Ambassador MARINE S01-0308 Series Installation Instructions

I
NSTALLATION
Thank you for choosing Ambassador Marine.
Your new Ambassador Marine faucet, shower, sprayer or accessory
will give you years of trouble-free performance. Please read these
instructions carefully before installing your new item. If you have any
additional questions about the installation of this product, feel free
to contact a customer service representative at 1.800.270.4262.
The Drain Size is a standardized term used to refer to the category of drain
body or flange sizes. The actual hole in the sink is typically
diameter than the "Drain Size".
I R
F EPLACING
Remove your existing unit, taking care not to damage your existing sink or
drain line. Remove any existing plumber's putty and clean inside and bottom
of sink surface in preparation for new unit.
Safety Glasses
1
2
3
4
5
I
NSTRUCTIONS
D S :
RAIN IZE
A E
N XISTING
I Y
NSTALLING OUR
N
EEDED
Hose Clamp Pliers
1) Set the flip body assembly with the thin gasket in the drain hole in the sink. NOTE: The thin
gasket is supplied for your convenience, however, we recommend using plumber's putty (not
included) instead of the gasket. Do not use both the gasket and plumber's putty.
2) Ensure the trap cup and the 1 1/4" adapter are tightly screwed onto the trap body with the
rubber gaskets inside the connections.
3) From under the sink, slide the thick rubber gasket up onto the threaded flip body assembly.
Screw the lock nut onto the flip body assembly, but do not tighten completely.
4) Screw the trap body with the adapter installed onto the threaded flip body securely. Make
sure the side port of the trap body is pointed in the desired direction for connecting the waste
line, rotate complete assembly if needed. Tighten lock nut.
5) Securely screw the hose barb onto the side port of the trap body, ensuring the rubber gasket
is properly seated inside the head of the hose barb. Slide 3/4" or 1" ID hose all the way onto the
hose barb. 3/4" hose will fit the first set of smaller barbs, while 1" hose will pass over the first set
of smaller barbs and secure on the second set of larger barbs. Secure hose with a stainless steel
hose clamp (not included).
/ " to / " larger
1 1
16 2
U :
NIT
N A
EW MBASSADOR
/ H T
ELPFUL OOLS
Adjustable Wrench Plumber's Putty
S01-0308- _ _
Flip/Trap Drain (No Overflow)
/ " & 1" Hose Barb
3
4
Available Color/Finish Suffix Codes
-CP
-NP
ANY SUFFIX FOLLOWED WITH "-R" OR
"-W" INDICATES – RETAIL PACKAGED
Installation Hole Requirement
This unit requires the drain hole to be
this size or slightly larger:
1 / " Drain
1
2
2 2 / / " "
1 1
4 4
1 1 / / " "
5 5
8 8
M U :
ARINE NIT
Plumber's
Tape Clean Rags
(Teflon)
1 / " Drain
1
2
Chrome
Brushed Nickel
