UNIPOWER
UP-2210R/P
UP-2210R/P Hardware installation and configuration manual
English version 25.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UP-2210R and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Unipower UP-2210R

Summary of Contents for Unipower UP-2210R

  • Page 1 UNIPOWER UP-2210R/P UP-2210R/P Hardware installation and configuration manual English version 25.0...

  • Page 2: Introduction

    PQ Secure is the result of targeted efforts by Unipower and our customers to create an advanced, user-friendly and reliable power quality monitoring system.

  • Page 3: Table Of Contents

    UNIPOWER UP-2210R/P Hardware installation and configuration manual INTRODUCTION ................................2 SAFETY INFORMATION ............................6 ..........................6 NSTALLATION CONDITIONS ........................... 6 NSTALLING THE INSTRUMENT ..............................7 OWER SUPPLY ............................7 RODUCT END OF LIFE UNDERTAKING AND WARRANTY ........................7 ................................7 IABILITY ..............................
  • Page 4 UNIPOWER UP-2210R/P Hardware installation and configuration manual ................................ 48 THERNET GSM/3G ..........................48 IRELESS ROUTER RS-485................................51 GDW-11 GSM/GPRS- RS-485 ......52 SING MULTIPLE METERS WITH ESTERMO MODEM AND ................................54 ODBUS 7.5.1 Binary registers 16 bit signed ........................54 7.5.2...
  • Page 5 UNIPOWER UP-2210R/P Hardware installation and configuration manual 10.6.3 Oscilloscope tab ........................... 101 ............................102 OMMUNICATION SETTINGS 10.6.4 Ethernet ..............................102 10.6.5 DHCP and SmartCom .......................... 103 10.6.6 IEC 61850............................. 103 10.6.7 TLS Encryption ............................. 104 10.7 ............................105 OWNLOAD DATA 10.8...

  • Page 6: Safety Information

    Only authorized and well-informed personnel must use the instrument, because normal use of the instrument involves dangerous high voltages, which can cause death or serious injury. Only trained Unipower personnel may carry out any intervention in the instrument. Installation conditions Make sure the area in which you plan to install the meter is clean, dry and dust-free.

  • Page 7: Power Supply

    In the event of a claim for repair under the warranty, Unipower AB is entitled to choose whether to repair or to replace the product. The purchaser's claim under the warranty must be made in writing to Unipower AB before the warranty expires.

  • Page 8: Patent

    UNIPOWER UP-2210R/P Hardware installation and configuration manual obligations above, Unipower AB is not bound by other warranties or obligations unless these have been agreed between the parties or are imposed by law. Patent Unipower AB´s products are covered by one or more of the following patents/patent applications: Swedish Pat.

  • Page 9: Components Of The Pq Secure System

    UNIPOWER UP-2210R/P Hardware installation and configuration manual COMPONENTS OF THE PQ SECURE SYSTEM PQ Secure system is a collective name for a permanently installed measuring system for the continuous monitoring of power quality in the electricity network. It consists of three parts - the measuring device, communication equipment and a computer for storing the measured data.

  • Page 10: Measuring Device

    UNIPOWER UP-2210R/P Hardware installation and configuration manual Measuring device The measuring device UP-2210 is an advanced, 3-phase power quality and disturbance analyser designed for permanent installation. There are different models, UP-2210 wall mount and UP- 2210R/P rack/panel mount. UP-2210 Rack and panel mount...

  • Page 11: Portable Meter Unilyzer 900 / Unilyzer 900C

    UNIPOWER UP-2210R/P Hardware installation and configuration manual Portable meter Unilyzer 900 / Unilyzer 900c The meters Unilyzer 9900/900c are portable power quality and disturbance analysers. They can also be integrated in a PQ Secure system together with permanently installed meters.

  • Page 12: Server Performance

    Server performance 3.4.1 The required server performance depends on which PQ Secure application is being used. Unipower or our representatives can help you with choosing the right computer/server solution. Data growth in the database is approximate 29 MB to 75 MB per Meter per year (MY) depending on configuration.

  • Page 13: Installing Permanent Meter Up-2210R/P

    We recommend making the connections to the measure core and only in exceptional cases directly to the relay cores. Location and fitting UP-2210R is designed to be installed in standard 19” rack. UP-2210P is designed to be installed in a panel. Figure 5...
  • Page 14 Figure 6 The picture above shows a few UP-2210R installed in typical a substation (130/10 kV). The UP-2210R can be used with all standard connection options and can measure both line-to- neutral and line-to-line voltages. The picture also shows a sub-station display that is used for real-time monitoring and configuration of all the units in the sub-station.

  • Page 15: Installation Diagram

    UP-2210R/P Hardware installation and configuration manual Installation diagram The UP-2210R meter can be mounted on a rack/panel. For mounting dimensions, refer to the drawing below. It is important to install the meter as close as possible to the measured object. When installing the unit, also bear in mind the type of communication facility you will be using, for example close to the window for a GSM modem, near a telephone outlet for an external modem, etc.
  • Page 16 UNIPOWER UP-2210R/P Hardware installation and configuration manual Figure 8 A. Digital outputs. Optional. The digital outputs are relays, which can be used for alarms and for controlling other equipment. The meter can also be programmed to activate the digital outputs under certain conditions, for example when a transient of a certain level is recorded.
  • Page 17 If there is no station/internal battery backup, Unipower recommends that you connect the instrument to an external UPS type battery source in order to prevent power failure disturbances. Protect the feeding cable with a 2A fuse.

