- Page 1 ASSEMBLY INSTRUCTIONS - BATTERY...
- Page 2 Insert the battery inside the down tube, passing it through the Place the upper and lower bearings in hole positioned on the underside of the bottom bracket. The the head tube of the Cento10 Hybrid battery must be inserted so that the end with two terminal frame.
- Page 3 W I L I E R . C O M # L OV E M Y W I L I E R Proceed to fit the shimano group electronic Feed the 1200 mm long Shimano electronic cables. cable through the down tube (it will be con- nected to one of the control levers).
- Page 4 W I L I E R . C O M # L OV E M Y W I L I E R Attach the dropout to the frame. Feed the 700 mm long electronic cable through the chainstay (it will be connected to the rear shi- fter).
- Page 5 W I L I E R . C O M # L OV E M Y W I L I E R Fit the shimano Press Fit bottom bracket into Connect the speed sensor cable to the connector the bottom bracket shell. following the direction arrows shown on the cables.
- Page 6 W I L I E R . C O M # L OV E M Y W I L I E R Attach the iwoc to its support bracket Connect the connector of the iwoc with the cor- responding battery cable. Put the connection back inside the down tube, so that only the wire of the iwoc exits the head tube.
- Page 7 W I L I E R . C O M # L OV E M Y W I L I E R Pass the shimano electronic cable from the SM- Position the handlebar onto the steerer tube over JC41 hub into the handlebar toward the left side. the spacers and fix it with the expander to the fork.
