RainPoint HTV107B User Manual

1-zone wireless water timer with smart hub
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER MANUAL
1-Zone Wireless Water Timer
Free Hotline
US: +1 833-381-5659 (EN)
DE: +49 800-182-0576 (EN, DE)
UK: +44 800-808-5337(EN)
with Smart Hub
Model: HTV107B+HWG009WB
Email: service@rainpointonline.com
Website: www.rainpointonline.com
WhatsApp: +1 626-780-5952

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HTV107B and is the answer not in the manual?

Questions and answers

Related Manuals for RainPoint HTV107B

Summary of Contents for RainPoint HTV107B

  • Page 1 USER MANUAL 1-Zone Wireless Water Timer with Smart Hub Model: HTV107B+HWG009WB Free Hotline Email: service@rainpointonline.com US: +1 833-381-5659 (EN) Website: www.rainpointonline.com DE: +49 800-182-0576 (EN, DE) WhatsApp: +1 626-780-5952 UK: +44 800-808-5337(EN)
  • Page 2 01 - 44 46 - 90...

  • Page 3: Table Of Contents

    CONTENT 1. INTRODUCTION ··············································· 1.1 Contents in the Box ········································· 1.2 Product Overview··········································· 1.3 Specification ··············································· 1.4 Product Features ··········································· 2. INSTALLATION AND CONNECTION ····························· 2.1 Install App On Your Phone ··································· 2.2 Pair the Smart Hub·········································· 2.3 Connect the Wireless Water Timer to Smart Hub ··············· 2.4 Timer Installation ···········································...

  • Page 4: Introduction

    1.INTRODUCTION 1.1 Contents in the Box A. 1 x HTV107B 1-Zone Wireless Water Timer B. 1 x HWG009WB Smart Hub C. 1 x User Manual D. 1 x Quick Setup Guide - 01 -...

  • Page 5: Product Overview

    1.2 Product Overview Inlet Filter 1'' or 3/4'' Timer Water Inlet Button Indicator Battery Compartment Water Outlet Button Power Plug Indicator 1.3 Specification • 1'' or 3/4'' inlet thread and 3/4'' outlet thread. • Operating Water Pressure: 0.5-8 bar (7 - 116 PSI). •...

  • Page 6: Product Features

    • Can pair with smart hub. 2. INSTALLATION AND CONNECTION Setup Video Customer Support Tips: Please scan the QR code or search the link for setup video or customer support to install the device quickly. Setup Video: www.youtube.com/@rainpoint Customer Support: www.rainpointonline.com/pages/support - 03 -...

  • Page 7: Install App On Your Phone

    2.1 Install App On Your Phone 1) Download the RainPoint Home APP Search for ''RainPoint Home APP'' on Google Play or App Store or scan the QR code to download the RainPoint Home APP. 2) Register your RainPoint Home APP account Open your RainPoint Home APP, select Register.

  • Page 8: Pair The Smart Hub

    1) Plug your Smart Hub into an indoor power source near your WiFi router and the outdoor location of your timer. 2) Open the RainPoint Home APP and tap ''Add device '' or ''＋'' to add a new device. Or tap to scan the QR code to add a new device.
  • Page 9 4) Select 2.4GHz WiFi, and enter the password. Tips: If your router is a dual-band router, and you cannot identify the 2.4GHz or 5GHz WiFi, please tap the green words "Common router setting method" to name the 2.4GHz WiFi differently, then you can select it individually. NOTE: The Smart Hub connection only supports 2.4GHz WiFi.
  • Page 10 5) Plug the HWG009WB Smart Hub into an outlet near the router and wait 10 seconds for the device initialization to complete. Press and hold the hub button for 5 seconds until the blue indicator light flashes rapidly(2 times per second). Select "All steps completed"...
  • Page 11 6) Tap "+" to add the smart hub. - 08 -...
  • Page 12 7) Click "Save" for final confirmation after the device is successfully added. 8) After the connection is successful, the color icon of Smart Hub will be displayed on the APP home screen. - 09 -...

  • Page 13: Connect The Wireless Water Timer To Smart Hub

    2.3 Connect the Wireless Water Timer to Smart Hub 1) On the device page of "HWG009WB", press "+" to add the device. 2) Find "HTV107B" or the icon to add the water timer. - 10 -...
  • Page 14 3) Insert 4 new AA alkaline batteries (not included) into the battery compartment of the timer. Restore the battery compartment and make certain it is secured. WARNING: *Please use only alkaline batteries. *Do not mix old and new batteries. *Batteries are to be inserted with the correct polarity. *Exhausted batteries are to be removed from the product.
  • Page 15 4) Press and hold the button of the timer until the light flashes red quickly. Meanwhile, select "Next" on the APP and it will start searching the device automatically. NOTE: The water timer can be paired with a smart hub or Bluetooth. Use a 2.4GHz WiFi to connect the hub and router, then pair the timer with the hub via Bluetooth.
  • Page 16 5) If you fail to connect the timer for the first time, you can hold the button on the timer(or refer to RESET THE DEVICE in the manual) to reset and reconnect it. 6) After successfully connecting and creating plans, the next watering plan time will be displayed on the device page.

