- Page 1 OPERATION AND INSTALLATION Air | water heat pump » WPL 09 ICS classic » WPL 09 IKCS classic » WPL 17 ICS classic » WPL 17 IKCS classic...
-
Page 2: Table Of Contents
CONTENTS SPECIAL INFORMATION 12.2 Fitting the side panels 20 12.3 Fitting the front panel 20 OPERATION Routing the air hoses �������������������������������������� 21 General information �����������������������������������������3 13.1 Connection with air routing accessory Relevant documents 3 LSWP 315 AWG Set 21 Safety instructions 3 13.2 Connection with quick-fit adaptor ZSA 315 22 Other symbols in this documentation 4... -
Page 3: Special Information
SPECIAL INFORMATION | OPERATION General information SPECIAL INFORMATION OPERATION - The appliance may be used by children aged 8 General information and older and persons with reduced physical, sensory or mental capabilities or a lack of ex- The chapters "Special information" and "Operation" are intended for both users and qualified contractors. -
Page 4: Other Symbols In This Documentation
OPERATION Safety Other symbols in this documentation Safety Note Intended use General information is identified by the adjacent symbol. The appliance is designed for central heating and cooling within f Read these texts carefully. the application limits provided in the specification. The appliance is intended for domestic use. -
Page 5: Appliance Description
OPERATION Appliance description Appliance description 3.1.2 Cooling The appliance is an air | water heat pump that oper- Material losses ates as a heating heat pump. The appliance extracts heat The heat pump is not suitable for continuous, year-round from the outdoor air at a low temperature level and trans- cooling. -
Page 6: Troubleshooting ����������������������������������������������6 17.2 Resetting The Temperature Controller
OPERATION Troubleshooting Troubleshooting Fault Cause Remedy There is no hot No power at the appli- Check the fuses/MCBs in your water or the ance. distribution board. Replace the heating system fuses/reset the MCBs if required. remains cold. Notify your qualified contractor if the fuses/MCBs blow/trip again after switching the system back Water is leaking... -
Page 7: Safety
INSTALLATION Safety INSTALLATION Required accessories If installing a new appliance - 2x air routing accessory LSWP 315 AWG Set Safety The air routing accessory is available in different lengths (0.7-4 m), in silver (SR) or grey (GL), and as a version for light wells (L): Only a qualified contractor should carry out installation, commis- - LSWP 315-0.7 S AWG SR Set sioning, maintenance and repair of the appliance. -
Page 8: Minimum Clearances
INSTALLATION Preparation f Implement pipe outlets through walls and ceilings with an- WPL 09 IKCS classic | WPL 17 IKCS classic ti-vibration insulation. Minimum clearances WPL 09 ICS classic | WPL 17 ICS classic ≥300 ≥500 ≥300 ≥500 f Maintain the minimum clearances to ensure trouble-free op- eration of the appliance and facilitate maintenance work. f Maintain the minimum clearances to ensure trouble-free op- eration of the appliance and facilitate maintenance work. -
Page 9: Preparing The Installation Location
INSTALLATION Preparation Preparing the installation location Wall outlet f Observe chapter "Sound emissions". Note The air duct connection on the wall outlet is oval. When Material losses selecting the installation position for the wall outlet, note The installation room floor must be water resistant. Dur- how the connections on the appliance are arranged, to ing appliance operation, the outdoor air releases up to ensure that the air hose will not have to be twisted. - Page 10 INSTALLATION Preparation 9.4.1 WPL 09 ICS classic | WPL 17 ICS classic f Select one of the possible installation versions. Air routing with a shaft: Through an exterior wall | Through two external walls around a corner ≥600 ≥600 ≥R170 ≥500 ≥120 ≥100 ≥1000 ≥1000 ≥2000 ≥358 9.4.2 WPL 09 IKCS classic | WPL 17 IKCS classic f Select one of the possible installation versions.