  • Page 18: Connection Alternatives

    I. Ground terminal. Always connect this point to protective earth. J. Power/status LED. Green indicates power on and all ok. Red indicates failing UST (Unit Self Test). Contact your Unipower representative if you see red colour. K. Sync LED. When blinking it indicates that time/clock is synchronised with GPS.

  • Page 19: Phase With 4 Wire Measurement With Direct Voltage And 3 Ct's

    UNIPOWER UP-2210R/P Hardware installation and configuration manual 3 phase with 4 wire measurement with direct voltage and 3 CT’s 4.4.1 Figure 9 The above wiring diagram is used for 3-phase measurement in low voltage networks. The voltage channel of the unit is connected directly to the electricity network for measuring line-to-neutral voltage (230 V) and therefore do not require an instrument transformer (PT).

  • Page 20: Phase With 4 Wire Measurement With Direct Voltage And 2 Ct's

    UNIPOWER UP-2210R/P Hardware installation and configuration manual 3 phase with 4 wire measurement with direct voltage and 2 CT’s 4.4.2 Figure 10 The above wiring diagram is used for 3-phase measurement in low voltage networks. The voltage channel of the unit is connected directly to the electricity network for measuring line-to-neutral voltage (230 V) and therefore do not require an instrument transformer (PT).

  • Page 21: Phase With 4 Wire Measurement With 3 Ct's And 3 Pt's

    UNIPOWER UP-2210R/P Hardware installation and configuration manual 3 phase with 4 wire measurement with 3 CT’s and 3 PT’s 4.4.3 Figure 11 The above wiring diagram is used for three-phase measurement in public distribution networks with 3 CT´s and 3 PT’s. The voltage channels of the unit are connected to PT’s (normally 63 V AC secondary), for supplying line-to-earth voltages, and current channels are connected to CT´s...

  • Page 22: Phase With 4 Wire Measurement With 2 Ct's And 3 Pt's

    UNIPOWER UP-2210R/P Hardware installation and configuration manual 3 phase with 4 Wire measurement with 2 CT’s and 3 PT’s 4.4.4 Figure 12 The above wiring diagram is used for three-phase measurement in in public distribution networks with 2 CT´s and 3 PT’s. The voltage channels of the unit are connected to PT’s (normally 63 V AC secondary to earth), for supplying line-to-line voltages, and current channels are connected to CT´s...

  • Page 23: Phase With 4 Wire Measurement With 3 Ct's And 2 Pt's

    UNIPOWER UP-2210R/P Hardware installation and configuration manual 3 phase with 4 wire measurement with 3 CT’s and 2 PT’s 4.4.5 Figure 13 The above wiring diagram is used for three-phase measurement in in public distribution networks with 3 CT´s and 2 PT’s. The voltage channels of the unit are connected to PT’s (normally 63 V AC secondary to earth), for supplying line-to-line voltages, and current channels are connected to CT´s...

  • Page 24: 3-Phase 4 Wire Measurement With 2 Ct's And 2 Pt's

    UNIPOWER UP-2210R/P Hardware installation and configuration manual 3-phase 4 wire measurement with 2 CT’s and 2 PT’s 4.4.6 Figure 14 The above wiring diagram is used for three-phase measurement in public distribution networks with 2 CT´s and 2 PT’s. The voltage channels of the unit are connected to PT’s (normally 63 V AC secondary to earth), for supplying line-to-line voltages, and current channels are connected to CT´s...

  • Page 25: 1-Phase Measurement With Direct Voltage And One Ct (Line-To-Neutral Voltage)

    UNIPOWER UP-2210R/P Hardware installation and configuration manual 1-phase measurement with direct voltage and one CT (Line-to-neutral voltage) 4.4.7 Figure 15 The above wiring diagram is used for single-phase measurement in low voltage networks. The voltage channel of the unit is connected directly to the public distribution networks for measuring line-to-neutral voltage (230 V) and therefore do not require an instrument transformer (PT).

  • Page 26: 1-Phase Measurement With One Pt And One Ct

    UNIPOWER UP-2210R/P Hardware installation and configuration manual 1-phase measurement with one PT and one CT 4.4.8 Figure 16 The above wiring diagram is used for single-phase measurement in public distribution networks with one CT and one PT. The voltage channel of the unit is connected to PT for measuring line-to-neutral voltage.

  • Page 27: Hv 3-Phase Measurement With 2 Ct's And 2 Pt's (Line-To-Line Voltages)

    UNIPOWER UP-2210R/P Hardware installation and configuration manual HV 3-phase measurement with 2 CT’s and 2 PT’s (Line-to-line voltages) 4.4.9 Figure 17 The above wiring diagram is used for three-phase measurement in public distribution networks with 2 CT´s and 2 PT’s. The voltage channels of the unit are connected to PT’s for measuring line-to-line.

