order to log in as an administrator. In this section, make only minimum settings required for FAX communication. 1.

  • Page 409: Paper Feed Options

    Paper Feed Options Paper Deck Unit-E1......402 Paper Deck Heater Unit-A1....430 POD Deck Lite-C1......446 Paper Deck Heater Unit for POD Deck Lite-C1........... 474 Cassette Heater Unit-38....483...

  • Page 410: Paper Deck Unit-E1

    5. Paper Feed Options Paper Deck Unit-E1 Checking before Installation Requirements for the installation place are given below. It is recommended to look over the place to be used for installation before delivering the equipment to the user. CAUTION: • Install the host machine first and then install the Paper Deck. •...

  • Page 411: Checking The Contents

    5. Paper Feed Options 2. Open the plastic packing bag. Remove the Paper Deck from the palette holding the parts as shown in the figure. 3. Remove the packaging tapes and the cushioning materials. Checking the Contents Check that none of the included parts is missing.

  • Page 412: Installation Procedure

    5. Paper Feed Options □ [1] Papar Deck x1 □ [2] Paper Size Label x1 □ [3] Latch Plate x2 □ [4] Screw (Binding;M4x5) x3 □ [5] Screw (P Tightening;M3x8) x1 □ [6] Door Stopper x1 □ [7]Wire Saddle x1 The parts [5], [6] are not used.
  • Page 413 5. Paper Feed Options ■ Preparation of the Paper Deck Unit 1. Remove the screw from the base stay unit. • 1 Screw...
  • Page 414 5. Paper Feed Options 2. Push the Paper Deck Unit until it stops while holding the base stay unit and then attach the screw removed at procedure 2 as shown in the figure. CAUTION: Do not attach the screw removed at procedure 1 to the original position. NOTE: The screw is used to fix the base stay unit when the Paper Deck Unit is transported for relocation.
  • Page 415 5. Paper Feed Options 3. Remove the screws from bottom left side of the Paper Deck Unit (the removed screws are used at procedure 4, "Preparation of the Host Machine"). • 3 Screws NOTE: The fixing plate is removed at procedure 6, "Preparation of the Paper Deck Unit". 4.
  • Page 416 5. Paper Feed Options 5. Insert screwdrivers into the hole at rear left side of the compartment and then release the lever to open it. 6. Remove the fixing plate and the cushioning material from bottom left side of the compartment (the removed screws are not used).
  • Page 417 5. Paper Feed Options 7. Remove the fixing plate and cushioning material from bottom right side of the compartment (the removed screw is not used). • 1 Screw NOTE: Do not forget to remove the cushioning material. 8. Remove the fixing sheet fixing the lifter plate (the removed screws are not used). •...
  • Page 418 5. Paper Feed Options ■ Preparation of the Host Machine 1. Remove the feed cover (the removed cover is not used). 2. Remove the lower right cover (the removed cover and the screws are not used). • 2 Screws...
  • Page 419 5. Paper Feed Options 3. Cut the front and rear blinded covers with a side cutter. CAUTION: Be sure to cut the cover properly so that no burr is formed.
  • Page 420 5. Paper Feed Options 4. Attach the latch plates (front and rear) to the host machine with screws removed at procedure 3, 4, “Preparation of the Paper Deck Unit". CAUTION: Attach the 2 latch plates in the center of the hole. RS Tightening M4x8...
  • Page 421 5. Paper Feed Options 5. Remove the connector cover (the removed connector cover is not used). 6. Remove the lower blindfold seal (the removed lower blindfold seal is not used).
  • Page 422 5. Paper Feed Options 7. Attach the wire saddle to the host machine. • 1 Wire saddle ■ Connection with the Host Machine 1. Insert the positioning pins to the holes on the host machine and then fix the base stay unit. •...
  • Page 423 5. Paper Feed Options 2. Connect the Paper Deck Unit with the host machine. NOTE: Do not nip the cable between the Paper Deck Unit and the host machine when connecting. NOTE: When it is difficult to insert the rear connection pin into the rear latch hole, loosen the 2 screws fixing the latch plate and then adjust the position of the latch plate to fit it.
  • Page 424 5. Paper Feed Options 3. Loosen the 2 screws fixing the front bottom wheel to touch it to the floor. • 2 Screws...
  • Page 425 5. Paper Feed Options 4. Fasten the 2 screws loosened at procedure 3. • 2 Screws Fasten...
  • Page 426 5. Paper Feed Options 5. Loosen the 2 screws fixing the bottom right wheel to touch it to the floor. • 2 Screws...
  • Page 427 5. Paper Feed Options 6. Fasten the 2 screws loosened at procedure 5. • 2 Screws Fasten 7. Connect the latice connector of the Paper Deck Unit to the host machine and then fix it with the wire saddle.
  • Page 428 5. Paper Feed Options 8. Paste the paper size label with a gap in 5mm from the cassette no. label while aligning right edge of the labels (the remaining labels are not used). NOTE: Keep the paper size label for use when paper size is changed. 9.
  • Page 429 5. Paper Feed Options ■ Switching of the Paper Size 1. Press the open button to open the compartment.
  • Page 430 5. Paper Feed Options 2. Relocate the left/right edge guide plates at the specified paper size. CAUTION: Paper size is marked on both top and bottom of the compartment. Check that the marked paper size is the specified paper size when relocating the the left/right edge guide plates.
  • Page 431 5. Paper Feed Options 3. Relocate the rear edge guide plate at the specified paper size. CAUTION: Paper size is marked on both top and bottom of the compartment. Check that the marked paper size is the specified paper size when relocating the rear edge guide plate. 4.

  • Page 432: Checking After Installation

    5. Paper Feed Options Checking after Installation ■ Disposal Parts 1. Following disposal parts are remained after the installation procedure. Screw (RS tightening; M4x8) 3pcs. Screw (RS tightening; M4x10) 2pcs. Screw (TP; M3x6) 2pcs. Screw (P tightening; M3x8) 1pc. Paper Size Label (remaining label) 1pc.
  • Page 433 5. Paper Feed Options ● Adjustment Procedure (Manual) 1. Release the Paper Deck from the host machine and press the open button of the Paper Deck to open the compartment. 2. Loosen the 2 screws at the latch plate on left side of the compartment. •...
  • Page 434 5. Paper Feed Options 3. Move the latch plate toward front [A] or rear [B] (1 scale = 1mm) • Move the latch plate to front [A] when L1 is large. • Move the latch plate to rear [B] when L1 is small. Loosen...
  • Page 435 5. Paper Feed Options 4. Fasten the 2 screws loosened at procedure 2. • 2 Screws Fasten 5. Move the front cover fitting to the amount of the latch plate adjustment. Refer to the next item "Front Cover Positioning Adjustment" for detail. 6.

