FACSIMILE EQUIPMENT
SERVICE MANUAL
MODEL: MFC3100C/MFC580/
MFC3200C/FAX1800C

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MFC3100C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Brother MFC3100C

Summary of Contents for Brother MFC3100C

  • Page 1 FACSIMILE EQUIPMENT SERVICE MANUAL MODEL: MFC3100C/MFC580/ MFC3200C/FAX1800C...
  • Page 2 © Copyright Brother 2001 All rights reserved. No part of this publication may be reproduced in any form or by any means without permission in writing from the publisher. Specifications are subject to change without notice.
  • Page 3 PREFACE This publication is a Service Manual covering the specifications, construction, theory of operation, and maintenance of the Brother facsimile equipment. It includes information required for field troubleshooting and repair--disassembly, reassembly, and lubrication--so that service personnel will be able to understand equipment function, to rapidly repair the equipment and order any necessary spare parts.

  • Page 4: General Description

    CHAPTER GENERAL DESCRIPTION...
  • Page 5 CHAPTER 1 GENERAL DESCRIPTION CONTENTS EQUIPMENT OUTLINE ....................1-1 1.1.1 External Appearance and Weight ................1-1 1.1.2 Components ......................1-1 SPECIFICATIONS......................1-2...

  • Page 6: Equipment Outline

    1.1 EQUIPMENT OUTLINE 1.1.1 External Appearance and Weight The figure below shows the equipment appearance and approximate dimensions. 217 mm 8.5" 426 mm 342 mm 16.8" 13.5" (including handset) Weight: Machine proper Approx. 6.5 kg (14.3 lbs.) In package Approx. 10.5 kg (23.2 lbs.) 1.1.2 Components The equipment consists of the following major components: Control panel ASSY...

  • Page 7: Specifications

    Scan Speed (A4:Standard) Approx. 5 sec./page (A4:standard) Memory Transmission (Brother#1 Chart) Yes (100:MMR) Yes (85:MMR) Memory Transmission (ITU-T Chart) Yes (100:MMR) Out-of-Paper Reception (Brother #1 Chart) Yes (85:MMR) Out-of-Paper Reception (ITU-T Chart) Color FAX (Document Send/Receive) Yes/Yes No/Yes Color FAX (Memory Send/Receive)
  • Page 8 Model Name MFC 3100C PRINTER Color/Mono Color/Mono Piezo Ink Jet (2-head BH: 75 nozzles/color) Engine Type 1200x1200 /2400x1200 (Mono/Color) Resolution (dpi) 10/8 (Mono/Color: 600*150) 4/3.5 (Mono/Color: 600*300) Speed (ppm) 2/1.5 (Mono/Color: 600*600) 0.2/0.2 (Mono/Color: 1200*1200/2400*1200) Paper Capacity (sheets) Output Paper Capacity (sheets) Windows GDI Standard Print Language Emulation...
  • Page 9 HandSet Volume Approx. 5 sec./page (A4:standard) Scan Speed (A4:Standard) Memory Transmission (Brother#1 Chart) Yes (100:MMR) Yes (85:MMR) Memory Transmission (ITU-T Chart) Out-of-Paper Reception (Brother #1 Chart) Yes (100:MMR) Out-of-Paper Reception (ITU-T Chart) Yes (85:MMR) Color FAX (Document Send/Receive) Yes/Yes No/Yes...
  • Page 10 Model Name MFC-580 PRINTER Color/Mono Color/Mono Piezo Ink Jet (2-head BH: 75 nozzles/color) Engine Type 1200x1200/2400x1200 (B&W/Color) Resolution (dpi) 10/8 (Mono/Color: 600*150) 4/3.5 (Mono/Color: 600*300) 2/1.5 (Mono/Color: 600*600) Speed(ppm) 0.2/0.2 (Mono/Color: 1200*1200/2400*1200) Paper Capacity (sheets) Output Paper Capacity (sheets) Windows GDI Standard Print Language Emulation Resident Fonts...
  • Page 11 Yes (480:MMR) Yes (480:MMR) Memory Transmission (Brother#1 Chart) Yes (400:MMR) Yes (400:MMR) Memory Transmission (ITU-T Chart) Yes (480:MMR) Yes (480:MMR) Out-of-Paper Reception (Brother #1 Chart) Yes (400:MMR) Yes (400:MMR) Out-of-Paper Reception (ITU-T Chart) Yes/Yes Yes/Yes Color FAX (Document Send/Receive) No/Yes...
  • Page 12 Fax 3200C Fax 1800C Model Name PRINTER Color/Mono Color/Mono Color/Mono Piezo Ink Jet (2-head BH: 75 nozzles/color) Piezo Ink Jet (2-head BH: 75 nozzles/color) Engine Type 1200x1200 /2400x1200 (Mono/Color) 1200x1200/2400x1200 (B&W/Color) Resolution (dpi) 10/8 (Mono/Color: 600*150) 10/8 (Mono/Color: 600*150) 4/3.5 (Mono/Color: 600*300) 4/3.5 (Mono/Color: 600*300) Speed (ppm) 2/1.5 (Mono/Color: 600*600)

  • Page 13: Installation

    CHAPTER INSTALLATION...
  • Page 14 CHAPTER 2 INSTALLATION CONTENTS INSTALLING THE UPDATE DATA TO THE FACSIMILE MACHINE......2-1 SETTING ID CODES TO FACSIMILE MACHINES ............2-5 UPDATING HEAD PROPERTY INFO STORED IN THE FACSIMILE MACHINE ..2-8...

  • Page 15: Installing The Update Data To The Facsimile Machine

    The program installation requires a PC/AT-compatible computer running MS-DOS, Windows 95, or Windows 98. For the MFC3200C/FAX1800C, it requires Windows 98, Windows Me, or Windows2000. MFC3100C/MFC580 Setting up the facsimile machine and your PC (1) Make sure that your PC is turned off.
  • Page 16 Installing the update data onto the flash ROM of the facsimile machine NOTE: The following is an installation procedure example on a PC that is running Windows 98. (1) Copy the update data and transfer utility onto the desired directory of the hard disk. e.g., C:\UPDATE (2) Click the Start button, point to Programs, and then click MS-DOS Prompt to open an MS-DOS window.
  • Page 17 MFC3200C/FAX1800C CAUTION: During installation, do not turn the power off, interrupt downloading, or download invalid data. If you do so, downloading will fail so that you need to replace the main PCB of the facsimile machine with a new one and download update data again. The failure PCB is no longer usable. Installing the printer driver to your PC If the MFC3200C/FAX1800C is first connected to your PC, no printer driver is installed to your PC.
  • Page 18 (1) Get "Filedg32.exe" utility and save it onto the desk top of your PC. (2) Double-click the “Filedg32” icon. The Filedrgs window will appear. (3) Drag and drop the firmware update file (ex. 1800usaC.dat) onto the printer icon (e.g., "Brother FAX1800C") in the Filedrgs window. During downloading, the facsimile machine beeps intermittently.

  • Page 19: Setting Id Codes To Facsimile Machines

    2.2 SETTING ID CODES TO FACSIMILE MACHINES Brother facsimile machines are assigned unique ID codes (character strings) at the factory. If you replace the main PCB of the machine, the machine will lose its assigned ID code so that it will not be identified by the connected PC*.
  • Page 20 (1) On your PC, run the ID/head property setup utility (BRUSBSN.EXE). The following window will appear. (2) On the Model menu, click BH. MFC3100C/MFC580: Click the Port down arrow to select the LPT1. MFC3200C/FAX1800C: Click the Port down arrow to select the USB port to which the MFC3200C/FAX1800C is connected.
  • Page 21 (3) In the Serial No = BRO box, type the 9-digit serial number (e.g., L2J012345) printed on the nameplate labeled to the back of the facsimile machine as an ID code. Then press the Enter key. The setup utility will transmit the entered data from your PC to the facsimile machine and then it will terminate.
  • Page 22 TIP: The updating procedure given here uses a PC. For the updating procedure in the maintenance mode without using a PC, refer to CHAPTER 5, Subsection 5.3.14. MFC3100C/MFC580 Connecting the facsimile machine to your PC (See the illustration on page 2-1.) (1) Make sure that your PC is turned off.
  • Page 23 (1) On your PC, run the ID/head property setup utility (BRUSBSN.EXE). The following window will appear. (2) On the Model menu, click BH. MFC3100C/MFC580: Click the Port down arrow to select the LPT1. MFC3200C/FAX1800C: Click the Port down arrow to select the USB port to which the MFC3200C/FAX1800C is connected.
  • Page 24 12-digit code is printed. NOTE: The MFC3100C may fail to print it out correctly if the four starting numerals of the entered property code are other than 6666, 7777, and 8888. To print it correctly, update the current program stored in the EEPROM.

