Thank you for purchasing this quality product. Be sure to check all packing materials
carefully for small parts, which may have come loose during shipment. Identify and count
all items and compare with the parts list shown below. It is recommended to have two
people during assembling and to remove the back and base of the furniture out from the box.
Please follow the drawings below to assemble the item
NO.
DESCRIPTION
A
Seat
B
Left Side Facing (LSF) backrest
Right Side Facing (RSF) backrest
C
Right Side Facing (RSF) Wing
D
ASSEMBLY INSTRUCTIONS
KAMARI COLLECTION
ITEM# : U092-20R
DESCRIPTION : KAMARI RAF LOVESEAT
W/ONE RECLINER
Parts List
All images shown are for illustration purpose only.
Actual product may vary due to product enhancement.
Page 1 of 3
SKETCH
Q'TY
1 PC
1 PC
1 PC
1 PC
49901581
Advertisement
Related Manuals for New Classic Furniture KAMARI U092-20R
Summary of Contents for New Classic Furniture KAMARI U092-20R
- Page 1 ASSEMBLY INSTRUCTIONS KAMARI COLLECTION ITEM# : U092-20R DESCRIPTION : KAMARI RAF LOVESEAT W/ONE RECLINER Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts, which may have come loose during shipment. Identify and count all items and compare with the parts list shown below.
- Page 2 ASSEMBLY INSTRUCTIONS KAMARI COLLECTION ITEM# : U092-20R DESCRIPTION : KAMARI RAF LOVESEAT W/ONE RECLINER S tep 1: Step 2: A ttach the LSF and RSF backrests (B & C) to Attach the RSF (D) Wing to RSF Backrest (C). the s eat (A). Step 3: Open the footrest by pulling the handle.
- Page 3 ASSEMBLY INSTRUCTIONS KAMARI COLLECTION ITEM# : U092-20R DESCRIPTION : KAMARI RAF LOVESEAT W/ONE RECLINER Connect the sectional pieces by connecting the metal connectors between each sectional piece. Please note there are 2 types of interlocking hardware: 1. Connect the rail pins style connector A to B 2.