  • Page 436: Front Cover Positioning Adjustment

    5. Paper Feed Options ● Front Cover Positioning Adjustment 1. Check that the gap between the front cover and the Paper Deck is as follows. • Gap between the front cover and the right cover: 3+/-1mm • Gap between the front cover and the upper cover: 4+/-1mm...
  • Page 437 5. Paper Feed Options NOTE: Loosen the 6 screws on the front cover and then move it to adjust the gap within the standard. Loosen Fasten...

  • Page 438: Paper Deck Heater Unit-A1

    5. Paper Feed Options Paper Deck Heater Unit-A1 Checking before Installation Requirements for the installation place are given below. It is recommended to look over the place to be used for installation before delivering the equipment to the user. CAUTION: •...

  • Page 439: Installation Procedure

    5. Paper Feed Options *[6] Cable protection bushing is not used for the installation. <Others> Including guides Installation Procedure ■ Preparation of the Paper Deck Unit 1. Turn OFF the main power switch of the host machine. 2. Disconnect the lattice connector from the host machine and then release the cable from the wire saddle. •...
  • Page 440 5. Paper Feed Options 4. Insert screwdrivers into the hole at rear left side of the compartment and then release the lever to open it. 5. Remove the right cover. • 5 Screws...
  • Page 441 5. Paper Feed Options 6. Remove the rear cover. • 6 Screws 7. Cut the blindfold cover from the rear cover.
  • Page 442 5. Paper Feed Options 8. Loosen the 2 screws and then remove the upper left cover. Loosen 9. Remove the upper cover. • 3 Screws...
  • Page 443 5. Paper Feed Options 10. Put the connector through the hole in the top plate and then fix the Heater Unit in the Paper Deck Unit. • 2 Hooks • 1 Screw (Toothed washer; M4x6) Screw with toothed washer; M4x6 11.
  • Page 444 5. Paper Feed Options 12. Insert the AC input connector and then fix the ground cable. • 1 Screw (Toothed washer; M4x6) Screw with toothed washer; M4x6...
  • Page 445 5. Paper Feed Options 13. Install the relay harness unit on the rear side panel of the Paper Deck Unit. • 2 Screws (RS Tightening; M4x8) • 2 Connectors • 2 Snap Fit RS Tightening; M4x8 14. Re-attach the external covers. ■...
  • Page 446 5. Paper Feed Options 2. Hold and remove the rear lower cover unit. • 4 Screws CAUTION: When disassembling, do not deform the grounding plate.
  • Page 447 5. Paper Feed Options 3. Remove the blindfold plate. • 2 Screws 4. Insert the AC cord into the hole of the cord mount and fix it. • 1 Screw (Flat spring; M4x10) Screw with flat spring; M4x10...
  • Page 448 5. Paper Feed Options 5. Fix the ground cable to the cord mount. • 1 Screw (Toothed washer; M4x6) Screw with toothed washer; M4x6 6. Connect the AC cable to the host machine and then fix it. • 1 Connector •...
  • Page 449 5. Paper Feed Options 7. Attach the noise reduction cover and the lower rear cover. • 4 Screws CAUTION: • When assembling, do not deform the grounding plate. • When assembling, be sure to insert the edge [A] of the left lower cover in the groove [B] of the rear lower cover Unit.
  • Page 450 5. Paper Feed Options 8. Attach the 2 screws of the left lower cover. ■ Connection with the Host Machine 1. Close the compartment and then connect the Paper Deck Unit with the host machine. 2. Paste the power supply label on the above the AC input connector.
  • Page 451 5. Paper Feed Options 3. Connect the AC cable to the Paper Deck Unit. 4. Remove the 4 blindfold seals.
  • Page 452 5. Paper Feed Options 5. Attach the wire saddle. • 3 Wire Saddles 6. Fix the cable with the wire saddles and the snap fit. • 3 Wire Saddles • 1 Snap Fit...

  • Page 453: Checking After Installation

    5. Paper Feed Options 7. Connect the lattice connector of the Paper Deck to the host machine and then fix the cable with the wire saddle. • 1 Connector • 1 Wire Saddle 8. Turn ON the host machine. Checking after Installation ■...

  • Page 454: Pod Deck Lite-C1

    5. Paper Feed Options POD Deck Lite-C1 Checking before Installation Requirements for the installation place are shown below. It is recommended to look over the installation place before delivering the equipment to the user. CAUTION: • Install the host machine first and then install the POD Deck Lite. •...

  • Page 455: Checking The Contents

    5. Paper Feed Options 1. Open the box and remove the accessory box and cushioning materials. 2. Open the plastic packing bag. Remove the POD Deck Lite from the palette. 3. Remove the fixing plate and 2 tags (the removed tags, fixing plate and screws are not used). •...
  • Page 456 5. Paper Feed Options ■ Contents □ [2] Latch Plate x2 □ [1] POD Deck Lite x1 □ [4] Screw (P Tightening;M3x8) x1 □ [7] Door Stopper x1 □ [5] Screw □ [6] Screw (RS Tightening;M4x8) x6 (Binding;M4x5) x5 Use 3 of them □...