  • Page 25: Theory Of Operation

    CHAPTER THEORY OF OPERATION...

  • Page 26: Table Of Contents

    CHAPTER 3 THEORY OF OPERATION CONTENTS OVERVIEW ........................3-1 MECHANISMS .........................3-2 3.2.1 Scanner Mechanism ....................3-3 3.2.1.1 Document feeding and ejecting mechanism ..........3-3 3.2.1.2 Scanner......................3-3 3.2.2 Ink Jet Printing Mechanism ..................3-4 3.2.2.1 Paper pulling-in, registration, feeding, and ejecting mechanisms....3-4 3.2.2.2 Ink jet printing and capping mechanisms.............3-6 3.2.2.3 Purging mechanism ..................3-9 3.2.2.4...

  • Page 27: Overview

    3.1 OVERVIEW Host Centronics Control parallel panel interface interface* Fax Control Section Printer Control Section Print data Ink jet printer unit Paper feeding Line Scanner Power mechanism - Ink jet print head supply - CIS unit - Paper feed unit - Scanner motor motor - Carriage motor...

  • Page 28: Mechanisms

    3.2 MECHANISMS The facsimile machine is classified into the following mechanisms: SCANNER MECHANISM - Document feeding and ejecting mechanism - Document scanning mechanism INK JET PRINTING MECHANISM - Paper pulling-in, registration, feeding, and ejecting mechanisms - Ink jet printing and head capping mechanisms - Purging mechanism - Carriage drive mechanism SENSORS AND ACTUATORS...

  • Page 29: Scanner Mechanism

    3.2.1 Scanner Mechanism 3.2.1.1 Document feeding and ejecting mechanism This mechanism consists of the document stacker, automatic document feeder (ADF), document feed roller ASSY, document ejection roller ASSY, and document sensors. (For details about the sensors, refer to Subsection 3.2.3.) If you set documents on the document stacker with their faces down and start the scanning operation, then the scanner motor rotates so that the ADF (which consists of the separation roller and ADF parts) feeds those documents into the machine, starting from the bottom sheet (first page)

  • Page 30: Ink Jet Printing Mechanism

    3.2.2 Ink Jet Printing Mechanism 3.2.2.1 Paper pulling-in, registration, feeding, and ejecting mechanisms The paper pulling-in, registration, feeding, and ejecting mechanisms are driven by a single paper feed motor located at the left side of the main chassis via the gear train. (See the illustration given on the next page.) First, the paper feed motor rotates clockwise (when viewed from the output gear).
  • Page 31 Gear 31MF Gear shaft 17 PF roller gear R ASF roller unit Gear 39 Paper feed roller Gear 25 ASF-purge switching gear 23 ASF/purge idle gear PF roller gear Paper feed motor 3 -5...

  • Page 32: Ink Jet Printing And Capping Mechanisms

    3.2.2.2 Ink jet printing and capping mechanisms (1) Print head unit This machine uses drop-on-demand ink jet printing. Each of the right and left print heads has an ink-jet unit that has a pair of nozzle columns for two color inks. A nozzle column consists of 75 nozzles, 75 channels covered with piezoelectric ceramic (PZT), a manifold, and filter.

  • Page 33: Ink Cartridges

    If the controller issues a print command, a biased voltage will be applied to all electrodes formed on the surface of the piezoelectric ceramic so that each actuator will be distorted as shown with broken lines. If the electrodes on a target channel are deenergized according to drive signals, then the associated piezoelectric ceramic actuator returns to the previous form so that the ink in the manifold will be vacuumed out to the channel.
  • Page 34 (3) Head caps Shown below is a head cap mechanism that prevents the nozzles of the print heads from drying up when they are not in use. Upon completion of printing, the carriage travels to the right and moves the head cap holder provided on the purge unit to the right together.

  • Page 35: Purging Mechanism

    3.2.2.3 Purging mechanism The purge mechanism is driven by the paper feed motor located at the left side of the main chassis. As described in Subsection 3.2.2.1, the motor rotation is transmitted to the ASF/purge idle gear at the right side of the main chassis. Engaged with the ASF/purge idle gear, the ASF-purge switching gear 23 works as a clutch gear.
  • Page 36 During printing: The ASF-purge switching gear 23 is During purging: The ASF-purge not engaged with purge bevel gear A (but engaged with switching gear 23 is engaged with gear 25 in the ASF gear train). purge bevel gear A. When the motor rotation is transmitted to the purge unit, its counterclockwise rotation will drive the purge cam and its clockwise rotation, the pump switching unit (when viewed from the output gear of the motor).
  • Page 37 The purge cam is so designed that: - the carriage lock pops out to lock the carriage before purging and pops in before cleaning with the head wiper (see the illustration below), - the pump works to draw out ink from each of the four head nozzles and drain it to the ink absorber felts, and - the head wiper comes out to clean the nozzle surface (see the illustration below).

  • Page 38: Carriage Drive Mechanism

    3.2.2.4 Carriage drive mechanism The carriage motor controls horizontal motion. The motor rotation is transmitted via the motor pulley to the timing belt. The carriage, which is supported and guided by the carriage rail, is secured to the timing belt. Clockwise and counterclockwise rotations of the carriage motor move the carriage to the right and left, respectively.

  • Page 39: Sensors And Actuators

    3.2.3 Sensors and Actuators This machine has the following sensors and thermister. Sensor name Type Located on Document front sensor Photosensor Document rear sensor Photosensor Control panel PCB Cover/panel open sensor Mechanical switch Registration sensor Photosensor Paper chute Paper width sensor Photosensor Main PCB Ink empty sensor...
  • Page 40 These photosensors (except the ink empty sensor that is a reflection type) are a photointerrupter consisting of a light-emitting diode and a light-sensitive transistor. Each of them has an actuator separately arranged as shown on the next page. 3 -1 4...
  • Page 41 Location of Sensors and Actuators NOTE: The hook switch (not shown above) is provided in the MFC3200C/FAX1800C. 3 -1 5...

  • Page 42: Control Electronics

    3.3 CONTROL ELECTRONICS 3.3.1 Configuration The hardware configuration of the facsimile machine is shown below. Control panel PCB Document front sensor 8-pin Document rear sensor Paper width sensor Cover/panel open sensor Piezo ringer INK JET PRINTER UNIT Main PCB Carriage PCB Ink cartridge sensors Print head Carriage encoder...
  • Page 43 CHAPTER DISASSEMBLY/REASSEMBLY, LUBRICATION, AND ADJUSTMENT...
  • Page 44 CHAPTER 4 DISASSEMBLY/REASSEMBLY, LUBRICATION, ADJUSTMENT CONTENTS DISASSEMBLY/REASSEMBLY..................4-1 Safety Precautions ......................4-1 Tightening Torque List......................4-2 Preparation ........................4-3 How to Access the Object Component .................4-3 Disassembly Order Flow....................4-4 4.1.1 Print Head Unit .....................4-5 4.1.2 Jam Clear Cover and Auto Sheet Feeder (ASF)..........4-9 4.1.3 Bottom Plate, Ink Absorber Box, Main PCB, NCU PCB, and Power Supply PCB .....................4-11 4.1.4...
  • Page 45 4.1.19 Encoder Strip and Carriage Motor..............4-41 4.1.20 Carriage Rail, Carriage ASSY, and Purge-Related Parts ........4-43 4.1.21 Flushing Box.......................4-48 4.1.22 Harness Routing....................4-49 LUBRICATION .......................4-51 ADJUSTMENT .......................4-56...

  • Page 46: Disassembly/Reassembly

    4.1 DISASSEMBLY/REASSEMBLY Safety Precautions To prevent the creation of secondary problems by mishandling, observe the following precautions during maintenance work. (1) Unplug the power cord from the power outlet before replacing parts or units. When having access to the power supply, be sure to unplug the power cord from the power outlet. (2) Be careful not to lose screws, washers, or other parts removed for parts replacement.

