Summary of Contents for STIEBEL ELTRON SHP-0 200 Plus
- Page 1 Operation and installation SHP-O 200 Plus SHP-O 300 Plus Domestic hot water heat pump...
-
Page 2: Table Of Contents
Table of contents 1 Special information ........... 3 15.1 Descaling the electric emergency/auxiliary heater.............. 20 2 General information..........3 15.2 Checking valves ..........21 Units of measurement ........3 15.3 Checking consumption indicator on signal an- Symbols in this document ........ 3 ode.............. -
Page 3: Special Information
Special information Special information General information – The appliance may be used by children over u Read these instructions carefully before using the 8 years of age and persons with reduced appliance and retain them for future reference. physical, sensory or mental capabilities or a lack of experience and expertise, provided Information for Australia and New Zealand that they are supervised or they have been... -
Page 4: Safety
Safety Observation of these instructions, the instructions for any ac- Safety cessories used as well as the specifications also forms part of the correct use of this appliance. Structure of the warning notices Foreseeable misuse 3.1.1 Section-specific warning notices Any other use beyond that described shall be deemed to be out- Section-specific warning notices apply to all steps in the section. -
Page 5: Appliance Description
Appliance description – WARNING: If the hot water unit is not used for two or more Function weeks, an amount of highly flammable hydrogen gas may There is a closed circuit within the heat pump which contains accumulate in the water tank. To dissipate this gas safely, it refrigerant. - Page 6 Appliance description SHP-O 200 Plus: You can use the following functions with the MyStiebel app: – Establish a connection between a smartphone and the ap- pliance from anywhere in the world (integration in the cloud) – Set the temperature – Set the heating type (efficient, balanced, fast) –...
- Page 7 Appliance description The defrosting process is shown in the MyStiebel app until it fin- ishes. 4.3.4 Frost protection / holiday The operating modes must be activated in order to use the func- tions. The appliance activates a frost protection function if the DHW Servicewelt Servicewelt temperature is below a limit value (< 8 °C).
-
Page 8: Transportation (Qualified Contractors)
Transportation (qualified contractors) – Energy management system u Carry the appliance to its installation site by the recessed grips. – Signal from the power supply utility (EVU) that interrupts the power supply Only transport appliance with cardboard back panel without a pallet 4.3.8 Runtime-dependent rapid heat-up u Cut the vertical straps. -
Page 9: Installation (Qualified Contractors)
Installation (qualified contractors) Minimum clearances Installation (qualified contractors) – Leave sufficient space to provide access for installation, maintenance and cleaning. Maintain the required minimum Installation site clearances. Property damage, consequential losses, environmental pollution – Observe the need for a properly drained safe-tray under the appliance where leakage may cause damage. -
Page 10: Siting The Appliance
Installation (qualified contractors) Siting the appliance u Cut the vertical straps. u Remove the cardboard sleeve from the appliance. D0000117569_L Water connection ü The electrical conductivity of the DHW is within the limits specified to ensure cathodic corrosion protection (see chapter Data table [} 29] ). -
Page 11: Condensate Drain
Commissioning (qualified contractors) Temperature and pressure relief valve D0000117570 u Size the drain pipe so that water can drain off unimpeded when the temperature and pressure relief valve is fully opened. u Hot expansion water escapes from the temperature and pressure relief valve. - Page 12 Commissioning (qualified contractors) 8.2.2 Connection variant: Operation with external switching device that interrupts appliance power supply u Prepare the electric cables in such a way that each cable terminates with a wire ferrule. D0000117573 u Release the lock on the underside of the control panel. u Push the control panel cover down slightly and remove it.
- Page 13 Commissioning (qualified contractors) – The minimum pause time following a shutdown is 20 minutes. – Do not switch the appliance on or off more than 10 times a day using an external switching device. – The contact load capacity of the switching actuator must satisfy the fuse protection requirements according to the data table.