  • Page 17: Timer Installation

    2.4 Timer Installation 1) Turn off the garden faucet. 2) Wrap Teflon Tape around the faucet thread. 3) Screw the timer to the garden faucet and make it as vertical as possible to the ground (as shown below) to prevent rainwater from accumulating and leaking into the interior.

  • Page 18: Test Before Use

    2.5 Test Before Use Congratulations, you have completed the connection and installation of the Bluetooth Water Timer. Please test whether the internal valve of your water timer is normal before using 1) Keep the faucet turned off. 2) Press the button of the timer, with a "click"...

  • Page 19: App Features And Functions

    Add Devices have added to You can add multiple program the RainPoint devices on the APP operation schedule to create a smart home of the device. irrigation system. Info On the "Info" screen,...

  • Page 20: Device Home Page

    3.2 Device Home Page Setting Setting Tap the setting icon on the top right corner, you will enter the page for device setting and customize the device watering. Next Plan Time After setting your watering schedules, the device page will show the next plan time. Manual Click on "Manual", and you can choose three manual irrigation modes, namely normal...

  • Page 21: Basic Setting

    3.3 Basic Setting Find the icon in the upper right corner of the APP's home page and enter the "Settings" page. In the basic settings, you can view and manage the basic information of the device. You can also set some advanced settings for specific functions.
  • Page 22 Default Duration Time: Set the default watering duration for manual irrigation mode. - 19 -...

  • Page 23: Plan Setting

    3.4 Plan Setting Select Plan and start to create a new auto-watering plan. Select the "+" button and then start creating a new automatic watering plan. - 20 -...
  • Page 24 2) Set the watering mode and time Press the icon in the upper right corner of the Irrigation "Plan" page and choose the type of irrigation plan you want to set. Normal Irrigation: Set the start time, working duration,frequency and effective date.
  • Page 25 3) Set the watering frequency of your plan.There are five options namely every day, odd dates, even dates, at intervals and custom. After completing the settings, click the button in the upper right corner to save your plan. You will see an overview of the plan displayed in the list.
  • Page 26 Seasonal Adjustment: The adjustment ratio ranges from 10% to 200% to meet the irrigation needs of different seasons. - 23 -...
  • Page 27 Plan Calendar: Click Calendar to check watering plan. Used to view the schedules of all plans. - 24 -...

  • Page 28: Manual Watering

    3.5 Manual Watering Select the "Manual" on the home page, manually open the temporary irrigation plan, and you can set the irrigation duration. Three manual irrigation mode: normal irrigation, interval irrigation, or cycle&soak. - 25 -...
  • Page 29 Note: When you turn on manual watering, if there is a plan running now or there will be a plan starting during your manual water time, the schedule will be skipped for this time. - 26 -...

  • Page 30: Rain Delay Setting

    3.6 Rain Delay Setting After clicking the ＂plan＂ button, you can see the rain delay button. The rain delay is applicable to rainy days or other weather conditions that result in high soil moisture. During the rain delay period, the timer stops watering.

  • Page 31: Event

    3.7 Event Tap "Event" to check the online/offline status and irrigation records. - 28 -...

  • Page 32: Smart Scene

    The Smart Scene function allows you to set schedules for the devices execute automatically according to the set conditions such as device status, time and weather. For example, RAINPOINT HOME APP can obtain weather forecast information of your home location. When you set the condition for immediately delaying the watering plan when it rains, the timer will automatically execute the watering delay when it rains in your local area.
  • Page 33 Steps to Set Smart Scene Create Smart Scene: Go to the "Smart" page, tap "Create Smart Scene" or the "+" icon on the top right corner to add an automation task. Add Condition: Set the conditions that needs to perform，suah as: device status, time, weather.
  • Page 34 How to set automatic rain delay? Tap "Smart" at the bottom of the APP home screen. Tap "Create Smart Scene" or the "+" icon on the top right corner to add an automation task. Tap "Add Condition", then select "Weather" ; locate the city, select "Type Of Weather"...
  • Page 35 Tap "Add Task", select "Control Device" to set up a task about the device operation. Select "HTV107B". Tap "All Plans Delayed" to set the delay days and tap "Confirm". Note: For the task performed by the device, select "Control Device".
  • Page 36 Tap "Create" to save your settings. For example: The picture on the right shows that when the weather in New York is heavy rain, the valve of the HTV107B wireless irrigation timer will be automatically closed, and watering will be delayed for one day.

