45VM900055: Installation and Owners Manual
ABOUT THE DOCUMENTATION
Notice: Make sure that the user has the printed documentation and ask
him/her to keep it for future reference.
Target audience
Authorized installers + end users
This appliance is intended to be used by expert or trained users in shops,
in light industry, and on farms, or for commercial and household use by
lay persons.
WARNING
Please thoroughly read and ensure that you fully understand
the safety precautions (including the signs and symbols) in this
manual, and follow relevant instructions during use to prevent
damage to health or property.
Documentation set
This document is part of a documentation set. The complete set consists
of:
• General safety precautions:
– Safety instructions that you must read before installing
• Indoor unit installation and operation manual:
– Installation and operation instructions
• Repeater installation and operation manual:
– Installation and operation instructions
Technical engineering data
Latest revisions of the supplied documentation may be available via your
dealer.
The original documentation is written in English. All other languages are
translations.
SAFETY SIGNS
EXPLANATION OF SAFETY SIGNS
The precautions and things to note in this document involve very
important information. Please read them carefully.
DANGER
Indicates a hazardous situation which, if not avoided, will
result in death or serious injury
WARNING
Indicates a hazardous situation which, if not avoided, could
result in death or serious injury
CAUTION
Indicates a hazardous situation which, if not avoided, could
result in minor or moderate injury
Note: Is used to address practices not related to physical
injury
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
Shut-Off Valve for Mini Variable Refrigerant Flow (VRF)
Safety Instructions: Safety instruction (or equivalent) signs indicate
specific safety-related instructions or procedures
Important Information for the Dealer and Service
Personnel
1
Table 1 — Explanation of Symbols Displayed on Unit
DANGER
This symbol shows that this appliance used a
mild flammable refrigerant. If the refrigerant is
leaked and exposed to an external ignition
source, there is a risk of fire.
WARNING
This symbol shows that appliance shall be
installed, operated and stored in a room with a
floor area not less than the minimum room
area.
CAUTION
This symbol indicates that the operation
manual should be read carefully.
CAUTION
This symbol indicates that service personnel
should be handling this equipment while
referencing the installation
manual.
CAUTION
This
symbol
information is available in documents such as
the operating manual or installation manual.
WARNING
• Risk of Fire. Flammable Refrigerant Used.
• Installation, repair, maintenance, decommission and
disposal Should Be Performed Only By Trained and
Certified Service Personnel.
• Information of procedures additional to usual
information for refrigerating appliance installation,
repair, maintenance and decommission procedures is
required when an appliance with FLAMMABLE
REFRIGERANTS is affected.
• The training of these procedures is carried out by
national training organizations or manufacturers that
are accredited to teach the relevant national competency
standards that may be set in legislation.
• The achieved competence should be documented by a
certificate.
45VM900055
indicates
that
additional