-
Page 11: Preparing The Electrical Installation
INSTALLATION Preparation Air routing without a shaft: Through two external walls around a corner LSWP 315-0.7 S AWG SR Set LSWP 315-0.7 S AWG GL Set 236930 237762 Length ≥450 ≥500 ≥450 ≥450 ≥1125 ≥670 9.4.3 Example: Installation with an air hose of 2 m in length 9.4.4 Insulating the brickwork Ensure that no cold bridges form between the brickwork and the wall outlets. -
Page 12: Buffer Cylinder
INSTALLATION Installation 10. Installation Material losses Provide common fuses/MCBs for the appliance control 10.1 Transport cable and the heat pump manager. If possible, transport the appliance to the installation site on the f Use cables with the relevant cross-sections. Observe the ap- non-returnable pallet. -
Page 13: Siting
INSTALLATION Installation 10.3 Flow and return connection 10.1.1 Transport using a transport aid To facilitate transport, you can fit a transport aid to the r.h. side Material losses panel of the appliance (see chapter "Appliance description / Fur- In cooling mode, condensate can form when the dew ther accessories"). -
Page 14: Heating Water Connection
INSTALLATION Installation 10.5 Heating water connection Making the push-fit connection The connector must be in its relaxed position before the pipe is Material losses inserted. In this position, there is a small gap between the screw The heating system to which the heat pump is connected cap and main body. -
Page 15: Condensate Drain And Overpressure Valve
INSTALLATION Installation 10.8 Condensate drain and overpressure valve 10.11 Filling the heating system Heating water quality Carry out a fill water analysis before filling the system. This analy- sis may, for example, be requested from the relevant water supply utility. Material losses To avoid damage as a result of scaling, it may be neces- sary to soften or desalinate the fill water. -
Page 16: Venting The Heating System
INSTALLATION Installation 10.12 Venting the heating system 10.13 Minimum flow rate The minimum flow rate and the defrost energy must always be Automatic air vent valve in the multifunction assembly MFG assured (see chapter "Specification / Data table"). f Remove the cover panel in front of the refrigerant circuit (see chapter "Fitting the appliance casing"). -
Page 17: Electrical Connection
Lead room Number of cir- floor area cuits floor area cuits m² n x m m² n x m WPL 09 ICS classic 400 2x70 2x70 WPL 09 IKCS classic 400 2x70 2x70 WPL 17 ICS classic 600 3x70 2x70 WPL 17 IKCS classic 600... - Page 18 INSTALLATION Electrical connection Terminal XD02: Appliance and electric emergency/booster Heat pump manager terminal assignment heater (DHC) WARNING Electrocution f Connect the power supply for the electric emergency/booster Only components that operate with safety extra low heater to terminal XD02 if you want to utilise the following voltage (SELV) and that ensure secure separation from appliance functions: the mains voltage supply may be connected to the low...