  • Page 28: Hv 3-Phase Measurement With 3 Ct's And 2 Pt's (Line-To-Line Voltages)

    UNIPOWER UP-2210R/P Hardware installation and configuration manual HV 3-phase measurement with 3 CT’s and 2 PT’s (Line-to-line voltages) 4.4.10 Figure 18 The above wiring diagram is used for three-phase measurement in public distribution networks with 3 CT´s and 2 PT’s. The voltage channels of the unit are connected to PT’s (normally 110 V AC secondary), for supplying line-to-line voltages, and current channels are connected to CT’s (normally...

  • Page 29: Hv 3-Phase Measurement With 2 Ct's And 3 Pt's (Line-To-Line Voltages)

    UNIPOWER UP-2210R/P Hardware installation and configuration manual HV 3-phase measurement with 2 CT’s and 3 PT’s (Line-to-line voltages) 4.4.11 Figure 19 The above wiring diagram is used for three-phase measurement in in public distribution networks with 2 CT’s and 3 PT’s. The voltage channels of the unit are connected to the PT’s (normally 63 V AC secondary to earth), for supplying line-to-line voltages, and current channels are connected to the CT´s (normally 1 - 5 A AC secondary).

  • Page 30: Hv 3-Phase Measurement With 3 Ct's And 3 Pt's (Line-To-Line Voltages)

    UNIPOWER UP-2210R/P Hardware installation and configuration manual HV 3-phase measurement with 3 CT’s and 3 PT’s (Line-to-line voltages) 4.4.12 Figure 20 The above wiring diagram is used for three-phase measurement in public distribution networks with 3 CT´s and 3 PT’s. The voltage channels of the unit are connected to PT’s (normally 63 V AC secondary to earth), for supplying line-to-line voltages, and current channels are connected to CT´s...

  • Page 31: 3-Phase Measurement With Direct Voltage, 2 Ct´s (Line-To-Neutral)

    UNIPOWER UP-2210R/P Hardware installation and configuration manual 3-phase measurement with direct voltage, 2 CT´s (Line-to-neutral) 4.4.13 Figure 21 The above wiring diagram is used for 3-phase measurement in low voltage networks. The voltage channel of the unit is connected directly to the electricity network for measuring line-to-neutral voltage (230 V) and therefore do not require an instrument transformer (PT).

  • Page 32: 3-Phase Measurement With Direct Voltage, 3 Ct´s And Neutral (Line-To-Neutral Voltages)

    UNIPOWER UP-2210R/P Hardware installation and configuration manual 3-phase measurement with direct voltage, 3 CT´s and neutral (Line-to-neutral 4.4.14 voltages) Figure 22 The above wiring diagram is used for 3-phase measurement in low voltage networks. The voltage channel of the unit is connected directly to the electricity network for measuring line-to-neutral voltage (230 V) and therefore do not require an instrument transformer (PT).

  • Page 33: Split Phase 2Ct 2Pt

    UNIPOWER UP-2210R/P Hardware installation and configuration manual Split Phase 2CT 2PT 4.4.15 Figure 23 The above wiring diagram is used for Channel: Measured object: Channel: Measured object: (Neutral)

  • Page 34: Sp 2Ct Dv

    UNIPOWER UP-2210R/P Hardware installation and configuration manual SP 2CT DV 4.4.16 Figure 24 The above wiring diagram is used for Channel: Measured object: Channel: Measured object: (Neutral)

  • Page 35: Connecting Sense Voltage Inputs

    UNIPOWER UP-2210R/P Hardware installation and configuration manual Connecting SENSE voltage inputs 4.4.17 The above wiring diagram is used for three-phase measurement in public distribution networks with 3 CT´s and 3 PT’s together with SENSE calibration. The voltage channels of the unit are connected to high bandwidth PT’s (around 65 V AC secondary to earth).
  • Page 36 UNIPOWER UP-2210R/P Hardware installation and configuration manual When using SENSE calibration, the configuration for the VT/PT apply to the SENSE inputs. In the example above the voltage ratio should be set to the reference VT/PT for example the CVT and not the high bandwidth VT/PT.

  • Page 37: Hv/Mv Earth Fault Monitoring Via Channel U4

    UNIPOWER UP-2210R/P Hardware installation and configuration manual HV/MV Earth fault monitoring via channel U4 4.4.18 In high impedance grounded MV networks the voltage in the transformer’s ground point is of interest to study. Earth faults and emerging earth faults can be detected by analyzing the ground point voltage.

  • Page 38: Vector Graph For Correct Connection

    UNIPOWER UP-2210R/P Hardware installation and configuration manual Vector graph for correct connection To check and certify a correct connection of the measuring device you can use the program PQ Online. In PQ Online, under “Real time Analysis” a tab called “Vector”. This tool is a good controller to verify that you have plugged in phases correctly and turned the ammeters in the right direction.

