- Page 1 SUPERSONICA SLR ASSEMBLY INSTRUCTIONS...
- Page 2 W I L I E R .C O M #LOVEMYWILIER SUPERSONICA SLR ASSEMBLY INSTRUCTIONS 1. Insert the fork cone complety on its seat. 2. Insert the lower bearing in the crown race. 3. Insert the Anti Rotation System into the fork cone horizontally and tighten it to 5 Nm.
- Page 3 W I L I E R .C O M #LOVEMYWILIER SUPERSONICA SLR ASSEMBLY INSTRUCTIONS 4. Using a cable guide, insert the front brake hose through the fork arm hole. Slide the brake hose making sure it gets out from the central hole on top of the fork.
- Page 4 W I L I E R .C O M #LOVEMYWILIER SUPERSONICA SLR ASSEMBLY INSTRUCTIONS 6. Apply grease in the headtube, both lower and upper bearing seats and install the up- per bearing in the headtube making sure the brake hose goes through it.
- Page 5 W I L I E R .C O M #LOVEMYWILIER SUPERSONICA SLR ASSEMBLY INSTRUCTIONS 9. Tighten the fork cone with its nut making sure the complete system is correctly blocked but allowing the bearings to properly rotate (NB. The seal of the nut must be placed upwards).
- Page 6 W I L I E R .C O M #LOVEMYWILIER SUPERSONICA SLR ASSEMBLY INSTRUCTIONS 12. Slide the brake hoses completely out of the handlebar until they get out from the han- dlebar ends. 13. Tighten the handlebar to the fork using the three M5 bolts at the specified torque (6...
- Page 7 W I L I E R .C O M #LOVEMYWILIER SUPERSONICA SLR ASSEMBLY INSTRUCTIONS 14. Tighten the handlebar nut and bolt in 15. Afterwards, insert the handlebar top co- the fork cone to 4 Nm. ver and tighten it to 2 Nm.
- Page 8 W I L I E R .C O M #LOVEMYWILIER SUPERSONICA SLR ASSEMBLY INSTRUCTIONS 17. Insert the support bottle clip on top of the bottle cage and tighten the two bolts to 3 18. Place the bottle cage against the frame and tighten it to 4 Nm (the bottle cage is cor-...
- Page 9 W I L I E R .C O M #LOVEMYWILIER SUPERSONICA SLR ASSEMBLY INSTRUCTIONS 19. Insert the seat tube cutting jig placed 20. Lightly mark the seat tube area whe- at the correct height previously determined re the frame will be cut using a sharpened (according to your needs and size) tool.
- Page 10 W I L I E R .C O M #LOVEMYWILIER SUPERSONICA SLR ASSEMBLY INSTRUCTIONS 22. Once the seat tube is cut at the correct 23. Insert the seat tube expander into the height, insert the resin collar on top of the seat tube, making sure it is aligned with the seat tube.
- Page 11 W I L I E R .C O M #LOVEMYWILIER SUPERSONICA SLR ASSEMBLY INSTRUCTIONS 26. Place the seat post rail on top of the seat tube and tighten it with the two M5 bolts to 6 Nm (any spacers installed should be placed underneath the seat post rail).
- Page 12 W I L I E R .C O M #LOVEMYWILIER SUPERSONICA SLR ASSEMBLY INSTRUCTIONS 28. Place the threaded pin to secure the desired saddle position, ensuring the threads align with the bolt holes in the seat post rail. 29. Place the seat post clamp on top of the rail and tighten it to 6 Nm (two bolts should...
- Page 13 W I L I E R .C O M #LOVEMYWILIER COMPONENTS TOURQUE VALUES COMPONENT DESCRIPTION TOOL TORQUE NOTES SIZE in-lbf Anti rotation system bolt AllenKey 3 mm 44.25 Medium thread lock Handlebar clamp bolt to fork cone AllenKey 4 mm 35.4 Medium thread lock Handlebar bolts...