  • Page 457: Installation Procedure

    5. Paper Feed Options [9] Foreign Language [10] Paper Size Overlay [11] Paper Size Label x1 □ □ □ Label x1 Label x1 [12] Paper Size Plate x1 [13] Cassette No. Label x1 [14]Total Map Label x1 □ □ □ [16] *1 Power Cord x3 [17] *1 Power Cord x1 [15] JAM Label x1...
  • Page 458 5. Paper Feed Options ■ Preparation of the Host Machine 1. Remove the feed cover. 2. Remove the lower right cover. • 2 Screws...
  • Page 459 5. Paper Feed Options 3. Cut the blindfold covers (front /rear) with a side cutter. CAUTION: Be sure to remove the face cover properly so that no burr is formed. 4. Attach the 2 latch plates to the host machine. •...
  • Page 460 5. Paper Feed Options 5. Remove the connector cover from rear of the host machine. ■ Preparation of the POD Deck Lite 1. Attach the door stopper. • 1 Screw ( P tightening screw; M3x8) P Tightening M3x8...
  • Page 461 5. Paper Feed Options 2. Attach the slope guide. • 2 Screws ( Binding screws; M4x5) Binding M4x5 3. Remove the screw and spacer from the base stay unit. Push the POD Deck Lite until it stops while holding the base stay unit .
  • Page 462 5. Paper Feed Options 4. Fix the removed screw at procedure 3 to the original position. NOTE: The screw is used to fix the base stay unit when the POD Deck Lite is transported. ■ Connection with the Host Machine 1.
  • Page 463 5. Paper Feed Options 3. Remove the sheet and tapes from the compartment. 4. Remove the stay guide. Removed 1 screw and the stay guide are used at procedure 25. • 3 Screws NOTE: The removed screw is used to fix the stay guide plate when the POD Deck Lite is transported. 5.
  • Page 464 5. Paper Feed Options 6. Affix the foreign language label by language over the original label as shown in the figure. 7. Affix the paper size overlay label over the original label by language as shown in the figure. 8. Close the compartment.
  • Page 465 5. Paper Feed Options 9. Insert the 2 positioning pins to the holes of the host machine and then fix the base stay. • 3 Screws (Binding screws; M4x5) Binding M4x5...
  • Page 466 5. Paper Feed Options 10. Connect the POD Deck Lite with the host machine. NOTE: • Do not nip the cable between the POD Deck Lite and the host machine when connecting. NOTE: • When inserting the rear connection pin into the rear latch hole is difficult, loosen the 2 screws fixing the latch plate and then adjust the position of the latch plate to fit it in.
  • Page 467 5. Paper Feed Options 11. Loosen the 2 screws on the bottom right side wheel. • 2 Screws Loosen...
  • Page 468 5. Paper Feed Options 12. Match position(a) with position(b) by adjusting the height of the POD Deck Lite with the 2 adjusters. • Position (a) : 2 fixing screw tapped holes (middle) of the POD Deck Lite. • Position (b) : 2 fixing screw tapped holes (middle) of the bottom right side wheel. Rotate to [A] direction: Ascent Rotate to [B] direction: Descent...
  • Page 469 5. Paper Feed Options 13. Fix the bottom right side wheel with Screw A and Screw B. • Screw A: Supplied 2 Screws ( RS tightening; M4x8) • Screw B: 2 screws loosened at procedure 12 RS Tightening M4x8 Fasten 14.
  • Page 470 5. Paper Feed Options 15. Fasten the 2 screws loosened at procedure 15. • 4 Screws Fasten...
  • Page 471 5. Paper Feed Options 16. Adjust tilt with the 2 adjusters until a top gap [1] and a bottom gap [2] between the POD Deck Lite and the host machine are same width. • Rotate to [A] direction: Ascent • Rotate to [B] direction: Descent CAUTION: •...
  • Page 472 5. Paper Feed Options 17. Attach the wire saddle to the hole on rear side of the POD Deck Lite and then clamp the cable with it. • 1 Wire saddle 18. Connect the Interface Cable with the host machine. CAUTION: When connecting the Interface Cable, be sure to turn off the host machine and disconnect its power cable from the outlet.
  • Page 473 5. Paper Feed Options 19. Connect the power cord to the inlet of the POD Deck Lite and then plug it to the external source. CAUTION: Make sure that the power cord is fully connected to the outlet. If the connection is incomplete, smoke or fire may occur. 20.
  • Page 474 5. Paper Feed Options 21. If the cassette heater is installed, turn ON the cassette heater in high humidity or low temperature environment. 22. Turn ON the main power on the host machine. 23. Press the open button of the POD Deck Lite to open the compartment.
  • Page 475 5. Paper Feed Options 24. Press the relay paper sensor until the lifter reaches to the bottom position. 25. Fix the stay guide inside of the front frame with the screw removed at procedure 4. • 1 Screw (TP; M3x6) 26.
  • Page 476 5. Paper Feed Options 27. Affix the cassette No. label "5" . 28. Affix the paper size label on the size plate. NOTE: • Be sure to check with the user whether or not to affix the Paper Size Label, and then affix it. •...

  • Page 477: Disposal Parts

    5. Paper Feed Options Disposal Parts 1. Following disposal parts are remained after the installation procedure. Screw (RS Tightening;M4x8) 3pcs Screw (Stepped Screw; M4x8) 1pc Feed Cover 1pc Lower Right Cover 1pc Connector Cover 1pc Blindfold Cover 2pcs Total Map Label 1pc Foreign Language Label 1pc Cassette No.
  • Page 478 5. Paper Feed Options NOTE: Setting range: -20 to 20 (0.1mm by 1 setting value) L1 is increased 0.1mm by setting value 1. +: L1 is increased (Image moves to the right). -: L1 is decreased (Image moves to the left). 2.
  • Page 479 5. Paper Feed Options 3. Loosen the 2 screws at the latch plate on the right side of the compartment. • 2 Screws Loosen 4. Move the latch plate toward front [A] or rear [B] (1 scale = 1mm) and then fasten the 2 screws. The adjusted value is used at procedure 6.
  • Page 480 5. Paper Feed Options 5. Loosen the 2 screws at the latch plate on the left side of the compartment. • 2 Screws Loosen 6. Move the latch plate in the same scale position as procedure 4 and then fasten the 2 screws (1 scale = 1mm). Fasten 7.
  • Page 481 5. Paper Feed Options ■ Front Cover Positioning Adjustment 1. Check that the gap is 4 +/- 1mm between the front cover and upper cover, the front cover and right cover. NOTE: Loosen the 7 screws on the front cover to adjust the gap in 4+/-1mm. Loosen Fasten...

  • Page 482: Paper Deck Heater Unit For Pod Deck Lite-C1

    5. Paper Feed Options Paper Deck Heater Unit for POD Deck Lite-C1 Checking the Parts to be Installed Each part of the Paper Deck Heater Unit for the Paper Deck is supplied as a service part, so prepare the following parts. Also, use the appropriate Paper Deck Heater Unit for each country.
  • Page 483 5. Paper Feed Options 3. Remove the cable. • 1 Wire saddle • 1 Connector 4. Slide the POD Deck Lite until it stops with holding the release lever.

  • Page 484: Installation Procedure

    5. Paper Feed Options Installation Procedure 1. Remove the Rear Cover. • 5 Screws 2. Open the Compartment while unlocking the release lever. 3. Remove the Right Cover. • 5 Screws...
  • Page 485 5. Paper Feed Options 4. Open the Compartment until it stops while releasing stoppers with pressing the left and right Latches. 5. Install the Paper Deck Heater Unit. • 3 Claws • 1 Screw (TP; M3x6) Boss Base Plate TP; M3x6...
  • Page 486 5. Paper Feed Options 6. Connect the connector to the POD Deck Lite. 7. Install the Heater Connector Cover. • 2 Protrusions • 1 Claw Protrusion Claw...
  • Page 487 5. Paper Feed Options 8. Install the Paper Deck Heater Harness. • 3 Reuse bands • 2 Connectors 9. Install the Switch Unit. NOTE: When installing the Switch Unit, check that the Cassette Heater Switch is OFF.
  • Page 488 5. Paper Feed Options 10. Attach the wire saddle. • 1 Wire saddle 11. Fix the Switch Unit Harness as follows. • 2 Wire saddles • 1 Connector 12. Attach the external covers. 13. Connect the POD Deck Lite with the host machine.
  • Page 489 5. Paper Feed Options 14. Connect the cable. • 1 Wire saddle • 1 Connector 15. Connect the power cord to the inlet of the POD Deck Lite and then plug it to the external source. CAUTION: Make sure that the power cord is fully connected to the outlet. If the connection is incomplete, smoke or fire may occur.
  • Page 490 5. Paper Feed Options 16. Check that the circuit breaker is ON. 17. Turn ON the Cassette Heater Switch. 18. Turn ON the main power of the host machine.