  • Page 39: Recommended Practices

    UNIPOWER UP-2210R/P Hardware installation and configuration manual Recommended practices Below, recommendations are given for a number of common network situations. Impedance grounded 3-wire systems 4.6.1 Typical examples: MV distribution networks in a 3-phase, 3-wire network without neutral conductor impedance grounding (Petersen coil with/without resistor) is common. Figure 27 shows the secondary side of the transformer and the grounding impedance.

  • Page 40: Isolated (Ungrounded) 3-Wire Systems

    Digital inputs and outputs The UP-2210R can be equipped with 16 digital inputs and 3 relay outputs. They can be used to record external events to the PQ Secure system or send signals to other equipment in case of a sag/ swell or transient.

  • Page 41: Connection Of Digital Inputs

    The UP-2210R is activated on positive flanks, which means that the trig takes place when the signal changes from a zero value to the upper limit. If you have signals with normally high values, active, you can via the configuration in PQ Online invert the signal to trigger events when the signal drops to zero.

  • Page 42: Energy Pulses S0 Interface

    UNIPOWER UP-2210R/P Hardware installation and configuration manual Energy pulses S0 interface 4.7.3 The S0 interface (DIN 43864) is an optical, open collector output to register energy pulses. It can be connected either way described by the below pictures: The number of pulses per kWh of energy measured by the meter is stated on the front of the meter.

  • Page 43: Replaceable Power Supply And Micro Sd Card

    UNIPOWER UP-2210R/P Hardware installation and configuration manual Replaceable power supply and Micro SD card The power supply and the Micro SD card of the unit are replaceable parts. If any of these are in need of a replacement, first disconnect the power connector then unscrew the two screws on the power supply part and gently pull it out.

  • Page 44: Substation Display

    UNIPOWER UP-2210R/P Hardware installation and configuration manual To replace the Micro SD card, look inside the unit on the motherboard and find the existing Micro SD card, click on it to get it out and replace it with the new one, then mount the power supply unit back into the meter.

  • Page 45: Pq Online Substation Display Configuration

    UNIPOWER UP-2210R/P Hardware installation and configuration manual Figure 31 From the substation display realtime values can be viewed and meter configuraton can be done. For physical installation measures please see separate document. Figure 32 In the substation display PQ Online 3 is installed (see section 9.3) and configured for autostart operation.
  • Page 46 UNIPOWER UP-2210R/P Hardware installation and configuration manual 1. Create a connection using either Ethernet or USB. Figure 33 2. Repeat for each meter in the substation. 3. Launch the Panel display setup Figure 34 4. Select the previously saved configuration from the Connection drop down list and select which starting view to show when PQ Online 3 opens.

  • Page 47: Display

    UP-2210R/P Hardware installation and configuration manual Display On the front side of the UP-2210R there is a colour touch display that can show voltage and current values in real-time. Several parameters can be shown, such as, Voltage values, current values, harmonics, flicker, power frequency etc.

  • Page 48: Installing Communication Equipment

    1000BaseT/100BaseT-switch or converter between the network and the UP-2210R. The UP-2210R has a standard RJ-45 connector and is connected to the network using a standard patch cable. The meter must be given a unique IP-address. Consult with your network administrator, which IP-address you can use.
  • Page 49 UNIPOWER UP-2210R/P Hardware installation and configuration manual Figure 37 Note how UDP 16427 is routed to UDP 16421 IP 192.168.1.7. The meter given the IP 192.168.1.7 will respond to communication on UDP port 16427 to the router’s (actually the SIM card’s) public...
  • Page 50 UNIPOWER UP-2210R/P Hardware installation and configuration manual shows UP-2210R connected to a 3G router: Standard switch Figure 38 GPRS or 3G router The standard switch is only needed when there are multiple meters that needs internet access.
  • Page 51 UNIPOWER UP-2210R/P Hardware installation and configuration manual RS-485 RS-485 is a serial communication that can be used together with some meters. It is similar to the common RS-232 but works with larger distances. Another advantage is that you can connect multiple meters to the same RS-485 cable (multi drop).

  • Page 52: Using Multiple Meters With Westermo Gdw-11 Gsm/Gprs- Modem And Rs-485

    UNIPOWER UP-2210R/P Hardware installation and configuration manual Using multiple meters with Westermo GDW-11 GSM/GPRS-modem and RS- The Westermo GDW-11 is an example of an industry GSM/GPRS modem with both RS-485. The RS-485 is an easy solution if you want to connect one or several meters to one wireless modem/SIM card.
  • Page 53 UNIPOWER UP-2210R/P Hardware installation and configuration manual...

