l e x
F
W1062-860
Dresser
W1062-880
Mirror
IMPORTANT NOTES
Carefully remove all the parts from the carton and put them
individually on a soft cloth to prevent damage to the parts.
We have taken great care in the design of this product
and request that you carefully and accurately follow our
assembly instructions to ensure proper set-up.
We recommend at least two adults assemble this product.
A. Mirror
1 piece
D. Bolt
Ø5/16" - 18 UNC x 1-5/8"
8 pieces
G. Hex Key 4mm
1 piece
t e e l
Hardware pack
B.Dresser
1 piece
E. Spring Washer
Ø5/16" x 1.5mm
8 pieces
Anti-tipping
1 set
R
C. Stretcher
2 pieces
F. Flat Washer
Ø5/16" x Ø19mm x 2mm
Not included
Phillips Screwdriver
PH2 x 100mm
8 pieces
Advertisement
Related Manuals for FLEXSTEEL W1062-860
Summary of Contents for FLEXSTEEL W1062-860
- Page 1 W1062-860 Dresser W1062-880 Mirror IMPORTANT NOTES Carefully remove all the parts from the carton and put them individually on a soft cloth to prevent damage to the parts. We have taken great care in the design of this product and request that you carefully and accurately follow our assembly instructions to ensure proper set-up.
- Page 2 l e x t e e l IMPORTANT NOTES Do not tighten up all the screws until each part is properly assembled. Keep the Hex Key in a safe place as you may need to tighten up the bolts in the future. Use a soft cloth between these parts and the floor.
- Page 3 l e x t e e l NOTE: There are 2 hangers assembled on the back of this mirror. If you don't assemble mirror with the Dresser (B), you can attach the Mirror (A) on a wall by the hangers. STEP 3 Attach the Mirror (A) on the Dresser (B), put two Stretcher (C) to back the Mirror and the Dresser, attach all Bolts (D), Spring Washer (E), Flat Washer (F), level two Stretcher then tighten with the...
- Page 4 Avoid the use of harsh chemicals or abrasive cleaning materials. Wipe the table clean with a soft. dry cloth after each use. Wipe up spills quickly with a soft, dry cloth. Flexsteel Industries, Inc. For Parts or Customer Service call toll-free:...