  • Page 47: Tightening Torque List

    Tightening Torque List Location Screw type Q'ty Tightening torque N•m (kgf•cm) Taptite, bind B M4x12 0.88 ±0.10 (9 ±1) Bottom plate Taptite, cup B M3x12 0.78 ±0.10 (8 ±1) Grounding terminal Screw, pan (washer) M4x8 0.59 ±0.10 (6 ±1) Bottom shield plate Taptite, cup B M3x12 0.78 ±0.10 (8 ±1)

  • Page 48: Preparation

    Preparation Prior to proceeding to the disassembly procedure, (1) Unplug - the modular jack of the telephone line, - the modular jack of the curled cord* (and remove the handset*), - the PC interface cable if connected (Not shown below), and - the modular jack of an external telephone set if connected (Not shown below).

  • Page 49: Disassembly Order Flow

    Disassembly Order Flow 4 -4...

  • Page 50: Print Head Unit

    4.1.1 Print Head Unit During disassembly jobs (except when removing the purge unit, carriage rail, or carriage ASSY), the print head unit and all the four ink cartridges should be kept in place. NOTE: To replace the print head unit with a new one, you need to move the carriage to the ink replacement position by placing the machine in the ink replacement mode.
  • Page 51 (8) Pull the head clamp springs in the direction of arrows shown below to release the print head unit. (9) Lift the print head unit up and out of the carriage (arrow Setting the head clamp spring Top cover Carriage Head clamp spring Head clamp spring Correct...
  • Page 52 NOTE: Once the ink cartridges are removed, their colored covers rise upright. If you turn the machine upside down with those covers being upright, then they will break. To prevent it, set them to the horizontal position by turning them in the direction of arrow and pushing them up in the direction of arrow (10) Turn the head adjuster lever located on the right side of the carriage to position 1.
  • Page 53 (13) Press the front center of the carriage to the rear and move the print head unit to the right and left several times. This is to assure the dimple contact between the head PCB and carriage PCB. (14) Remove the head filter seal. Carriage Print head unit (15) While pressing the center of the print head unit as shown above, lock the print head unit with...

  • Page 54: Jam Clear Cover And Auto Sheet Feeder (Asf)

    4.1.2 Jam Clear Cover and Auto Sheet Feeder (ASF) (1) Remove the jam clear cover. (2) Remove the four screws from the ASF to release it. (3) Pull out the separation pad ASSY. 4 -9...
  • Page 55 (4) Disassemble the separation pad ASSY as shown below. 4 -1 0...

  • Page 56: Bottom Plate, Ink Absorber Box, Main Pcb, Ncu Pcb, And Power Supply Pcb

    4.1.3 Bottom Plate, Ink Absorber Box, Main PCB, NCU PCB, and Power Supply PCB (1) Disconnect the following harnesses and flat cables from the main PCB: • Head flat cables • Registration sensor harness • Purge switch harness • Ink empty sensor harness •...
  • Page 57 (2) Remove three screws "e" from the rear of the machine (two for the parallel I/F connector and one for the USB I/F connector). (3) Turn the machine upside down. NOTE: Cover the workbench with cloth to protect the top cover and control panel from scratches or damages.
  • Page 58 (7) Push down the latch and remove the ink absorber box as illustrated below. NOTE: Do not remove the ink absorber box unless it requires replacement. When replacing it, set a new one soon after the removal to prevent the machine from getting stained with drained ink.
  • Page 59 (8) Remove the screw from the FG plate R. (9) Slightly pull up the FG plate R, pull two latches "a" outwards, and then lift up the power supply PCB. Disconnect the power supply harness from the PCB. (10) Slightly pull up the FG plate L and release the main PCB from it. Release the NCU PCB from latch "b"...
  • Page 60 Setting up the main PCB after replacement - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Important - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - NOTE: Before starting the following procedure, make sure that the print head unit is installed.

  • Page 61: Enclosure Cover And Paper Width Sensor Actuator

    4.1.4 Enclosure Cover and Paper Width Sensor Actuator (1) While pulling up the FG plate R, lift up the enclosure cover. (2) Slightly push down the locking arm and remove the paper width sensor actuator as shown below. 4 -1 6...

  • Page 62: Top Cover

    4.1.5 Top Cover (1) Turn the machine back to the normal position. (2) Open the control panel ASSY. (3) Open the top cover (not fully) and lift it up and to the rear. 4 -1 7...

  • Page 63: Control Panel Assy

    4.1.6 Control Panel ASSY (1) Open the control panel ASSY to you (in the direction of arrow (2) Push the right and left arms of the control panel ASSY outwards (arrow ) to release those arms from bosses "X" provided on the upper cover with a flat screwdriver. (3) Open the control panel ASSY further, then take out the panel-main harness from the harness guides provided on the panel rear cover and disconnect the panel-main harness from the control panel PCB.

  • Page 64: Panel Rear Cover And Control Panel

    4.1.7 Panel Rear Cover and Control Panel (1) Place the control panel ASSY upside down. If you do not need to remove the ADF parts, antistatic brush, or document rear sensor actuator, skip to step (5). (2) To remove the ADF parts (spring plates and separation rubber), remove the screw. (3) To replace the antistatic brush, peel it off.
  • Page 65 (6) Remove the two screws from the panel rear cover. (7) Unhook the panel rear cover from ten "X" latches provided on the control panel and lift up the panel rear cover. (8) Fully turn the document front sensor actuator to the rear and lift it up. (9) Unhook the control panel PCB from seven "Y"...
  • Page 66 (11) As shown below, pull up the locking arm "x," slide the LCD to the right, pull the locking arm "y" to the rear, and take out the LCD while pulling the LCD flat cable gently. Reassembling Notes • Before reinstalling the LCD to the control panel, wipe fingerprints or dust off the LCD surface and control panel window with a soft cloth.

  • Page 67: Cis Unit

    4.1.8 CIS Unit (1) Remove the screw from the CIS side spring and lift it up. (2) Move the CIS unit to the left and lift up the right edge of the CIS unit. While holding up the CIS unit, disconnect the CIS harness. The CIS springs also come off. Reassembling Notes •...

  • Page 68: Upper Cover

    4.1.9 Upper Cover (1) Remove the two screws from the upper cover. (2) Disconnect the panel-main harness and CIS harness from the main PCB if you have not removed the main PCB. (3) Disconnect the scanner motor harness from the main PCB if you have not removed the main PCB.
  • Page 69 Reassembling Notes • Before installing the upper cover, make sure that the panel-main harness, CIS harness, and scanner motor harness are routed properly on the inside of the upper cover. (Refer to Subsection 4.1.22 "Harness Routing B" and "Harness Routing C." •...

  • Page 70: Document Feed Roller Assy, Document Ejection Roller Assy, Pressure Roller, And Pinch Rollers

    4.1.10 Document Feed Roller ASSY, Document Ejection Roller ASSY, Pressure Roller, and Pinch Rollers (1) Remove the two pawled plastic bushings from the left ends of the document feed roller and document ejection roller. (Access those bushings from the inside of the upper cover.) Move the document feed roller and document ejection roller to the right and upwards.

  • Page 71: Panel Lock Springs, Scanner Chassis, Separation Roller, Scanner Drive Unit, And Scanner Motor

    4.1.11 Panel Lock Springs, Scanner Chassis, Separation Roller, Scanner Drive Unit, and Scanner Motor (1) Remove screws "a" and "b" from the panel lock springs R and L, respectively, then take those springs out of the upper cover. (Access them from the inside of the upper cover.) (2) Remove the scanner motor harness from the cable guides provided on the inside of the upper cover (see Subsection 4.1.22, "Harness Routing B."...
  • Page 72 (5) Press the lock arm to the rear and move the separation roller gear. Press the lock arm again to remove bushing 12. Then the separation roller and bushing 6. (Access them from the inside of the upper cover.) (6) Lift up the scanner drive unit together with the separation roller gear. 4 -2 7...
  • Page 73 (7) Remove the screw and release the scanner motor from the scanner drive unit. Reassembling Notes • When securing the scanner motor to the scanner drive unit, face the motor connector as shown above. • When setting the separation roller and its gear, first fit bushing 6 into the upper cover with its flange facing towards the scanner drive unit and with its stopper facing down (when viewed from the bottom), as illustrated on the previous page.

  • Page 74: Purge Unit

    4.1.12 Purge Unit (1) Remove the print head unit (refer to Subsection 4.1.1). (2) Disconnect the purge switch harness (blue and white) from the main PCB if you have not removed the main PCB. Remove the purge switch harness from the cable guides provided on the lower cover. (Refer to Subsection 4.1.22 "Harness Routing A."...
  • Page 75 (6) Take off the purge cam HP switch and pump switching cam HP switch from the purge unit by pulling the latches outwards, respectively. (7) Remove the purge bevel gear A. (See the illustration given on the previous page.) Reassembling Notes •...

