- Page 1 IX Series DSP Multichannel Networked Power Amplifiers IX60:8 | IX60:4 | IX30:8 | IX30:4 | IX15:4 Installation manual...
-
Page 3: Table Of Contents
IX Series DSP Multichannel Networked Power Table of contents | en Amplifiers Table of contents Important product information Safety information FCC information Disposal instructions About this manual Digital document Intended audience Copyright notice Trademarks Notice of liability Short information Product introduction... -
Page 4: Important Product Information
IX Series DSP Multichannel Networked Power en | Important product information Amplifiers Important product information Safety information Read and keep these safety instructions. Follow all instructions and heed all warnings. Download the latest version of the applicable installation manual from www.boschsecurity.com for installation instructions. -
Page 5: Disposal Instructions
IX Series DSP Multichannel Networked Power Important product information | en Amplifiers Compliance statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 6: About This Manual
This manual is intended for everyone who is authorized and professionally qualified to install and use this product. Copyright notice Unless otherwise indicated, this publication is the copyright of Dynacord. All rights are reserved. Trademarks Throughout this document trademark names may have been used. Rather than put a trademark... -
Page 7: Short Information
IX Series DSP Multichannel Networked Power About this manual | en Amplifiers Short information This document is applicable to these products: Description IX60:8 8-channel DSP power amplifier,6kW IX60:4 4-channel DSP power amplifier,6kW IX30:8 8-channel DSP power amplifier,3kW IX30:4 4-channel DSP power amplifier,3kW IX15:4 4-channel DSP power amplifier,1.5kW... -
Page 8: Product Introduction
IX series is fully integrated in Dynacord‘s SONICUE Sound System Software and can be used as a SONICUE control server, for direct use with the WPN1 wall controller as well as TPC-1, iOS and Windows devices. - Page 9 IX Series DSP Multichannel Networked Power Product introduction | en Amplifiers IX60:8 IX60:4 IX30:8 IX30:4 IX15:4 Dante 8 x 8 8 x 8 8 x 8 8 x 8 8 x 8 channels Power all 8 x 600 W 4 x 1500 W 8 x 375 W 4 x 600 W 4 x 375 W channels 4Ω Power all 8 x 750 W 4 x 1200 W 8 x 375 W 4 x 750 W 4 x 375 W channels 8Ω/100V...
-
Page 10: General Installation Procedures
The product should be unpacked and handled with care. If an item appears to be damaged, notify the shipper immediately. If any items are missing, notify your Dynacord representative. The original packaging is the safest container in which to transport products and can also be used to return products for service, if necessary. - Page 11 IX Series DSP Multichannel Networked Power General installation procedures | en Amplifiers IX60:4 Quantity Component Power amplifier Mains power cord Euroblock input connector 5-pin Euroblock control port connector 8-pin Euroblock output connector 4-pin Quick installation guide Safety information F.01U.434.765, MC1,5/5_ST-3,81 or EC381V-05P F.01U.434.764, MC 1,5/8-ST-3,81, EC381V-08P...
-
Page 12: Dimensions
IX Series DSP Multichannel Networked Power en | General installation procedures Amplifiers Quantity Component Euroblock input connector 5-pin Euroblock control port connector 8-pin Euroblock output connector 8-pin Quick installation guide Safety information F.01U.434.765, MC1,5/5_ST-3,81 or EC381V-05P F.01U.434.764, MC 1,5/8-ST-3,81, EC381V-08P F.01U.434.762, IC 2,5/8-STF-5,08... -
Page 13: Mounting And Ventilation
General installation procedures | en Amplifiers Mounting and ventilation IX series amplifiers are designed for installation in common 19-inch racks. Attach the amplifier with four 20 mm screws and washers. >= 20 mm Additionally securing the amplifier by rack rails might be necessary in case you intend to transport the rack. - Page 14 Consider that those devices accumulate heat within the rack space. An air duct of at least 30 cm between the rear panel of the IX series amplifiers and the inner wall of the cabinet or rack case is recommended. Make sure that the duct reaches up to the top ventilation louvers of the cabinets or the rack cases.
-
Page 15: Mains Power Connection
Amplifiers Mains power connection The IX series products receive their power supply via the IEC MAINS inlet connector that will accept voltages from 100 to 240 volts AC, 50-60 Hz. Only use the included AC cable or AC cables approved for your country of use. During installation, always separate the device from the mains. Connect the device only to a mains network once the device is ready for operation. - Page 16 IX Series DSP Multichannel Networked Power en | General installation procedures Amplifiers Indicator status General meaning Meaning for DSP/Dante Meaning for amp PoE green PoE in use Will operate without mains power PoE flashing red PoE dropped and is not...
