Ambassador MARINE S00-0109 Series Installation Instructions

I
NSTALLATION
Thank you for choosing Ambassador Marine.
Your new Ambassador Marine faucet, shower, sprayer or accessory
will give you years of trouble-free performance. Please read these
instructions carefully before installing your new item. If you have any
additional questions about the installation of this product, feel free
to contact a customer service representative at 1.800.270.4262.
The Drain Size is a standardized term used to refer to the category of drain
body or flange sizes. The actual hole in the sink is typically
diameter than the "Drain Size".
I R
F EPLACING
Remove your existing unit, taking care not to damage your existing sink or
drain line. Remove any existing plumber's putty and clean inside and bottom
of sink surface in preparation for new unit.
Safety Glasses
1
2
3
4
5
I
NSTRUCTIONS
D S :
RAIN IZE
A E
N XISTING
I Y
NSTALLING OUR
N
EEDED
Hose Clamp Screwdriver
1) Set the flange with the foam gasket and screw in the drain hole in the sink. NOTE: The foam
gasket is supplied for your convenience, however, we recommend using plumber's putty (not
included) instead of the foam gasket. Do not use both the foam gasket and plumber's putty.
2) Ensure the trap cup and the drain body are tightly screwed onto the trap body with the
rubber gaskets inside the connections.
3) From under the sink, line up the drain body with the thick rubber gasket inside with the flange
and screw.
4) From above the sink, tighten the screw into the metal nut inside the drain body. Make sure
the side port of the trap body is pointed in the desired direction for connecting the waste line,
before securing.
5) Securely screw the hose barb onto the side port of the trap body, ensuring the rubber gasket
is properly seating inside the head of the hose barb. Slide 1 1/4" or 1 1/2" ID hose all the way
onto the hose barb. 1 1/4" hose will fit the first set of smaller barbs, while 1 1/2" hose will pass
over the first set of smaller barbs and secure on the second set of larger barbs. Secure hose with
a stainless steel hose clamp (not included).
6) Remove the protective sticker from the polished surface of the stopper.
7) OPTIONAL- Drill a 3/16" hole in the counter-top or other surface
and secure the stopper screw using the stopper nut, where desired. If
you choose not to secure the stopper screw, you may remove the
stopper chain (and stopper screw) from the stopper. Spread the ends of
the stopper triangle connector and remove it from the stopper.
/ " to / " larger
1 1
16 2
U :
NIT
N A
EW MBASSADOR
/ H T
ELPFUL OOLS
Pliers Plumber's Putty
S00-0109- _ _
1 / " & 1
1
4
Available Color/Finish Suffix Codes
-BP
Brushed
-UP
Ultra-Mirror
ANY SUFFIX FOLLOWED WITH "-R" OR
"-W" INDICATES – RETAIL PACKAGED
Installation Hole Requirement
This unit requires the drain hole to be
this size or slightly larger:
2" Drain
2 2 / / " "
3 3
4 4
2 2 / / " "
1 1
16 16
M U :
ARINE NIT
Drill Clean Rags
(with / " Bit)
3
16
2" Drain
Trap Drain Kit
/ " Hose Barb
1
2
7