  • Page 76: Main Chassis

    4.1.13 Main Chassis (1) Disconnect the carriage motor harness, registration sensor harness, ink empty sensor harness, head flat cables, and paper feed motor harness from the main PCB if you have not removed the main PCB. Remove those harnesses from the cable guides provided on the lower cover. (2) Remove screw "x"...

  • Page 77: Asf Roller Unit And Its Related Gears

    4.1.14 ASF Roller Unit and its Related Gears (1) Remove the three screws from the rear of the ASF. (2) Move the ASF to the left and remove it to the rear. (3) Remove the gear 31MF by pulling its pawls outwards. The gear shaft 17 and bushing also come off.
  • Page 78 Disassembly of the ASF Roller Unit 1) Pull the pawl of the ASF gear 31 outwards and pull out the gear shaft 15. The ASF roller ASSY and the ASF gear 32 also come off. 2) Remove the screw from the ASF roller ASSY. Then it will be disassembled as shown below. 4 -3 3...

  • Page 79: Roller Pressure Holders

    4.1.15 Roller Pressure Holders (1) At each of the paper pressure holders, unhook the top end of the spring from the main chassis. (2) Remove the roller pressure holders. Paper pressure holder R Paper pressure holders M Springs Paper pressure holder L Main chassis Reassembling Notes...

  • Page 80: Paper Chute And Registration Sensor

    4.1.16 Paper Chute and Registration Sensor (1) Remove the screw from the rear of the paper chute and take it off from the main chassis. Paper chute Taptite, cup S M3x6 Main chassis 4 -3 5...
  • Page 81 (2) Unhook the registration sensor. (3) Unhook the actuator spring. (4) Push the lock arm and slide the sensor actuator in the direction of arrows 4 -3 6...

  • Page 82: Paper Ejection Roller Gear, Ink Empty Sensor Pcb, Platen, Star Wheel Support, And Paper Ejection Roller

    4.1.17 Paper Ejection Roller Gear, Ink Empty Sensor PCB, Platen, Star Wheel Support, and Paper Ejection Roller (1) Pull out the paper ejection roller gear from the left end of the paper ejection roller. (2) Remove the screw from the left side of the sensor support and take it off in the direction of the arrow.
  • Page 83 (4) Remove the screws from the platen and pull it out in the direction of the arrow. NOTE: Take care not to touch the flushing sponge that is impregnated with ink. 4 -3 8...
  • Page 84 (5) Unhook the four latches of the star wheel support and separate it from the platen. (6) Remove star wheels A and B from the star wheel support. (7) Pull out the paper ejection joint from the left end of the paper ejection roller. (8) Remove the pawled bushing by pulling its pawls outwards.

  • Page 85: Paper Feed Motor And Paper Feed Roller

    4.1.18 Paper Feed Motor and Paper Feed Roller (1) Remove the paper feed motor by removing the two screws. (2) Remove the crescent ring from the PF roller gear and pull out the gear. (3) Unhook the PF spring. (4) Turn the PF bushings as shown below and disengage them from the main chassis. Then remove the paper feed roller.

  • Page 86: Encoder Strip And Carriage Motor

    4.1.19 Encoder Strip and Carriage Motor (1) At the left end of the encoder strip, unhook the spring from the main chassis. NOTE: Take care not to scratch or damage the encoder strip. This should point up. Encoder strip Main chassis Carriage motor pulley Encoder strip spring...
  • Page 87 (5) Remove the carriage motor by removing the two screws. Carriage motor Main chassis Screw, pan (s/p washer) M3x6 Reassembling Notes • Pass the encoder strip through the strip guide provided on the back of the carriage so that the encoder strip will route as illustrated on the previous page and the -marked end comes to the ▲...

  • Page 88: Carriage Rail, Carriage Assy, And Purge-Related Parts

    4.1.20 Carriage Rail, Carriage ASSY, and Purge-Related Parts (1) If the ink cartridges and print head have not been removed, remove them as follows: Push the colored ink cartridge covers and remove all ink cartridges (arrow Pull the head clamp springs in the direction of arrow to release the print head.
  • Page 89 (3) Remove the screw from the eccentric bushing R, then turn it to align its boss with the cutout provided in the main chassis and pull it out. The wavy washer also comes off. NOTE: Take care not to lose the wavy washer. (4) Pull out the carriage rail to the right.
  • Page 90 (6) From the rear side of the main chassis, remove the cable clamp stopper that is attached with double-sided adhesive tape. From the front side, unlatch the flat cable clamp to release the head flat cables. (7) Remove the FFC clamp film from the left end of the main chassis. (8) Remove tapes from the flat cable guide.
  • Page 91 (10) Push up the carriage PCB to unhook its lower edge from the PCB holders and remove the PCB together with the sensor actuator support. Unlatch the sensor actuator support from the carriage PCB. (11) Press the right end of the purge shaft inwards and pull it out of the purge lever. The purge lever spring also comes off.
  • Page 92 Reassembling Notes • To install the carriage rail, temporarily set the eccentric bushing L to the left side of the main chassis with the screw, align the bushing L with marking made on the main chassis, and then tighten the screw firmly. Pass the carriage rail through the opening in the right side of the main chassis and through the carriage, then fit it into the eccentric bushing L.

  • Page 93: Flushing Box

    4.1.21 Flushing Box (1) From the bottom, insert the tip of a flat screwdriver to unhook the latch and then slide the flushing box to the front and upwards. 4 -4 8...

  • Page 94: Harness Routing

    4.1.22 Harness Routing Harness routing A: Main PCB-related harnesses Harness routing B: Scanner motor harness on the inside of the upper cover 4 -4 9...
  • Page 95 Harness routing C: Panel-main harness and CIS harness on the inside of the upper cover Harness routing D: Purge cam HP switch harness and pump switching cam HP switch harness on the lower cover (Purge unit) (Main chassis) CAUTION: Be sure to insert the end of the drain tube into this hole (provided in the lower cover) that leads to the ink...

  • Page 96: Lubrication

    4.2 LUBRICATION Apply the specified lubricants to the lubrication points as shown below. Lubricant amount Lubricant type Thin coat of 1/4 sesame-sized Sesame-sized Rice-sized pinch Bean-sized (Manufacturer) pinch of grease pinch of grease of grease pinch of grease grease with (0.5 mm dia.
  • Page 97 [ 2 ] ASF roller unit [ 3 ] Paper ejection roller and platen Star wheel A Star wheel support EM0.1 EM0.1 Apply to a total of 16 points on EM0.1 the star wheel support. Platen EM0.5 Paper ejection roller EM0.5 EM0.5 EM0.5...
  • Page 98 [ 4 ] Paper ejection roller gear and PF roller gear [ 5 ] Paper feed roller and PF spring 4 -5 3...
  • Page 99 [ 6 ] Carriage rail Apply a thin coat of grease to the right and left edges of the carriage rail with a brush. P0.02 Carriage rail P0.02 Carriage [ 7 ] Main chassis (slideway of the carriage guide) 4 -5 4...
  • Page 100 [ 8 ] Purge shaft 4 -5 5...

  • Page 101: Adjustment

    4.3 ADJUSTMENT Correcting the positioning error of the print head Once the print head or carriage is removed, you need to correct the positioning error of the print head according to the procedure given below. The head nozzle columns should be perpendicular to the carriage travel path.
  • Page 102 (10) From your PC, send the specified test chart to the machine to print it out. (11) Check the printed test patterns 1 though 5 (see the test pattern sample on the next page) given and choose one that has the least uneven print (Pattern 1 in this sample). Make a note of the pattern number.
  • Page 103 Head Positioning Test Pattern 4 -5 8...

  • Page 104: Maintenance Mode

    CHAPTER MAINTENANCE MODE...
  • Page 105 CHAPTER 5 MAINTENANCE MODE CONTENTS ENTRY INTO THE MAINTENANCE MODE ..............5-1 LIST OF MAINTENANCE-MODE FUNCTIONS ..............5-2 DETAILED DESCRIPTION OF MAINTENANCE-MODE FUNCTIONS ......5-4 5.3.1 EEPROM Parameter Initialization ..................5-4 5.3.2 Printout of Scanning Compensation Data ................ 5-5 5.3.3 ADF Performance Test..................... 5-7 5.3.4 Test Pattern 1........................