  • Page 491: Cassette Heater Unit-38

    5. Paper Feed Options Cassette Heater Unit-38 Checking the Contents [1] Cassette Heater [2] Screw Unit x 1 (RS Tightening: M4x8) x 2 Installation Outline Drawing Essential Items to Be Performed Before Installation • Turn OFF the main power of the host machine, and disconnect the power plug from the outlet. WARNING: •...
  • Page 492 5. Paper Feed Options 2. Pull out the Left Deck to remove. • 2 Screws 3. Put the 2 Rails in. 4. Pull out the Right Deck to remove the Left Deck in the same way. 5. Put the 2 Rails in. 6.
  • Page 493 5. Paper Feed Options 7. Put the 2 Rails in. 8. Remove the Connector Cover. • 1 Claw • 2 Protrusions Claw Protrusion 9. Remove tapes on the Cassette Heater Unit.
  • Page 494 5. Paper Feed Options 10. Fit the protrusions of the Cassette Heater Unit into the holes of the Host Machine. Hole Protrusion Protrusion 11. Fit the holes of the Cassette Heater Unit with the bosses of the Host Machine. CAUTION: When fitting the Cassette Heater Unit with the bosses, be sure to support the bottom side with your hand;...
  • Page 495 5. Paper Feed Options 12. Install the Cassette Heater Unit. • 2 Screws (RS Tightening; M4x8) RS Tightening ; M4x8 13. Install the Connector. 14. Install the Connector Cover.
  • Page 496 5. Paper Feed Options 15. Pull out the Rails at the installation area of Cassette 3. Fit the 4 pins on the Rails with the grooves of Cassette 3 to place Cassette 3 over the Rails. 16. After having installed Cassette 3 with 4 screws, close Cassette 3.
  • Page 497 5. Paper Feed Options 17. Pull out the Rails at the installation area of the Right Deck. Fit the 4 pins on the Rails with the grooves of the Right Deck to place the Right Deck over the Rails. 18. After having installed Right Deck with 2 screws, close the Right Deck. 19.

  • Page 498: Paper Output Options

    Paper Output Options Shift Tray-F1........491 Document Insertion Unit-P1, Document Insertion/Folding Unit-J1 ............497 Staple Finisher-AC1/ Booklet Finisher- AC1..........542 2/3 2/4 4 Hole Puncher Unit-A1..581 Finisher Jogger Kit-A1.......604...

  • Page 499: Shift Tray-F1

    6. Paper Output Options Shift Tray-F1 Checking the Contents [1] Shift Tray X 1 [2] Shift Drive Unit X 1 Points to Note before Installation The pictures and illustrations used may be different from the product in front of you, but the procedure is the same. [3] Shift Tray Cover X 1 [4] Shift Tray Support Base X 1...

  • Page 500: Essential Items To Be Performed Before Installation

    6. Paper Output Options Essential Items to Be Installation Procedure Performed Before Installation • Turn OFF the main power of the host machine, and 1. Remove the Left Rear Cover. disconnect the power plug from the outlet. • 1 Claw •...
  • Page 501 6. Paper Output Options 4. Remove the Left Upper Cover. 6. Remove the 2 screws, and install the Shift Delivery Support Base (1) using the removed screws. • 3 Screws • 3 Hooks • 3 Protrusions Protrusion Hook Hook 5. Remove the Delivery Cover. •...
  • Page 502 6. Paper Output Options 7. Remove the screw, and install the Shift Delivery 9. Install the Shift Tray Cover.Install the Shift Tray Support Base (2) using the removed screw and the Cover. screw included in the package. • 2 Hooks •...
  • Page 503 6. Paper Output Options 12. Install the Reinforcing Plate. 14. Remove the tapes, and install the Shift Drive Unit. • 2 Screws (RS Tightening; M4x20) • 2 Screws (Binding; M4x6) • 3 Rubber Caps CAUTION: Be sure to put the harness for connecting to the host machine into the groove when installing the unit.

  • Page 504: Checking After Installation

    6. Paper Output Options 16. Using a flat-blade screwdriver, remove the Face Cover from the Delivery Cover removed in step 5 (the Delivery Cover will not be used). 17. Install the Face Cover removed in the previous step and the Face Cover included in the package. •...

  • Page 505: Document Insertion Unit-P1, Document Insertion/Folding Unit-J1

    6. Paper Output Options Document Insertion Unit-P1, Document Insertion/Folding Unit-J1 Checking Before Installation The following conditions are required for the installation site. Therefore, it is recommended to see the installation site in advance before delivering this equipment to the user's site. ■...
  • Page 506 6. Paper Output Options 1. Take out the accessory box from the cushioning materials. CAUTION: Don't remove 4 cushioning materials because it may cause to deform this equipment. Otherwise, you would likely deform some areas of this equipment. 2. Lift the equipment together with the pallet. CAUTION: •...
  • Page 507 6. Paper Output Options 3. Remove the pallet and cushioning materials. Then, put the plastic cover down to the position shown. 4. Lift the front and rear side lightly to remove the cushioning materials and plastic cover. 5. Remove the tapes used outside of this equipment. NOTE: In the case of the Document Insertion/Folding Unit, be sure not to remove the tapes from the Folder Unit because those are removed later.
  • Page 508 6. Paper Output Options ■ Unpacking Procedure on the Folder Unit (for Document Insertion/Folding Unit) 1. Open the Front Upper Cover. 2. Holding the Jam Removal Lever, raise the Transfer Guide, and pull out the Folder Unit.
  • Page 509 6. Paper Output Options 3. Remove all tapes from the Folder Unit and open the Folder Guide Plate (Right) fully (at two levels). CAUTION: The 2 screws (pointed by screwdrivers) at the front and rear are used to adjust the Folding Roller Pressure. Never loosen these screws.
  • Page 510 6. Paper Output Options 4. Remove the 3 fixings on the front side of the folder unit. CAUTION: The Folder Guide Plate (Right) must be opened fully when removing the fixings. Do not pull them out forcibly.
  • Page 511 6. Paper Output Options 5. Remove the 3 Fixings on the rear side of the folder unit. CAUTION: The Folder Guide Plate (Right) must be opened fully when removing the Fixings. Do not pull them out forcibly.
  • Page 512 6. Paper Output Options 6. Close the Folder Guide Plate (Right) and return the Folder Unit to the original position. Then, holding the Jam Removal Lever, lower the Transfer Guide. 7. Close the Front Upper Cover.

