ICON PRO-FORM 425 CT User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
www.proform.com
Model No. PFTL49612.2
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
ACTIVATE YOUR
WARRANTY
To register your product and
activate your warranty today,
go to www.proformservice.com/
registration.
CUSTOMER CARE
For service at any time, go to
www.proformservice.com.
Or call 1-888-533-1333
Mon.––Fri. 6 a.m.––6 p.m. MT
Sat. 8 a.m.––4 p.m. MT
Please do not contact the store.
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER’'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRO-FORM 425 CT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ICON PRO-FORM 425 CT

Summary of Contents for ICON PRO-FORM 425 CT

  • Page 1 www.proform.com Model No. PFTL49612.2 USER’’S MANUAL Serial No. Write the serial number in the space above for reference. Serial Number Decal ACTIVATE YOUR WARRANTY To register your product and activate your warranty today, go to www.proformservice.com/ registration. CUSTOMER CARE For service at any time, go to www.proformservice.com.

  • Page 2: Table Of Contents

    Apply the decal in the location shown. Note: The decals may not be shown at actual size. PROFORM is a registered trademark of ICON IP, Inc.

  • Page 3: Important Precautions

    To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your treadmill before using your treadmill. ICON assumes no responsibility for personal injury or property damage sus- tained by or through the use of this product.
  • Page 4 20. The heart rate monitor is not a medical frame securely in the storage position. device. Various factors, including the user’’s movement, may affect the accuracy of heart 24. Never insert any object into any opening on rate readings. The heart rate monitor is the treadmill.

  • Page 5: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the new PROFORM reading this manual, please see the front cover of this ® CT treadmill. The 425 CT treadmill offers an impres- manual. To help us assist you, please note the product sive selection of features designed to make your model number and serial number before contacting us.

  • Page 6: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly.

  • Page 7: Assembly

    ASSEMBLY •• To hire an authorized service technician to •• To identify small parts, see page 6. assemble the treadmill, call 1-800-445-2480. •• Assembly requires the following tools: •• Assembly requires two persons. the included hex key •• Place all parts in a cleared area and remove the one Phillips screwdriver packing materials.
  • Page 8 2. See the inset drawing. Cut the plastic tie near the Upright Wire (87). Plastic Tie Attach a Wheel (96) to the Base (95) with a 3/8" x 2" Bolt (8) and a 3/8" Nut (10). Do not over- tighten the Nut; the Wheel must turn freely. Then, press a Base Cap (89) into the Base (95).
  • Page 9 4. Hold the Right Upright (85) against the Base (95). Be careful not to pinch the Upright Wire (87). Insert two 3/8" x 4" Screws (7) with two 3/8" Star Washers (11) and a 3/8" x 1 1/2" Screw (14) with a 3/8" Star Washer (11) into the Right Upright.
  • Page 10 6. Hold the Left Upright (84) against the Base (95). Insert two 3/8" x 4" Screws (7) with two 3/8" Star Washers (11) and a 3/8" x 1 1/2" Screw (14) with a 3/8" Star Washer (11) into the Left Upright.
  • Page 11 8. Identify the Right Upright Cover (86) and the Right Handrail (83). Slide the Right Upright Cover (86) onto the Right Upright (85). Remove the tie from the bracket on Bracket the Right Handrail. If necessary, press the 5/16" Cage Nut (38) back into place. Next, hold the Right Handrail (83) near the Right Upright (85).
  • Page 12 10. IMPORTANT: To avoid damaging the Crossbar (73), do not use power tools and do not overtighten the #10 x 3/4" Screws (2). Orient the Crossbar (73) as shown. Attach the Crossbar to the Handrails (82, 83) with four #10 x 3/4"...
  • Page 13 12. Firmly tighten the four 5/16" x 1" Screws (3) and the two 5/16" x 1" Bolts (4) (only one side is Console Console shown). Assembly Wire With the help of a second person, hold the con- sole assembly near the Right Handrail (83) and the Left Handrail (not shown).
  • Page 14 14. Set the console assembly on the Left and Right Handrails (82, 83). Be careful not to pinch any Console Assembly wires. Insert the excess Upright Wire (87) into the Right Handrail. Attach the console assembly to the Crossbar (73) with six #8 x 3/4" Screws (1). Start all six Screws, and then tighten them.
  • Page 15 16. Raise the Frame (55) to the position shown. Have a second person hold the Frame until this step is completed. Orient the Storage Latch (51) so that the large barrel and the latch knob are in the positions shown. Attach the Latch Bracket (39) to the Base (95) Latch with two 3/8"...