-
Page 14: Initial Start-Up
Commissioning (qualified contractors) Example 2: Photovoltaic signal via on-site relay and phase routed outside the appliance The relay in the inverter or photovoltaic system must meet the following requirements: – Potential-free relay (240 V AC, 1 A) with N/O contact – Adherence to safety regulations and standards for safety ex- tra low voltage –... -
Page 15: Operation
Operation Symbol Meaning Operation – Flashing slowly Frost protection active, SG Ready function active Display and controls – Flashing rapidly The appliance can be operated via an app and the buttons on Load shedding the appliance. – On Frost protection active Button Meaning Rapid heat-up... -
Page 16: Activating/Deactivating Rapid Heat-Up
Settings 11.1 Cleaning the casing top After the appliance has been successfully integrated into the network, communication between the appliance and the mobile u Clean the casing top with a cloth moistened with water. end device may be restricted for several minutes. If this occurs, it does not indicate an error;... -
Page 17: Troubleshooting
Troubleshooting u Remove the insulation material screw before removing the Fault Possible cause Remedy insulation on the air discharge side. connected to the power sup- u Remove the insulation on the air intake side. ply. u WARNING: The sharp-edged fins of the evaporator can The appliance does The air intake grille u Remove dirt or... -
Page 18: Activating/Deactivating Emergency Heating Mode
If you cannot remedy the fault, contact STIEBEL ELTRON. u To facilitate and speed up your enquiry, please provide STIEBEL ELTRON with the number from the type plate. The type plate is located next to the power cable. -
Page 19: Troubleshooting (Qualified Contractors)
Troubleshooting (qualified contractors) 14 Troubleshooting (qualified con- tractors) u Please also observe the notifications in the Servicewelt app. Fault Possible cause Remedy The appliance does The appliance has u Replace the not supply hot wa- no power. The power cable. ter. -
Page 20: Maintenance (Qualified Contractors)
Maintenance (qualified contractors) 15 Maintenance (qualified contractors) You may only carry out maintenance work as described here. Component Activity Interval Electric emergency/ Descale the emer- For the first time auxiliary heater gency/auxiliary after 1 year heater to increase As required its service life. If necessary, shorten the interval depend- ing on the water... -
Page 21: Checking Valves
Maintenance (qualified contractors) u Fit the insulation on the emergency/auxiliary heater. Checking consumption indicator on signal anode u Replace the control panel cover. u Lock the control panel. u Reconnect the appliance to the power supply. 15.2 Checking valves u Regularly check the valves in the system to ensure the oper- ational reliability of the appliance. -
Page 22: Shutdown (Qualified Contractors)
STIEBEL ELTRON maintenance and service guidelines shall be Checks to the area followed. If in doubt consult the STIEBEL ELTRON technical de- partment for assistance. The following checks shall be applied to Prior to beginning work on systems containing flammable refri-... - Page 23 This process may need to be repeated several ginal spare parts from STIEBEL ELTRON. times. Compressed air or oxygen shall not be used for this task.
- Page 24 Maintenance and inspection (qualified contractors) recovered safely. Prior to the task being carried out, an oil and refrigerant sample shall be taken in case analysis is required prior to re-use of reclaimed refrigerant. It is essential that elec- trical power is available before the task is commenced. u Become familiar with the equipment and its operation.
-
Page 25: Specification
Specification 18 Specification 18.1 Dimensions and connections 18.1.1 SHP-O 200 Plus D0000117729 Entry electrical cables Cold water inlet Male thread DHW outlet Male thread T&P valve Female thread Rp ½ Condensate drain Male thread G ¾ Air intake Air discharge Cover for manufacturing aper- ture www.stiebel-eltron.com... - Page 26 Specification 18.1.2 SHP-O 300 Plus D0000117737 Entry electrical cables Cold water inlet Male thread DHW outlet Male thread T&P valve Female thread Rp ½ Condensate drain Male thread G ¾ Air intake Air discharge Cover for manufacturing aper- ture | SHP-O Plus www.stiebel-eltron.com...
-
Page 27: Wiring Diagram
Specification 18.2 Wiring diagram FC11 Fuse 1.25 A FH800 Retainer for fuse AA02 Integral control unit 1 EB R.WWP MA01 Compressor motor AA06 Programming unit MA04 Motor, expansion valve AA09 Wireless module MA20 Motor, heat pump fan BP03 Pressure sensor, low pressure (16 bar) S200 DIP switch BP05... - Page 28 Specification MA04 MA01 (FA01) MA20 CA01 BP05 GNYE GYBN GNYE WHGY YEBN WHYE BNGN XE19 XE17 WHGN GYPK RDBU XD20 XD14 1 N 2 GNYE GNYE AA02 FH800 (FC11) AA09 X604 4x GY X606 T > X621 BT55 X100 X620 X601 AA06 X618...
-
Page 29: Data Table
Specification 18.3 Data table SHP-O 200 Plus SHP-O 300 Plus 204472 204473 Hydraulic data Nominal capacity Application limits Max. DHW temperature with °C heat pump Max. DHW temperature with °C emergency/auxiliary heater Max. permissible DHW temper- °C ature in the cylinder High limit safety cut-out °C Min./max. - Page 30 Specification SHP-O 200 Plus SHP-O 300 Plus Weight, full Connections Condensate connection G 3/4 A G 3/4 A Water connection G 1 A G 1 A Safety valve connection Rp 1/2 Rp 1/2 Values Type of anode Signal anode Signal anode Air flow rate m³/h Recommended number of users Further details...
-
Page 31: Warranty
Who gives the warranty – The serial number of the unit; The warranty is given by Stiebel Eltron (Aust) Pty Ltd – The date of purchase of the unit and the name of the (A.B.N. 82 066 271 083) of 294 Salmon Street, Port Mel- seller of the unit;... -
Page 32: Guarantee
19. The Stiebel Eltron warranty for the unit is in addition to any rights and remedies you may have under the Aus- tralian Consumer Law. - Page 33 www.stiebel-eltron.com SHP-O Plus |...
- Page 34 | SHP-O Plus www.stiebel-eltron.com...
- Page 35 www.stiebel-eltron.com SHP-O Plus |...
- Page 36 Co m f o r t t h r o u gh Te c h n o l o g y STIEBEL ELTRON GmbH & Co. KG Dr.-Stiebel-Straße 33 | 37603 Holzminden | Germany info@stiebel-eltron.com | www.stiebel-eltron.com 4 0 1 7 2 1 3 6 5 7 7 4 3...