-
Page 19: Fitting The Appliance Casing
INSTALLATION Fitting the appliance casing 11.1.1 Internet Service Gateway ISG Safety extra low voltage X1.18 CAN (connection for FET remote control and The Internet Service Gateway ISG enables you to operate the heat CAN B ISG Internet Service Gateway) pump within your local home network and via the internet when you are away. -
Page 20: Fitting The Side Panels
INSTALLATION Fitting the appliance casing 12.2 Fitting the side panels f Position the programming unit from the front in the designer fascia. f Keep hold of the programming unit as you push the retaining frame onto it from behind. f Connect the connecting cable to the programming unit. Ensure that it is connected correctly. -
Page 21: Routing The Air Hoses
INSTALLATION Routing the air hoses f Never incorporate more than four 90° bends. The radius of the bends must be at least 170 mm, relative to the centre of the hose. f Secure the air hose at intervals of approx. every 1 m to pre- vent it from sagging. -
Page 22: Connection With Quick-Fit Adaptor Zsa 315
INSTALLATION Commissioning 13.2 Connection with quick-fit adaptor ZSA 315 Note If air hoses and wall outlets AWG 315 are available, the quick-fit adaptors ZSA 315 can be used to connect the air hoses to the appliance. f Observe the quick-fit adaptor installation instructions. f If the air hose is too long for the installation situation, you may need to trim it. -
Page 23: Appliance Shutdown
INSTALLATION Appliance shutdown 15.2 Power interruption If the "HEATING CURVE" parameter has been raised and outside temperatures relatively high, adjust the zone valve or thermostatic If the system is to be isolated from the power supply permanently, valve in the lead room to the required temperature. please observe the following: Material losses Material losses... -
Page 24: Control Elements On The Iws
INSTALLATION Troubleshooting 17.1 Control elements on the IWS WP - Typ If the fault cannot be identified using the WPM, the IWS will help you to troubleshoot. DIP switch (BA) Factory setting 1 Reset button 2 DIP switch (WP-Typ) 3 DIP switch (BA) 4 LEDs 17.1.2 Light emitting diodes (LEDs) 17.1.1 DIP switch... -
Page 25: Fan Noise
INSTALLATION Maintenance 18. Maintenance 17.1.3 Reset button If the IWS was incorrectly initialised, you can reset the settings with this button. WARNING Electrocution f Prior to commencing any service or cleaning work, f For this, also observe chapter "Reinitialising the IWS" in the isolate the appliance across all poles from the heat pump manager commissioning instructions. -
Page 26: Cleaning The Condensate Drain
INSTALLATION Maintenance f Pull the EPS cover 6 to 8 cm to the right. Material losses f Tilt the top of the EPS cover towards you from the appliance. When cleaning the evaporator fins, ensure that no water f Pull the EPS cover upwards to remove. comes into contact with the PCB. - Page 27 INSTALLATION Maintenance www.stiebel-eltron.com WPL ICS classic | WPL IKCS classic |...
-
Page 28: Operation Of The Appliance In Buildings With 19. Specification
INSTALLATION Specification 19. Specification 19.1 Dimensions and connections WPL 09 ICS classic | WPL 17 ICS classic WPL 09 ICS classic WPL 17 ICS classic Entry electrical cables Safety valve drain Diameter Heat exchanger flow Diameter Heat exchanger return Diameter d44 Outlet condensate drain Diameter Heating flow... - Page 29 INSTALLATION Specification WPL 09 IKCS classic | WPL 17 IKCS classic WPL 09 IKCS classic WPL 17 IKCS classic Entry electrical cables Safety valve drain Diameter Heat exchanger flow Diameter Heat exchanger return Diameter d44 Outlet condensate drain Diameter Heating flow Diameter Heating return Diameter Air intake Nominal diameter DN 315 DN 315...
-
Page 30: Wiring Diagram
INSTALLATION Specification 19.2 Wiring diagram AA07 MFG KF20 KF22 KF21 2. W 4 3 2 1 3 2 1 3 2 1 6 5 4 3 2 1 4 3 2 1 4 3 2 1 5 4 3 2 1 5 4 3 2 1 XE14 “+”... - Page 31 INSTALLATION Specification AA01 (WPM4) X1.19 X2.15 X1.18 X2.14 Mischer Heizkreis 2 PWM Ausgang 2 X1.17 PWM Ausgang 1 X1.16 X2.13 Analogeingang 0...10V X1.15 X2.12 Zirkulationspumpe / Analogeingang 0...10V X1.14 X2.11 2.WE Warmwasser Störausgang X1.13 X2.10 Zirkulationsfühler X1.12 X2.9 VL Kühlen X1.11 X2.8 2.
- Page 32 INSTALLATION Specification AA01 WPM heat pump manager X1.17 WPM PWM output 2 AA02 Integral heat pump control unit 1 IWS3 MOD.LC X1.19 WPM CAN MFG AA04 Inverter X2.1 WPM power supply AA06 Programming unit X2.2 WPM L’ (power supply utility input), L* (pumps L) AA07 PCB, booster heater MFG X2.3...