  • Page 16: Operation And Adjustment

    OPERATION AND ADJUSTMENT HOW TO CONNECT THE POWER CORD nominal 120-volt circuit capable of carrying 15 or more amps. To avoid overloading the circuit, do Use a Surge Suppressor not plug other electrical devices, except for low- power devices such as cell phone chargers, into Your treadmill, like other electronic equipment, can be the surge suppressor or into an outlet on the same damaged by sudden voltage changes in your home’’s...
  • Page 17 CONSOLE DIAGRAM FEATURES OF THE CONSOLE To turn on the power, see page 18. To use the man- ual mode, see page 18. To use an onboard workout, The treadmill console offers an impressive array of see page 20. To use an 8-week weight-loss work- features designed to make your workouts more effec- out, see page 21.
  • Page 18 HOW TO TURN ON THE POWER HOW TO USE THE MANUAL MODE IMPORTANT: If the treadmill has been exposed to 1. Insert the key into the console. cold temperatures, allow it to warm to room tem- perature before you turn on the power. If you do See HOW TO TURN ON THE POWER at the left.
  • Page 19 5. Follow your progress with the displays. When the manual mode is selected, the upper half of Track the display will show a Contacts track that represents 1/4 mile (400 m). As you walk or run, indicators will appear in succession around the track until the entire track appears.
  • Page 20 HOW TO USE AN ONBOARD WORKOUT The workout will continue in this way until the last segment of the pro le  ashes in the display and the 1. Insert the key into the console. last segment ends. The walking belt will then slow to a stop.
  • Page 21 HOW TO USE AN 8-WEEK WEIGHT-LOSS 4. Start the workout. WORKOUT Press the Go button, and then press the Start but- 1. Insert the key into the console. ton to start the workout. See HOW TO TURN ON THE POWER on page 18. The workout will function in the same way as an onboard workout (see step 3 on page 20).
  • Page 22 HOW TO USE THE SOUND SYSTEM THE INFORMATION MODE To play music or audio books through the console The console features an information mode that keeps sound system while you exercise, plug a 3.5 mm male track of treadmill usage information. The information to 3.5 mm male audio cable (not included) into the jack mode also allows you to select miles or kilometers as on the console and into a jack on your MP3 player,...

  • Page 23: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at the to zero before you fold the treadmill. Then, remove left.

  • Page 24: Troubleshooting

    TROUBLESHOOTING Most treadmill problems can be solved by follow- d. If the treadmill still will not run, please see the front ing the simple steps below. Find the symptom that cover of this manual. applies, and follow the steps listed. If further assis- tance is needed, see the front cover of this manual.
  • Page 25 2 to 3 in. (5 to 7 cm) off the walking platform. Be of a turn; if the walking belt has shifted to the careful to keep the walking belt centered. Then, right, turn the left idler roller screw counterclock- plug in the power cord, insert the key, and run the wise 1/2 of a turn.

  • Page 26: Exercise Guidelines

    EXERCISE GUIDELINES Burning Fat——To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.

  • Page 27: Part List

    PART LIST Model No. PFTL49612.2 R0713A Key No. Qty. Description Key No. Qty. Description #8 x 3/4" Screw #8 x 1" Screw #10 x 3/4" Screw Right Foot Rail 5/16" x 1" Screw Frame 5/16" x 1" Bolt Roller Bracket #8 x 1"...

  • Page 28: Exploded Drawing

    EXPLODED DRAWING A Model No. PFTL49612.2 R0713A...
  • Page 29 EXPLODED DRAWING B Model No. PFTL49612.2 R0713A...
  • Page 30 EXPLODED DRAWING C Model No. PFTL49612.2 R0713A...
  • Page 31 EXPLODED DRAWING D Model No. PFTL49612.2 R0713A...

  • Page 32: Ordering Replacement Parts

    ICON’’s option, the product through one of its authorized service centers. All repairs for which warranty claims are made must be preauthorized by ICON. If the product is shipped to a service center, freight charges to and from the service center will be the customer’’s responsibility. If replacement parts are shipped while the product is under warranty, the customer will be responsible for a minimal handling charge.
