  • Page 1 ASSEMBLY INSTRUCTIONS - BATTERY...
  • Page 2 W I L I E R . C O M # L OV E M Y W I L I E R Remove the metallic pieces from the downtube Pass a metallic guide through the side hole of the downtube until the bb. Connect the extremity of the battery/iwoc cable to the metallic guide.
  • Page 3 W I L I E R . C O M # L OV E M Y W I L I E R Slide the battery inside the downtube Pull out the cable fixed to the metallic guide through Connect the battery cable to the iwoc the side hole.
  • Page 4 W I L I E R . C O M # L OV E M Y W I L I E R Close the side hole with the two closing metallic plates.  Close the bb shell cover Assembly the bike as a normal jena. Once that the handlebar is compacted, fix the iwoc holder to the handlebar.