  • Page 54: Modbus

    UNIPOWER UP-2210R/P Hardware installation and configuration manual If you want to use the modem with RS-232 communication, change S1-4 from on to off. Power the modem off-on to make changes active. Modbus Modbus in the unit can communicate via RS232, RS485 or TCP/IP The modbus address is 10dec for every UP2210.
  • Page 55 UNIPOWER UP-2210R/P Hardware installation and configuration manual To read voltage U1, the modbus command should be 0A,03,00,0A,00,01,A5,73 and the response will be 0A,03,02,08,FF,5A,05 for 230.3V 8x256+255->2303. RMS Voltage Reg Name Unit Scale Range Comment Voltage phase 1 0-3276.8 Voltage phase 2 0-3276.8...
  • Page 56 UNIPOWER UP-2210R/P Hardware installation and configuration manual Displacement factor phase 3 0.01 0-1.0 Displacement factor tot 1-3 0.01 0-1.0 Digital inputs Name Unit Scale Range Comment 1000 0-15 digital inputs 1001 16-32 digital inputs...

  • Page 57: Floating-Point Registers

    UNIPOWER UP-2210R/P Hardware installation and configuration manual Floating-Point registers 7.5.2 The floating point registers applies for all UP2210 U901/U902 year model 2011 and later. To read voltage U1, the modbus command should be [14][03][08][00][00][02][C4][AE] and the response will be [14][03][04][47][F1][20][00][E2][75] for 123456.000 The float format is “Float inverse”.
  • Page 58 UNIPOWER UP-2210R/P Hardware installation and configuration manual RMS Current Name Unit Comment 2088 Current phase 1 2090 Current phase 2 2092 Current phase 3 2094 Current 4 2096 Current sum 1-4 Active Power Name Unit Comment 2128 Active power phase 1...
  • Page 59 UNIPOWER UP-2210R/P Hardware installation and configuration manual Voltage unbalance Name Unit Comment 2448 Negative sequence/ Positive sequence 2450 Positive sequence 2452 Negative sequence 2454 Zero sequence Current unbalance Name Unit Comment 2456 Negative sequence/ Positive sequence 2458 Positive sequence 2460...
  • Page 60 UNIPOWER UP-2210R/P Hardware installation and configuration manual Current harmonic THD Name Unit Comment 2524 THD Current phase 1 THD fundamental 2526 THD Current phase 2 2528 THD Current phase 3 2530 THD Current I4 Current harmonic TDD Name Unit Comment...
  • Page 61 UNIPOWER UP-2210R/P Hardware installation and configuration manual Individual Current Phase Angle Name Unit Comment 3848-3946 Current harmonic phase 1 Degree 3848-> Fund phae, 3850->H2 phase … 3948-4046 Current harmonic phase 2 Degree +-180 degree in relation to U1 fundamental 4048-4146...

  • Page 62: Gps Clock Synchronisation Module

    The GPS clock synchronization module can be used with the Unipower UP-2210. In order for the synchronization to work, the units must be equipped with the appropriate software as well as the necessary peripheral hardware.

  • Page 63: Installation

    UNIPOWER UP-2210R/P Hardware installation and configuration manual INSTALLATION The GPS adapter connects to the UP-2210 via the Time/TTL input. The following sections will describe the connection method in detail. GPS communication configuration 8.1.1 Connect to the unit with PQ Online and go to the Tools-Status Tab. Select the appropriate connection method for the GPS (Time/TTL), and set the baud rate according to the baud rate configured in the GPS (default values are normally 19200, but can also be 4800).
  • Page 64 UNIPOWER UP-2210R/P Hardware installation and configuration manual If the GPS can’t send reliable time information to the meter (it loses contact with satellites, for instance) the meter will wait for 1 hour before starting to accept time setting from other sources, like PQ Schedule.

  • Page 65: Gps Connection Instruction For Up2210R

    UP2210R measurement instruments. To perform this installation, you will need:  A Garmin GPS16x-LVS antenna. Unipower article no: 22-4042.  A UP2210 or UP2210R with the 22-4052 module installed.  4 wire signal/connection cable (for several UP2210/UP2210R to the same GPS) ...

  • Page 66: Attaching Several Up2210R To The Same Gps

    UNIPOWER UP-2210R/P Hardware installation and configuration manual Attaching several UP2210R to the same GPS It is easy to attach several adjacent instruments to the same GPS. Use suitable installation cable and connect the green, white and black wires in the terminal plug to each terminal in parallel. See figure below.

  • Page 67: Installing Software

    UNIPOWER UP-2210R/P Hardware installation and configuration manual Installing Software All programs that form part of the PQ Secure system can be found on the supplied installation CD. Installation procedure Depending on the architecture of the PQ Secure the different programs should be installed on different computers.

  • Page 68: Installing Pq Online

    "PQ Online 3 Setup 3.7.1" FORCELOGIN=YES FORCEECRYPTION=YES Installing UniLauncher UniLauncher is a utility application that helps you to connect to your Unipower meters via USB. When you connect the USB cable UniLauncher will automatically connect with the meter and launch PQ Online.
  • Page 69 UNIPOWER UP-2210R/P Hardware installation and configuration manual the Installation program to open. Select “UniLauncher” and complete the installation wizard. Usually there is no need to make any changes, so you can simply accept the recommended settings. If the installation doesn’t start automatically, click on the Windows Start button and select Run. Use the Browse button to open the file "UniLauncherSetup.msi"...
  • Page 70 UNIPOWER UP-2210R/P Hardware installation and configuration manual Figure 49 – Connecting the USB cable The very first time you connect your meter to the PC the system needs to install some drivers. Be patient and wait (don’t pull out the USB cable and retry to fast! It could take 30-60 seconds to do the...

