USER MANUAL
RainPoint 4-Zone Digital Water Timer
Email:
service@rainpointonline.com
Free Hotline
US toll free: +1 833-381-5659
DE toll free: +49 800-182-0576
UK toll free: +44 800-808-5337
ModeI No.ITV405
WhatsApp:
+1 626-780-5952

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ITV405 and is the answer not in the manual?

Questions and answers

Related Manuals for RainPoint ITV405

Summary of Contents for RainPoint ITV405

  • Page 1 USER MANUAL RainPoint 4-Zone Digital Water Timer ModeI No.ITV405 Email: WhatsApp: service@rainpointonline.com +1 626-780-5952 Free Hotline US toll free: +1 833-381-5659 DE toll free: +49 800-182-0576 UK toll free: +44 800-808-5337...
  • Page 3 WARM TIPS PLEASE READ BEFORE USING Don't use the water timer when the temperature is below 37.4°F (3℃), and please store the timer indoors to avoid potential freezing damage. The filter traps dirt particles, preventing them from entering the timer and causing clogging. Please clean the filter regularly and replace it if worn.

  • Page 4: What In The Box

    WHAT IN THE BOX RainPoint 4-Zone Water Timer x 1 User Manual x 1 Nut x 1 Brace x 1 Thin shim x 2 Bracket accessory x 1 Small Screw x 2 Thick shim x 1 Big Screw x 1...
  • Page 5 OVERVIEW WATER SCREEN INLET - BUTTON SETTING DIAL + / DELAY BUTTON ZONE BUTTON OK / MANUAL BUTTON BATTERY BOX WATER OUTLETS -02-...

  • Page 6: Specification

    SPECIFICATION ITEM SPECIFICATION Inlet Thread NH(US) for 3/4’’ faucet BSP(EU) for 3/4’’ or 1’’ faucet Working Temperature 37.4℉-122℉(3℃-50℃) Working Water Pressure 0.5bar-8bar(7.25PSI-116PSI) Time Format 12H/24H Rain Delay 24/48/72H Water Frequency 1H-12H, 1Day-7Day Water Duration 1min-4H Manual Watering Time 1min-8H Powered By 4*AA Alkaline batteries (not included) Waterproof Level...
  • Page 7 BUTTON FUNCTION INTRODUCTION Dial Functions Dial Turn the dial to set the watering plans and save the settings Run the timer as scheduled Turn off the timer SET CLOCK Choose 12H/24H time format and set current time START TIME Set the time to start watering HOW LONG Set the duration of watering plan HOW OFTEN...
  • Page 8 INSTALL THE TIMER BRACKET Firstly, before installing timer to faucet, please screw the "bracket accessory" onto the back of the water timer with 2 screws. Parts used in this step: ⑥Bracket accessory x 1, ⑦Small screw x 2. Secondly, use a screw to fix the "brace"...
  • Page 9 At the marked place, drilling a hole on the wall for screwing. At last, fix the other end of the brace to the wall. Parts used in this step: ⑨Big screw x 1. -06-...

  • Page 10: Battery Installation

    BATTERY INSTALLATION Remove the battery compartment at the bottom of the timer. Insert 4 new AA (1.5V) alkaline batteries(not included). Put the battery compartment back to the timer and press firmly to make sure it is completely sealed. NOTE: Install the battery compartment securely after installing the battery to ensure waterproofing.
  • Page 11 INSTALL THE TIMER ON THE FAUCET 1) Turn off the garden faucet. 2) Wrap Teflon Tape around the faucet threads. 3) Screw the timer to the garden faucet and make the display as vertical as possible to the ground to prevent rainwater from accumulating and leaking into the interior.
  • Page 12 ACTIVATE THE TIMER BEFORE USE Please active the valves when getting the timer for the first time, or it's been a long time since your last time to use it. 1) Pulling out the battery box and install 4*AA batteries. 2) Keep the faucet closed and turn the dial to "ON".

  • Page 13: Programming The Timer

    PROGRAMMING THE TIMER This four-zone timer allows you to water four different areas using a single faucet, with each zone customizable for independent start times, irrigation durations, and frequencies. NOTE: Single Zone Operation: The device can only run one zone's program at a time; running multiple zones simultaneously will split and reduce water pressure.

  • Page 14: Step 1: Set Clock

    STEP 1: SET CLOCK Turn the dial to "SET CLOCK". Use the "+" or "-" buttons to select either the 24H or 12H format, then press the "OK" button to confirm and enter the time setting. The hour number flashes. Use the "+" or "-" buttons to adjust the number to your local time.

  • Page 15: Step 2: Start Time

    STEP 2: START TIME Turn the dial to "START TIME". The hour flashes; use the "+" and "-" buttons to set your start time. Use the "OK" button to switch between hours or minutes. Rotate the dial clockwise to save the changes and proceed to the next step.

  • Page 16: Step 3: How Long

    STEP 3: HOW LONG Turn the dial to "HOW LONG". The hour flashes. Use the "+" and "-" buttons to select the watering duration, ranging from 1 minute to 4 hours. Use the "OK" button to confirm and switch between hours or minutes.

  • Page 17: Step 4: How Often

    STEP 4: HOW OFTEN Turn the dial to "HOW OFTEN". Use the "+" and "-" buttons to set your watering frequency. You can choose every 1 to 12 hours or every 1 to 7 days. Rotate the dial clockwise to save the changes and proceed to the next step.
  • Page 18 STEP 5: AUTOMATIC WATERING Next Plan For Zone 1 Next Plan For Zone 2 Next Plan For Zone 3 Next Plan For Zone 4 Turn the dial to "ON". The LCD will display the current time and automatically switch to show program details for each of the four zones. CONGRATULATIONS! Your timer has now been programmed successfully.