  • Page 106: Entry Into The Maintenance Mode

    5.1 ENTRY INTO THE MAINTENANCE MODE To make the facsimile equipment enter the maintenance mode, press the Menu, *, 2, 8, 6, and 4 keys in this order. Within 2 seconds The equipment beeps for approx. one second and displays " "...

  • Page 107: List Of Maintenance-Mode Functions

    5.2 LIST OF MAINTENANCE-MODE FUNCTIONS Maintenance-mode Functions Reference Function Function Subsection Code (Page) 5.3.1 (5-4) EEPROM Parameter Initialization 5.3.2 (5-5) Printout of Scanning Compensation Data 5.3.3 (5-7) ADF* Performance Test 5.3.4 (5-8) Test Pattern 1 5.3.5 (5-9) Firmware Switch Setting 5.3.5 (5-11) Printout of Firmware Switch Data 5.3.6 (5-12)
  • Page 108 - - - - - - - - - - - - - - - - - - - - - - - - - - IMPORTANT - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Basically, the maintenance-mode functions listed on the previous page should be accessed by service personnel only.

  • Page 109: Detailed Description Of Maintenance-Mode Functions

    5.3 DETAILED DESCRIPTION OF MAINTENANCE-MODE FUNCTIONS 5.3.1 EEPROM Parameter Initialization Function The equipment initializes the parameters, user switches, and firmware switches registered in the EEPROM, to the initial values. Entering the function code 01 initializes almost all of the EEPROM areas, but entering 91 does not initialize some areas, as listed below. Function code Data item Maintenance-mode functions...

  • Page 110: Printout Of Scanning Compensation Data

    5.3.2 Printout of Scanning Compensation Data Function The equipment prints out the white and black level data for scanning compensation. Operating Procedure Do not start this function merely after powering on the equipment but start it after carrying out a sequence of scanning operation.
  • Page 111 Scanning Compensation Data List 5 -6...

  • Page 112: Adf Performance Test

    5.3.3 ADF Performance Test Function The equipment counts the documents fed by the automatic document feeder (ADF) and displays the count on the LCD for checking the ADF performance. Operating Procedure (1) Set documents. (Allowable up to the ADF capacity.) The "DOC.

  • Page 113: Test Pattern 1

    5.3.4 Test Pattern 1 Function This function, much like the copying function, prints out test pattern 1 to allow the service personnel to check for record data missing or print quality. Operating Procedure Press the 0 and 9 keys in this order in the initial stage of the maintenance mode. The figure below shows test pattern 1.

  • Page 114: Firmware Switch Setting And Printout

    5.3.5 Firmware Switch Setting and Printout [ A ] Firmware switch setting Function The facsimile equipment incorporates the following firmware switch functions which may be activated with the procedures using the control panel keys and buttons. The firmware switches have been set at the factory in conformity to the communications standards and codes of each country.
  • Page 115 Firmware Switches (WSW01 through WSW50) Continued WSW No. Function WSW34 Function setting 12 WSW35 Not used. WSW36 Function setting 14 WSW37 Function setting 15 WSW38 Not used. WSW39 Not used. WSW40 Not used. WSW41 Not used. WSW42 Function setting 20 WSW43 Function setting 21 WSW44...

  • Page 116: Printout Of Firmware Switch Data

    [ B ] Printout of firmware switch data Function The equipment prints out the setting items and contents specified by the firmware switches. Operating Procedure (1) Press the 1 key twice in the initial stage of the maintenance mode. The "PRINTING" will appear on the LCD. (2) The equipment prints out the configuration list as shown in the figure below.

  • Page 117: Operational Check Of Lcd

    5.3.6 Operational Check of LCD Function This function allows you to check whether the LCD on the control panel works normally. Operating Procedure (1) Press the 1 and 2 keys in this order in the initial stage of the maintenance mode. The LCD shows the screen given at right.

  • Page 118: Operational Check Of Control Panel Pcb

    (3) After the last number key or button is pressed, the equipment beeps and returns to the initial stage of the maintenance mode. To terminate this operation, press the Stop key. The equipment returns to the initial stage of the maintenance mode. MFC3100C/MFC580 Key & Button Entry Order (1) 5 -1 3...
  • Page 119 MFC3200C/FAX1800C Key & Button Entry Order (2) 5 -1 4...

  • Page 120: Receiver Volume Adjustment (Applicable To The Mfc3200C/Fax1800C)

    5.3.8 Receiver Volume Adjustment (Applicable to the MFC3200C/FAX1800C) Function The HIGH level of the handset receiver's volume will be influenced by the characteristics of the FET on the main PCB, so it requires fine adjustment according to the procedure given below. Operating Procedure (1) Connect the telephone line cord to the modular jack of the facsimile equipment and the telephone wall socket.

  • Page 121: Sensor Operational Check

    NOTE: To stop beeping, press the Menu key. If the sensing status are as listed below, the LCD will show the following two letter strings which can be switched by pressing the Black Fax Start key: MFC3100C/MFC580: "DFDRCVRSPWP1P2HD" and "IKIYICIMVT" MFC3200C/FAX1800C: "HKDFDRCVRSPWHDVT" and "P1P2IKIYICIM"...

  • Page 122: Fine Adjustment Of Scanning Start/End Position

    5.3.10 Fine Adjustment of Scanning Start/End Position Function This function allows you to adjust the scanning start/end position. Operating Procedure (1) Press the 5 and 4 keys in this order in the initial stage of the maintenance mode. The "SCAN START ADJ." appears on the LCD. After two seconds, the current scanning position correction value appears.

  • Page 123: Cis Scanner Area Setting

    5.3.11 CIS Scanner Area Setting Function The equipment sets the CIS scanner area and stores it into the EEPROM. Operating Procedure (1) Press the 5 key twice in the initial stage of the maintenance mode. The "SCANNER AREA SET" will appear on the LCD. The equipment checks and sets the area to be scanned.

  • Page 124: Setting The Sensing Reference Level Of The Ink Empty Sensor

    5.3.12 Setting the Sensing Reference Level of the Ink Empty Sensor Function This function allows you to set the sensing reference level of the ink empty sensor which apply when the controller judges whether there is ink in the ink cartridge. The setting procedure requires a foam-empty cartridge as a reference cartridge.

  • Page 125: Alignment Of Vertical Print Lines

    5.3.13 Alignment of Vertical Print Lines Function This function allows you to align vertical lines printed in the forward and backward direction of the carriage. NOTE: Before this alignment job, be sure to correct the positioning error of the print head. Refer to CHAPTER 4, Section 4.3 "ADJUSTMENT."...
  • Page 126 Vertical Alignment Check Pattern 5 -2 1...

  • Page 127: Updating Of Head Property Information

    5.3.14 Updating of Head Property Information Function To keep the print quality, the controller optimizes the head drive strength, ink jet-out timing, and other drive conditions according to the electromechanical properties unique to individual print heads and ambient temperature. The head property information is stored in the EEPROM of the main PCB.

  • Page 128: Initial Adjustment Of Pwm Value (Aging Of The Carriage)

    5.3.15 Initial Adjustment of PWM Value (Aging of the Carriage) Function This function obtains the initial value of the PWM by aging the carriage and writes it onto the EEPROM, as well as checking the head drive voltage level. This aging procedure should be performed if you replace the print head, carriage ASSY, carriage motor, or encoder strip or if you loosen the timing belt.

  • Page 129: Eeprom Customizing

    The current customizing code (e.g., B001 in the case of MFC3100C U.S.A. versions) appears. (2) Enter the desired customizing code (e.g., 2002 in the case of MFC3100C Canadian versions). NOTE: To enter letters "A" through "F," press the 1 through 6 keys while holding down the # key, respectively.

  • Page 130: Display Of The Equipment's Log Information

    5.3.17 Display of the Equipment's Log Information Function The equipment may display the its log information on the LCD. Operating Procedure (1) Press the 8 and 0 keys in this order in the initial stage of the maintenance mode. The USB serial number appears on the LCD. (2) Press the Black Fax Start key.

  • Page 131: Equipment Error Code Indication

    5.3.18 Equipment Error Code Indication Function This function displays an error code of the last error on the LCD. Operating Procedure (1) Press the 8 and 2 keys in this order in the initial stage of the maintenance mode. The LCD shows the "MACHINE ERROR X X." (2) To stop this operation and return the equipment to the initial stage of the maintenance mode, press the Stop key.

