INSTALLATION AND USE MANUAL
Installation and use manual model MODULAR rev. 1.1 June 2025 page 1 of 20
MODULAR
200
MODULAR
300
MODULAR
400
MODULAR
500
MODULAR
800
ENGLISH MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MODULAR 500 and is the answer not in the manual?

Questions and answers

Summary of Contents for UR FOG MODULAR 500

  • Page 1 INSTALLATION AND USE MANUAL MODULAR MODULAR MODULAR MODULAR MODULAR ENGLISH MANUAL Installation and use manual model MODULAR rev. 1.1 June 2025 page 1 of 20...
  • Page 2: Table Of Contents

    WARNING! All UR FOG fogging systems should only be used with UR FOG-branded fluids. It is strictly forbidden to use any fluid not previously authorized in writing by UR FOG srl. SUMMARY Package contents page 2 Product presentation page 3...
  • Page 3: Product Presentation

    - Cheap: the lowest power consumption among fogging systems. CONDITIONS OF USE AND WARNINGS The fog generated by UR Fog does not create problems or injuries to people during a short stay in a room filled with fog, if the system is used according to the manufacturer’s recommendations.
  • Page 4: Installation Tips To Install Fogging Systems

    13. Never direct the fog jet towards an object or a wall less than 2 meters away and if possible increase the suggested minimum distance. Thanks to the power of the jet, UR Fog reaches and exceeds more than 10 meters away in the first 3 seconds from the point where the machine is installed.
  • Page 5: Technical Specifications And Battery Endurance/Backup

    TECHNICAL SPECIFICATIONS AND BATTERY ENDURANCE/BACKUP * Industrial standard as from MODULAR MODULAR MODULAR MODULAR MODULAR other manufacturers Weight without bag 7,5 Kg 8 Kg 8,5 Kg 8,5 Kg 9,5 Kg Max fog emission in a single shot 200 m 300 m 400 m 500 m 800 m...
  • Page 6: Electrical Power Supply

    ELECTRICAL POWER SUPPLY The 230V input provides primary power to the heat exchanger and, by the use of a switching power supply, to the electronic board and the pump. The heat exchanger’s working time without mains power ensures proper functioning for a certain period of time, usually around one hour, even in complete absence of mains power.
  • Page 7: Power Supply Connection

    POWER SUPPLY CONNECTION 12V Power supply connection 230V Power supply connection 230V Mains power Ground connection Battery slot (battery not included) - The battery is essential for the safe use of the device, it is recharged by the board’s circuitery. - The predisposition 2A 12V lead-acid battery is lodged below the exchanger.
  • Page 8 OUTPUT Power DC12V 1-2 Output DC12V (max 200 mA) for electrical connection of local devices connected to the board. It can be used to power a local PIR or a remote receiver. It is recommended not to overload the output. OUTPUTS 3 ARD/SHP - Reports the ARMING status (W2 open), or is active when TRIG is in progress (W2 close).
  • Page 9: Connection Examples

    CONNECTION EXAMPLES The diagrams and examples below are intended only for a “better understanding” of the operation of the inputs/outputs. None of the diagrams below represents the “single scheme to perform” as, in respect of the reference standard EN 50131-8:2019, there are precise indications and only using all inputs and outputs on the PCB it is possible to abide by the standard.
  • Page 10 B - MODULAR inputs connected with a clean contact (relays) alarm panel outputs RELAY ARM ARM OUT RELAY TRIG TRIG OUT The ON/OFF output of this alarm panel is an open relay when panel is OFF that continuosly keep close for all the time the alarm panel is monitoring.
  • Page 11: Shooting Time Setting

    SHOOTING TIME SETTING AND FOG FLOW DIRECTION RESET SET TIME To set the shooting time, after opening the front panel, you must CLOSE the jumper W1 in SET position then, holding down the button S1, the 3 LEDs on the front will flash and each flash is equivalent to one second fog emission. If you press the button again, the shooting time is not added to the one previously set, but will restart from zero.
  • Page 12 150 (450*) 300 (900*) 75 (225*) 200 (600*) 400 (1200*) 100 (300*) 250 (750*) SHOOTING TABLE MODULAR 500 (max 48 sec.) m³ to protect Seconds of emission m³ to protect Seconds of emission m³ to protect Seconds of emission 50 (150*)
  • Page 13: Fluid Bag Installation, Exchange And Reset

    INSTALLATION, EXCHANGE AND BAG RESET Insert the bag in place as show in picture. To reset the unit the jumper W1 must be open, as shown in picture. Insert a new bag and push metal connector till a “click” is heard. Metal plug...
  • Page 14: Front Leds Meaning

    Metal plug Press button S1 FRONT LEDS MEANING RED LED (right) EMPTY ON: Error (Empty bag or low fluid , Mains power off/Battery low) or Fault RESERVE OFF: No error condition. BLU LED (center) FAULT ON: Unit is armed and ready to shoot (with green led ON). OFF: Unit is disarmed, shot not possible.
  • Page 15: Maintenance

    MAINTENANCE UR FOG fogging systems don’t need special maintance , nevertheless is suggested a periodical check to the following parts by skilled operators: 1) Verify battery and power supply status. 2) Verify screws are firmly closed. 3) Verify the output nozzle is not damaged and without anyting inside.
  • Page 16: Defects Possible Solution

    DEFECTS POSSIBLE SOLUTION DEFECT FOUND POSSIBLE CAUSE POSSIBLE SOLUTION Small fog flow coming out All products are 100% This condition is normal and can happen on first from nozzle and a small ammount installation, it will completely disappear in a while of liquid could be still in when the unit will become completely hot.
  • Page 17 DEFECT FOUND POSSIBLE CAUSE POSSIBLE SOLUTION Bag changed ,reset needed Follow instructions Paragraph 13 Red front led ON Empty bag- replace it following instructions on Paragraph 13 Green front led is OFF Unit still warming , wait max 120min. with the unit connected to the mains power Unit ARMED Wires error...
  • Page 18: Warranty And Conditions Of Use

    WARRANTY The warranty of UR Fog is two years and is handled directly from the dealer or authorized installer, so please contact your supplier to take advantage of warranty with the copy of the purchase document that contains the serial number of the machine.
  • Page 19: Maintenance And Operations

    MAINTENANCE DATE BATTERY EXCHANGE BAG EXCHANGE SIGNATURE It is mandatory to fill out this table in accordance with the security rules...
  • Page 20 N.B. Ask for the PDF module writing to: support@urfog.com UR FOG S.r.l. Via Toscana 38 - 10099 San Mauro T.se (Turin) Italy...
