Dynacord FX12 Architects And Engineers Specifications

Features:
.
ND 12A MF Transducer
.
ND6 Neodymium HF Driver
.
Extremely High Sensitivity, 106dB 1W/1m
.
Voice Coil Tracking Protection
Wir weisen ausdrücklich darauf hin, dass bei
gehängten Lautsprecherboxen die einschlägigen
Sicherheitsbestimmungen zu beachten sind. Es
muss unbedingt qualifizierte Fachberatung in
Anspruch genommen werden!
We expressly point out that the relevant safety
regulations must be observed for „flying"
loudspeaker systems. It is imperative that quali-
fied expert advice is sought.
Technische Informationen
Architects and engineers
specifications
FX12
MID-HIGH-CABINET
COAXIAL CONICAL HORN
Specifications
TYPE / NAME
Order No.
Cabinet
Configuration
Operating Mode
Nominal impedance
Rated power RMS
Program power
SPL 2,83 V / 1m 1 W / 8 Ohm
Max. SPL 1m (calculated)
Frequency response ( -10dB )
Coverage angle 1kHz (-6dB)
measured with Xa 4000
Passive crossover frequency
Recommended active crossover
frequency to subwoofer
Voice coil tracking protection
Components HIGH
Order No.
Connector wiring
Connector model
Dimensions (WxHxD)
Net weight
Shipping weight
Enclosure material
Finish
Grille
Handles
Rigging tracks
Webbing strap points
Castors
Warranty
FX 12
D 113 004
Mid-High-Cabinet
Coaxial Conical Horn
Passive
8 Ohms
350 W
700 W
106 dB
134 dB
120 Hz - 10 kHz
H 80° V 40°
1000Hz
140 Hz / 18dB/Oct. Butterworth
Separate circuits for LO-MID and HIGH
ND 6-8 / CDH 8040-14
D 360439
4-pole NORMAL 1+/1-, SYSTEM 2+/2-
Speakon 2x NL4 MPR
600mm x 610mm x 814 mm
(23.386" x 23.780" x 31.811")
48 kg (105.82 Ibs)
57 kg (125.66 Ibs)
Poplar plywood 15 mm
Heavy-Duty black carpet
Acoustic foam, powder coated steel
2
4
2
4
36 Months
