- Page 1 ÖZHAK MAKİNA FAN MOUNTİNG MACHİNE USER MANUAL 1- General options of the display 2- Main menu details 3- Time settings 4- Counter settings 5- İn/Out Controls 6- Factory settings - Laser Sensors 8- Pressure Setting Prepared By Furkan Aydın...
- Page 2 1- General Options of the display DELTA TOUCH PANEL DOPB07S411...
-
Page 3: Main Menu Details
2- Main Menu Details 1) This area is show the alarms. İf lighting green, This part ready for work. İf lighting red, there are a problems.Touch this red part and see which sensor have a problem. 2) Reset button is used to fill air and make ready for work. -
Page 4: Time Settings
3- Time Settings If need to set working times, push the Time button in the toolbar. Want to time setting, choose this parts in page. from the page that opens, touch the time you want to change. -
Page 5: Counter Settings
4- Counter Settings İf you want enter counter settings, push the number of product in the toolbar. This window will open when the desired product is completed. You can continue by pressing Continue button. Holding the push 2 second reset the displays. We can change request product and machine stop the automatic. - Page 6 5- İn/Out Controls If need to control in/out, push the I/O Control button in the toolbar. İf lighting green, this part OK. İf lighting red, this part...
-
Page 7: Factory Settings
6- Factory Settings If need to return factory settings, push the Reset button in the toolbar. If you press and hold the center button for 3 seconds, Return factory settings. all settings will be cleared when you push !!! - Page 8 7- Laser Sensors (TABLE LASERS) Fan Cap Work Permission Laser Sensor: This Sensor, if it detect fan, its let the fan cap operate. Fan Cap Rotate Permission Laser Sensor: This Sensor, if it detect fan cap, its let the fan cap rotating.
- Page 9 7- Laser Sensors (FAN CAP LASERS) Fan Cap Front Permission Laser Sensor: This Sensor, if it detect cap, its let the fan cap move the front. Vibration Start Laser Sensor: This Sensor, if not detect, let the start . Vibration Stop Laser Sensor: This Sensor, if detect, let the stop vibration.
- Page 10 7- Laser Sensors (FAN LASERS) Fan Transport Front Permission Laser Sensor: This Sensor, if it detect fan, its let the fan move the front. Vibration Start Laser Sensor: This Sensor, if not detect, let the start . Vibration Stop Laser Sensor: This Sensor, if detect, let the stop vibration.
-
Page 11: Pressure Setting
8- Pressure Setting Firstly, unloose the upper and lower nut. Then left or right middle shaft rotate. - Page 12 ÖZHAK MAK NA İ FAN MOUNT NG İ USER MANUAL Phone: 0212 501 86 43 Adress: Aykosan San. Sitesi 4'lü D Blok No153/154 kitelli OSB. Ba ak ehir İ ş ş stanbul/Tukiye İ Mail: info@ozhakmakina.com Web: www.ozhakmakina.com...
