USER MANUAL
RainPoint 4-Zone Digital Water Timer
ModeI No.ITV405-DLS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ITV405-DLS and is the answer not in the manual?

Questions and answers

Related Manuals for RainPoint ITV405-DLS

Summary of Contents for RainPoint ITV405-DLS

  • Page 1 USER MANUAL RainPoint 4-Zone Digital Water Timer ModeI No.ITV405-DLS...
  • Page 2 RainPoint 4-Zone Water Timer x 1 User Manual x 1 Quick Start Guide x 1 Sealing tap x 2 Brace x 1 Bracket accessory x 1 Thin shim x 2 Thick shim x 1 Small Screw x 2 Middle Screw x 1...

  • Page 3: Important! Please Read

    IMPORTANT! PLEASE READ! PLEASE ACTIVATE THE VALVE BEFORE USE IF YOU ARE USING IT FOR THE FIRST TIME OR AF TER A PERIOD OF IDLENESS TO ENSURE YOU CAN USE IT PROPERL Y: BEFORE FIRST TIME USE, TO ACTIVATE THE TIMER WITH AUTO-TEST MODE, HOLD THE OK BUTTON WITHOUT RELEASING AND THEN INSERT BATTERIES.
  • Page 4 BUTTON FUNCTION INTRODUCTION Dial Functions Run the timer as scheduled Turn off the timer SET CLOCK Set current time START TIME Set the time to start watering HOW LONG Set the duration of watering plan HOW OFTEN Set the frequency of watering plan Button Functions OK/MANUAL Confirm settings or water...

  • Page 5: Installation

    INSTALLATION Screw the supporting part on the back of the water timer. Use the screw to install the bracket accessory onto the supporting part through the hole. Install the timer on the tap and mark a proper position before install the brace. Drill a hole for screwing.

  • Page 6: Set Clock

    FUNCTIONS SET CLOCK 1) Turn the dial to SET CLOCK. 2) Use + and - buttons to set the hours, then press OK to confirm and set minutes. Hold buttons for 3 seconds to quickly adjust. 3) Press OK to make a final confirm after set up minutes and then everything stops blinking.

  • Page 7: Start Time

    FUNCTIONS START TIME 1) Turn the dial to START TIME. 2) Use + and - buttons to set the hour of the watering start time, then press OK to confirm and set minutes. Hold buttons for 3 seconds to quickly adjust. 3) Press OK to make a final confirrn after set up minutes and then everything stops blinking.
  • Page 8 FUNCTIONS HOW LONG 1) Turn the dial to HOW LONG. 2) Use + and - buttons to set the hour of the watering duration, then press OK to confirm and set minutes. Hold buttons for 3 seconds to quickly adjust. 3) Press OK to make a final confirm after set up minutes and then everything stops blinking.

  • Page 9: How Often

    HOW OFTEN 1) Turn the dial to HOW OFTEN. 2) Use + and - buttons to set watering frequency, then press OK to confirm and set minutes. 3) Press OK to make a final confirm and then everything stops blinking. At this time, ONL Y press + and - button to resume set 4) The options of the frequency is every 8 hours, 12 hours, and 1to 7 days.

  • Page 10: More Functions

    MORE FUNCTIONS Manual Watering Mode 1) When the dial stays in ON, press and hold OK button for 3 seconds to enter manual watering model. 2) First, set the zone preferred to manually water. Zone 1 will start blinking. Short press ZONE button to switch zone options and use OK button to select.

  • Page 11: Delay Mode

    MORE FUNCTIONS Delay Mode When the dial stays in ON, press and hold the + button for 3 seconds to enter the delay mode setting. Press + and - button to set the delay time for 0, 24, 48, or 72 hours, and press OK button to confirm.

  • Page 12: Off Mode

    MORE FUNCTIONS Off Mode 1) lf you wish to stop all watering plan for an extended period, turn the dial to "OFF". (Your settings are saved) 2) The timer will not water automatically while in OFF mode. (The screen will display the word OFF in large letters) 3) To start watering automatically again, turn the dial back to "ON"...

  • Page 13: Troubleshooting

    TROUBLE SHOOTING Problem Possible Factors Solution may help Condensation Air condenses inside the The fog will disappear as screen due to the the temperature rises, or on the screen difference in temperature leave it stand for a period between inside and of time.
  • Page 14 1) After screwing the timer onto the faucet, keep the tap closing and turn the dial to the ON position. 2) Hold the "-" button for at least 2 seconds to self-inspection. This will cause all four outlets to open simultaneously to check each valve usually works.

  • Page 15: Warranty

    To place a warranty request, please email your order lD to XXXXXXXXXX and we'll respond within 24 hours. CUSTOMER SERVICE Still have trouble with setup, please search for "RainPoint" on YouTube for installation videos ! lf the user manual doesn't have what you're looking for or you need some help, please prepare the LOT NO.

  • Page 16: Need Help

    Need Help ? Scan the QR code for more help. or Email： support@rainpointonline.com...
