I
NSTALLATION
Thank you for choosing Ambassador Marine.
Your new Ambassador Marine faucet, sprayer, shower or
accessory will give you years of trouble-free performance.
Please read these instructions carefully before installing your
new item. If you have any additional questions about the
installation of this product, please feel free to contact one of
our friendly customer service representatives at 800.270.4262.
1
2
3
4
5
I
NSTRUCTIONS
1) Set the flip body assembly with the thin gasket in the drain hole in the sink. NOTE: The thin
gasket is supplied for your convenience, however, we recommend using plumber's putty (not
included) instead of the gasket. Do not use both the gasket and plumber's putty.
2) If you are using the 1 1/4" sweat fitting tailpipe, you may discard the threaded adapter on the
flip body.
3) From under the sink, slide the thick rubber gasket up onto the threaded flip body assembly.
Screw the lock nut onto the flip body assembly and tighten.
4) Screw the tailpipe into the bottom of the flip body.
5) Securely waste line to tailpipe. This procedure will vary depending on the type of waste line
being used.
S01-0511-CP
S01-0511-CP-R
1
/
1
2
Flip Drain Kit
1
3
/
" Sweat Fitting
4
Chrome
(OEM)
(Retail)
" Drain
