1. Attach the stand, as shown below: Note: The phone may also be wall mounted using the optional ZIP 47GE wall mount bracket. Refer to wall mount installation guide for additional information. 2. Connect the handset and optional wired headset, as shown below: Note: Optional headset may be purchased separately.
Page 3
3. Connect optional USB device if supplied: Note: Optional USB devices include the ZIP 450M Expansion Module, USB headset and the EHS4x Electronic Hook Switch adapter for wireless headsets. Refer to the related manuals for additional information. 4. Connect the network and power, as detailed below: a) Wired Network: There are two options for wired network and power connections.
Basic Call Features Placing a Call Using the handset: 1. Pick up the handset. 2. Enter the number, and then press the Call soft key or --Alternatively-- Enter the number and then lift the handset to initiate the call. Using the speakerphone: 1.
Page 5
If there is more than one call on hold, press to select the desired call, and then press or the Resume soft key. Call Transfer You can transfer a call in the following ways: Blind Transfer 1. Press or the Transfer soft key during an active call. The call is placed on hold. 2.
Voice Message The message waiting indicator on the idle screen indicates that one or more voice messages are waiting at the message center. The power indicator LED also slowly flashes red when there is an unread voice message. To listen to voice messages: or the Connect soft key if the ‘New Voice Mail’...
Page 7
My Details Name Extension ZAC Login Credentials Login Name (case sensitive) Password Host/URL Assigned Phone ID Support Contact Phone Email Notes...
Page 8
Zultys is the global provider of a true all-in-one unified communications solution. Innovative, reliable and scalable, Zultys IP phone systems integrate voice, video, data and mobility in a single premise based appliance or in the cloud - to optimize collaboration for businesses of all sizes.