  • Page 513: Checking Bundled Components

    6. Paper Output Options Checking Bundled Components [17] [15] [16] [11] [10] [8] *2 [12] [13] [14] [1] Relay Connector (for Finisher) 1pc. *1 [2] Screw (Binding; M4x7) 6pcs. [3] Document Insertion Unit or Document Insertion/Folding Unit 1pc. [4] Fixing Plate (Rear) 1pc. [5] Screw (Stepped Screw;...

  • Page 514: Installation Procedure

    6. Paper Output Options [17] Screw (P Tightening; M4x12) 2pcs. *4 *1: Use the part [1] when connecting this equipment and the Finisher. (Refer to Finisher Installation Procedure.) *2: The package may contain several power cords intended for use in Europe. Use the correct power cord to match the location/ area of installation.
  • Page 515 6. Paper Output Options ■ Preparing of the Host Machine 1. Remove the 2 covers. (Removed covers are not reused.) • 2 Claws 2. Install the Fixing Plates (Front/Rear). • 4 Screws (Binding; M4x7) Binding ; M4x7 3. Mount the Delivery Tray (U) which is supplied with the Finisher. •...
  • Page 516 6. Paper Output Options 4. Mount the Delivery Tray (L) which is supplied with the Finisher. • 2 Hooks • 2 Screws (P Tightening; M4x12) (supplied with the Finisher) 5. Open the Feeder Cover, and then remove the screws. • 3 Screws 6.
  • Page 517 6. Paper Output Options 7. Open the ADF, and then remove the ADF Front Cover. • 2 Screws [A] Binding [B] P Tightening • 2 Claws Claw Claw 8. Remove the ADF Left Lower Cover. • 2 Screws • 3 Claws Claws...
  • Page 518 6. Paper Output Options 9. At the rear part of the ADF, install the Stopper (Rear). • 1 Screw (Flat Head Screw; M3x5) Flat Head Screw; M3x5...
  • Page 519 6. Paper Output Options 10. At the front part of the ADF, install the Stopper (Front). • 1 Screw (Flat Head Screw; M3x5) Flat Head Screw; M3x5 11. Install the ADF Left Lower Cover. • 2 Screws • 3 Claws...
  • Page 520 6. Paper Output Options 12. Install the ADF Front Cover, and then close the ADF. • 2 Screws [A] Binding [B] P Tightening • 2 Claws NOTE: When install the ADF Front Cover, be careful not to make a mistake in the screw to use. Claw Claw 13.
  • Page 521 6. Paper Output Options 14. Close the Feeder Cover. ■ Connecting to the Host Machine (for Document Insertion Unit) 1. Fit the pin of the Fixing Plate (Front) on the Host Machine in the slot on this equipment. 2. Open the Inserter Pickup Unit and the Front Upper Cover.
  • Page 522 6. Paper Output Options 3. Remove the Front Upper Cover, and then holding the Jam Removal Lever, raise the Transfer Guide. • 1 Clip 4. Remove the Front Lower Cover. • 1 Screw...
  • Page 523 6. Paper Output Options 5. Check whether the screw hole is between the upper marking-off line and the lower marking-off line on the Fixing Plate (Front). NOTE: If the screw hole is not positioned between the marking-off lines, carry out the adjustment described in "Adjusting the Height and Tilt."...
  • Page 524 6. Paper Output Options 6. Check whether the screw hole is between the upper marking-off line and the lower marking-off line on the Fixing Plate (Rear). NOTE: If the screw hole is not positioned between the marking-off lines, carry out the adjustment described in "Adjusting the Height and Tilt."...
  • Page 525 6. Paper Output Options 8. Fix the Fixing Plate (Front) in place to this equipment. • 1 Screw (Stepped Screw; M4x5) Stepped Screw; M4x5...
  • Page 526 6. Paper Output Options 9. Attach the Front Lower Cover by engaging to the hook. • 1 Screw...
  • Page 527 6. Paper Output Options 10. Holding the Jam Removal Lever, lower the Transfer Guide, and then install the Front Upper Cover. • 1 Clip 11. Close the Front Upper Cover and the Inserter Pickup Unit. ■ Connecting to the Host Machine (for Document Insertion/Folding Unit) 1.
  • Page 528 6. Paper Output Options 2. Open the Front Upper Cover. 3. Holding the Jam Removal Lever, raise the Transfer Guide, and pull out the Folder Unit.
  • Page 529 6. Paper Output Options 4. Check whether the screw hole is between the upper marking-off line and the lower marking-off line on the Fixing Plate (Front). NOTE: If the screw hole is not positioned between the marking-off lines, carry out the adjustment described in "Adjusting the Height and Tilt."...
  • Page 530 6. Paper Output Options 5. Check whether the screw hole is between the upper marking-off line and the lower marking-off line on the Fixing Plate (Rear). NOTE: If the screw hole is not positioned between the marking-off lines, carry out the adjustment described in "Adjusting the Height and Tilt."...
  • Page 531 6. Paper Output Options 7. Fix the Fixing Plate (Front) in place to this equipment. • 1 Screw (Stepped Screw; M4x5) Stepped Screw; M4x5 8. Return the Folder Unit to the original position, and then holding the Jam Removal Lever, lower the Transfer Guide.

  • Page 532: Connecting To The Power Cord

    6. Paper Output Options 9. Close the Front Upper Cover. ■ Connecting to the Power Cord 1. Insert the Power Cord into the equipment. Connect the plug end of the Power Cord into an external power outlet. CAUTION: Make sure that the Power Cord is fully connected to the outlet. If the connection is not right, an accident causing the smoke or fire may occur.
  • Page 533 6. Paper Output Options ■ Attaching the Document Setting Label and Document Prohibition Label 1. Affix the Document Setting Label [1] and Document Prohibition Label [2] to the Inserter. ■ Attaching the Jam Removal Label (for Document Insertion/Folding Unit) 1. Open the Front Upper Cover.
  • Page 534 6. Paper Output Options 2. Holding the Jam Removal Lever, raise the Transfer Guide, and pull out the Folder Unit. 3. Open the Transfer Guide (Right), and then affix the Jam Removal Label.
  • Page 535 6. Paper Output Options 4. Close the Folder Guide Plate (Right) and return the Folder Unit to the original position. Holding the Jam Removal Lever, lower the Transfer Guide. 5. Close the Front Upper Cover.

  • Page 536: Operation Checks

    6. Paper Output Options Operation Checks 1. After the completion of all installations, check that the Leakage Breaker is turned ON. Leakage Breaker 2. Turn on the Host Machine. 3. Confirm that the combination of the firmware version for the Host Machine and the equipment is appropriate. 4.
  • Page 537 6. Paper Output Options 1. Remove the Wrench. • 1 Screw ■ Removing the Wrench (for Document Insertion/Folding Unit) If it is necessary to use the Wrench for “Adjusting the Heights and Tilt”, remove the Wrench according to the following procedures.
  • Page 538 6. Paper Output Options 3. Holding the Jam Removal Lever, raise the Transfer Guide, and pull out the Folder Unit. 4. Remove the Wrench. • 1 Screw 5. Return the Folder Unit to the original position, and then holding the Jam Removal Lever, lower the Transfer Guide.