  • Page 132: Cancellation Of The Pin Tx Lock Mode (Not Applicable To American Models)

    5.3.20 Cancellation of the Pin TX Lock Mode (Not applicable to American models) Function This procedure can cancel the Pin TX lock mode. Use this procedure if the user forgets his/her password entered when setting the Pin TX lock mode so as not to exit from the mode. NOTE: Carrying out this procedure will lose passwords previously entered but retain FAX messages received in the Pin TX lock mode.
  • Page 133 CHAPTER ERROR INDICATION AND TROUBLESHOOTING...
  • Page 134 CHAPTER 6 ERROR INDICATION AND TROUBLESHOOTING CONTENTS ERROR INDICATION.......................6-1 6.1.1 Equipment Errors ....................6-1 [ 1 ] Error messages on the LCD ................6-1 [ 2 ] Error codes shown in the "MACHINE ERROR X X " message....6-4 6.1.2 Communications Errors..................6-8 TROUBLESHOOTING ....................6-15 6.2.1 Introduction......................6-15 6.2.2...

  • Page 135: Error Indication

    6.1 ERROR INDICATION To help the user or the service personnel promptly locate the cause of a problem (if any), the facsimile equipment incorporates the self-diagnostic functions which display error messages for equipment errors and communications errors. For the communications errors, the equipment also prints out the transmission verification report and the communications list.

  • Page 136: Cooling Down

    Messages on the LCD Probable Cause CHECK DOCUMENT Document loading error CHECK ORIGINAL (1) The document rear sensor detects no leading edge of a Remove documents, then document within 10 seconds from the start of document press STOP KEY. loading operation. (The document rear sensor stays OFF even after the (These messages appear alternately.) document has been fed when the document front sensor...

  • Page 137: Scanner Error

    Messages on the LCD Probable Cause NEAR EMPTY CYAN The ink empty sensor detects that the ink cartridge (cyan, magenta, yellow, or black) is near empty. NEAR EMPTY MGENT Even if any of these messages is displayed, color printing is still NEAR EMPTY YELLW possible.

  • Page 138: 2 ] Error Codes Shown In The "Machine Error X X " Message

    [ 2 ] Error codes shown in the "MACHINE ERROR X X " message If the LCD shows the "PLS OPEN COVER" message, you can display the detailed error code following the MACHINE ERROR, by using the maintenance-mode function code 82 described in CHAPTER 5, Section 5.3.18.
  • Page 139 Error Code Error factor Check: (Hex) Flushing operation abnormally ended. (The head • Print head unit temperature has arisen abnormally.) The number of performed purge sequences has reached • Ink absorber box the limit. • Main PCB Head parameters stored in the EEPROM are invalid. •...
  • Page 140 Error Code Error factor Check: (Hex) Recording paper jam. • Paper width sensor actuator (The paper width sensor and/or registration sensor has • Registration sensor detected a paper jam.) actuator Recording paper jam. • Main PCB (Even after paper pulling-in operation, the registration sensor is still OFF.) Top cover or control panel opened.
  • Page 141 Error Code Error factor Check: (Hex) Black level data error. • CIS unit • Main PCB • CIS harness ∗ Modem error. • Main PCB Out of recording paper. • ASF • Registration sensor actuator • Document feed roller • Main PCB Write error in EEPROM.

  • Page 142: Communications Errors

    6.1.2 Communications Errors If a communications error occurs, the facsimile equipment emits an audible alarm (intermittent beeping) for approximately 4 seconds, displays the corresponding error message, and prints out the transmission verification report if the equipment is in sending operation. 6 -8...
  • Page 143 Definition of Error Codes on the Communications List Calling Code 1 Code 2 Causes Wrong number called. No dial tone detected before start of dialing. Busy tone detected before dialing. 2nd dial tone not detected. No loop current detected.* Busy tone detected after dialing or called. No response from the remote station in sending.
  • Page 144 Compatibility [checking the NSF and DIS] Code 1 Code 2 Causes Remote terminal only with V.29 capability in 2400 or 4800 bps transmission. Remote terminal not ready for polling. Remote terminal not equipped with password function or its password switch OFF. Remote terminal not equipped with or not ready for confidential mailbox function.
  • Page 145 Instructions received from the remote terminal [checking the NSC, DTC, NSS, and DCS] Code 1 Code 2 Causes Illegal coding system requested. Illegal recording width requested. ECM requested although not allowed. Polled while not ready. No document to send when polled. Nation code or manufacturer code not coincident.
  • Page 146 ID checking Code 1 Code 2 Causes Password plus "lower 4 digits of telephone number" not coincident. Password not coincident. Polling ID not coincident. DCN reception Code 1 Code 2 Causes DCN received. TCF transmission/reception Code 1 Code 2 Causes Fallback impossible.
  • Page 147 Signal isolation Code 1 Code 2 Causes Unable to detect video signals and commands within 6 seconds after CFR is transmitted. Received PPS containing invalid page count or block count. (10) Video signal reception Causes Code 1 Code 2 Error correction sequence not terminated even at the final transmission speed for fallback.
  • Page 148 (11) General communications-related Code 1 Code 2 Causes Unable to receive the next-page data. Unable to receive polling even during turn-around transmission due to call reservation. PC interface error. (12) Maintenance mode Code 1 Code 2 Causes Failed to detect 1300 Hz signal in burn-in operation. Failed to detect PB signals in burn-in operation.

  • Page 149: Troubleshooting

    6.2 TROUBLESHOOTING 6.2.1 Introduction This section gives the service personnel some of the troubleshooting procedures to be followed if an error or malfunction occurs with the facsimile equipment. It is impossible to anticipate all of the possible problems which may occur in future and determine the troubleshooting procedures, so this section covers some sample problems.
  • Page 150 Recording paper Check that: (1) A recommended type of recording paper is used. (2) The recording paper is not dampened. Ink cartridges (1) Check that all of four ink cartridges are loaded. Print head (1) Check that the print head is installed on the carriage correctly. (Check the dimple contact between the print head PCB and the carriage PCB.) (2) Repeat the head purging operation several times.

  • Page 151: Troubleshooting Procedures

    6.2.4 Troubleshooting Procedures [ 1 ] Control panel related Trouble Check: (1) LCD shows nothing. • Panel-main harness • Control panel PCB • Power supply PCB • Main PCB (2) Control panel inoperative. • Panel-main harness • Control panel PCB •...

  • Page 152: 3 ] Communications Related

    [ 3 ] Communications related Trouble Check: (1) No tone is transmitted. • Main PCB • NCU PCB [ 4 ] Paper/document feeding related Trouble Check: (1) Neither "COPY: PRESS • Sensors by using the maintenance-mode function code 32. COPY" nor "FAX: NO. & (Refer to CHAPTER 5, Subsection 5.3.9.) START"...

  • Page 153: 5 ] Print-Image Related

    [ 5 ] Print-image related If the received or sent image has any problem, first make a copy with the facsimile equipment. If the copied image is normal, the problem may be due to the remote terminal; if it is abnormal, proceed to the following checks: Trouble Action to be taken...
  • Page 154 Trouble Action to be taken (4) Light At the scanner Check the following components: - CIS unit - Main PCB At the printer Check the following components: - Ink cartridges - Print head unit - Main PCB - Power supply PCB - Print head parameters (to be installed to the main PCB from the connected PC.
  • Page 155 Trouble Action to be taken (7) Print edges not aligned At the printer • Check the alignment of vertical print lines by using the maintenance-mode function code 65. (Refer to CHAPTER 5, Subsection 5.3.13). • Check the print head unit. •...

  • Page 156: 6 ] Pc-Driven Printing

    Trouble Action to be taken (10) White horizontal streaks • For each of the four ink-jet units, perform the head purging operation several times to remove dust or air bubbles from its nozzles. • Replace the print head unit. • Check the paper feed-related rollers. •...
  • Page 157 Cleaning the purge unit (1) Unplug the machine's power cord from the wall socket. (2) Plug the power cord again. When you hear the carriage moving out of the home position for initialization, then unplug the power cord again. The carriage will stop at the middle of the travel.

  • Page 158: Appendix 1. Eeprom Customizing Codes

    MFC3100C/MFC580/MFC3200C/FAX1800C Appendix 1. EEPROM Customizing Codes...
  • Page 159 (2) Press the 7 and 4 keys in this order in the initial stage of the maintenance mode. The current customizing code (e.g., B001 in the case of MFC3100C U.S.A. versions) appears. (3) Enter the desired customizing code (e.g., 2002 in the case of MFC3100C Canadian version). The newly entered code appears.
  • Page 160 EEPROM Customizing Codes List (1) MFC3100C Model Versions MFC3100C U.S.A. B001 CANADA 2002 AUSTRALIA 2006 ASIA (SINGAPORE, 2040 HONG KONG) NEW ZEALAND 2027 (2) MFC580 Model Versions MFC580 GERMANY 2003 U.K. 2004 FRANCE 2005 BELGIUM 2008 NETHERLANDS 2009 SWITZERLAND 2010...