  • Page 37: Weather Conditions & Devices' Next Plan Time

    3.9 Weather Conditions & Devices' Next Plan Time In the Info screen, you can check for the weather conditions, last water usage and next watering time of each valve of the timer. For the first time, you need to tap "Get Location" and then tap "Save" to save your location information, and the Info screen will display the weather conditions of the day, including temperature, humidity, rain forecast, wind direction and wind speed, as well as the next 7-days' weather conditions.

  • Page 38: Plan Overview & Setting

    3.10 Plan Overview & Setting In the Plan screen, you can check the plan you set of all your connected devices and adjust each plan here conveniently. You can also set the Rain Delay by 24/48/72H easily or turn off the Rain Delay schedule through the button on the right or the icon on the top right corner.

  • Page 39: Home Management

    3.11 Home Management Rainpoint supports adding family members and sharing your home device to achieve co-manage the home irrigation system with your family. 1) Tap Me at the bottom of the APP home screen. 2) Select HOME Management. You can set the current home or create a new home.

  • Page 40: Google Assistant/Alexa Voice Control

    3.12 Google Assistant/Alexa Voice Control How to get third-party control / voice control? If you have a Google Assistant or Amazon Alexa, please tap "Third-party Voice Service" in "Me" page, and then tap "Google Assistant" or "Amazon Alexa" to check the operation guide to connect your water timer to the voice control device.

  • Page 41: Reset The Device

    4. RESET THE DEVICE How to reset the water timer? Step 1. Remove all batteries from the battery compartment. Step 2. After 10 seconds, insert 4 fresh AA alkaline batteries into the compartment of the timer. Step 3. After installing the battery, press and hold the button on the timer without releasing it until the LED indicator quickly flashes (2 times per second), indicating that the water timer is restored to pairing mode.

  • Page 42: The Meaning Of Led Light

    5. THE MEANING OF LED LIGHT LED indicator color of HTV107B Wireless water timer 1) Power-on reset: When powered on, the WHITE and RED lights are on simultaneously for 1 second. 2) Factory reset - -Power-on self-test - Pairing state: RED light on for 2...

  • Page 43: Troubleshooting

    6. TROUBLESHOOTING Issue Possible Cause Advice 1) Low battery. 1) Replace fresh batteries . Can't Turn On 2) Impurities in water 2) Regularly clean the filter /off The Valve inlet. port of impurities to avoid 3) Unstable network or disruptions in use. delayed response.
  • Page 44 Issue Possible Cause Advice 1) Inlet impurities need to be Plan Not 1) There are impurities cleared regularly so that Executed On in the water inlet filter. they do not clog up and Time 2) Rain delay function is interfere with the irrigation programs.

  • Page 45: Warnings

    During the warranty period, we'll replace free of charge the product found to be defective under reasonable use and service as determined solely by RainPoint. To extend and activate your warranty, please email us with your order ID at service@rainpointonline.com and we'll respond within 24 hours.

  • Page 46: Customer Support

    If you find it difficult to set up and want to watch the setting tutorial video, please subscribe to our channel RainPoint on YouTube. Or scan the QR code to visit the RainPoint channel on YouTube quickly. If the app and the user manual don’t have what you’re looking for, and you need some help about our product, please contact us before returning the product to the store and let us know the LOT NO.
  • Page 47 FCC STATEMENT: (FCC ID: 2AWDBTCS024B+2AWDBHWG023WRF) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) This device may not cause harmful interference. 2) This device must accept any interference received, including interference that may cause undesired operation.
  • Page 48 EC REP NAME：VIAJE ELECTRONIC COMPANY LIMITED ADDRESS：E588, 13 ADELAIDE ROAD, DUBLIN, D02 P950, IRELAND Email：VIAJEELE@outlook.com UK REP NAME：SUJE ELECTRONIC COMPANY LIMITED ADDRESS：S211 92a Bury Old Road, Manchester, England, M45 6TQ Email：SUJEELECTRONIC@outlook.com MANUFACTURER/HERSTELLER/FABRICANT/PRODUTTORE/ FABRICANTE: FUJIAN BALDR TECHNOLOGY CO.,LTD ADDRESS/ADRESSE/ADRESSE/INDIRIZZO/DIRECCIÓN: Floor 3, Building 2, No.71 Yangqi Road, Fuwan Industrial Area Cangshan District, Fuzhou, China.
  • Page 50 Scan the QR code to get fast support Need Help? Please contact us US toll free: +1 833-381-5659 (Mon-Fri: 9:30 AM-5:30 PM PST) DE toll free: +49 800-182-0576 (Mon-Fri: 9:00 AM-5:00 PM CET) UK toll free: +44 800-808-5337 (Mon-Fri: 9:00 AM-5:00 PM CET) Email: service@rainpointonline.com WhatsApp: +1 626-780-5952...