-
Page 17: Mains Operation And Resulting Temperature
IX Series DSP Multichannel Networked Power General installation procedures | en Amplifiers Check for a green PoE indicator. Connect the mic/line inputs and apply phantom power if required. The PoE indicador shall maintain green. If the PoE indicator starts flashing red, you run into a power limitation issue: Check for proper PoE supply (no power limits and proper cabling). - Page 18 IX Series DSP Multichannel Networked Power en | General installation procedures Amplifiers BTU/hr mains mains mains 1/8 of 375 W 1 kHz sine 70 V mode 1/8 of 375 W Pink Noise 100 V mode 1/8 of 375 W 1 kHz sine 100 V mode Conversion factors for mains current 100 V = 2.3, 120 V = 1.9, 240 V = 0.96 1 BTU = 1055.06 J = 1055.06 Ws...
- Page 19 IX Series DSP Multichannel Networked Power General installation procedures | en Amplifiers 1 BTU = 1055.06 J = 1055.06 Ws Power dissipation All powers measured without PoE provided. With PoE the mains power will drop, but device power loss will remain the same.
- Page 20 IX Series DSP Multichannel Networked Power en | General installation procedures Amplifiers BTU/hr mains mains mains 1/8 of 1500 W 1158 1392 Pink Noise @ 4 Ω, (Lo-Z mode) 1/8 of 1500 W 1247 1696 Pink Noise 70 V mode 1/8 of 1500 W 1158 1392 1 kHz sine 70 V...
- Page 21 IX Series DSP Multichannel Networked Power General installation procedures | en Amplifiers BTU/hr mains mains mains 1/8 of 750 W 1037 Pink Noise 100 V mode 1/8 of 750 W 1066 1078 1 kHz sine 100 V mode Conversion factors for mains current 100 V = 2.3, 120 V = 1.9, 240 V = 0.96 1 BTU = 1055.06 J = 1055.06 Ws...
-
Page 22: Installation
IX Series DSP Multichannel Networked Power en | Installation Amplifiers Installation Front panel POWER 1 2 3 4 5 6 7 8 MIC/LINE STANDBY IX60:8 AMPLIFIER FAULT 1 2 3 4 5 6 7 8 OMNEO Figure 5.1: IX60:8 shown but description is valid for all models. Only the number of inputs and channels varies. -
Page 23: Control Port
IX Series DSP Multichannel Networked Power Installation | en Amplifiers IX60:4 - 4 + - 3 + - 2 + - 1 PRIMARY (PoE) SECONDARY CONTROL PORT STATUS INIT DATA V: +10V BRIDGED BRIDGED Output connectors channels 1 & 2 Output connectors channels 3 &... -
Page 24: Audio Connections
Unbalanced Balanced In addition to the analog mic/line inputs, IX series amplifiers can also receive their input signal from an OMNEO/Dante/AES67 network. For more information on OMNEO/Dante/OCA network connection, refer to OMNEO/Dante/OCA network connection, page 25. -
Page 25: Omneo/Dante/Oca Network Connection
Property damage and/or personal injury may occur. OMNEO/Dante/OCA network connection IX series amplifiers have two OMNEO/Dante/OCA network ports. They are labeled PRIMARY (PoE) and SECONDARY. Configuration is done in SONICUE and allows selecting between the operation modes: –... - Page 26 Transparent RSTP Glitch-Free IX series amplifiers operate natively at 96 kHz sampling rate, Dante can be switched to either 48 kHz or 96 kHz. Factory default setting is 48 kHz. Notice! The OMNEO network comprises audio transport using the Dante protocol as well as OCA control commands.
-
Page 27: Configuration In Sonicue
IX Series DSP Multichannel Networked Power Configuration in SONICUE | en Amplifiers Configuration in SONICUE The entire configuration and operation of IX series amplifiers is done via SONICUE Sound System Software. SONICUE is available as a free download at www.dynacord.com... -
Page 28: Web Server
IX Series DSP Multichannel Networked Power en | Configuration in SONICUE Amplifiers Connect the IX amplifier to your PC and start the OMNEO Firmware Upload Tool app. The tool will display the available devices. Ensure the network interface of your PC is set to Obtain IP address automatic. - Page 29 IX Series DSP Multichannel Networked Power Configuration in SONICUE | en Amplifiers – Network Allows you to set the IP address and time of the device, important for correct logging information. – Logging Provides the current device log. – Miscellaneous Hosts the open source licenses.
