100343224_2000600568_Rev R
w/RealTime O2 Trim
TM
Installation & Operation Manual
Models: 1000 - 6000
Series: 100
C o m b u s t i o n
T e c h n o l o g y
This manual must only be used by
⚠
WARNING
a qualified heating installer / service
technician. Read all instructions,
including this manual and the Crest
Service Manual, before installing.
Perform steps in the order given.
Failure to comply could result in
severe personal injury, death, or
substantial property damage.
Save this manual for future reference.