  • Page 539: Adjusting The Height

    6. Paper Output Options 6. Close the Front Upper Cover. ■ Adjusting the Height CAUTION: When have performed the procedure of "Adjusting the Height", be sure to perform the procedure of "Adjusting the Caster Roller Height of the Folding Unit". (Document Insertion/Folding Unit only) 1.
  • Page 540 6. Paper Output Options 3. Holding the Jam Removal Lever, raise the Transfer Guide. (Document Insertion/Folding Unit only) 4. Loosen the nut [1] on the Caster of the front side (upstream equipment side). Then turn the nut [2] to adjust the height.
  • Page 541 6. Paper Output Options 5. Loosen the nut [1] on the Caster of the rear side (upstream equipment side). Then turn the nut [2] to adjust the height. NOTE: • Turn the nut [1] clockwise (direction of arrow [B]) to loosen. •...
  • Page 542 6. Paper Output Options ■ Adjusting the Tilt 1. Loosen the nut [1] on the Caster of the front side (paper ejection side). Then turn the nut [2] to adjust the tilt. NOTE: • Turn the nut [1] clockwise (direction of arrow [B]) to loosen. •...
  • Page 543 6. Paper Output Options 2. Loosen the nut [1] on the caster of the front side (rear side). Then turn the nut [2] to adjust the tilt. NOTE: • Turn the nut [1] clockwise (direction of arrow [B]) to loosen. •...
  • Page 544 6. Paper Output Options 3. Loosen the 2 screws of the Caster Roller. Loosen 4. Adjust the height of the Caster Roller by turning the nut so that the space between the Caster Roller and the floor becomes about 1 mm. NOTE: Turn the nut [2] counterclockwise (direction of arrow [A]) to increase the height of the Caster Roller, and clockwise (direction of arrow [B]) to reduce the height of the Caster Roller.
  • Page 545 6. Paper Output Options 5. After adjustment, tighten the 2 screws of the Caster Roller. Tighten 6. Pull out the Folder Unit, and then attach the Folder Unit Cover by engaging to the hook. • 2 Screws (Binding ; M4x7)
  • Page 546 6. Paper Output Options 7. Return the Folder Unit to the original position, and then holding the Jam Removal Lever, lower the Transfer Guide. 8. Close the Front Upper Cover.
  • Page 547 6. Paper Output Options ■ Storing the Wrench (for Document Insertion Unit) NOTE: After store the wrench, perform “Connecting to the Host Machine” procedure. 1. Store the wrench at the original position. • 1 Screw (W Sems; M4x8) ■ Storing the Wrench (for Document Insertion/Folding Unit) NOTE: After store the wrench, perform “Connecting to the Host Machine”...
  • Page 548 6. Paper Output Options 2. Open the Front Upper Cover. 3. Holding the Jam Removal Lever, raise the Transfer Guide, and pull out the Folder Unit. 4. Store the wrench at the original position. • 1 Screw (W Sems ; M4x8) Boss...
  • Page 549 6. Paper Output Options 5. Return the Folder Unit to the original position, and then holding the Jam Removal Lever, lower the Transfer Guide. 6. Close the Front Upper Cover.

  • Page 550: Staple Finisher-Ac1/ Booklet Finisher-Ac1

    6. Paper Output Options Staple Finisher-AC1/ Booklet Finisher-AC1 Checking before Installation The installation site must satisfy the conditions given below. Therefore, it is recommended that the installation site be looked over before delivering this equipment to the customer. CAUTION: • Install the host machine first and then install this equipment. •...

  • Page 551: Unpacking

    6. Paper Output Options ■ Order of Installation of Options When installing this equipment together with the other options, first install the host machine and then install options in the following order: 1. Document Insertion Unit or Document Insertion/ Folding Unit 2.
  • Page 552 6. Paper Output Options...
  • Page 553 6. Paper Output Options Hold the specified parts as shown and unload the finisher. - For Staple Finisher - For Booklet Finisher CAUTION: Hold the specified parts as shown and do not hold the other parts to lift up the finisher. - For Staple Finisher - For Booklet Finisher CAUTION:...

  • Page 554: Checking The Contents

    6. Paper Output Options Remove all the tapes and cushioning materials outside this equipment. Checking the Contents Check that none of the included parts is missing.

  • Page 555: Installation Procedure

    6. Paper Output Options Screw (Binding ; M4x8) Screw (TP ; M3x6) [14] [10] [11] [13] [12] [16] [15] [17] Screw (P Tightening ; M4x12) NOTE: *1 : Booklet Finisher only <Others> Other bundled items such as Installation Procedure, leaflets, etc. Installation Procedure CAUTION: Check that the main power switch is OFF and the power plug is disconnected from the outlet.
  • Page 556 6. Paper Output Options ■ Connecting to the Host Machine P Tightening (M4x12) P Tightening (M4x12)
  • Page 557 6. Paper Output Options Binding ; M4x8...
  • Page 558 6. Paper Output Options (M3ｘ6) NOTE: Install the Ground rail to the position [C]. ■ Connecting to the Document Insertion/ Folding Unit or Document Insertion Unit Binding ; M4x8...
  • Page 559 6. Paper Output Options (M3ｘ6) NOTE: Install the Ground rail to the position [C].
  • Page 560 6. Paper Output Options Install the Relay Connector supplied with the Document Insertion/ Folding Unit to the Finisher.
  • Page 561 6. Paper Output Options Connect the Relay connector of the Document Insertion/ Folding Unit to the Finisher. ■ Connecting to the Upstream Connection Machine Check the height of the upstream connection machine and the Finisher. Check that the hole of the connection plate is positioned between the marking-off lines of the Finisher. NOTE: If the hole is not positioned between the marking-off lines, carry out the adjustment described in "Adjusting the Height."...
  • Page 562 6. Paper Output Options TP ; M3ｘ6...
  • Page 563 6. Paper Output Options Pull out the Saddle Unit. (Booklet Finisher only)
  • Page 564 6. Paper Output Options Loosen two screws, and then fix the Saddle Unit auxiliary caster so that its caster can touch floor. (Booklet Finisher only)
  • Page 565 6. Paper Output Options Put the Saddle Unit back. (Booklet Finisher only)

  • Page 566: Affixing The Labels

    6. Paper Output Options CAUTION: When connecting the interface cable, be sure to turn off the host machine and disconnect its power cable from the outlet. If you do not do so, electric shock can result. Affixing the Labels ■ Affixing the Jam Label / Saddle Caution Label (Booklet Finisher only)
  • Page 567 6. Paper Output Options Affix the label in the appropriate language. Affix the label in the appropriate language.
  • Page 568 6. Paper Output Options Affix the label in the appropriate language.
  • Page 569 6. Paper Output Options ■ Affixing the Tray Labels Affix the Tray labels which is specified by user.