  • Page 161: Appendix 2. Firmware Switches (Wsw)

    MFC3100C/MFC580/MFC3200C/FAX1800C Appendix 2. Firmware Switches (WSW)
  • Page 162 WSW No. Function Reference Page WSW01 Dial pulse setting WSW02 Tone signal setting WSW03 PABX mode setting WSW04 TRANSFER facility setting WSW05 1st dial tone and busy tone detection WSW06 Pause key setting and 2nd dial tone detection WSW07 Dial tone setting 1 WSW08 Dial tone setting 2 WSW09...

  • Page 163: Wsw01 Dial Pulse Setting

    WSW01 (Dial pulse setting) Selector Function Setting and Specifications No. 1 2 Dial pulse generation mode 10-N No. 3 4 60 ms Break time length in pulse dialing 67 ms 40 ms (for 16 PPS) 64 ms (at 106-ms intervals) No.

  • Page 164: Wsw02 Tone Signal Setting

    Selector 7: Switching between pulse (DP) and tone (PB) dialing, by the function switch This selector determines whether or not the dialing mode may be switched between the pulse (DP) and tone (PB) dialing by using the function switch. Selector 8: Default dialing mode, pulse (DP) or tone (PB) dialing This selector sets the default dialing mode (pulse dialing or tone dialing) which may be changed by the function switch.

  • Page 165: Wsw03 Pabx Mode Setting

    WSW03 (PABX* mode setting) Selector Function Setting and Specifications CNG detection when sharing a modular wall socket with a 0: A 1: B telephone No. 2 3 4 0 0 0 : 50 ms 0 0 1 : 210 ms 0 1 0 : 500 ms Min.

  • Page 166: Wsw04 Transfer Facility Setting

    Selectors 6 and 7: Dial tone detection in PABX These selectors activate or deactivate the dial tone detection function which detects a dial tone when a line is connected to the PABX. Setting both of these selectors to "1" activates the dial tone detection function so that the equipment starts dialing upon detection of a dial tone when a line is connected.

  • Page 167: Wsw05 1St Dial Tone And Busy Tone Detection

    WSW05 (1st dial tone and busy tone detection) Selector Function Setting and Specifications No. 1 2 3 0 0 0 3.5 sec. WAIT 0 0 1 7.0 sec. WAIT 0 1 0 10.5 sec. WAIT 1st dial tone detection 0 1 1 14.0 sec.
  • Page 168 Selectors 5 and 6: Busy tone detection in automatic sending mode These selectors determine whether or not the equipment automatically disconnects a line upon detection of a busy tone in automatic sending mode. Setting selector 6 to "0" ignores a busy tone so that the equipment does not disconnect the line. Setting selectors 5 and 6 to "0"...

  • Page 169: Wsw06 Pause Key Setting And 2Nd Dial Tone Detection

    WSW06 (Pause key setting and 2nd dial tone detection) Selector Function Setting and Specifications No.1 2 3 0 0 0 : No pause 0 0 1 : 3.5 sec. WAIT 0 1 0 : 7 sec. WAIT 0 1 1 : 10.5 sec.
  • Page 170 Selectors 1 through 3: Pause key setting and 2nd dial tone detection Selectors No WAIT is inserted even if the Pause key is pressed. If you press the Pause key during dialing, the facsimile equipment will insert WAIT as defined in the above table. If the Pause key is pressed repeatedly, the equipment inserts the specified WAIT multiplied by the number of depressions.

  • Page 171: Wsw07 Dial Tone Setting

    WSW07 (Dial tone setting 1) Selector Function Setting and Specifications No. 1 2 : Narrows by 10 Hz Frequency band range : Initial value : Widens by 10 Hz Line current detection 0: No 1: Yes No. 4 5 6 0 0 : -21 dBm 0 1 : -24 dBm 1 0 : -27 dBm...

  • Page 172: Wsw08 Dial Tone Setting

    WSW08 (Dial tone setting 2) Selector Function Setting and Specifications No. 1 2 3 0 0 0 : 50 ms 0 0 1 : 210 ms 0 1 0 : 500 ms 1st dial tone detection time 0 1 1 : 800 ms length 1 0 0 :...

  • Page 173: Wsw09 Protocol Definition

    WSW09 (Protocol definition 1) Selector Function Setting and Specifications Frame length selection 256 octets 1: 64 octets Use of non-standard Allowed 1: Prohibited commands No. 3 4 times No. of retries 3 times 2 times 1 time T5 timer 0: 300 sec. 60 sec.

  • Page 174: Wsw10 Protocol Definition

    WSW10 (Protocol definition 2) Selector Function Setting and Specifications Not used. Time length from transmission of the last dial digit to CML 0: 100 ms 1: 50 ms Time length from CML ON to 0: 2 sec. 1: 4 sec. CNG transmission Time length from CML ON to CED transmission (except for...

  • Page 175: Wsw11 Busy Tone Setting

    WSW11 (Busy tone setting) U.S.A. and Canadian versions Selector Function Setting and Specifications No. 1 : Narrows by 10 Hz Frequency band range : Initial value : Widens by 10 Hz Not used. 1: 400-600/400-600 ms 1: 175-440/175-440 ms ON/OFF time length ranges (More than one setting 1: 100-1000 ms/17-660 ms allowed)

  • Page 176: Wsw12 Signal Detection Condition Setting

    WSW12 (Signal detection condition setting) Selector Function Setting and Specifications No. 1 1500 ms Min. OFF time length of 500 ms calling signal (Ci) 700 ms 900 ms No. 3 6 sec. Max. OFF time length of 7 sec. calling signal (Ci) 9 sec.

  • Page 177: Wsw13 Modem Setting

    WSW13 (Modem setting) Selector Function Setting and Specifications No. 1 0 km Cable equalizer 1.8 km 3.6 km 5.6 km No. 3 -43 dBm Reception level -47 dBm -49 dBm -51 dBm 0: 0 dB 1: 8 dB 0: 0 dB 1: 4 dB Modem attenuator 0: 0 dB...

  • Page 178: Wsw14 Auto Ans Facility Setting

    WSW14 (AUTO ANS facility setting) Selector Function Setting and Specifications No. 1 13 Hz Frequency band selection 15 Hz (Lower limit) 23 Hz 20 Hz No. 3 30 Hz Frequency band selection (Upper limit) 55 Hz 70 Hz No. 5 Fixed to once Fixed to 2 times Fixed to 3 times...

  • Page 179: Wsw15 Redial Facility Setting

    WSW15 (REDIAL facility setting) Selector Function Setting and Specifications No. 1 5 minutes Selection of redial interval 1 minute 2 minutes 3 minutes No. 3 16 times 1 times No. of redialings 2 times 3 times 15 times Redialing for no response sent 0: Redialing 1: No redialing from the called terminal...

  • Page 180: Wsw16 Function Setting

    WSW16 (Function setting 1) Selector Function Setting and Specifications Not used. ITU-T (CCITT) superfine 0: OFF 1: ON recommendation Not used. Max. document length 0: 400 cm 1: 90 cm limitation Stop key pressed during 0: Not functional 1: Functional reception Selector 2: ITU-T (CCITT) superfine recommendation...

  • Page 181: Wsw17 Function Setting

    WSW17 (Function setting 2 Selector Function Setting and Specifications No. 1 No alarm Always valid Off-hook alarm Valid except when 'call reservation' is selected. Not used. Calendar clock type U.S.A. type 1: European type Not used. Non-ring reception 1: ON Not used.

  • Page 182: Wsw18 Function Setting

    WSW18 (Function setting 3) Selector Function Setting and Specifications Not used. No. 2 40 sec. Detection enabled time for CNG 0 sec. (No detection) and no tone 5 sec. 80 sec. Not used. Registration of station ID Permitted Prohibited No. 7 No monitoring Up to phase B at the Tone sound monitoring...