-
Page 30: Dsp And Routing
The internal mix matrix combined with the 8 (4) analog microphone/line, 8 Dante audio inputs and also 8 assignable Dante outputs provide a lot of flexibility and use cases for IX series besides the application as standard networked amplifiers that use an input routed to one or several amplifier channels: –... - Page 31 IX Series DSP Multichannel Networked Power Configuration in SONICUE | en Amplifiers IX60:4 , IX30:4 and IX15:4 Figure 6.2: Block diagram for inputs The input routing in SONICUE determines whether a source signal is routed directly to an amplifier channel, or if it is used with input processing in the 16 x 16 mixer (resp. 12 x 12 for the 4-channel amp versions).
- Page 32 IX Series DSP Multichannel Networked Power en | Configuration in SONICUE Amplifiers IX60:4 , IX30:4 and IX15:4 Figure 6.4: Dante router Other signal options for sending to Dante are mic/line input post pre amp, and input signal post channel processing (EQ, dynamics). It is also possible to send the signal of an amplifier channel including the full channel processing.
-
Page 33: Taskengine
The TaskEngine allows to program logic tasks for the amplifier or other devices in the network. This option takes full advantage of the internal mixing capabilities of IX series and avoids the use of a “system matrix” when operating the amplifiers. -
Page 34: Third Party Remote Control
Amplifiers Third party remote control It is possible to integrate IX series amplifiers with third party AV control or building control systems. Dynacord provides plug-ins for common AV control systems with instructions. For more information, refer to Dynacord’s download section “Third party plug-ins”. -
Page 35: Technical Data
IX Series DSP Multichannel Networked Power Technical data | en Amplifiers Technical data Output power OUTPUT POWER IX60:8 IX30:8 IX60:4 IX30:4 IX15:4 Total rated 6000 W 3000 W 6000 W 3000 W 1500 W output power Number of amplifier channels IX60:8 Load 2 Ω 2.7 Ω 4 Ω... - Page 36 IX Series DSP Multichannel Networked Power en | Technical data Amplifiers IX60:4 Load 2 Ω 2.7 Ω 4 Ω 8 Ω Maximum Output Power All channels 1000 W 1300 W 1500 W 1200 W equally driven Max. per channel 1000 W 1300 W 1800 W 1200 W Direct Drive 70 V 100 V Maximum Output Power All channels equally 1500 W...
-
Page 37: Amplifier
IX Series DSP Multichannel Networked Power Technical data | en Amplifiers Direct Drive 70 V 100 V All channels equally 375 W 375 W driven Max. per channel 750 W 1000 W Test signal for max. output power according IHFA-202 (Dynamic-Headroom, burst 1 kHz / 20 ms on /480 ms off / low level -20 dB) -
Page 38: Digital Signal Processing
IX Series DSP Multichannel Networked Power en | Technical data Amplifiers AMPLIFIER IX60:8 IX30:8 IX60:4 IX30:4 IX15:4 Gain 0 to 60 dB Maximum Input Level (balanced) +18 dBu Maximum Input Level (unbalanced) +12 dBu Phantom power +48 V, switchable per input Input Impedance, active balanced >10 kΩ... -
Page 39: Connectivity
IX Series DSP Multichannel Networked Power Technical data | en Amplifiers DIGITAL SIGNAL PROCESSING Speaker Limiters Peak Anticipation Limiter and RMS/TEMP Limiter per channel Load Supervision Pilot tone up to 30 kHz Other Functions Source Selection, Level, Mute, Polarity, Sine and... -
Page 40: General
IX Series DSP Multichannel Networked Power en | Technical data Amplifiers CONNECTIVITY IX60:8 IX30:8 IX60:4 IX30:4 IX15:4 Digital Outputs ON: Output switched to GND, max. 200 mA OFF: Open Collector Reference Voltage Output +10 V, max. 200 mA, supervised, short circuit protected READY/FAULT Galvanic isolated relay, max. - Page 41 IX Series DSP Multichannel Networked Power Technical data | en Amplifiers Amplifier at rated conditions, Lo-Z/2 - 4 Ω normal operation mode, all channels driven, 4 Ω loads, analog input, 32 dB Gain, unless otherwise specified. Dynacord 2025-06 | 01 | Installation manual...
- Page 42 IX Series DSP Multichannel Networked Power | Technical data Amplifiers 2025-06 | 01 | Dynacord Installation manual...
- Page 44 Bosch Security Systems, LLC 130 Perinton Parkway Fairport, NY 14450 www.dynacord.com © Bosch Security Systems, LLC, 2025 EU importer: Bosch Sicherheitssysteme GmbH Robert-Bosch-Platz 1 70839 Gerlingen Germany © Bosch Sicherheitssysteme GmbH, 2025 202506251616...