  • Page 570: Making Adjustments

    6. Paper Output Options ■ Affixing the Puncher Label. (When Installing Puncher Unit.) Making Adjustments The difference in height between the Finisher and the Host Machine and the tilt of the Finisher and the host machine need to be adjusted depending on the installation site floor condition. If the height or tilt is not adjusted properly, problems can occur (for example, a paper jam can occur frequently at the paper supply section of the Finisher).
  • Page 571 6. Paper Output Options ■ Checking the Height 1. Check that the hole of the connection guide plate is positioned between the marking-off lines of the Finisher. 2. When the adjustment of height is necessary, make adjustment by referring the "Adjusting the Height". NOTE: When the adjustment of height is not necessary, proceed to the "Checking the Difference in Tilt".
  • Page 572 6. Paper Output Options ■ Adjusting the Height 1. When it is fixed to the upstream connection machine, it is detached by approx. 150 mm. CAUTION: Be careful with the interface cable when detaching. NOTE: Disconnect the Relay connector when detaching the Finisher from the Document Insertion/ Folding Unit.
  • Page 573 6. Paper Output Options 2. Remove the Caster covers (front/ rear). 3. Turn the adjustment dial of the caster in the direction of the arrow by lifting the dial upward a little to adjust the height. NOTE: Adjust the height at 4 casters.
  • Page 574 6. Paper Output Options • To increase the height of the Finisher, turn the dial in the direction of arrow [A]. • To decrease the height of the Finisher, turn the dial in the direction of arrow [B]. A full turn of the adjustment dial changes the height of the Finisher by approx. 2.0 mm. NOTE: If the adjustment dial keeps lifting upward, lower the adjustment dial by releasing three claws.
  • Page 575 6. Paper Output Options 4. Install the Caster covers (Front / Rear). 5. Install the Finisher to the upstream connection machine. NOTE: Connect the Relay connector when installing the Finisher to the Document Insertion/ Folding Unit.
  • Page 576 6. Paper Output Options 6. Fix to the upstream connection machine. ■ Checking the Difference in Tilt Check the relational tilting amount of the Finisher and the upstream connection machine. Make sure that the gap between the right side of the Finisher and the left side of the upstream connection machine is within the standard shown in the figure. In the case the gaps are within the specification, this adjustment is not required.
  • Page 577 6. Paper Output Options 5.0 -/+ 1.5 mm 5.0 -/+ 1.5 mm ● Connecting to the Document Insertion/ Folding Unit or Document Insertion Unit 6.7 -/+ 1.5mm 8.5 -/+ 1.5mm...
  • Page 578 6. Paper Output Options 6.7 -/+ 1.5 mm 10.1 -/+ 1.5 mm...
  • Page 579 6. Paper Output Options ■ Adjusting the Tilt 1. When it is fixed to the upstream connection machine, it is detached by approx. 150 mm. CAUTION: Be careful with the interface cable when detaching. NOTE: Disconnect the Relay connector when detaching the Finisher from the Document Insertion/ Folding Unit.
  • Page 580 6. Paper Output Options 2. Remove the Caster Covers (Front/ Rear).
  • Page 581 6. Paper Output Options 3. Turn the adjustment dial of the caster in the direction of the arrow by lifting the dial upward a little to adjust the tilt. NOTE: Adjust the tilt at 2 left casters. • To tilt the Finisher to the right, turn the dial in the direction of arrow [A]. •...
  • Page 582 6. Paper Output Options NOTE: If the adjustment dial keeps lifting upward, lower the adjustment dial by releasing three claws. And be sure to insert the three pins of the adjustment dial to the hole of the caster support plate. Claw Claw Claw...
  • Page 583 6. Paper Output Options 5. Install the upstream connection machine. NOTE: Connect the Relay connector when installing the Finisher to the Document Insertion/ Folding Unit.

  • Page 584: Making Checks After Completion Of Installation Work

    6. Paper Output Options 6. Fix to the upstream connection machine. Making Checks After Completion of Installation Work ■ Disposal Parts Check Following disposal parts are remained after completion of the installation work. Face Cover of the host machine Puncher Label (When Puncher Unit is not installed) ■...
  • Page 585 6. Paper Output Options 2. Open the Front Cover, and then set the Staple Cartridge into the Stapler Unit. 3. If a message prompting the user to update the version appears, press [Update] to automatically update the version of this equipment. NOTE: If [Skip] is selected, a message prompting the user to update the version will appear every time the host machine is started.

  • Page 586: Detaching From The Upstream Connection Machine

    6. Paper Output Options 4. Check the operation such as paper feed and stapling to make sure that problems such as a jam or malfunction do not occur. CAUTION: Staple-free binding unit might be out of its correct position due to a mechanical shock during transportation. When the staple-free binding unit is out of the correct position, a paper stack is clinched at wrong position in the staple-free binding mode.
  • Page 587 6. Paper Output Options CAUTION: When disconnecting the Interface Cable, be sure to turn off the host machine and disconnect its power cable from the outlet.
  • Page 588 6. Paper Output Options Disconnect the Relay connector when detaching the Finisher from the Document Insertion/ Folding Unit.

  • Page 589: 2/3 2/4 4 Hole Puncher Unit-A1

    6. Paper Output Options 2/3 2/4 4 Hole Puncher Unit-A1 Checking Before Installation ■ Checking Before Installation When installing this Equipment together with the Finisher, install this Equipment before installing the Finisher to the Upstream Connection Machine. ■ Product Name Safety regulations require the product's name to be registered.
  • Page 590 6. Paper Output Options 3. Remove the 2 fixtures. • 3 Screws NOTE: Removed screws are used in latter steps.

