Camplex CMX-12GSDI-MINI Manual

Mini 12g-sdi over st fiber extender

Advertisement

Quick Links

CMX-12GSDI-MINI
Camplex MINI 12G-SDI
over ST fiber extender
E x p o r t I n f o r m a t i o n
U S E C C N : E A R 9 9
H T S C o d e : 8 5 4 4 . 4 2
sales@camplex.com
U S D e p t . o f C o m m e r c e C C A T S : N . a
www.camplex.com
A D i v i s i o n o f T o w e r P r o d u c t s I n c o r p o r a t e d
R e v i s i o n # 0 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the CMX-12GSDI-MINI and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Camplex CMX-12GSDI-MINI

  • Page 1 CMX-12GSDI-MINI Camplex MINI 12G-SDI over ST fiber extender E x p o r t I n f o r m a t i o n U S E C C N : E A R 9 9 H T S C o d e : 8 5 4 4 . 4 2 sales@camplex.com...
  • Page 2 Safety Precautions: Please read all instructions before installing or operating this equipment and connecting the power supply. Please keep the following in mind as you unpack and install the unit: 1. To prevent fire or shock hazards, do not expose this equipment to high humidity and/or dust. Do not use in an unprotected outdoor installation nor any area classified as overly damp or wet.
  • Page 3 CMX-12GSDI-MINI Introduction: The Camplex CMX-12GSDI-MINI is a compact 12G-SDI fiber extender that can transmit 12G-SDI signals up to 20km (12 mi) over one Single Mode ST fiber. Its unique design allows connection directly to equipment without the need for additional SDI cables. This single-link ST-2082-1 compliant system is directly compatible with DVB-ASI, AES10 (MADI), and 12G/6G/3G-SDI camera systems.
  • Page 4 Specifications: Dimensions (Inches): 0.76 x 0.76 x 1.96 Fiber Optical Connector: ST Fiber Type: Single Mode Fiber Transmission Distance: 10km Supported SDI Signal: 12G-SDI, 6G-SDI, 3G-SDI, HD-SDI, SD-SDI Data Rate: Up to 11.88 Gb/s Operation Temperature: -40°F to 185°F (-40°C to 85°C) Power Supply: DC +5V, 5.5mm DC Jack ICC: Tx: Max 200mA...
  • Page 5 Application Diagram: Single Mode Fiber Up to 20km Transmitter Receiver Installation Instructions: This product consists of a transmitter and receiver. These units are interconnected via a single- channel ST optical cable utilizing Single-Mode Fiber. First, remove the locking metal dust covers from the ST fiber optic connectors on the Transmitter (Tx) and receiver (Rx).
  • Page 6 Camplex specifically disclaims all other warranties, expressed or implied, and the installation or use of this product shall be deemed to be an acceptance of these terms by the user. Camplex reserves the right to repair or replace items identified as within warranty.