  • Page 71: Pq Online

    UP-2210R/P Hardware installation and configuration manual PQ ONLINE PQ Online is mainly used for configuring the measuring devices UP-2210R, UP-2210 and Unilyzer 900/900C, but is also used as a communication program between the measure site and the office. In that case, PQ Online is used for the manual polling of measure data or for real-time analysis.

  • Page 72: Connect

    UNIPOWER UP-2210R/P Hardware installation and configuration manual After connecting to a meter, the main window changes to the following. Figure 51 While connected to a meter, the following changes occur  Realtime, shows real time measurement data (section Error! Reference source not found.).
  • Page 73 UNIPOWER UP-2210R/P Hardware installation and configuration manual Ethernet Here you must specify the meters IP address that the unit has been configured with. It is possible to select different ports in order to route different meters on one IP address. The default port is 16421. TLS is described in 10.6.7 TLS Encryption...

  • Page 74: Meter Settings

    UNIPOWER UP-2210R/P Hardware installation and configuration manual Meter settings 10.3 The section Unit configuration is used for checking and editing the configuration of the meter. The configuration contains information about how the meter is connected to the measure site, the reference levels on the voltage and current, and the storage intervals for PQ parameters.

  • Page 75: En50160 Templates

    UNIPOWER UP-2210R/P Hardware installation and configuration manual  Review the configuration (section 10.4.3).  Save the configuration to the meter (section Error! Reference source not found.). These steps are described in detail below. Figure 56 It is also possible to create a configuration and save it to file without connecting a meter in case you wish to send a configuration.
  • Page 76 UNIPOWER UP-2210R/P Hardware installation and configuration manual EN50160HV: �� = 400 Voltage transformer ratio: 130kV/110V Current = 130���� �� transformer ratio: 400A/5A...

  • Page 77: Creating A New Configuration Template

    10.4.2 Figure 57 Begin with choosing the transformer configuration that fits your system. If possible Unipower always recommends measuring on a four-wire wye configuration. Note that the previously selected configuration is marked with a dark background color, in the above Case four-wire wye.
  • Page 78 UNIPOWER UP-2210R/P Hardware installation and configuration manual Note that each alternative has an associated number shown, this can be used to unambiguously identify the connection method of a meter, in Figure 59 you can see the Connection being specified in red as 1.3.3 this corresponds to option 1 for power transformer configuration (four-wire wye),...
  • Page 79 UNIPOWER UP-2210R/P Hardware installation and configuration manual  In the following window choose a Measurement standard(A).Chosing the EN 50160 setting will set and lock some key values to be compliant with EN 50160.  Then proceed and fill in the system frequency, reference voltage and current(B).

  • Page 80: Review Configuration

    UNIPOWER UP-2210R/P Hardware installation and configuration manual Review configuration 10.4.3 Review the configuration before saving it and begin measurement. Make sure that all parameters are correct according to the system measured. Figure 61 Store settings 10.4.4 The last step in the wizard has you chose how to store the configuration.

  • Page 81: Advanced Settings

    UNIPOWER UP-2210R/P Hardware installation and configuration manual Advanced settings 10.4.5 In advanced settings you have five overall setting icons. 1. General settings 2. Measure site properties 3. Storage intervals 4. Disturbance 5. Slowscan settings 6. Digital in 7. Digital out These are described below.

  • Page 82: Measure Site Properties (2)

    UNIPOWER UP-2210R/P Hardware installation and configuration manual Measure site properties (2) Figure 64 In measure site settings you have several settings. You can also here highlight a row and get information about the setting and edit the value. Signalling (2.6) Signaling is communications signals that are transmitted over the power distribution network.

  • Page 83: Detection Threshold (2.6.1)

    UNIPOWER UP-2210R/P Hardware installation and configuration manual Figure 66 Detection threshold (2.6.1) Here you set a value (% of nominal voltage) to be the trig condition. If the signaling value exceed this set value an event will be created which can be shown in the event viewer.

  • Page 84: Storage Intervals (3)

    UNIPOWER UP-2210R/P Hardware installation and configuration manual Storage intervals (3) Figure 68 In storage interval you set the intervals how often values will be stored to the memory. Disturbances (4) Figure 69 In disturbances you set values for disturbances such as sags/swells and transients.

  • Page 85: Sags/Swells Events

    UNIPOWER UP-2210R/P Hardware installation and configuration manual Sags/Swells events The recorder can do a high-speed recording to allow detailed analysis of, for instance, a sag/swell event. The storage time is the total recording length and is set so that the event you want to capture is covered.

  • Page 86: Voltage Triggers (4.2)

    UNIPOWER UP-2210R/P Hardware installation and configuration manual Example of sag event: According to IEC 61000-4-30 standard: a sag/dip begins when the voltage on one or more channels is below the trig threshold (level) and ends when the voltage on all measured channels is equal to or above the dip threshold plus the hysteresis voltage.