  • Page 591: Checking The Contents

    6. Paper Output Options Checking the Contents [1] Punch Unit x1 [2] Punch Waste Tray x1 [3] Punch Waste Full Sensor Unit x1 [4] Punch Unit [5] Punch Unit Fixing Pin [6] Punch Unit Fixing Pin Open/ Close Guide x1 Holder x1 [7] Punch Unit [8] Relay Harness x1...
  • Page 592 6. Paper Output Options ■ Installing the Punch Unit 1. Open the Front Cover of the Finisher. 2. Remove the Rear Cover of the Finisher. • 3 Screws • 3 Claws...
  • Page 593 6. Paper Output Options 3. Remove the Rear Inner Cover. • 1 Screw NOTE: Removed screw is used in the purocedure later.
  • Page 594 6. Paper Output Options 4. Remove the Inlet Feed Guide. • 1 Screw • 1 Connector • 1 Wire saddle • 2 Harness guides TP (M3x6)
  • Page 595 6. Paper Output Options 5. Install the Punch Unit Fixing Pin Holder. • 1 Screw (TP ; M3x6) NOTE: Use the screw removed in Unpacking Procedure.
  • Page 596 6. Paper Output Options 6. Remove the Magnet Unit. • 1 Screw NOTE: Removed screw is used in the purocedure later. 7. Remove a Screw. NOTE: Removed screw is used in the purocedure later.
  • Page 597 6. Paper Output Options 8. Install the Punch Unit Open/Close Guide. • 2 Screws (TP ; M3x6) • 1 Boss NOTE: Use screws removed in steps 6 and 7. Boss...
  • Page 598 6. Paper Output Options 9. Install the Punch Waste Full Sensor Unit. • 3 Hooks • Sensor Cover • 1 Screw (TP ; M3x6) NOTE: Use the screw removed in Unpacking Procedure.
  • Page 599 6. Paper Output Options 10. Cut out the face cover of the Inner Cover by using the side cutters. CAUTION: Be sure to remove the face cover properly so that no burr is formed.
  • Page 600 6. Paper Output Options 11. Install the Punch Unit Positioning Guide so that the right edge of the guide can match the center of scale. • 1 Screw (TP ; M3x6) NOTE: Use the screw removed in Unpacking Procedure. Scale...
  • Page 601 6. Paper Output Options 12. Affix the Face Seal to the Punch Unit.
  • Page 602 6. Paper Output Options 13. Install the Punch Unit from the back of the Finisher as shown in the figure. CAUTION: When having the Punch Unit, be careful not to have the PCB unit and its surrounding area.
  • Page 603 6. Paper Output Options 14. Install the Punch Unit Fixing Pin. • 1 Screw (W Sems ; M3x6) W Sems (M3x6) 15. Connect the connector of the Punch Waste Full Sensor Unit to the Punch Unit. • 4 Cable guides •...
  • Page 604 6. Paper Output Options 16. Connect the Relay Harness as shown in the figure. • 2 Connectors • 1 Reuse band • 4 Wire saddles...
  • Page 605 6. Paper Output Options 17. Install the Rear Inner Cover (small). • 1 Screw (TP ; M3x6) • 2 Bosses NOTE: Use the screw removed in step 3. Boss 18. Insert the Punch Waste Tray in the direction of the arrow from the front.

  • Page 606: Disposal Parts Check

    6. Paper Output Options 19. Close the Front Cover of the Finisher. 20. Install the Rear Cover of the Finisher. • 3 Screws • 3 Claws 21. Refer to the installation procedure of the Finisher to Install the Finisher in the Upstream Connection Machine. Disposal Parts Check 1.

  • Page 607: Adjusting The Output Level Of The Punch Waste Full Sensor

    6. Paper Output Options 2. If a message prompting the user to update the version appears, press [Update] to automatically update the version of this Equipment. NOTE: If [Skip] is selected, a message prompting the user to update the version will appear every time the Host Machine is started. In the service mode ( Level 2 ) shown below, it is possible to set not to display the message.

  • Page 608: Checking And Adjusting The Punch Hole Position

    6. Paper Output Options Checking and Adjusting the Punch Hole Position ■ Checking the Punch Hole Position 1. Make a print with the punch mode and check whether the skew and side registration and the paper stop position are within the standard. 2 Hole feed direction <front>...
  • Page 609 6. Paper Output Options <Standard> • 2/3 Hole Puncher Unit L1 , L2 12 ± 1.5 mm 2 holes : • 73 ± 1.5 mm (11"x17"/ LTRR) 3 holes : • 31.5 ± 1.5 mm (11"x17"/ LTR) • 40.5 ± 1.5 mm (A3/ A4) •...
  • Page 610 6. Paper Output Options 2. Lift the Punch Unit. Loosen the screw fixing the Punch Unit Positioning Guide, and then move the guide to adjust by referring the scale. After adjusting, tighten the screw. NOTE: When L1 > L2: Move the guide to the right. When L1 <...
  • Page 611 6. Paper Output Options ■ Paper Stop Position Adjustment (Service mode adjustment) 1. Enter the following service mode to adjust the paper stop position. Service Mode (Level 1) > SORTER > ADJUST > PNCH-X NOTE: When the setting value is increased by 1, L1 and L2 increase by 0.1mm. +: L1 and L2 increase.

  • Page 612: Finisher Jogger Kit-A1

    6. Paper Output Options Finisher Jogger Kit-A1 Checking Before Installation The installation site must satisfy the conditions given below. Therefore, it is recommended that the installation site be looked over before delivering this equipment to the customer. ■ Points to Note on Installation •...

  • Page 613: Checking The Contents

    6. Paper Output Options Remove all the tapes and cushioning materials outside this equipment. Checking the Contents Check that none of the included parts is missing.

  • Page 614: Installation Procedure

    6. Paper Output Options R - L Screw (TP ; M3x6) <Others> Other bundled items such as Installation Procedure, leaflets, etc. Installation Procedure CAUTION: Check that the main power switch is OFF and the power plug is disconnected from the outlet.
  • Page 615 6. Paper Output Options ■ Preparing the Finisher for Installation Disengage the ratchet gear to lower the Stack Tray by approx. 150mm for securing the room for the Jogger Kit. CAUTION: Hold the Stacking Tray by hand while disengaging the ratchet gear to avoid its free-fall.
  • Page 616 6. Paper Output Options NOTE: The removed face cover is stored in Rear Cover in a later step. NOTE: The removed face cover is stored in Rear Cover in a later step.
  • Page 617 6. Paper Output Options Store the removed face covers (2 pcs.) in the Rear Cover. ■ Installation Procedure TP ; M3x6...
  • Page 618 6. Paper Output Options TP ; M3x6 TP ; M3x6...
  • Page 619 6. Paper Output Options Place the Jogger Kit on Finisher. TP ; M3x6...
  • Page 620 6. Paper Output Options...
  • Page 621 6. Paper Output Options...

  • Page 622: Checking After Installation

    6. Paper Output Options Checking after Installation ■ Disposal Parts Check There are no parts left after installation work. ■ Operation Check 1. Install the Finisher. 2. Turn ON the main power of the host machine.
  • Page 623 6. Paper Output Options 3. If a message prompting the user to update the version appears, press [Update] to automatically update the version of this equipment. NOTE: If [Skip] is selected, a message prompting the user to update the version will appear every time the host machine is started. In the service mode (Level 2) shown below, it is possible to set not to display the message.

  • Page 624: Revision

    Revision Revision Chapter Category Product Name Reference Remarks First Edition Installation manual 2 Host Machine Add Con- Installing the Scanner “Installing the Scanner(Only for Ma- tents chines Equipped with the Image Reader Unit) ” on page 26...
