- Page 1 ® �liilt\PLOAD A1A-DC2508C 1-855-269-5623 www.anyload.com PN-250605 v1.o.o TECHNICAL MANUAL...
- Page 2 ANYLOAD Weigh & Measure Inc. disclaims all warranties not expressly stated in the Warranty Policy, including but not limited to implied warranties of merchantability and fitness for a particular purpose. ANYLOAD shall not be liable for any direct, indirect,...
-
Page 3: Table Of Contents
ANYLOAD Technical Manual – A1A-DC2508C – (v1.0.0) CONTENTS CONTENTS ................................... 1 Introduction ................................3 Safety ................................3 Features ................................. 3 Connection Diagram ............................5 Installation ................................5 Connecting Power and Signal Wires ......................5 Securing the Board ............................5 Communication Protocol ............................. 6 Communication Examples ........................7... -
Page 4: Revision History
ANYLOAD Technical Manual – A1A-DC2508C – (v1.0.0) Revision History: Record with brief description of all revisions made to product or manual Version Date Description 1.0.0 June 6 , 2025 First public release version. The most current version of this document, along with any software, firmware, and other product updates, can be found on our website: www.anyload.com... -
Page 5: Introduction
DO NOT allow untrained personnel to operate, clean, inspect, maintain, service, or modify this equipment. SAVE and distribute this manual for future reference. Failure to follow the instructions or heed the warnings could result in injury or death. Contact any ANYLOAD dealer or distributor for replacement manuals. - Page 6 ANYLOAD Technical Manual – A1A-DC2508C – (v1.0.0) General Safety: ⚠ ⚠ WARNING ONLY qualified professionals approved should carry out intrinsically safe installations. This work involves extensive knowledge of the product, specific safety standards, and the potentially hazardous environment in which it will be operating.
-
Page 7: Connection Diagram
ANYLOAD Technical Manual – A1A-DC2508C – (v1.0.0) 2. Connection Diagram Figure 2-1: Connection Diagram for A1A-DC2508C 3. Installation 3.1 Connecting Power and Signal Wires Connecting the power, output signal, and load cell to the amplifier can be accomplished with a small flat head screwdriver. -
Page 8: Communication Protocol
ANYLOAD Technical Manual – A1A-DC2508C – (v1.0.0) 4. Communication Protocol 4.1 CANOpen Parameters Table 4-1: CANOpen Index Parameters Primary Sub- Data Default Index index Attribute Type Function Name Parameter Additional Notes 0x2000 0x00 read only int32 AV raw value 0x2001 0x00... - Page 9 ANYLOAD Technical Manual – A1A-DC2508C – (v1.0.0) Table 4-2: CANOpen Index Parameters Cont. Primary Sub- Data Default Index index Attribute Type Function Name Parameter Additional Notes read/writ 9th calibration point 0x2016 0x00 int32 PV load value read/writ 0x2017 0x00 int32...
- Page 10 ANYLOAD Technical Manual – A1A-DC2508C – (v1.0.0) 2 20sps 3 80sps 4 320sps Table 4-5: FIR Filtering Value FIR Filtering 0 Cloture 1 Opens www.anyload.com | +1 (855) 269-5623 ©06/2025 ANYLOAD. Content subject to change without notice.
- Page 11 4.2 CANOpen Read Parameters Table 4-6: Read Parameters Serial Number Functionality Digital Data Return Data Additional Notes Read AV raw value 40 00 20 00 00 00 00 00 43 00 20 00 94 ED 00 00 AV raw value = 0x0000ED94 (60820) Read PV measured value 40 01 20 00 00 00 00 00...
- Page 12 ANYLOAD Technical Manual – A1A-DC2508C – (v1.0.0) 4.3 CANOpen Write Parameters Table 4-7: Write Parameters Serial Number Functionality Digital Data Additional Notes Write equipment device address 22 02 20 00 02 00 00 00 Device address = 0x00000002(2) Number of calibration points = 0x00000002(2)
-
Page 13: Calibration
5. Calibration Perform calibration via CAN bus by performing the following: 1. Enable calibration 2. Write PVPn value 3. Repeat steps 1-2 until all necessary calibration points are fulfilled (max: 9) 4. Lock calibration (Calibration forbidden) 5. Write calibration points to the appropriate indices 6. -
Page 14: Technical Specifications
ANYLOAD Technical Manual – A1A-DC2508C – (v1.0.0) 7. Technical Specifications 7.1 Drawings & Dimensions Figure 7-1: Chip Dimensions 7.2 Specifications Table Table 7-1: Product Specifications Acceptable Load Cell Type All strain gauge type Weight Approx. (g) Power Supply 9~24VDC Working Temperature -22°F —... - Page 15 Please for Technical Assistance: Contact Our Authorized Dealer Notes: V1.0.0 PN-250605 1-855-269-5623 © 2025 Anyload Weigh & Measure Inc. ® Specifications subject to change without notice. lnJU UY� ®l'rnn..JJI �oAD www.anyload.com...
