- Page 1 Installation Manual FREESTANDING REFRIGERATION COUNTER-DEPTH RFM-W MODELS zlinekitchen.com...
- Page 2 ZLINE Kitchen and Bath provides Attainable Luxury, where the kitchen and bath of your dreams is never out of reach. Through our unique designs and unparalleled quality, we’re dedicated to providing you an elevated experience in the heart of your home. With an endless selection of...
- Page 3 ZLINE is fueled by a passion for innovation; A relentless pursuit of bringing the highest end luxury designs and professional features into everyone’s homes. Because we continually strive to improve our products, we may change specifications and designs without prior notice.
- Page 4 TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS ....1 BEFORE INSTALLATION ....... 6 INSTALLATION .
-
Page 5: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS This unit's installation and user manuals contain important safety information. Failure to follow these instructions may result in death, fire, or electric shock. WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in WARNING death or serious injury. - Page 6 IMPORTANT SAFETY INSTRUCTIONS • WARNING: Do not damage the unit's refrigerant circuit and sealed cooling system. • WARNING: Do not use electrical or mechanical appliances inside the food storage chambers of the appliance. • WARNING: At the end of its service life, dispose of the refrigerator according to local regulations, due to the use of flammable blowing gas and refrigerant.
- Page 7 IMPORTANT SAFETY INSTRUCTIONS • To avoid food contamination, please read the following instructions and information: • Opening the door for long periods of time can cause a significant increase in the temperatures inside the appliance. • Users should regularly clean surfaces and accessible drainage systems that come in contact with food.
- Page 8 IMPORTANT SAFETY INSTRUCTIONS PLACEMENT OF ITEMS • Do not put flammable, explosive, volatile, or highly corrosive items in the refrigerator or freezer to prevent damage to the product and limit risk of fire or explosion. • Do not place flammable items near the refrigerator to limit risk of fire or explosion. •...
-
Page 9: Warnings For Disposal
IMPORTANT SAFETY INSTRUCTIONS WARNINGS FOR DISPOSAL Both the refrigerant (R600a isobutane) and cyclopentane foaming material used for this appliance are flammable. Therefore, when the appliance reaches the end of its service life, it should be kept away from any fire source and be disposed of according to local regulations so as to prevent damage to the environment or other harm. -
Page 10: Before Installation
BEFORE INSTALLATION WARNING ELECTRICAL CONNECTION • Do not pull on the power cord unplugging the refrigerator. Firmly grasp the plug and pull out it from the socket directly. • To ensure safe use, do not damage the power cord or use the power cord when it is damaged or worn. - Page 11 BEFORE INSTALLATION STARTING UP THE APPLIANCE • If the product has been transported horizontally, you must wait a minimum of 4 hours after standing it upright before plugging it in. • Before putting in any fresh or frozen food, the refrigerator should run for 2-3 hours or for over 4 hours in the summer when ambient temperatures are high.
- Page 12 BEFORE INSTALLATION PRODUCT AND CUTOUT SPECIFICATIONS 35 3/4" (908 mm) 69 1 1/16" (1770 mm) 28 13/16" 30 15/16" (732 mm) (789 mm) 35 3/4" (908 mm) 24 1/4" (616 mm) 42 3/16" 43 3/16" (1072 mm) (1097 mm) 135° 62 1 1/16"...
-
Page 13: Installation
24" (610 mm) cabinet depth. This is common for counter-depth refrigerator models to ensure doors can fully open. • Since kitchen layouts vary, ZLINE recommends consulting with a professional installer 2.2 Levelling feet to verify cabinet dimensions and electrical connections before installing the appliance. - Page 14 INSTALLATION 2.3 Levelling door LEVELING DOOR List of tools to be provided by the user Precautions before operation: plier • Disconnect the refrigerator from power before user maintenance. • Before adjusting the door, take precautions to prevent any personal injury. •...
-
Page 15: Installing Door Handles
INSTALLATION INSTALLING DOOR HANDLES Refrigerator Refrigerator Precautions should be taken to prevent handles from falling and causing door handle door handle personal injury. CAUTION Handle screw Handle screw Refrigerator door handle Hole for Hole for door anchor door anchor Handle screw Hole for door anchor 1. - Page 16 INSTALLATION ADJUSTMENT OF SHELVES • The shelves can be adjusted to multiple heights. • Adjust the shelves by following the arrows as shown in the diagram. Raise it upward first and then take it out by tilting it upward. During installation, put the upper end of the fixed leg into one of the upper slots on the shelf support bracket first, then put the lower end of the fixed leg into the slot below the top leg.
-
Page 17: Installing The Water Filter
5. When replacing the filter, the method of removing the old filter is the same as that of removing the water filter bypass plug in step 2. NOTE: When installing a new filter, drain 2–3 gallons of water from the dispenser to rid it of any debris. Only use a ZLINE filter. Otherwise, issues may occur. -
Page 18: Installing The Water Line
INSTALLATION INSTALLING THE WATER LINE WARNING WARNING: Risk of electric shock and damage to the appliance. Disconnect the appliance from the electrical power source before performing any work on the water connection. Only a qualified technician may connect the appliance to the water supply in accordance with plumbing and relevant water utility company regulations. -
Page 19: Connecting The Water Line
INSTALLATION CONNECTING THE WATER LINE NOTE: Water line installation kits are available at a local hardware store. 1. Turn off the water source, and then attach the new 1/4" stainless steel braided line in the kit to the 1/4" connector to the main water shut-off valve located at the wall behind the refrigerator. -
Page 20: Warranty
TERMS ZLINE warranties apply only to the original purchaser of a ZLINE product installed for normal residential use. This is defined as a single-family, residential dwelling in a non-commercial setting. Any warranty claim stemming from installation, operation, or any other use within a commercial setting is not covered under this limited warranty. - Page 21 If a product qualifies within the service window provided under these warranty terms, and ZLINE is unable to repair the product or a defective part of the product after a reasonable number of attempts, ZLINE reserves the right to offer to replace the defective part or the...
-
Page 22: Serial Number Location
Always check the ZLINE website for the most up-to-date version of its product manuals: www.zlinekitchen.com/pages/manuals. Do not install or operate any ZLINE product if it has missing or broken parts or if it arrives damaged due to shipping. If ZLINE products arrive damaged, contact ZLINE Customer Experience at 1-614-777-5004 for help. - Page 23 Customer Experience Portal. Scan the QR code to view the most up-to-date version of our Installation Manual and User Manual. Need to purchase a part or accessory for your ZLINE product? Visit www.zlineparts.com, ZLINE's official parts distribution partner.
- Page 24 2.1.3 zlinekitchen.com 1-614-777-5004 contact@zlinekitchen.com...
