Summary of Contents for Wilier Jena Hybrid

  • Page 1 TECHNICAL INTRODUCTION REV.01...
  • Page 2 # L OV E M Y W I L I E R Jena Hybrid has a carbon monocoque frame and fork. The frame’s geometry is similar to the Jena, offering a performance endurance ride combined with a comfortable ride position for long hours spent in the saddle.
  • Page 3 W I L I E R . C O M # L OV E M Y W I L I E R USABILITY There are practically no limits on Jena Hybrid’s usability and to the available configurations. The clearance between frame / fork and wheels allows you to install generously sized tires on 28”...
  • Page 4 W I L I E R . C O M # L OV E M Y W I L I E R COLOR BLUE / ORANGE FINISH GLOSSY COLOR CODE...
  • Page 5 W I L I E R . C O M # L OV E M Y W I L I E R SIZES AND GEOMETRIES SIZE REACH STACK WHEELBASE [cm] [cm] [cm] [°] [cm] [cm] [°] [mm] [mm] [mm] 52.9 72.8 12.5 42.3...
  • Page 6 W I L I E R . C O M # L OV E M Y W I L I E R SPARE PARTS LIST X35CHARG-EU EBIKE X35 CHARGER WIRE FOR EUROPE X35CHARG-US EBIKE X35 CHARGER WIRE FOR US X35CHARGER-C EBIKE X35 CHARGER-C (WITHOUT WIRE) X35CHGPNT-C EBIKE X35 CHARGING POINT -C...
  • Page 7 W I L I E R . C O M # L OV E M Y W I L I E R FRAME KEYPOINTS IWOC SUPPORT SEATPOST DIAMETER 27.2 mm RACK & MUDGUARD MOUNT MAIN BATTERY INSIDE THE DOWNTUBE CLEARANCE 700C x 42MM / 650B x 47MM FORK O.L.D.
  • Page 8 Is it possible to increase the Jena Hybrid’s autonomy? Yes, by installing an optional second battery placed inside a “dummy bottle” on the seat tube of the Jena Hybrid. The total capacity is 460 W/h. Do I have to wait until the battery is fully discharged before charging it? No, Jena Hybrid’s lithium battery can be charged at any...
  • Page 9 Of course. The system is waterproof. How can I wash the Jena Hybrid? You clean Jena Hybrid like any other racing bike. The bicycle must not be washed with high pressure water, as water could get into the motor or communication port above the bottom bracket box.