  • Page 183: Wsw19 Transmission Speed Setting

    WSW19 (Transmission speed setting) Selector Function Setting and Specifications No. 1 First transmission speed choice No. 4 for fallback 2,400 bps 4,800 bps 7,200 bps 9,600 bps 12,000 bps Last transmission speed choice for fallback 14,400 bps Not used. V. 17 mode 0: Permitted 1: Prohibited Selectors 1 through 6:...

  • Page 184: Wsw20 Overseas Communications Mode Setting

    WSW20 (Overseas communications mode setting) Selector Function Setting and Specifications EP* tone prefix 0: OFF 1: ON Overseas communications 0: 2100 Hz 1: 1100 Hz mode (Reception) Overseas communications 0: OFF 1: Ignores DIS once. mode (Transmission) No. 4 100 ms Min.

  • Page 185: Wsw22 Ecm And Copy Resolution Setting

    WSW21 (TAD setting 1 Selector Function Setting and Specifications Not used. Erasure of message stored in the memory after the message 0: Yes 1: No transfer Selector 8: Erasure of message stored in the memory after the message transfer Setting this selector to "0" will erase the message recorded in the memory after the document retrieval feature transfers the message.

  • Page 186: Wsw23 Communications Setting

    WSW23 (Communications setting) Selector Function Setting and Specifications 0: From the head of a series of zeros Starting point of training check (TCF) 1: From any arbitrary point No. 2 Allowable training error rate 0.5% No. 4 Decoding error rate for transmission of RTN Not used.

  • Page 187: Wsw24 Tad Setting

    WSW24 (TAD setting 2) Selector Function Setting and Specifications Not used. 4 sec. Time length from CML ON to start of pseudo ring 3 sec. backtone transmission 2 sec. 1 sec. Not used. Selectors 3 and 4: Time length from CML ON to start of pseudo ring backtone transmission These selectors set the length of time from CML-ON up to the start of pseudo ring backtone transmission.

  • Page 188: Wsw26 Function Setting

    WSW26 (Function setting 4) Selector Function Setting and Specifications Not used. Dialing during document reading into the temporary 0: Disabled 1: Enabled memory in in-memory message transmission No. of CNG cycles to be No. 4 detected (when the line is connected via the external telephone except in the external TAD mode or via the built-in telephone)

  • Page 189: Wsw27 Function Setting

    WSW27 (Function setting 5) Selector Function Setting and Specifications Not used. Ringer OFF setting Not used. Detection of distinctive ringing pattern Not used. NOTE: Selector 4 is applicable only to the U.S.A. versions. Selector 2: Ringer OFF setting This selector determines whether or not the ringer can be set to OFF. Selector 4: Detection of distinctive ringing pattern If this selector is set to "1,"...

  • Page 190: Wsw28 Function Setting

    WSW28 (Function setting 6) Selector Function Setting and Specifications No. 1 2 3 0 0 0 0 dB 0 0 1 +1 dB 0 1 0 +2 dB Transmission level of DTMF 0 1 1 +3 dB high-band frequency signal 1 0 0 0 dB 1 0 1...

  • Page 191: Wsw29 Function Setting

    WSW29 (Function setting 7) Selector Function Setting and Specifications Not used. Impedance switching control in 0: OFF 1: ON pulse dialing Prompt beep when the memory area for the activity report 0: No 1: Yes becomes full NOTE: Selectors 7 and 8 are applicable only to the European versions. Selector 8: Prompt beep for activity report This selector determines whether or not the equipment will beep if the memory area for the activity...

  • Page 192: Wsw31 Function Setting

    WSW31 (Function setting 9) Selector Function Setting and Specifications Not used. Default reduction rate for failure of automatic reduction 0: 100% 1: 70% during recording Not used. Ink empty sensor 0: Yes 1: No Minimum short-OFF duration 0: 130 ms 1: 90 ms in distinctive ringing Not used.

  • Page 193: Wsw32 Function Setting

    WSW32 (Function setting 10) Selector Function Setting and Specifications Not used. No. 5 Standard Default resolution Fine Super fine Photo No. 7 Automatic Default contrast Super light Super dark Selectors 5 and 6: Default resolution These selectors set the default resolution which applies when the equipment is turned on or completes a transaction.

  • Page 194: Wsw33 Function Setting

    WSW33 (Function setting 11) Selector Function Setting and Specifications Not used. No. 4 : 14,400 bps FAX receiving speed to be kept within the transmission speed : 12,000 bps limit to the PC 9,600 bps 7,200 bps Report output of polled 0: Yes 1: No transmission requests...

  • Page 195: Wsw34 Function Setting

    WSW34 (Function setting 12) Selector Function Setting and Specifications Not used. No. of CNG cycles to be No. 4 detected (when the line is connected via the external telephone in the external TAD mode or via the facsimile equipment in F/T mode) No.

  • Page 196: Wsw36 Function Setting

    WSW36 (Function setting 14) Selector Function Setting and Specifications ECP mode* 0: ON Recovery from Inactive PC 0: Disabled Enabled Interface PC Power-off Recognition 0: Normal Long Time Not used. Escape from phase C 0: Yes No. 6 7 8 0 0 0 : 0 (Not ignored) 0 0 1 :...

  • Page 197: Wsw37 Function Setting

    Selectors 6 through 8: Lower limit of frequency to be ignored after detection of calling signals (Ci) At the start of reception, if the equipment detects the frequency of calling signals (Ci) specified by selectors 1 through 4 of WSW14, it will start the ringer sounding. When doing so, the equipment may fail to detect the calling signals normally due to noises superimposed at the time of reception.

  • Page 198: Wsw42 Function Setting

    WSW42 (Function setting 20) Selector Function Setting and Specifications Not used. JBIG coding 0: Disabled 1: Enabled Not used. WSW43 (Function setting 21 Selector Function Setting and Specifications Not used. No. 2 50 ms Wait time for PC-Fax reception (Class 2) and FPTS command : 100 ms transmission : 150 ms...

  • Page 199: Wsw46 Monitor Of Power On/Off State And Parallel Port Kept At High

    Delay time at the start of scanning for making a single copy According to the setting made by these selectors, the MFC models may delay the scanning start timing to prevent the carriage drive vibration from affecting the document scanning. No setting change is required unless otherwise specified by Brother.

  • Page 200: Wsw47 Paper Handling For A Feed Error And Delay Of Fax Line Disconnection

    WSW47 (Paper handling for a feed error and delay of FAX line disconnection) Selector Function Setting and Specifications Handling paper at the 0: Eject paper w/o print 1: Print on the current occurrence of a paper feed paper timing error Not used.

  • Page 201: Appendix 3. Circuit Diagrams

    MFC3100C/MFC580/MFC3200C/FAX1800C Appendix 3. Circuit Diagrams A. Main PCB (MFC3100C/MFC580) Main PCB (MFC3200C/FAX1800C) B. Network Control Unit (NCU) PCB (MFC3100C/MFC580) Network Control Unit (NCU) PCB (MFC3200C/FAX1800C) C. Control Panel PCB (MFC3100C/MFC580) Control Panel PCB (MFC3200C/FAX1800C) D. Power Supply PCB Terms in circuit diagrams...
  • Page 202 A. Main PCB (1/6) (MFC3100C/MFC580)
  • Page 203 A. Main PCB (2/6) (MFC3100C/MFC580)
  • Page 204 A. Main PCB (3/6) (MFC3100C/MFC580)
  • Page 205 A. Main PCB (4/6) (MFC3100C/MFC580)
  • Page 207 A. Main PCB (6/6) (MFC3100C/MFC580)
  • Page 208 A. Main PCB (1/6) (MFC3200C/FAX1800C)
  • Page 209 A. Main PCB (2/6) (MFC3200C/FAX1800C)
  • Page 210 A. Main PCB (3/6) (MFC3200C/FAX1800C)
  • Page 211 A. Main PCB (4/6) (MFC3200C/FAX1800C)
  • Page 212 A. Main PCB (5/6) (MFC3200C/FAX1800C)
  • Page 213 A. Main PCB (6/6) (MFC3200C/FAX1800C)
  • Page 214 B. NCU PCB (MFC3100C/MFC580)
  • Page 215 B. NCU PCB (MFC3200C/FAX1800C)
  • Page 216 C. Control Panel PCB (MFC3100C/MFC580)
  • Page 217 C. Control Panel PCB (MFC3200C/FAX1800C)
  • Page 218 Power Supply PCB...
  • Page 219 Sep. ’02 SM-FAX004(4) 8XA401 Printed in Japan...

This manual is also suitable for:

Mfc580Mfc3200cFax1800c

Table of Contents