  • Page 87: Current Triggers (4.3)

    UNIPOWER UP-2210R/P Hardware installation and configuration manual a) U1-U3 trigs at deviation [% Uref] (4.2.1) A voltage sag (or swell) recording begins when the voltage one of the phases U1-U3 passes the Uref value +/- Figure 70 the trig level as in .

  • Page 88: Transient Triggers (4.4)

    UNIPOWER UP-2210R/P Hardware installation and configuration manual This trig gives you the possibility to trig on earth faults. Earth faults are detected by calculating the sum of the currents. Normally the current sum I1+I2+I3+I4=0. If this is not the case you probably have an earth fault and this trigger starts a recording.
  • Page 89 UNIPOWER UP-2210R/P Hardware installation and configuration manual a) Switching transients Switching transients are the most common ones in the power system. They have a duration in the magnitude of ca 1/256 cycle or ca 57 us @ 50 Hz. The waveform is compared sample by sample to the previous waveform and whenever there is a deviation between the voltage value in a sample point there is a trig.
  • Page 90 UNIPOWER UP-2210R/P Hardware installation and configuration manual c) Ultra-fast transients Ultra-fast transients have a duration in the magnitude of ca 650 ns (1/31000 cycle @ 50 Hz or 1/26000 cycle @ 60 Hz) An ultra-fast transient is captured if: Max level exceeds the 4.4.4 trig level setting in Volts. Remember that the in the normal case the max value = voltage RMS *2.

  • Page 91: Slowscan Settings (5)

    Since the resolution is lower a longer recording can be made. Maximum pre trig is 30 seconds and maximum recording length (including pre trig) is 300 seconds. For typical grid operations Unipower recommends a configuration of 10 seconds pre trig, 120 seconds post trig. Note that appropriate settings might take some trial and error before you find optimal storage length for your system.

  • Page 92: Voltage Triggers (5.2)

    UNIPOWER UP-2210R/P Hardware installation and configuration manual Voltage triggers (5.2) Current triggers (5.3) Frequency triggers (5.4) Power triggers (5.5) For power parameters the trigger is set on the rate of change (RoC). The system stores 5 values per second. If the change dP is 20 kW between to values, then dP/dt (rate of change) is 20 kW * 5 = 0,1 MW/s.

  • Page 93: Digital Inputs (6)

    UNIPOWER UP-2210R/P Hardware installation and configuration manual Digital inputs (6) Digital inputs allows external signals to trig different things in the meter. For physical connections see section 4.7.1) Each digital input can be configured for different actions as seen in 6.2: Basic options is to store an event.

  • Page 94: Power Quality Events (7.1)

    UNIPOWER UP-2210R/P Hardware installation and configuration manual Power Quality events (7.1) Each trigger (like Pst, subharmonics, unbalance etc.) can be set in three different modes_ a) Storage mode. The 10-minute values from the statistical memory are used for comparison. When a value exceeds the limit(s) there is a trig on the selected output.

  • Page 95: Harmonic Bandwidth Extension Hbe (Option)

    UNIPOWER UP-2210R/P Hardware installation and configuration manual Harmonic bandwidth extension HBE (option) 10.5 The harmonic bandwidth extension is used for Voltage Transformer frequency correction. The compensation is done for each harmonic component, both amplitude and phase angle error. The compensation is done in PQ Online, in the advanced meter configuration window (2.7.1). Press the three dots.
  • Page 96 UNIPOWER UP-2210R/P Hardware installation and configuration manual The picture below shows an amplitude/frequency graph of a magnetic 130kV voltage transformer. In this case the amplitude compensation for harmonic 35 (1750Hz) can be set to 0.2 to eliminate the majority of the PT error.

  • Page 97: Real-Time

    UNIPOWER UP-2210R/P Hardware installation and configuration manual Real-time 10.6 The real time values accessible from PQ Online are a useful tool when ensuring correct installation and configuration. Make a habit of always checking installation and configuration through real time analysis...

  • Page 98: Values Tab

    UNIPOWER UP-2210R/P Hardware installation and configuration manual Values tab 10.6.1 The first of the real time tabs accessible is the values tab. In this tab you may access numeric values and plots of basic electric power parameters. When investigating values before a measurement, focus on the quantity of each parameter. Make sure that all parameters are within plausible levels.

  • Page 99: Trend Graph

    UNIPOWER UP-2210R/P Hardware installation and configuration manual Trend graph 10.6.2 Figure 74 PQ Online includes a real-time function allowing you to contact a meter in order to study the measured power quality parameters in real time. The dialogue contains two tabs A and B, each with a different way of presenting the information.
  • Page 100 UNIPOWER UP-2210R/P Hardware installation and configuration manual Right clicking on the graph brings up the context menu with multiple options to adjust the graph, specifically note the Interval and History size options. Figure 76  Reset zoom: Undoes all zoom actions performed on the graph.

  • Page 101: Oscilloscope Tab

    UNIPOWER UP-2210R/P Hardware installation and configuration manual Oscilloscope tab 10.6.3 If you press the Oscilloscope tab B, following window appears. This tab shows the waveform of the measured voltage and current.  To plot the graphs, vectors or bars click the desired PQ parameter (marked in red below) ...