  • Page 19: Additional Functions

    ADDITIONAL FUNCTIONS Manual Watering Setting Process Setting Finished Turn the dial to "ON". Press and hold the "MANUAL" button for 3-5 seconds to enter manual watering mode. Press the "ZONE" button to switch zones, use the "+" button to select a zone, and the "-" button to deselect a zone. After making your selections, press the "OK"...
  • Page 20 One Zone Two Of The Three Of The All Of The Only Four Zones Four Zones Four Zones Use the "+" or "-" buttons to adjust the manual watering duration from 1 minute to 8 hours. The default watering duration is 10 minutes. Press and hold the "+" or "-" buttons will quickly increase or decrease the value.
  • Page 21 Note: Manual watering mode always takes priority over automatic watering mode. For a zone, when it's running an automatic watering, a manual watering with later start time conflicts with it, no matter comes from the same or a different zone, then automatic watering would be interruptted and lose its left watering time.

  • Page 22: Rain Delay

    RAIN DELAY 1) When dial at "ON", press and hold "+/DELAY" button for 3 sec to enter into rain delay mode interface. 2) When default time "24H" is flashing, press "+" and "-" buttons to adjust time between 0H, 24H, 48H and 72H. Select 0H means cancel delay mode.
  • Page 23 CLOSE ONE/TWO/THREE OF THE ZONES Setting Process Setting Finished If you want to use one, two or three of the four zones for watering and close the other zone(s), please refer to the following steps to close ZONE 1 and you can close the other zones using the same method.

  • Page 24: Off Mode

    OFF MODE 1) If you wish to stop all watering plans for an extended period, turn the dial to "OFF". 2) The timer will not water automatically while in OFF mode, but timer still saves your setted programs. Once you turn the dial to "ON", the setted programs will work again.
  • Page 25 WORKING IN DIFFERENT PROGRAMS Automatic Watering for 4 Zones Your Timed Watering Plan Real Working Finish Real Start Valve Start Time How Long Watering Time Time Zone 1 7�00 20 minutes 7�00 7�20 Zone 2 7�00 20 minutes 7�20 7�40 6�00 Zone 3 6�00...
  • Page 26 Different Watering Frequency Start How timer works in Next Start time often different frequency time Next start time 8�00 AM 16�00 PM = start time + 8H Next start time 8�00 AM 20�00 PM = start time + 12H Next start time 8�00 AM 8�00 AM 1 Day...
  • Page 27 Manual Watering for 4 Zones Your Manual Watering Plan Real Working Finish Real Start Valve Start Time How Long Watering Time Time Zone 1 9�00 20 minutes 9�00 9�20 Zone 2 9�00 20 minutes 9�20 9�40 20 minutes Zone 3 9�00 9�40 10�00...
  • Page 28 Timed Watering meets Manual Watering Start Valve Mode Really Run Time Long Run automatic Timed watering Zone 1 7�00 20 minutes watering program mode every day from 7�00~7�20 Run manual Manual watering Zone 2 7�10 30 minutes watering program mode only today from 7�10~7�40 Run automatic Timed watering...

  • Page 29: Troubleshooting

    TROUBLESHOOTING Problem Possible Factors Solution may help Condensation Air condenses inside the The fog will disappear on the screen screen due to the as the temperature difference in temperature rises, or leave it stand between inside and for a period of time. outside.
  • Page 30 WARNINGS 1) Intended for outdoor use only, put in the sheltered outdoor will prolong the product lifetime. 2) Using tools to secure the timer can lead to over-tightening and damage to the timer. Please do not use tools to install the timer;...

  • Page 31: Warranty

    To place a warranty request, please email your order lD to service@rainpointonline.com and we'll respond within 24 hours. CUSTOMER SERVICE Still have trouble with setup, please search for "RainPoint" on YouTube for installation videos ! lf the user manual doesn't have what you're looking for or you need some help, please prepare the LOT NO.
  • Page 32 EC REP NAME: VIAJE ELECTRONIC COMPANY LIMITED ADDRESS: E588, 13 ADELAIDE ROAD, DUBLIN, D02 P950, IRELAND Email: VIAJEELE@outlook.com UK REP NAME: SUJE ELECTRONIC COMPANY LIMITED ADDRESS: S211 92a Bury Old Road, Manchester, England, M45 6TQ EMAIL: SUJEELECTRONIC@outlook.com MANUFACTURER/HERSTELLER/FABRICANT/PRODUTTORE/FABRI- CANTE: FUJIAN BALDR TECHNOLOGY CO.,LTD ADDRESS/ADRESSE/ADRESSE/INDIRIZZO/DIRECCIÓN: Floor 3, Building 2, No.71 Yangqi Road, Fuwan Industrial Area Cangshan District, Fuzhou, China.
  • Page 33 Scan the QR code to get fast support Need Help? Please contact us US toll free: +1 833-381-5659 (Mon-Fri: 9:30 AM-5:30 PM PST) DE toll free: +49 800-182-0576 (Mon-Fri: 9:00 AM-5:00 PM CET) UK toll free: +44 800-808-5337 (Mon-Fri: 9:00 AM-5:00 PM CET) Email: service@rainpointonline.com WhatsApp: +1 626-780-5952...
