User ' ' s Manual
Intel Socket 478 CPU
Pentium 4
Celeron D
Celeron
* Please read this manual throughly before installation.
http://www.zalman.co.kr
(English version)
CNPS9500A
Intel Socket 775 CPU
Core 2 Duo
Pentium D
Pentium 4
Celeron D
AMD Socket AM2/754/939/940 CPU
Athlon 64
Athlon 64 X2 Dual-Core
Athlon 64 FX
Opteron
Dual-Core Opteron
Sempron
http://www.zalmanusa.com
Ver. 2.0
Advertisement
Related Manuals for ZALMAN CNPS9500A
Summary of Contents for ZALMAN CNPS9500A
- Page 1 Ver. 2.0 User ’ ’ s Manual (English version) CNPS9500A Intel Socket 775 CPU Core 2 Duo Pentium D Pentium 4 Celeron D Intel Socket 478 CPU Pentium 4 Celeron D Celeron AMD Socket AM2/754/939/940 CPU Athlon 64 Athlon 64 X2 Dual-Core...
-
Page 2: Specifications
(Note 1) The maximum weight specified for a cooler is 450g for Intel Socket 775/478 and AMD Socket AM2/754/939/940. Special care and attention must be taken when moving a computer equipped with a cooler exceeding the specified weight limit. Zalman Tech Co., Ltd. is not responsible for any damage resulting from moving a computer. - Page 3 5) Do not ingest or make oral contact with the Thermal Grease. If ingested, get medical attention. Disclaimer) Zalman Tech Co., Ltd. is not responsible for any damages due to external causes, including but not limited to, improper use, problems with electrical power, accident, neglect, alteration, repair, improper installation, or improper testing.
-
Page 4: Installation Requirements
8. Installation Requirements Cases equipped with an Air Guide must have their Air Guide Ducts removed before installation. Install only on systems meeting the following conditions; ① There must be no interfering components (e.g. PSU, VGA card) within 56mm distance from the center of the PSU. - Page 5 Clip(⑦) according to the orientation of the Retention Frame. ④ ④ Cooler Installation Insert the Clip Lever A(⑧) into the Clip(⑦). Place the CNPS9500A on the center of the CPU. Connect the Clip’ s Lug Slot with the Arrow marked Lug of the Clip Support for Socket 775(⑨).
- Page 6 ④ ④ Cooler Installation Insert the Clip Lever A(⑧) into the Clip(⑦). Place the CNPS9500A on the center of the CPU. Connect the Clip’ s Lug Slot with a Lug of the Clip Support for Socket 478(⑫). Press onto the Clip Lever A(⑧) when aligning and connecting the Lever’...
- Page 7 Clip(⑦) according to the orientation of the Retention Frame. ③ ③ Cooler Installation Insert the Clip Lever B(⑬) into the Clip(⑦). Place the CNPS9500A on the center of the CPU. Connect the Clip’ s Lug Slot with a Lug of the motherboard’ s Retention Frame. Press onto the Clip Lever B(⑬) when aligning and connecting the Lever’...
- Page 8 Speed Control Knob. Note) Fan Mate 2 has been specifically designed for the fan of this product. Zalman Tech Co., Ltd. is not responsible for any damages to the system or CPU resulting from its use with other types of fans.
- Page 9 12. Zalman Computer Noise Prevention Systems Zalman's Noiseless Power Supplies, Fanless Northbridge Coolers, Heatpipe HDD Cooler, Noiseless Case Fans, VGA Coolers, and Fan Controllers facilitate stable performance and a noiseless computing environment. Fanless Northbridge Cooler Heatpipe HDD Cooler Noiseless Power Supply...