  • Page 102: Communication Settings

    UNIPOWER UP-2210R/P Hardware installation and configuration manual Communication settings Figure 78 In communication settings there are several settings tabs depending on communication type. A, Settings for Ethernet B, Settings for Serial ports C, Settings for Wi-Fi D, Settings for SmartCom...

  • Page 103: Dhcp And Smartcom

    Now you can connect using SmartCom from PQ Online: Figure 81 Connect using SmartCom Note that SmartCom is a service provided by Unipower and you need to have a valid subscription of this before activating this function. Contact your local representative for more information.

  • Page 104: 10.6.7 Tls Encryption

    UNIPOWER UP-2210R/P Hardware installation and configuration manual 10.6.7 TLS Encryption If communication security is of a great concern, there is an option to enable TLS encryption. This is an optional feature which requires a license to enable. Furthermore, a certificate and a private key need to be uploaded to the measuring device.

  • Page 105: Download Data

    UNIPOWER UP-2210R/P Hardware installation and configuration manual Download data 10.7 Figure 83 In Download data window you can select the file to be downloaded. Pressing Custom Interval tab A gives you opportunities to specify an interval from the file that you will download data.

  • Page 106: Tools

    UNIPOWER UP-2210R/P Hardware installation and configuration manual Tools 10.8 Figure 84 In Tools there are four tabs. A, Status tab. In status tab you can see Date and time info for the meter, Hardware info and transducer info. You can set the time in meter to same time as in System by clicking on arrow E.

  • Page 107: Language

    UNIPOWER UP-2210R/P Hardware installation and configuration manual Language 10.9 Figure 85 In the startup window for PQ Online you can set language by clicking on the actual language A. Choose the language you want from the dropdown list. USB port 10.10...

  • Page 108: Upgrading Meter Firmware

    2. Start PQ Online and connect to the meter. Go to the Tools menu. Select the firmware update menu: Figure 86 3. Browse to the firmware (program) file. Important! Only try upgrade with certified and approved firmware files for your meter from Unipower! Your meter can be severely damaged!
  • Page 109 UNIPOWER UP-2210R/P Hardware installation and configuration manual 4. Enter the update code and press Update: Figure 87 5. Let the process finish, it can take several minutes. Don’t disconnect or unplug the meter during the update! Figure 88 6. When the meter is ready the text “Meter updated” is written in the information window.
  • Page 110 UNIPOWER UP-2210R/P Hardware installation and configuration manual Figure 89...

  • Page 111: Adding Meter Options

    UNIPOWER UP-2210R/P Hardware installation and configuration manual Adding meter options 10.12 Some meter options are “soft” and can be activated by a license code. Check further with your local representative on your meter’s capabilities and on how to get license codes.
  • Page 112 UNIPOWER UP-2210R/P Hardware installation and configuration manual Secondly, enter your credentials and you can continue to run PQ Online as instructed in 10.1. Figure 92 There are three levels of access determined by permissions in the PQ Secure system: Administrator – Full access to all functionality in PQ Online.

  • Page 113: Appendix - Comissioning Checklists

    UNIPOWER UP-2210R/P Hardware installation and configuration manual APPENDIX – COMISSIONING CHECKLISTS Meter Installation Checklist 11.1 Use this checklist when you install a new meter on site. Configuration of meter OK Comments PQ Secure system/meter owner contact information: Company: ________________________________________________________________ Name:...
  • Page 114 UNIPOWER UP-2210R/P Hardware installation and configuration manual Installed communication equipment Ethernet Unit IP: ☐ 1.2.1 Gateway: Subnet mask: Modem ☐ ☐ ☐ PSTN ISDN ☐ 1.2.2 Phone no: GPRS/4G Modem Unit IP: ☐ 1.2.3 Port number (standard 16421): Configuration 1) New ☐...
  • Page 115 UNIPOWER UP-2210R/P Hardware installation and configuration manual Reference and trig levels ☐ Select measuring standard (1.1.4) ☐ EN50160 (recommended) ☐Custom 1.4.1 ☐ 1.4.2 System frequency (2.4.1) ☐50Hz ☐60Hz Reference voltage (2.3.1) _______ V (as measured by channel U1) ☐ 1.4.3 Recommendation is given by configuration guide Reference current (2.3.3)
  • Page 116 UNIPOWER UP-2210R/P Hardware installation and configuration manual Last steps 1.7.1 Enter a setting name ______________________________________ ☐ Enter your signature_________________________________________ ☐ 1.7.2 Save the configuration to a file (optional). ☐ 1.7.3 Select Finish to store and activate the settings in the meter...
  • Page 117 UNIPOWER UP-2210R/P Hardware installation and configuration manual ☐ Check that PF is >0.7 on all phases as well as total ☐ Check that P is positive for each phase (if not measuring on a generator) ☐ Check that unbalance is low (high value means wrong phase sequence) Check measure status page and be sure the sag/swell and transient trig ☐...