-
Page 33: Output Diagrams
INSTALLATION Specification 19.3 Output diagrams 19.3.1 WPL 09 ICS classic | WPL 09 IKCS classic Heating output X Outside temperature [°C] Y Heating output [kW] 1 max. W55 2 max. W45 3 max. W35 4 min. W55 5 min. W45 6 min. W35 www.stiebel-eltron.com WPL ICS classic | WPL IKCS classic |... - Page 34 INSTALLATION Specification DHW output X Outside temperature [°C] Y DHW output [kW] 1 max. W55 2 max. W45 4 min. W55 5 min. W45 |WPL ICS classic | WPL IKCS classic www.stiebel-eltron.com...
- Page 35 INSTALLATION Specification Cooling capacity X Flow temperature [°C] Y Cooling capacity [kW] 1 max. A35 2 min. A35 www.stiebel-eltron.com WPL ICS classic | WPL IKCS classic |...
- Page 36 INSTALLATION Specification 19.3.2 WPL 17 ICS classic | WPL 17 IKCS classic Heating output X Outside temperature [°C] Y Heating output [kW] 1 max. W55 2 max. W45 3 max. W35 4 min. W55 5 min. W45 6 min. W35 |WPL ICS classic | WPL IKCS classic www.stiebel-eltron.com...
- Page 37 INSTALLATION Specification DHW output X Outside temperature [°C] Y DHW output [kW] 1 max. W55 2 max. W45 4 min. W55 5 min. W45 www.stiebel-eltron.com WPL ICS classic | WPL IKCS classic |...
- Page 38 INSTALLATION Specification Cooling capacity X Flow temperature [°C] Y Cooling capacity [kW] 1 max. A35 2 min. A35 |WPL ICS classic | WPL IKCS classic www.stiebel-eltron.com...
-
Page 39: Data Table
INSTALLATION Specification 19.4 Data table The output data refers to new appliances with clean heat exchangers. The power consumption of the integral auxiliary drives represents the maximum value and may vary subject to operating point. The power consumption of the integral auxiliary drives is included in the output data for the appliance (to EN 14511). WPL 09 ICS clas- WPL 09 IKCS WPL 17 ICS clas-... - Page 40 INSTALLATION Specification WPL 09 ICS clas- WPL 09 IKCS WPL 17 ICS clas- WPL 17 IKCS classic classic Application limits Min. application limit, heat source °C Max. application limit, heat source °C Min. application limit on the heating side °C Max.
- Page 41 INSTALLATION Specification Further details WPL 09 ICS classic WPL 09 IKCS classic WPL 17 ICS classic WPL 17 IKCS classic 236375 236377 236376 236378 Maximum altitude for instal- 2000 2000 2000 2000 lation www.stiebel-eltron.com WPL ICS classic | WPL IKCS classic |...
-
Page 42: Guarantee
GUARANTEE | ENVIRONMENT AND RECYCLING Guarantee The guarantee conditions of our German companies do not apply to appliances acquired outside of Germany. In countries where our subsidiaries sell our products a guarantee can only be issued by those subsidiaries. Such guarantee is only grant- ed if the subsidiary has issued its own terms of guarantee. - Page 43 NOTES www.stiebel-eltron.com WPL ICS classic | WPL IKCS classic |...
- Page 44 Deutschland Verkauf Tel. 05531 702-110 | Fax 05531 702-95108 | info-center@stiebel-eltron.de STIEBEL ELTRON GmbH & Co. KG Kundendienst Tel. 05531 702-111 | Fax 05531 702-95890 | kundendienst@stiebel-eltron.de Dr.-Stiebel-Straße 33 | 37603 Holzminden Ersatzteilverkauf Tel. 05531 702-120 | Fax 05531 702-95335 | ersatzteile@stiebel-eltron.de Tel.
